Proximity-Aware Directory-based Coherence for Multi-core Processor - - PowerPoint PPT Presentation

Proximity-Aware Directory-based Coherence for Multi-core Processor Architectures

Jeff Brown Rakesh Kumar Dean Tullsen

UC San Diego ● University of Illinois at Urbana-Champaign SPAA19 ● June 9, 2007

Introduction

• The chip multiprocessor (CMP)

era is upon us!

• Caching complicate writes
• Cache Coherence ensures

caching is done safely

• Multi-core designs offer new tradeoffs

Introduction

• The chip multiprocessor (CMP)

era is upon us!

• Caching complicate writes
• Cache Coherence ensures

caching is done safely

• Multi-core designs offer new tradeoffs

P M P M

Introduction

• The chip multiprocessor (CMP)

era is upon us!

• Caching complicate writes
• Cache Coherence ensures

caching is done safely

• Multi-core designs offer new tradeoffs

P M P M P P M M

Background: Directory-based Cache Coherence

• Directory-based; explicit per-block accounting

– Doesn't rely on broadcasts

• Directory operation: client/server

Background: Directory-based Cache Coherence

• Directory-based; explicit per-block accounting

– Doesn't rely on broadcasts

• Directory operation: client/server

– Processors request data, permissions

P

Background: Directory-based Cache Coherence

• Directory-based; explicit per-block accounting

– Doesn't rely on broadcasts

• Directory operation: client/server

– Processors request data, permissions – Directory controllers manage memory access

P Dir

Background: Directory-based Cache Coherence

• Directory-based; explicit per-block accounting

– Doesn't rely on broadcasts

• Directory operation: client/server

– Processors request data, permissions – Directory controllers manage memory access

P M Dir

Background: Directory-based Cache Coherence

• Directory-based; explicit per-block accounting

– Doesn't rely on broadcasts

• Directory operation: client/server

– Processors request data, permissions – Directory controllers manage memory access

P M Dir

Background: Directory-based Cache Coherence

• Directory-based; explicit per-block accounting

– Doesn't rely on broadcasts

• Directory operation: client/server

– Processors request data, permissions – Directory controllers manage memory access

• Updates, conflicts

P M P Dir

Background: Historical MP Cache Coherence

• Distributed directory, memory

P M P M P M P M

Background: Historical MP Cache Coherence

• Distributed directory, memory

P M P M P M P M Cache Miss

Background: Historical MP Cache Coherence

• Distributed directory, memory

P M P M P M P M Cache Miss "Home Node"

Background: Historical MP Cache Coherence

• Distributed directory, memory

P M P M P M P M Cache Miss "Home Node"

Background: Historical MP Cache Coherence

• Distributed directory, memory

P M P M P M P M Cache Miss "Home Node" Data Request

Background: Historical MP Cache Coherence

• Distributed directory, memory

P M P M P M P M Cache Miss "Home Node" Data Request Reply

Motivation: Multi-core Cache Coherence

M M P M P P P M

Motivation: Multi-core Cache Coherence

M M P M P P P M Cache Miss

Motivation: Multi-core Cache Coherence

M M P M P P P M Cache Miss

Motivation: Multi-core Cache Coherence

"Home Node" M M P M P P P M Cache Miss

Motivation: Multi-core Cache Coherence

"Home Node" Data Request M M P M P P P M Cache Miss

Motivation: Multi-core Cache Coherence

"Home Node" Data Request M M P M P P P M Cache Miss

Motivation: Multi-core Cache Coherence

"Home Node" Reply M M P M P P P M Cache Miss

Motivation: Multi-core Cache Coherence

M M P M P P P M Additional Sharer

Motivation: Multi-core Cache Coherence

M M P M P P P M Additional Sharer

• Multi-core designs present radically different

relative latency & bandwidth

Outline

• Introduction & Background
• System Architecture
• Proximity-Aware Coherence
• Results
• Conclusion

Directory-based Cache Coherence

• Directory structures

Directory-based Cache Coherence

• Directory structures

Main Memory

Directory-based Cache Coherence

• Directory structures

Main Memory

Directory-based Cache Coherence

• Directory structures

– Directory Memory

Main Memory Directory Memory

Directory-based Cache Coherence

• Directory structures

– Directory Memory – Directory Entries

Main Memory Directory Memory

Directory-based Cache Coherence

• Directory structures

– Directory Memory – Directory Entries – Directory Controller

Main Memory Directory Memory Controller

A Traditional Multiprocessor

Core L2 $ Dir Mem Interconnect Core L2 $ Dir Mem

…

A Traditional Multiprocessor

Core L2 $ Dir Mem Interconnect Core L2 $ Dir Mem

…

(Chassis, board, etc.)

A Traditional Multiprocessor

Core L2 $ Dir Mem Interconnect Core L2 $ Dir Mem

…

(Chassis, board, etc.)

Our 16-Core Chip Multiprocessor

Core L2 $ Bus

Dir control

Net. switch

Dir $

Mem. channel

Tile Tile 1 Tile 15 ...

Our 16-Core Chip Multiprocessor

Core L2 $ Bus

Dir control

Net. switch

Dir $

Mem. channel

Tile Tile 1 Tile 15 ...

Our 16-Core Chip Multiprocessor

Core L2 $ Bus

Dir control

Net. switch

Dir $

Mem. channel

Tile Tile 1 Tile 15 ...

Our 16-Core Chip Multiprocessor

Core L2 $ Bus

Dir control

Net. switch

Dir $

Mem. channel

Tile Tile 1 Tile 15 ...

Our 16-Core Chip Multiprocessor

Core L2 $ Bus

Dir control

Net. switch

Dir $

Mem. channel

Tile Tile 1 Tile 15 ...

Our 16-Core Chip Multiprocessor

Core L2 $ Bus

Dir control

Net. switch

Dir $

Mem. channel

Tile Tile 1 Tile 15 ...

Outline

• Introduction & Background
• System Architecture
• Proximity-Aware Coherence
• Results
• Conclusion

Proximity-Aware Coherence

• Idea: home node asks sharer nearest requester

to forward its cached copy

Proximity-Aware Coherence

• Idea: home node asks sharer nearest requester

to forward its cached copy

– Stay on-chip when possible

Proximity-Aware Coherence

• Idea: home node asks sharer nearest requester

to forward its cached copy

– Stay on-chip when possible – Minimize transit of large data-carrying replies

Proximity-Aware Coherence

• Idea: home node asks sharer nearest requester

to forward its cached copy

– Stay on-chip when possible – Minimize transit of large data-carrying replies

M M P M P P P M

Proximity-Aware Coherence

• Idea: home node asks sharer nearest requester

to forward its cached copy

– Stay on-chip when possible – Minimize transit of large data-carrying replies

"Home Node" Data Request Cache Miss M M P M P P P M

Proximity-Aware Coherence

• Idea: home node asks sharer nearest requester

to forward its cached copy

– Stay on-chip when possible – Minimize transit of large data-carrying replies

"Home Node" M M P M P P P M Additional Sharer

Proximity-Aware Coherence

• Idea: home node asks sharer nearest requester

to forward its cached copy

– Stay on-chip when possible – Minimize transit of large data-carrying replies

"Home Node" M M P M P P P M Additional Sharer Forward Request

Proximity-Aware Coherence

• Idea: home node asks sharer nearest requester

to forward its cached copy

– Stay on-chip when possible – Minimize transit of large data-carrying replies

Reply M M P M P P P M

Proximity-Aware Coherence

• To service read misses for shared data,

traditional protocols use main memory

• Other nodes may hold copies
• On the CMP landscape, inter-node latency is

much less than memory latency

Sharer Selection

• When the home node lacks a cached copy, it

selects a sharer to ask

Sharer Selection

• When the home node lacks a cached copy, it

selects a sharer to ask

Miss

Home

Sharer Selection

• When the home node lacks a cached copy, it

selects a sharer to ask

– rand

Miss

Home

Sharer Selection

• When the home node lacks a cached copy, it

selects a sharer to ask

– rand – near1

Miss

Home

Sharer Selection

• When the home node lacks a cached copy, it

selects a sharer to ask

– rand – near1 – via1

Miss

Home

Sharer Selection

• When the home node lacks a cached copy, it

selects a sharer to ask

– rand – near1 – via1

• Retries didn't prove beneficial

Miss

Home

Outline

• Introduction & Background
• System Architecture
• Proximity-Aware Coherence
• Results
• Conclusion

Methodology

• Detailed, execution-driven processor and

network simulation

• "RSIM" simulator, adapted to our CMP model
• Parallel workloads from several suites
• Hardware, benchmark details in paper

Proximity-Aware: Potential Coverage

appbt fft lu mp3d

• cean

quicksort unstruct 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1 6 5 4 3 2 1

Fraction of read misses to shared lines

Proximity-Aware: Potential Coverage

appbt fft lu mp3d

• cean

quicksort unstruct 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1 6 5 4 3 2 1

Fraction of read misses to shared lines

Proximity-Aware: Potential Coverage

appbt fft lu mp3d

• cean

quicksort unstruct 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1 6 5 4 3 2 1

Fraction of read misses to shared lines Overall x=43%

Proximity-Aware: Potential Coverage

appbt fft lu mp3d

• cean

quicksort unstruct 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1 6 5 4 3 2 1

Fraction of read misses to shared lines Overall x=43%

Proximity-Aware: Potential Coverage

appbt fft lu mp3d

• cean

quicksort unstruct 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1 6 5 4 3 2 1

Fraction of read misses to shared lines Overall x=43% dist 1 x=75%

Proximity-Aware: Latency Benefit

appbt fft lu mp3d

• cean

quick sort un- struct mean

0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1 1.1

rand near1 via1

Normalized L2 miss latency

Proximity-Aware: Latency Benefit

appbt fft lu mp3d

• cean

quick sort un- struct mean

0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1 1.1

rand near1 via1

Normalized L2 miss latency

Proximity-Aware: Latency Benefit

appbt fft lu mp3d

• cean

quick sort un- struct mean

0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1 1.1

rand near1 via1

Normalized L2 miss latency

Latency

• 25%

Proximity-Aware: Latency Benefit

appbt fft lu mp3d

• cean

quick sort un- struct mean

0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1 1.1

rand near1 via1

Normalized L2 miss latency

Latency

• 25%

Proximity-Aware: Latency Benefit

appbt fft lu mp3d

• cean

quick sort un- struct mean

0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1 1.1

rand near1 via1

Normalized L2 miss latency

Latency

• 25%

Reply traffic

• 6%

Proximity-Aware: Latency Benefit

appbt fft lu mp3d

• cean

quick sort un- struct mean

0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1 1.1

rand near1 via1

Normalized L2 miss latency

Latency

• 25%

Reply traffic

• 6%

Proximity-Aware: Speedup

appbt fft lu mp3d

• cean

quick sort un- struct mean 0.00 0.20 0.40 0.60 0.80 1.00 1.20 1.40 1.60 1.80

rand near1 via1

Speedup

Proximity-Aware: Speedup

appbt fft lu mp3d

• cean

quick sort un- struct mean 0.00 0.20 0.40 0.60 0.80 1.00 1.20 1.40 1.60 1.80

rand near1 via1

Speedup

Proximity-Aware: Speedup

appbt fft lu mp3d

• cean

quick sort un- struct mean 0.00 0.20 0.40 0.60 0.80 1.00 1.20 1.40 1.60 1.80

rand near1 via1

Speedup

Speedup 16%

Proximity-Aware: Speedup

• L2 latency sensitivity of workloads

appbt fft lu mp3d

• cean

quick sort un- struct mean 0.00 0.20 0.40 0.60 0.80 1.00 1.20 1.40 1.60 1.80

rand near1 via1

Speedup

Speedup 16%

Conclusion

• The latency/bandwidth aspects of CMPs

motivates multicore-aware coherence redesign

• One such change: Proximity-Aware Coherence

– Ideas: stay on-chip, decrease "bulk" transit – Mean speedup 16%, mean L2 latency down 25%

• More aggressive techniques are under study

Conclusion

• The latency/bandwidth aspects of CMPs

motivates multicore-aware coherence redesign

• One such change: Proximity-Aware Coherence

– Ideas: stay on-chip, decrease "bulk" transit – Mean speedup 16%, mean L2 latency down 25%

• More aggressive techniques are under study
• Questions?
