Development of Nek2 Substrates Based on C-Nap1 Using FMOC Solid Property of Phase Peptide Synthesis Daniel Andre Novoa Daniel Andre Novoa Introduction Property of Daniel Andre Novoa What is known What is needed What was done

slide-1
SLIDE 1

Development of Nek2 Substrates Based on C-Nap1 Using FMOC Solid Phase Peptide Synthesis

Daniel Andre Novoa

Property of Daniel Andre Novoa

slide-2
SLIDE 2

Introduction

  • What is known
  • What is needed
  • What was done

Property of Daniel Andre Novoa

slide-3
SLIDE 3

Introduction

  • What is known:

Property of Daniel Andre Novoa

slide-4
SLIDE 4

Introduction

  • What is known:
  • Nek2 is a NIMA-related serine/threonine kinase

Property of Daniel Andre Novoa

slide-5
SLIDE 5

Introduction

  • What is known:
  • Nek2 is a NIMA-related serine/threonine kinase
  • Regulates centrosome separation & spindle

formation

Property of Daniel Andre Novoa

slide-6
SLIDE 6

Introduction

  • What is known:
  • Nek2 is a NIMA-related serine/threonine kinase
  • Regulates centrosome separation & spindle

formation

  • Greatly over-expressed in many types of cancer

Property of Daniel Andre Novoa

slide-7
SLIDE 7

Introduction

  • What is known:
  • Nek2 is a NIMA-related serine/threonine kinase
  • Regulates centrosome separation & spindle

formation

  • Greatly over-expressed in many types of cancer
  • Biological functions are largely unknown

Property of Daniel Andre Novoa

slide-8
SLIDE 8

Introduction

  • What is known:
  • Nek2 is a NIMA-related serine/threonine kinase
  • Regulates centrosome separation & spindle

formation

  • Greatly over-expressed in many types of cancer
  • Biological functions are largely unknown
  • C-Nap1 is a known in vivo substrate of Nek2

Property of Daniel Andre Novoa

slide-9
SLIDE 9

Introduction

  • What is needed:

Property of Daniel Andre Novoa

slide-10
SLIDE 10

Introduction

  • What is needed:
  • A small molecule substrate to use in the design of:

Property of Daniel Andre Novoa

slide-11
SLIDE 11

Introduction

  • What is needed:
  • A small molecule substrate to use in the design of:
  • Biosensors to track the intracellular activity of

Nek2

Property of Daniel Andre Novoa

slide-12
SLIDE 12

Introduction

  • What is needed:
  • A small molecule substrate to use in the design of:
  • Biosensors to track the intracellular activity of

Nek2

  • A competitive enzyme inhibitor for anti-cancer

research

Property of Daniel Andre Novoa

slide-13
SLIDE 13

Introduction

  • What was done:

Property of Daniel Andre Novoa

slide-14
SLIDE 14

Introduction

  • What was done:
  • 2 peptides were synthesized based on the

consensus sequence of C-Nap1:

Property of Daniel Andre Novoa

slide-15
SLIDE 15

Introduction

  • What was done:
  • 2 peptides were synthesized based on the

consensus sequence of C-Nap1:

  • NAP_3: Ac-Leu-Thr-Gln-Ala-Leu-Thr-Ser-Ala-

Gly-Ahx-Arg-Arg-Arg-NH2

Property of Daniel Andre Novoa

slide-16
SLIDE 16

Introduction

  • What was done:
  • 2 peptides were synthesized based on the

consensus sequence of C-Nap1:

  • NAP_3: Ac-Leu-Thr-Gln-Ala-Leu-Thr-Ser-Ala-

Gly-Ahx-Arg-Arg-Arg-NH2

  • NAP_4: Ac-Ala-Thr-Gln-Ser-Leu-Thr-Ser-Ala-

Gly-Ahx-Arg-Arg-Arg-NH2

Property of Daniel Andre Novoa

slide-17
SLIDE 17

Introduction

  • What was done:
  • 2 peptides were synthesized based on the

consensus sequence of C-Nap1:

  • NAP_3: Ac-Leu-Thr-Gln-Ala-Leu-Thr-Ser-Ala-

Gly-Ahx-Arg-Arg-Arg-NH2

  • NAP_4: Ac-Ala-Thr-Gln-Ser-Leu-Thr-Ser-Ala-

Gly-Ahx-Arg-Arg-Arg-NH2

  • The two peptides have been purified, characterized

and lyophilized

Property of Daniel Andre Novoa

slide-18
SLIDE 18

Peptide Design

Property of Daniel Andre Novoa

slide-19
SLIDE 19

Peptide Design

3 Phosphorylatable Residues

Property of Daniel Andre Novoa

slide-20
SLIDE 20

Peptide Design

Property of Daniel Andre Novoa

slide-21
SLIDE 21

Peptide Design

4 Phosphorylatable Residues

Property of Daniel Andre Novoa

slide-22
SLIDE 22

Property of Daniel Andre Novoa

slide-23
SLIDE 23

Aminohexanoic Acid Linker

Property of Daniel Andre Novoa

slide-24
SLIDE 24

3 Arginine Residues

Property of Daniel Andre Novoa

slide-25
SLIDE 25

Methodology

Property of Daniel Andre Novoa

slide-26
SLIDE 26

Methodology

Insoluble Resin Bead

Property of Daniel Andre Novoa

slide-27
SLIDE 27

Methodology

Insoluble Resin Bead Resin Linker

Property of Daniel Andre Novoa

slide-28
SLIDE 28

Methodology

Insoluble Resin Bead Resin Linker FMOC Protection Group

Property of Daniel Andre Novoa

slide-29
SLIDE 29

Methodology

Property of Daniel Andre Novoa

slide-30
SLIDE 30

Methodology

Free N-Terminus

Property of Daniel Andre Novoa

slide-31
SLIDE 31

Methodology

Property of Daniel Andre Novoa

slide-32
SLIDE 32

Methodology

Property of Daniel Andre Novoa

slide-33
SLIDE 33

Methodology

Property of Daniel Andre Novoa

slide-34
SLIDE 34

Methodology

Property of Daniel Andre Novoa

slide-35
SLIDE 35

Methodology

Desired Peptide

Property of Daniel Andre Novoa

slide-36
SLIDE 36

Purification

0.00 0.50 1.00 1.50 2.00 2.50 3.00 3.50 4.00 AU 0.00 5.00 10.00 15.00 20.00 25.00 30.00 35.00 40.00 45.00 50.00 55.00 60.00 Minutes 220.00 240.00 260.00 280.00 300.00 320.00 340.00

HPLC Chromatogram of NAP_3

Property of Daniel Andre Novoa

slide-37
SLIDE 37

Purification

0.00 0.50 1.00 1.50 2.00 2.50 3.00 3.50 4.00 AU 0.00 5.00 10.00 15.00 20.00 25.00 30.00 35.00 40.00 45.00 50.00 55.00 60.00 Minutes 220.00 240.00 260.00 280.00 300.00 320.00 340.00

HPLC Chromatogram of NAP_3

NAP_3 at 7 Minutes

Property of Daniel Andre Novoa

slide-38
SLIDE 38

Purification

0.00 0.50 1.00 1.50 2.00 2.50 3.00 3.50 4.00 AU 0.00 5.00 10.00 15.00 20.00 25.00 30.00 35.00 40.00 45.00 50.00 55.00 60.00 Minutes 220.00 240.00 260.00 280.00 300.00 320.00 340.00

HPLC Chromatogram of NAP_4

Property of Daniel Andre Novoa

slide-39
SLIDE 39

Purification

0.00 0.50 1.00 1.50 2.00 2.50 3.00 3.50 4.00 AU 0.00 5.00 10.00 15.00 20.00 25.00 30.00 35.00 40.00 45.00 50.00 55.00 60.00 Minutes 220.00 240.00 260.00 280.00 300.00 320.00 340.00

HPLC Chromatogram of NAP_4

NAP_4 at 9 Minutes

Property of Daniel Andre Novoa

slide-40
SLIDE 40

Results

#81 AV: 10 IT: 11.630 ST: 0.24 uS: 1 NL: 5.33E3 F: ITMS + p ESI Full ms [100.00-1800.00] 100 200 300 400 500 600 700 800 900 1000 1100 1200 1300 1400 1500 1600 1700 1800 m/z 5 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100 Relative Intensity 495.4 212.2 742.7 545.8 583.8 634.5 663.2 477.4 452.9 874.5 782.1 433.3 148.8 950.5 381.5 1047.6 1211.8 1083.9 1228.1 1289.0 1468.9 1578.7 1680.0 1764.5

Mass Spectrum of NAP_3

Molecular Weight = 1484.70 g/mol

Property of Daniel Andre Novoa

slide-41
SLIDE 41

Results

#81 AV: 10 IT: 11.630 ST: 0.24 uS: 1 NL: 5.33E3 F: ITMS + p ESI Full ms [100.00-1800.00] 100 200 300 400 500 600 700 800 900 1000 1100 1200 1300 1400 1500 1600 1700 1800 m/z 5 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100 Relative Intensity 495.4 212.2 742.7 545.8 583.8 634.5 663.2 477.4 452.9 874.5 782.1 433.3 148.8 950.5 381.5 1047.6 1211.8 1083.9 1228.1 1289.0 1468.9 1578.7 1680.0 1764.5

Mass Spectrum of NAP_3

Molecular Weight = 1484.70 g/mol Our Product with 3 Charges Our Product with 2 Charges

Property of Daniel Andre Novoa

slide-42
SLIDE 42

Results

#137 AV: 10 IT: 5.093 ST: 0.21 uS: 1 NL: 5.79E4 F: ITMS + p ESI Full ms [100.00-1500.00] 100 200 300 400 500 600 700 800 900 1000 1100 1200 1300 1400 1500 m/z 5 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100 Relative Intensity 486.7 729.1 537.0 769.0 375.0 574.9 785.6 804.6 365.3 861.8 707.3 403.4 587.6 116.8 891.7 361.2 166.8 969.2 1108.8 1252.3 1175.3 1305.0 1409.2 1456.7

Mass Spectrum of NAP_4

Molecular Weight = 1458.62 g/mol

Property of Daniel Andre Novoa

slide-43
SLIDE 43

Results

#137 AV: 10 IT: 5.093 ST: 0.21 uS: 1 NL: 5.79E4 F: ITMS + p ESI Full ms [100.00-1500.00] 100 200 300 400 500 600 700 800 900 1000 1100 1200 1300 1400 1500 m/z 5 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100 Relative Intensity 486.7 729.1 537.0 769.0 375.0 574.9 785.6 804.6 365.3 861.8 707.3 403.4 587.6 116.8 891.7 361.2 166.8 969.2 1108.8 1252.3 1175.3 1305.0 1409.2 1456.7

Mass Spectrum of NAP_4

Molecular Weight = 1458.62 g/mol Our Product with 3 Charges Our Product with 2 Charges

Property of Daniel Andre Novoa

slide-44
SLIDE 44

Future Work

NAP_3 NAP_4

Enzyme Kinetics

Append Fluorophore Append Key Residue

Optimal Substrate

Biosensor

Enzyme Inhibitor

Property of Daniel Andre Novoa

slide-45
SLIDE 45

Aknowledgements

  • Dr. Sanjai Kumar, Queens College
  • Queensborough Community College NIH

Bridges to Baccalaureate Program, Director:

  • Dr. Patricia Schneider

Property of Daniel Andre Novoa

slide-46
SLIDE 46

References

1) Toshio Kokuryo, Takeshi Senga, Yukihiro Yokoyama, Masato Nagino, Yuji Nimura, Michinari Hamaguchi. Nek2 as an Effective Target for Inhibition of Tumorigenic Growth and Peritoneal Dissemination of

  • Cholangiocarcinoma. Cancer Res. 2007;15;67(20):9637-42.

2) Nobuyuki Tsunoda, Toshio Kokuryo, Koji Oda, Takeshi Senga, Yukihiro Yokoyama, Masato Nagino, Yuji Nimura, Michinari Hamaguchi. Nek2 as a novel molecular target for the treatment of breast carcinoma. Cancer

  • Sci. 2009;100(1):111-6.

3) Andrew M. Fry, Patrick Meraldi, and Erich A. Nigg. A centrosomal function for the human Nek2 protein kinase, a member of the NIMA family of cell cycle regulators. EMBO J. 1998;17(2):470–481. 4) Andrew M Fry. The Nek2 protein kinase: a novel regulator of centrosome structure. Oncogene. 2002;21(40):6184-94. 5) Daniel G. Hayward and Andrew M. Fry. Nek2 Kinase in Chromosome Instability and Cancer. Cancer Lett. 2006;8;237(2):155-66.

Property of Daniel Andre Novoa

slide-47
SLIDE 47

Questions?
