Project Project Walrus Walrus Make the most of your card cloning devices Make the most of your card cloning devices Whois Team Walrus Daniel Underhay Matthew Daley @dunderhay bugfuzz.com Security Consultant at Aura Information Security

slide-1
SLIDE 1

Project Project Walrus Walrus

Make the most of your card cloning devices Make the most of your card cloning devices

slide-2
SLIDE 2

Whois Team Walrus

Daniel Underhay

@dunderhay

Security Consultant at Aura Information Security

Matthew Daley

bugfuzz.com

Senior Security Consultant at Aura Information Security

slide-3
SLIDE 3

Backstory – More Red Teaming J

  • Phishing and social engineering attacks targeted at staff
  • Bypassing lock and access control systems
  • Attempts to physically access the premises
  • Attempts to remove sensitive data
  • Assessment and attempted infiltration of any internet-connected

services or devices

  • And more...
slide-4
SLIDE 4

Access Control Systems

  • Restrict entrance to a property, building or room to authorized persons
  • Electronic locks
  • Card or biometric access readers

and software

  • Some of these cards are easily

cloned

slide-5
SLIDE 5

Where Do We Find These

  • Building entrance
  • Elevators
  • Office doors
  • Areas that require additional privilege:

q Server rooms q Secure rooms

slide-6
SLIDE 6

Card Cloning Devices

slide-7
SLIDE 7

Proxmark3

  • Created by Jonathan Westhues
  • Industry standard card cloning device
  • Low Frequency: 125kHz and 134kHz

(HID Prox II, HITAG, and EM4100)

  • High Frequency: 13.56Mhz

(Mifare Classic/Ultralight, and iClass)

slide-8
SLIDE 8

Chameleon Mini

  • Created by Kasper & Oswald
  • Portable tool for ISO14443/ISO15693/NFC

security analysis

  • Emulate and clone contactless cards
  • High Frequency: 13.56Mhz

(Mifare Classic 1K/4K 4B/7B/Ultralight)

slide-9
SLIDE 9

Tastic RFID Thief

  • HID Maxiprox 5375
  • Long range RFID card reader
  • Modified by Bishop Fox
  • Low Frequency: 125kHz

(HID Prox II)

  • Range ~ 0.5 meters
slide-10
SLIDE 10

Difficulties with Card Cloning

  • No common tool that controls all the devices
  • No common database to store cloned cards
  • Cloning cards surreptitiously can be tricky
  • Existing standalone mode on Proxmark3 is sketchy (no feedback)
  • Devices are often not very ‘user friendly’
slide-11
SLIDE 11

An Idea

slide-12
SLIDE 12

PoC || GTFO

slide-13
SLIDE 13

Wireframing

slide-14
SLIDE 14

Introducing Walrus

  • Walrus provides a common interface for your card cloning devices
  • Cards are stored in a common wallet instead of in separate databases
  • Reliable card cloning during red team engagements using your Android

phone instead of your laptop – much less suspicious

  • No need to use your device’s limited physical interface or a

cumbersome command prompt – use a simple, quick GUI instead

  • Easy to use, rated for users aged years 3+ on Play Store
slide-15
SLIDE 15

Cloning Cards with Walrus - Proxmark3

slide-16
SLIDE 16

Walrus - Proxmark3

slide-17
SLIDE 17

Walrus - Proxmark3

slide-18
SLIDE 18

Walrus - Proxmark3

slide-19
SLIDE 19

Walrus - Proxmark3

slide-20
SLIDE 20

Walrus - Proxmark3

slide-21
SLIDE 21

Walrus - Proxmark3

slide-22
SLIDE 22

Walrus - Proxmark3

slide-23
SLIDE 23

Walrus - Proxmark3

slide-24
SLIDE 24

Walrus - Proxmark3

slide-25
SLIDE 25

Walrus - Chameleon Mini

slide-26
SLIDE 26

Walrus Bulk Read Mode (Walrus- Driving)

slide-27
SLIDE 27

How Many Devices Can It Take?

slide-28
SLIDE 28

How Many Devices Can It Take?!

slide-29
SLIDE 29

Tastic RFID Thief to Walrus?

?

slide-30
SLIDE 30

Tastic RFID Thief + Bluetooth

+

HC-06

slide-31
SLIDE 31

Tastic RFID Thief BLE Edition

slide-32
SLIDE 32

Disclaimer

  • Bad actors ahead
  • Only clone cards if you have been given permission to do so
  • UI is out of date and has been upgraded
slide-33
SLIDE 33

Video of lumpy

slide-34
SLIDE 34

Help us Test!

Open alpha release on Play Store now! Search for “Walrus cloning” or visit

https://play.google.com/store/apps/details?id =com.bugfuzz.android.projectwalrus

slide-35
SLIDE 35

Future Plans

  • Modify the Bishop Fox Tastic RFID Thief PCB
  • Add features:

q Brute force emulation mode q Sharing cards between Android devices q Gamification?

  • Add support for additional devices:

q Generic Wiegand support via Team Walrus Arduino software q Magspoof q BLEKey q ESP-RFID-Tool q More?

slide-36
SLIDE 36

Tastic RFID Thief PCB

slide-37
SLIDE 37

PCB Modification

slide-38
SLIDE 38

Gamification (Maybe)

  • Wie-Gotta Catch ‘em All
  • Not a public database
slide-39
SLIDE 39

MagSpoof v2

  • Created by Samy Kamkar
  • Commercialized by Rysc Corp
  • Emulate magnetic stripe or credit card data
slide-40
SLIDE 40

BLEKey

  • Created by Mark Baseggio and Eric Evenchick
  • A Bluetooth Low Energy (BLE) enabled tap

for the Wiegand devices

  • Installed in a reader to passively sniff

Wiegand data

  • Data can be offloaded to a phone

via Bluetooth

  • Inject card data
  • Cheap
  • Emulate cards on that reader
slide-41
SLIDE 41

ESP-RFID-Tool

  • Created by Corey Harding
  • A Wi-Fi enabled tap for the Wiegand devices
  • Installed in a reader to passively sniff

Wiegand data

  • Data can be offloaded to a phone

via Wi-Fi AP

  • Inject push-to-exit signal
  • Cheap

HTTPS://GITHUB.COM/RFIDTOOL/ESP-RFID-TOOL HTTPS://BLOG.APRBROTHER.COM/PRODUCT/ESP-RFID-TOOL

slide-42
SLIDE 42

Thank you!

Getting Started:

http://project-walrus.io

Open alpha release on Play Store now:

https://play.google.com/store/apps/details?id= com.bugfuzz.android.projectwalrus

Open source (GPLv3). Code is on Github:

https://github.com/megabug/Walrus
