Progress on Off-site Cleanup Effort on Fukushima Nuclear Power Plants - - PowerPoint PPT Presentation

Progress on Off-site Cleanup Effort on Fukushima Nuclear Power Plants Accident Yutaka Kawakami

2

Amount of Disaster Waste (Coastal Area) Total 26,410,000 ton

Prefecture

Amount of Disaster Waste

Fukushima 3,370,000 ton Miyagi 17,770,000 ton Iwate 5,270,000 ton

As of Sep. 30, 2013

3

Current Status of Specific (Designated) Waste (over 8,000 Bq/kg ) (as of August 31rd, 2013)

4

Comparison of Released Radioactivity, Chernobyl and Fukusima

(7) OECD/NEA(2003)”chapter II The release, dispersion and deposition of radionuclides.

Chernobyl: Assessment of radiological and health impact; 2002” (8),(9) NISA report

Chernobyl NPP, No,4 Reactor（７） Fukusima Daiiti NPS, Total of Unit 1 to Unit 3（８）（９）

Radio nuclides

I-131 Cs-137 I-131 Cs-137

Core inventory

(1015Bq)

3,200 280 6,100 710

Released radioactivity

（1015Bq)

~1,760 ~85 160 15

Release rate(%)

50~60 20~40 2.6 2.1

5

The Point at Issue on The Contaminated Waste

 Nuclear regulations are only applied for nuclear facility and facility related materials.  “Act on Special Measures concerning the Handling of Pollution by Radioactive Materials” was legislated.  Regulations on radiation protection was corresponded by amendment of “Ordinance on Prevention of Ionizing Radiation Hazards”. This ordinance is a part of the “Industrial Safety and Health Law” and is aimed for protection of radiation workers.  Huge amount of contaminated waste.  Widespread of radioactive contamination.  Progress on the remediation activities, a large amount of contaminated waste which are removed soil and other materials including ash from incineration of combustible waste are generated.

6

Act on Special Measures concerning the Handling of Pollution by Radioactive Materials（Enacted Aug. 2011)

Objective

On the special measures concerning environmental pollution by radioactive materials, by establishing measures to be implemented by the national government , local government and nuclear operators, quickly reduce the influence on human health and living environment due to the contamination of environment.

Responsibilities

• The national government：implement necessary measure in view of social responsibility on

promoting the nuclear policy.

• Local government: play an appropriate role through cooperation to the national government

measures.

• Nuclear operators: implement necessary measure in good faith and cooperate with policy of

the national government and local government..

Institution

• Establishment of basic policy

Minister for the environment establishes measures on environmental pollution by radioactive material and requires cabinet decision.

• Establishment of standard

Minister for the environment establishes criteria for treatment of soil and waste contaminated by radioactive materials.

• Implement of monitoring and measurement

The national government arranges and implements unified monitoring and measurement to grasp the situation of contamination of environment immediately.

7

Framework of Decontamination

100 municipalities in 8 prefectures , in which over 0.23 μSv/hour of air dose rate (equivalent to over 1 mSv/Year of additional dose rate) is observed, were designated.  Decontamination is implemented by each municipality. The national government will take financial and technical measures.  11 municipalities in (former) restricted zone or planned evacuation zone (less than 20km from the NPS, or annual cumulative dose is more than 20mSv )  Decontamination is implemented by the national government  The Act on Special Measures Concerning the Handling of Radioactive Pollution come into the force on January 1, 2012.  Based on this Act the followings are carried out

• Planning and implementation of decontamination work
• Collection, transfer, temporary storage, and final disposal

Special Decontamination Area Intensive Contamination Survey Area Legislation for Promoting Decontamination

8

Special Decontamination Area and Intensive Contamination Survey Area

Fukushima Tochigi Gunma Chiba Iwate Miyagi Ibaraki Saitama

・・Special Decontamination Area ・・Intensive Contamination Survey Area

20ｋｍ Fukushima City Koriyama City Iwaki City Fukushima Pref.

Fukushima Dai-ichi NPP Fukushima Dai-ichi NPP

9

Decontamination Policy for Special Decontamination Area

Decontamination should be implemented taking into account the level of air

dose rate.  Area less than 20mSv/year： Aiming to reduce additional exposure dose to less than 1mSv/year as long-term goal.  Area from 20～50mSv/year： Aiming to reduce exposure dose in residential and farmland area to less than 20mSv/year.

• Decontamination work in all municipalities in the Area has been uniformly

scheduled to be completed within 2 years, assuming the securing of temporary storage sites and consent of land owners, etc.

• In the case of areas more than 50mSv/year, demonstration projects will be
• implemented. Lessons learned will be taken into consideration in future

decontamination policy.

Policy in FY2012 and 2013

Policy Review at Sep. 2013

Decontamination work will be implemented in cooperation with reconstruction measures depending

• n the situation of each municipality. Additional measures for further progress will be conducted.

10

Decontamination Activities

Guideline for measurement of radio activities in contaminated area Guideline for decontamination techniques Guideline for collection and transportations

• f recovered soil

Guideline for storage of recovered soil Guideline for decontamination

11

Before & After the Decontamination Work (Tamura City )

Before After Before After Before Before After After

12 High pressure water cleaning of a drain pipe Removal of crushed stones and topsoil, and cover with clean soil Wiping off rooftop and walls Wiping off a gutter High pressure water cleaning of paved road Mowing and removal of sludge

Decontamination Activities (Tamura City )

13

Decontamination Activities

Packages and Transportation Criteria for Contaminated Soil

Below 100μSv/h

Punching bag sheet Plastic case Flexible container bag Drum

14

Effect of Radiation Dose Reduction by Decontamination Work (Air Dose Rate at the height of 1m above ground)

※ The measurement was taken before and after the decontamination work so that natural attenuation effect after the work was not included.  Measurement period before the decontamination work: July 25, 2012～May 23, 2013  Measurement period after the decontamination work: August 7, 2012～May 30, 2013 ・・・Before the decontamination work ・・・After the decontamination work Ambient Dose Rate at the height of 1m above the ground(µSv/h)

Measurement Points

and more

Tamura City

15

Flow Chart of The Contaminated Disaster Waste (Fukushima Pref.)

Specific Waste Waste in Designated Area Designated Waste Soil and Waste Generated by Decontamination

~500,000t ~110,000t 15,000,000t~31,000,000t

More than 8,000Bq/kg less than 8,000Bq/kg More than 8,000Bq/kg

Same Treatment as Outside of Designated Area Same Treatment as Designated Waste Incineration

Combustible Waste Non-combustible Waste Temporally Storage Interim Storage less than 100,000Bq/kg More than 100,000Bq/kg Controlled Landfill Final Disposal

Monitoring is implemented by the state

Volume reduction

16

The Policy on Decontamination in Specified Decontamination Area (The point of roadmap)

Start of transfer to interim storage Interim storage facility will established only in Fukushima prefecture where huge amount of soil and waste generated by decontamination activities. (transfer from outside of the prefecture is prohibited) Besides Fukushima prefecture, waste management is promoted in each prefectures. Requirement from decontamination activity, interim storage facilities will be operated for 30years, and final dispose of the waste will be conducted

17

Temporally Storage of Contaminated Soil

Fence Cover Soil Water Shield Packages Fence Sandbag Collective Tank Monitoring System

18

Illustration of Interim Storage Facility

①Storage Facility

②Emplacement & Segregation Facility ③Volume Reduction Facility ④24-hour monitoring Equipment( placed in several points, not specifically indicated in the figure) ⑤R & D Facility ⑥Public information Center

Scale of the whole facility（estimation） Total storage volume ranges between 15-28 million ㎥, which is 12-23 times big as a baseball stadium( approx. 1.24million ㎥ )

ISF will be consisted of facilities with various functions

Buffer Green Zone Admin Office

18

19

Conceptual Structure of Interim Storage Facility

Type-I Soil Storage Facility Type-II Soil Storage Facility Waste Storage Facility Main substances for storage (Radioactive cesium concentration) Soil and other materials that do not risk polluting public water area and groundwater with radioactive cesium ( 8,000Bq/kg or less ） Soil and other materials exceeding the condition shown in left column (More than 8,000Bq/kg ) Waste Measures to prevent water seeping into ground water － Seepage control and other infrastructure (Seepage control sheet and other infrastructure

• r low-permeability soil

layer) Package

19

20

Conceptual Structure of Interim Storage Facility

Drainage ditch

<Type-I >

Applicable geography and geology: Any low land Radioactive cesium concentration : 8,000Bq/kg or less

Covering soil Seeping water monitoring Groundwater monitoring Drainage layer Soil improvement (ensuring heavy machinery construction)* *Basement: In the case of alluvium, soil improvement (approximately up to 1m depth) will be performed. In the case of mudstone formation, no action will be needed. ※To water treatment facility (under water table) Water collection pipe (under water table) Water treatment facility (temporary) 【Alluvium】 【Mud stone formation and

• thers】

Soil and other materials

Shallow sump drainage (temporary) ※To water treatment facility

Schematic View of Type-Ⅰ Soil Storage Facility

20

21

Concept of Structure of Interim Storage Facility

Schematic View of Type- II Soil Storage Facility

<Type – II >

Leakage control : Seepage control sheet patterns Applicable geography and geology：Hill ,Tableland Radioactive cesium concentration：more than 8,000Bq/kg

21

Covering soil and seepage control construction and others Vertical drainage hole (perforated pipe)

Drainage ditch

【Mudstone formation 】

Soil and others Protective soil Drainage layer Seepage control construction and others (sheet and others) Groundwater monitoring ※To water treatment facility

Water treatment facility (temporary)

Groundwater collection pipe Collection pipe for retained water and others

22

Concept of Structure of Interim Storage Facility

Schematic View of Waste Storage Facility

Storage containers with shielding effect and durability if necessary (drums and others) Groundwater monitoring Inspection and management gallery Building (e.g. RC Construction) with shielding effect

Applicable geography and geology: Hill, Tableland Radioactive cesium concentration: More than 100,000Bq/kg

23

Future Plan on the Interim Storage Facility

Survey started Survey completed

Approx. 3 months Review & provision on actual image of the facility Local coordination (coordination of land acquisitions, etc.) Negotiations for the land acquisitions Construction of the facility

Commencement of service

• f the facility

Jan., 2015~

24

 Structure of landfill disposal site

• underground strictly controlled landfill doubly-covered by concrete construction in order to

accept radioactive materials contained in designated waste

 During landfill operation

• Installation of roof and wall enabling to prevent rain infiltration and scatter of waste

 After landfill operation

• Covering upper section of the disposal site by concrete construction and soil

 Interception of groundwater and surface water

• Prevention of designated waste from contact with water and radioactive materials from

leaching as well as shielding radiation

Ground water prevention Surface water prevention

Double concrete Cover soil

Landfill Disposal of Designated Waste (Isolated type landfill site)

Structure of landfill disposal sites in 5 prefectures (Miyagi, Ibaraki, Tochigi, Gunma and Chiba Pref.)

25

Consistency between Nuclear regulations and the Act on Special Measures Concerning the Handling of Pollution by Radioactive Materials  “Nuclear reactor regulation law” stated disposal of radioactive waste depending on its radioactivity concentration.

• Radioactive waste whose Cs-137 content below 100,000,000,000 Bq/kg (in case of single

nuclide) is disposed of at near surface disposal facility with artificial barrier.

• Radioactive waste whose Cs-137 content below 100,000 Bq/kg (in case of single

nuclide) is disposed of at near surface disposal facility without artificial barrier.

 Radioactive waste whose total radioactive cesium content below 100,000Bq/kg is possible to keep the dose rate of the people who live vicinity of the repository below 1mSv/y with relatively simple shielding measures such as covered with 15cm cover soil on the day and keeping the 8m distance.  From the above, on the radioactive waste whose total radioactive cesium content below 100,000Bq/kg, it is possible to dispose of at controlled landfill site with appropriate counter measures of shield and protection of migration.

26
