Programming the Internet of Things

Why Devices Need APIs

December 8, 2014 Greg Burns Chair of Technical Steering Committee AllSeen Alliance

2

Mobile – The largest technology platform

~3.3 billion unique subscribers

Source: GSMA Intelligence, November 13; UN, November 2013

6.8 B

connections people

7.2 B

3

And that platform is about to be dwarfed…

Massive surge in connected things has already begun

By 2020, 40.9 billion things will be connected*

− Via Wi-Fi, wire line, cellular, and proximal networks − Benefiting billions of people worldwide − 75% of the growth between today and the end of the decade will come from non-hub devices

Transforming:

− Industry − Infrastructure − Media − Education − Work − Recreation − Family − Daily life

* Source: https://www.abiresearch.com/press/the-internet-of-things-will-drive-wireless-connect

AllSeen Alliance

4

Internet of Things Today

NOW PLAYING: Artist: Flowers Song: Daisy

Fridge Cloud Laundry Cloud Lighting B Cloud Speaker B Cloud Speaker A Cloud TV Cloud Lighting A Cloud Lighting C Cloud Security Camera Cloud

5

Ubiquitous connectivity promises to make devices “smart”

But ONLY if they speak the same language

당신은 내 말 들려?

Tem alguém aí? 100010101011 hello world!  Auto Home Consumer goods and appliances Industrial Computing devices

Devices that can’t connect across brands, categories, and operating systems will be left out

6

Network topology matters

Direct communication is fast, efficient, and secure. No need to go out to the cloud to talk to the device right next to you!

“Coffee is done” “Coffee is done” “Laundry is ready!” “Laundry is ready!” “Someone’s at the door” “Someone’s at the door”

NOW PLAYING: Artist: Flowers Song: Daisy

“Someone’s at the door”

7

Internet of Things Tomorrow

NOW PLAYING: Artist: Flowers Song: Daisy

Secured Proximal Cloud Various Cloud Services

8

What are these “things”

• f which you speak?

Without the right combination of hardware, connectivity and software a “Thing” is just a “Thing”. Ultimately it is software that makes a “Thing” an Internet-of -Things Thing.

2 December 2014 AllSeen Alliance 9

APIs - how software talks to software

• Well constructed software has clean boundaries between the internals of the

implementation and the external interfaces exposed to other software.

– We generally call these external interfaces Application Programming Interfaces (APIs) – APIs are what makes it possible to incorporate existing functionality into new code

• Software platforms are simply collections of APIs

– Windows, Linux, Android, iOS, OSX – are defined by the APIs they provide – Examples abound - OpenGL, PhysX, Webkit, every social network on the planet!

2 December 2014 AllSeen Alliance 10

APIs – for IoT devices

• IoT devices are characterized by the software they run so:

– When IoT devices talk to IoT devices it is software talking to software

• IoT devices should have APIs

– But these IoT devices are all so different – But often have very similar functions

• What APIs should IoT devices have?

– Some standard APIs – Some device specific APIs

11

IoT needs a framework to expose the various APIs of connected devices in a consistent way.

A single platform allowing products to expose their capabilities

LOCK DOORS LIGHT BULBS GARAGE DOOR SENSORS PICTURES VIDEO DRAPES DISPLAYS SPEAKERS CLOCKS COOL HEAT TVs

The AllJoyn software framework is a collaborative open source project of the AllSeen Alliance

12

Devices describe their capabilities via discoverable self-describing service interfaces

I can send notifications I have control panel I have lighting interface I can send notifications. I have control panel I have a clock interface I display notifications. I have the clock interface! I display notifications. I have the clock interface! I display notifications. I have the clock interface! I can send and display notifications I can send notifications

The AllJoyn software framework is a collaborative open source project of the AllSeen Alliance

72°

120 80

2 December 2014 AllSeen Alliance 13

Standards

• What we don’t want:

– There’s an App for that thing – And an App for that thing – And yet another App for that thing – …

• Devices that have similar functionality should expose the same APIs

– Every device with a clock should expose a set-clock API – Every device that has a battery should expose a battery level API – Manufacturers cannot differentiate by exposing necessary functionality in different ways

14

Exposing smartphone APIs enabled new experiences - that no one had ever thought of

GPS GPU DSP GYRO MICROPHONE TOUCHSCREEN ACCELEROMETER

15

The problems to be solved…in an open interoperable way

DISCOVER nearby friendly devices IDENTIFY services running

• n those devices

ADAPT to devices coming and going MANAGE diverse transports INTEROPERATE across different OSes EXCHANGE information and services SECURE against nearby bad actors

2 December 2014 AllSeen Alliance 16

Baseline for an API framework for IoT

• Must be designed to work with existing programming languages

– Java, C, C++, C#, JavaScript, Python, etc

• Must support modular construction

– To allow standard building blocks – To allow innovation

• Must include facilities for discovery

– Find out what APIs a device has rather than what the device is

• Must support privacy and security

– Which APIs can be used by other devices – Authentication and data encryption

17

The AllJoyn™ Project

An Open Source Framework for the Internet of Things

2 December 2014 AllSeen Alliance 18

A year ago a group of companies formed the AllSeen Alliance

• A nonprofit consortium dedicated to enabling the widespread adoption of products, systems and

services that support the Internet of Things through an open environment, vibrant ecosystem and thriving technical community.

• Hosts and advances an industry-supported software and services framework based on the

collaborative AllJoyn open source project.

• This collaborative open source framework enables hardware manufacturers and software

developers to create interoperable products that can discover, connect and communicate directly with other devices, systems and services regardless of brand.

2 December 2014 AllSeen Alliance 19

Alliance and Objectives

Supporting the Internet of Things through an open environment, vibrant ecosystem and thriving technical community.

Alliance

Open Source Community Industry leaders Tech/software innovators

Contribute & Use Evangelize Evolution

• f AllJoyn

Enable Vibrant Ecosystem

To learn more about the AllSeen Alliance visit: www.allseenalliance.org To find out about participating in the AllSeen Alliance contact: Joe Speed <jspeed@linuxfoundation.org>

20

AllJoyn Software Framework: High-level architecture

A comprehensive software framework lets devices and applications communicate Standard Application Layer AllJoyn Application Layer AllJoyn Service Frameworks AllJoyn Core Libs

Onboarding Control Panel Notifications Audio Lighting

Physical Layer (Wi-Fi, PLC, Ethernet, Bluetooth)

Discovery & Advertisement APIs Connection APIs Security APIs

AllJoyn Core Libs

Provides ability to find and connect to devices to do interesting things. Core libraries interact with the AllJoyn Router Provides access control and encryption

AllJoyn Service Frameworks

Interoperable, cross-platform modules for common IoE functionality Defines common interfaces between devices

The AllJoyn software framework is a collaborative open source project of the AllSeen Alliance

OS

AllJoyn Apps

Config

AllJoyn App Layer

Defines the User experience

AllJoyn Router

AllJoyn Router

• Manages

communications between devices and apps

• Dynamic network

management

Interface APIs Events and Actions ….

21

Two Versions of the AllJoyn Framework To Choose

Standard Application Layer Standard Application Layer App Layer AllJoyn Standard Service Frameworks AllJoyn Standard Core Libs

Physical Layer (Wi-Fi, PLC, Ethernet, Bluetooth)

Standard Core Libraries

Multiple bindings, runs on HLOS C bindings, runs on RTOS Thin Apps using Thin Core requires an AllJoyn Router in the network

Thin Core Libraries

The AllJoyn software framework is a collaborative open source project of the AllSeen Alliance

HLOS RTOS

App Layer AllJoyn Thin Service Frameworks AllJoyn Thin Core Libs Standard Apps Thin Apps

Standard App Layer

App dev or OEM writes this

Thin App Layer

OEM writes this

AllJoyn Router

AllJoyn Router

AllJoyn Router can be bundled with a Standard App or run standalone

22

Licensed under open source; general IOE use cases Not licensed under open source; addresses specific use cases Value e Added ed S Services es (e.g., y your d diff ffer eren entiation)

AllJoyn Core: Discovery, connectivity, network management from AJ Router + core libraries Onboarding, notification, audio compatibility from AllJoyn Service Frameworks

AllJoyn Router AllJoyn Core Libraries

Discovery Connection / Network Management Security

AllJoyn Service Frameworks

Onboarding Control Panel Notifications Audio Future… Config

Open source building blocks for value added services

Use AllJoyn Core Library and Service Frameworks to create differentiated offerings

23

− Alliance Wiki: https://wiki.allseenalliance.org

− Documents, downloads, and developer tools − Source Code, release overviews, roadmaps − Training & Service Framework details − Working Groups, New Proposals & meeting minutes

− Forums: https://ask.allseenalliance.org/questions − Certification: https://allseenalliance.org/certification − Releases & Roadmaps: https://wiki.allseenalliance.org/release/overview − Public Mail Lists: https://lists.allseenalliance.org/mailman/listinfo − Showcase: https://allseenalliance.org/showcase − Monthly Newsletter: https://allseenalliance.org/news-and- events/newsletters

For More Information

2 December 2014 AllSeen Alliance 24

For more information on AllSeen Alliance, visit us at: allseenalliance.org & allseenalliance.org/news/blogs
