Improving Downstream Manufacturing Productivity with Pre-Packed Chromatography Columns

Michael Dittmer

MedImmune, BioProcess Engineering

BPI West, San Francisco, CA March 2nd, 2017

• Motivation and Scope
• Technical Evaluation
• Details of study
• Results
• Economic Analysis
• Cost Comparison
• Impact on Plant Productivity
• Additional Topics

Outline

Motivation and Scope

Motivation and Goals

• MedImmune evaluated pre-packed columns as a potential

technology to improve productivity in antibody production

• Productivity improvements resulting from:

– Lower costs – Decrease processing time

• Two primary considerations:

– Does the technology work? (Technical Evaluation)

• Comparable to existing solutions
• Durable and robust

– Does the cost of the technology make financial sense? (Economic Analysis)

Scope

5

• Focus on existing GMP facility
• Facility already contains significant stainless equipment

– Purification skids – Columns – Buffer and product tanks

• Facility is a “hybrid” facility in that it also contains many single-use and

disposable technologies – Single-use instrumentation – Buffer bags

• Facility would continue to support traditional chromatography columns

Technical Evaluation

Technical Evaluation – Study Details

• Collaboration with GE Lifesciences

(Ready-To-Process columns)

• Goal:

– Evaluate performance of 45cm prepacked column over 10+ cycles

• Bed stability
• Consistent column performance
• Impurity clearance
• Comparability to conventional packed

columns

– Provide feedback to vendor on prototype pre-packed column

Technical Evaluation – Study Details cont.

8

• Studies performed at MedImmune pilot facility in Gaithersburg, MD.

– Multi product facility – Scale: 500L bioreactor – Facility equipment: Mostly stainless. Disposable bags/tubing – Molecule type: mAb – Resin type: ProteinA (MabSelect SuRe) – Column dimensions: 45x20cm

• 19 Cycles recorded

– 12 cycles with protein load (5 different products) – 7 cycles with just buffer and hydroxide

• Data compared and normalized against manual packed 45cm
• column. Same projects.

HETP and Asymmetry Results

9

• HETP and asymmetry

results used to monitor integrity of bed throughout study – Cycle# 1, 8, 19

• Results demonstrate stable

bed performance

0.01 0.02 0.03 0.04 0.05 5 10 15 20

HETP (cm) Cycle Number

0.7 0.9 1.1 1.3 5 10 15 20

Asymmetry Cycle Number

Column Performance Results

10

• Column performance metrics:

– Elution Volume (CV) – Yield (%)

• Values are normalized against

historical data (w/ conventional manual pack column)

• Pre-packed column performed

consistent with conventional column

0.5 0.7 0.9 1.1 1.3 1.5 5 10 15 20

Cycle Number

Normalized Elution Volume

0.5 0.7 0.9 1.1 1.3 1.5 5 10 15 20

Cycle Number

Normalized Protein Yield

Impurity Clearance Results

11

• Protein aggregate removal same as

conventional columns – Monomer % within (+/- 0.1)

• HCP and DNA clearance, bioburden, and

endotoxin levels all within range

Technical Evaluation – Summary

12

• When compared to a gold standard (conventional manual packed

column), the pre-packed column performed the same: – Column Bed Integrity – Column Performance – Impurity Clearance

• Performance was consistent across 19 cycles and 5 different

projects

• No technical concern with repeated cycling on pre-packed column

Economic Analysis

Cost Analysis – Scope and Assumptions

• Facility – Existing stainless GMP production area
• Resin

– MabSelect SuRe – 2016 List Price

• Labor (employee-hours)

– Packing and unpacking – 48 – Cleaning and changeover – 28 – Buffer preparation – 12 – QC – 16

• Buffer

– Cost of water and chemicals

• Other

– Column maintenance and changeover – Depreciation

• Pre-Pack Premium

– Cost differential between resin and pre-packed column cost

Cost Analysis - Results

15

45cm x 20cm MabSelect SuRe

100 200 300 400 500 600 700 Conventional Pre-Packed

Cost ($1k)

Total Column Cost

Pre-Pack Premium Other Buffer Labor Resin 10 20 30 Conventional Pre-Packed

Cost ($1k)

Column Cost (excl. Resin)

Cost Analysis (additional discussion)

16

• Existing stainless GMP facility

– Equipment/cleaning validation not completely eliminated – CIP/SIP systems available

• Usage of production area is not factored in cost analysis.

– Significant advantage for pre-packed!

• Cost is comparable between pre-packed and manually packed

columns

Purification Suite Utilization

17

Packing (3 days) Protein Purification (5 days) Unpacking (2 days)

Column Activities 5d Production 5d Column Activities 5d Production 15d Column Activities 5d Production 25d

1 Batch 3 Batches 5 Batches

Productivity Improvement

18

Column Activities 5d Production 15d

25% of time spent

• n Column Packing

5d Production 15d

Replace Columns w/ Pre-Packed

• 33% more grams of

protein per year

• Up to 18* more

batches per year

3 Batches per Campaign

Similar Cost No additional capital

*Facility runs year-round

Productivity Impact – Bottleneck discussion

19

• These time savings only realized if downstream processing is

primary bottleneck for production

• Other likely bottlenecks:

– Bioreactor turnover/production – Product and buffer tank availability – Support functions (buffer prep, cleaning) Productivity Improvement Save Time Save Cost 𝑕 ℎ𝑠 ∗ 𝑀𝑠𝑓𝑡𝑗𝑜 𝑕 ℎ𝑠 ∗ 𝑀𝑠𝑓𝑡𝑗𝑜 𝑕 ℎ𝑠 ∗ 𝑀𝑠𝑓𝑡𝑗𝑜

Productivity Improvement w/o bottleneck

20

Column Activities 5d Production 15d

25% of time spent

• n Column Packing

Replace Columns w/ smaller Pre-Packed

• Smaller Columns =

Additional Cycles

• Replace column

packing days with additional production days

3 Batches per Campaign

Similar Processing Time Reduced Resin/Cost

Production 20d

Economic Analysis Summary

21

• Pre-packed column cost is comparable to conventional manually

packed columns

• Can eliminate ~25% days in production suite while keeping costs

the same (avg. 3 runs per campaign)

• If cost and not time is primary concern, can reduce cost with

smaller pre-packed columns

• Pre-packed columns increase productivity

Additional Topics

Additional Pre-Packed Column Advantages

• Safety stock of ready to use columns. Inventory managed by

customer or vendor – Platform resins

• Streamlines storage of resin for reoccurring campaigns

– Wheel column into storage – No unpacking/storage/repacking required

Future Considerations

24

• Recovery of resin

– Procedure and means for accessing resin. Troubleshooting

• Initial HETP testing

– Can further improve productivity by eliminating initial HETP testing

• Continuous Chromatography

– Pre-packed columns extremely advantageous for multi-column systems – Would require shorter bed heights than typical offerings

• 5 – 10cm

Overall Summary

25

• Pre-packed columns perform identically to conventional manually

packed columns – Bed Integrity – Column Performance – Impurity Clearance

• Cost is comparable to conventional columns
• Pre-packed columns increase productivity in existing

stainless GMP facilities – Fewer days in production suite, or less resin
