Probabilisti tic Model Checking
 & P & PRIS RISM


Dave Parker


University of Birmingham HIERATIC kick-off meeting, Birmingham, Dec 2012

Overview

• Quantitative verification

− probabilistic model checking

• Probabilistic models + logics

− discrete-time Markov chains + PCTL − continuous-time Markov chains + CSL − discrete stochastic models of biological systems

• PRISM: probabilistic model checker

− overview, modelling language, symbolic implementation

• Techniques for scalability, efficiency

− bisimulation, symmetry, abstraction, simulation

Quantitative verification

• Formal verification…

− is the application of rigorous, mathematics-based techniques to establish the correctness of computerised systems

• Quantitative verification

− applies formal verification techniques to the modelling and analysing of non-functional aspects of system behaviour (e.g. probability, time, cost, …)

• Probabilistic model checking…

− is a an automated quantitative verification technique
 for systems that exhibit probabilistic behaviour

Verification via model checking

Finite-state model Temporal logic specification Result System Counter- example System require- ments

¬EF fail

Model checker

e.g. SMV, Spin

Model ch Model checkin ecking: Automatic formal verification of correctness properties of computerised systems

Probabilistic model checking

• Why and what?
• Why probability?

− unreliability (e.g. component failures) − uncertainty (e.g. message losses/delays over wireless) − randomisation (e.g. in protocols such as Bluetooth, ZigBee) − stochasticity (e.g. biological/chemical reaction rates)

• Quantitative properties

− reliability, performance, quality of service, … − “the probability of an airbag failing to deploy within 0.02s” − “the expected power usage of a sensor network over 1 hour” − “the expected time for a cell signalling pathway to complete”

Probabilistic model checking

Probabilistic model

e.g. Markov chain

Probabilistic temporal
 logic specification

e.g. PCTL, CSL, LTL

Result Quantitative results System Counter- example System require- ments

P<0.01 [ F≤t fail]

0.5 0.1 0.4

Probabilistic model checker

e.g. PRISM

Probabilisti tic model checking: Automatic verification of quantitative properties of systems with stochastic behaviour

Probabilistic model checking

• Construction and analysis of finite probabilistic models

− e.g. Markov chains, Markov decision processes, … − specified in high-level modelling formalisms − exhaustive model exploration (all possible states/executions)

• Automated analysis of wide range of quantitative properties

− properties specified using temporal logic − “exact” results obtained via numerical computation − linear equation systems, iterative methods, uniformisation, … − as opposed to, for example, Monte Carlo simulations − efficient techniques from verification + performance analysis − mature tool support available, e.g. PRISM

Overview

• Quantitative verification

− probabilistic model checking

• Probabilistic models + logics

− discrete-time Markov chains + PCTL − continuous-time Markov chains + CSL − discrete stochastic models of biological systems

• PRISM: probabilistic model checker

− overview, modelling language, symbolic implementation

• Techniques for scalability, efficiency

− bisimulation, symmetry, abstraction, simulation

Probabilistic models

Di Discrete te ti time Conti tinuous ti time Nondete terministi tic Fully probabilisti tic Discrete-time Markov chains (DTMCs) Continuous-time Markov chains (CTMCs) Markov decision processes (MDPs)

(probabilistic automata)

CTMDPs/IMCs Probabilistic timed automata (PTAs)

Probabilistic models

• Discrete-time Markov chains (DTMCs)

− discrete states + probability − for: randomisation, unreliable communication media, …

• Continuous-time Markov chains (CTMCs)

− discrete states + exponentially distributed delays − for: component failures, job arrivals, molecular reactions, …

• Markov decision processes (MDPs)

− in fact: probabilistic automata [Segala] − probability + nondeterminism (e.g. for concurrency) − for: randomised distributed algorithms, security protocols, …

• Probabilistic timed automata (PTAs)

− probability, nondeterminism + real-time − for wireless comm. protocols, embedded control systems, …

Discrete-time Markov chains

• Formally, a DTMC D is a tuple (S,sinit,P,L) where:

− S is a finite set of states (“state space”) − sinit ∈ S is the initial state − P : S × S → [0,1] is the transition probability matrix where Σs’∈S P(s,s’) = 1 for all s ∈ S − L : S → 2AP is function labelling states with atomic propositions

• Note: no deadlock states

− i.e. every state has at least

• ne outgoing transition

− can add self loops to represent final/terminating states s1 s0 s2 s3

0.01 0.98 0.01 1 1 1 {fail} {succ} {try}

Paths and probabilities

• A (finite or infinite) path through a DTMC

− is a sequence of states s0s1s2s3… such that P(si,si+1) > 0 ∀i − represents an execution (i.e. one possible behaviour) of the system which the DTMC is modelling

• To reason (quantitatively) about this system

− need to define a probability space over paths

• Intuitively:

− sample space: Path(s) = set of all
 infinite paths from a state s − basic events: cylinder sets (or “cones”) − cylinder set C(ω), for a finite path ω
 = set of infinite paths with the common finite prefix ω − event set: least σ-algebra on Path(s) containing C(ω) for all finite paths ω starting in s − probability of cylinder set, e.g. C(ss1s2)=P(s,s1)P(s1,s2)

s1 s2 s

PCTL

• Temporal logic for describing properties of DTMCs

− PCTL = Probabilistic Computation Tree Logic [HJ94]

• Extension of (non-probabilistic) temporal logic CTL

− key addition is probabilistic operator P − quantitative extension of CTL’s A and E operators

• Example

− send → P≥0.95 [ F≤10 deliver ] − “if a message is sent, then the probability of it being delivered within 10 steps is at least 0.95”

• Other possibilities for P operator

− unbounded reachability (F), until (U), globally (G), …

• Model checking for PCTL

− determine states of a DTMC satisfying a PCTL formula − boils down to: graph analysis, solution of linear equation systems, iterative numerical solution

Quantitative properties

• Consider a PCTL formula P~p [ ψ ]

− if the probability is unknown, how to choose the bound p?

• When the outermost operator of a PTCL formula is P

− we allow the form P=? [ ψ ] − “what is the probability that path formula ψ is true?”

• Model checking is no harder: compute the values anyway
• Useful to spot patterns, trends
• Example

− P=? [ F err/total>0.1 ] − “what is the probability
 that 10% of the NAND
 gate outputs are erroneous?”

Some real PCTL examples

• NAND multiplexing system

− P=? [ F err/total>0.1 ] − “what is the probability that 10% of the NAND gate outputs are erroneous?”

• Bluetooth wireless communication protocol

− P=? [ F≤t reply_count=k ] − “what is the probability that the sender has received k acknowledgements within t clock-ticks?”

• Security: EGL contract signing protocol

− P=? [ F (pairs_a=0 & pairs_b>0) ] − “what is the probability that the party B gains an unfair advantage during the execution of the protocol?” reliability performance fairness

Continuous-time Markov chains

• Continuous-time Markov chains (CTMCs)

− labelled transition systems augmented with rates − continuous time delays, exponentially distributed

• Formally, a CTMC C is a tuple (S,sinit,R,L) where:

− S is a finite set of states
 (the “state space”) − sinit ∈ S is the initial state − R : S × S → ℝ≥0 is the
 transition rate matrix − L : S → 2AP is a labelling with atomic propositions

• Transition rate matrix assigns rates to each pair of states

− used as a parameter to the exponential distribution − transition between s and s’ when R(s,s’)>0 − probability triggered before t time units: 1 – e-R(s,s’)·t s1 s0

3/2 1 {full} {empty}

s2 s3

3/2 3/2 3 3 3

CSL

• Temporal logic for describing properties of CTMCs

− CSL = Continuous Stochastic Logic [ASSB00,BHHK03] − extension of (non-probabilistic) temporal logic CTL − transient, steady-state and path-based properties

• Key additions:

− probabilistic operator P (like PCTL) − steady state operator S

• Example: down → P>0.75 [ ¬fail U≤[1,2.5] up ]

− when a shutdown occurs, the probability of a system recovery being completed between 1 and 2.5 hours without further failure is greater than 0.75

• Example: S<0.1[ insufficient_routers ]

− in the long run, the chance that an inadequate number of routers are operational is less than 0.1

Modelling biological systems

• Aim: model a mixture of interacting molecules

− multiple molecular species, interacting through reactions − cell signalling pathway, gene regulatory network, … − fixed volume (spatially uniform), pressure and temperature

• Simple example:

− 3 species A, B and AB; 3 reactions: − reversible binding of A and B to form AB; degradation of A

• Two approaches to modelling

− discrete, stochastic − continuous, deterministic

A

k3

A + B AB

k1 k2

Modelling biological systems

• Discrete, stochastic approach

− (integer) counts of number of
 each molecule: x=(xA,xB,xAB) − inherently stochastic process
 [McQuarrie, Gillespie] − continuous-time Markov chain with states x x − stochastic simulation, numerical soln.,
 probabilistic model checking, …

• Continuous, deterministic approach

− (real-valued) concentrations: [A], [B], [AB] − solution of system of coupled


• rdinary differential equations

− good approximation of E[x]
 for very large num.s of molecules

A

k3

A + B AB

k1 k2

Discrete stochastic approach

• Chemical master equation

− state vector x=(xA,xB,xAB) − probability P(x,t) that at time
 t there will be xZ of species Z − stoichiometric vectors: v1=(-1,-1,1), v2=(1,1,-1), v3=(-1,0,0) − ai(x) are time-independent propensity functions − mass-action: proportional to reactant combinations

• e.g. a1(xA,xB,xAB) = k1·xA·xB
• Stochastic process: continuous-time Markov chain (CTMC)

− transition rates (of exponential delays) derived from ai

δP(x,t) δt = ai(x − v i)P(x − v i,t) −

i=1 3

∑

ai(x)P(x,t)

A

k3

A + B AB

k1 k2

Continuous-time Markov chain (CTMC)

• Example
• CTMC with:

− states (xA,xB,xAB) ∈ S = {0,1,2}3 − initial state (2,2,0)

• Rates for reactions

− r1 (binding): rate = xA·xB·k1 − r2 (unbinding) rate = xAB·k2 − r3 (degradation): rate = xA·k3

2,2,0

4k1

1,1,1 0,0,2 1,2,0 0,1,1

k1 2k2 k2

0,2,0

2k3 k3 k3 2k1 k2

A

k3

A + B AB

k1 k2

CSL properties for biological systems

• P=? [ F[t,t] a=i ]

− “the probability that there are exactly i A after t seconds”

• P=? [ F a=0 ]

− “probability that all A proteins are eventually degraded”

• S=? [ c+d>M ]

− “long-run probability that the total number of Cs and Ds activated is above M”

• P=? [ c=0 U>t c>0 {c=0}{“max”} ]

− “highest probability of it taking more than t seconds for C to become activated, from any state where there are none”

• P=? [ F c=N ] / P=? [ F c>0 ]

− “the (conditional) probability that all C proteins are eventually activated, given that at least some of them are”

• R{“active_d”}=? [ I=t ]

− “the expected number of activated D at time instant t”

Example (FGF)

• Example: Fibroblast Growth Factor (FGF) [Heath et al.]

− pathway: 12 species, 14 sets of reaction rules − model checking (PRISM)
 and simulation (stoch. π-calculus) − “in-silico” experiments:
 systematic removal of components − results validated by
 subsequent lab experiments

• Probabilistic model checking

− probability that a signal is present at time T? − P=? [ F=T (FRS2_GRB>0 &relocFRS2=0 & degFRS2=0) ]

Probabilistic model checking

Probabilistic model checking for systems biology…

CTMC Temporal logic

e.g. CSL, LTL

Result Quantitative results Biological system Counter- example System properties

P=? [ F=t a>0 ]

0.5 0.1 0.4

PRISM

System
 model

Overview

• Quantitative verification

− probabilistic model checking

• Probabilistic models + logics

− discrete-time Markov chains + PCTL − continuous-time Markov chains + CSL − discrete stochastic models of biological systems

• PRISM: probabilistic model checker

− overview, modelling language, symbolic implementation

• Techniques for scalability, efficiency

− bisimulation, symmetry, abstraction, simulation

The PRISM tool

• PRISM: Probabilistic symbolic model checker

− developed at Birmingham/Oxford University, since 1999 − free, open source software (GPL), runs on all major OSs

• Support for:

− models: Markov chains, Markov decision processes, … − properties: PCTL, CSL, LTL, PCTL*, costs/rewards, …

• Features:

− simple but flexible high-level modelling language − user interface: editors, simulator, experiments, graph plotting − multiple efficient model checking engines (e.g. symbolic)

• Many import/export options, tool connections

− in: (Bio)PEPA, stochastic π-calculus, DSD, SBML, Petri nets, … − out: Matlab, MRMC, INFAMY, PARAM, …

• See: http://www.prismmodelchecker.org/

PRISM – Case studies

• Randomised communication protocols

− Bluetooth, FireWire, Zeroconf, 802.11, Zigbee, gossiping, …

• Randomised distributed algorithms

− consensus, leader election, self-stabilisation, …

• Security protocols/systems

− pin cracking, anonymity, quantum crypto, contract signing, …

• Planning & controller synthesis

− robotics, dynamic power management, …

• Performance & reliability

− nanotechnology, cloud computing, manufacturing systems, …

• Biological systems

− cell signalling pathways, DNA computation, …

• See: www.prismmodelchecker.org/casestudies

PRISM modelling language

• Simple, textual, state-based modelling language

− for Markov chains (and other models)

• Language basics

− networks formed from interacting modules − state of each module given by finite-ranging variables − behaviour of each module specified by guarded commands − interactions between modules through synchronisation − interactions are associated with state-dependent rates

[r1] (a>0) → k1*a : (a’=a-1)&(ab’=ab+1);

action guard rate update

PRISM language - example

mo modul ule A a : [0..N] in init it N; ab : [0..N] in init it 0; [r1] a>0 → k1*a : (a’=a-1)&(ab’=ab+1); [r2] ab>0 → k2*ab : (a’=a+1)&(ab’=ab-1); [r3] a>0 → k3*a : (a’=a-1); en endm dmodu

• dule

le mo modul ule B b : [0..N] in init it N; [r1] b>0 → b : (b’=b-1); [r2] b<N → b : (b’=b+1); en endm dmodu

• dule

le

Example (r1): (a,ab,b) (a-1,ab+1,b-1)

k1·a·b

A

k3

A + B AB

k1 k2

Reactions r1/r2 : Reaction r3 :

PRISM - Model checking engines

• Probabilistic model checking in PRISM
• Basic ingredients

− graph-based algorithms, e.g. reachability, qualitative verif. − numerical solution techniques, e.g. probability computation − usually rely on iterative methods: uniformisation-based for transient properties, Gauss-Seidel/etc. for linear equations

• Efficiency, scalability is essential

− primary source: symbolic implementation techniques − (multi terminal) binary decision diagrams: (MT)BDDs − exploit structure, regularity in high-level model

• PRISM includes multiple efficient model checking engines

− “MTBDD”: fully symbolic (up to 1010 states for regular models) − “sparse”: converts to explicit-state storage for fast solution − “hybrid”: mix of symbolic/explicit; best overall performance; usually allows model checking for up to 107-108 states

Symbolic storage techniques

• Matrix: MTBDD:

En Entr try in M x1

1

x2 y1

1

y2

2

x1y1x2y2

2

fM

M

(0,1) = 8 1 0001 8 (1,0) = 2 1 0010 2 (0,3) = 5 1 1 0101 5 (1,3) = 5 1 1 1 0111 5 (2,3) = 5 1 1 1 1101 5 (3,2) = 2 1 1 1 1110 2 y1 x1 8 2 x2 y1 5 x2 y2 y2 y2

Symbolic storage techniques

• Matrix: MTBDD:

En Entr try in M x1

1

x2 y1

1

y2

2

x1y1x2y2

2

fM

M

(0,1) = 8 1 0001 8 (1,0) = 2 1 0010 2 (0,3) = 5 1 1 0101 5 (1,3) = 5 1 1 1 0111 5 (2,3) = 5 1 1 1 1101 5 (3,2) = 2 1 1 1 1110 2

Recursion

y1 x1 8 2 x2 y1 5 x2 y2 y2 y2

Symbolic storage techniques

• Matrix: MTBDD:

y1 x1 8 2 x2 y1 5 x2 y2 y2 y2 En Entr try in M x1

1

x2 y1

1

y2

2

x1y1x2y2

2

fM

M

(0,1) = 8 1 0001 8 (1,0) = 2 1 0010 2 (0,3) = 5 1 1 0101 5 (1,3) = 5 1 1 1 0111 5 (2,3) = 5 1 1 1 1101 5 (3,2) = 2 1 1 1 1110 2

Repeated
 submatrices Shared
 MTBDD node

Symbolic storage techniques

• Matrix: MTBDD:

y1 x1 8 2 x2 y1 5 x2 y2 y2 y2 En Entr try in M x1

1

x2 y1

1

y2

2

x1y1x2y2

2

fM

M

(0,1) = 8 1 0001 8 (1,0) = 2 1 0010 2 (0,3) = 5 1 1 0101 5 (1,3) = 5 1 1 1 0111 5 (2,3) = 5 1 1 1 1101 5 (3,2) = 2 1 1 1 1110 2

Identical adjacent
 submatrices MTBDD node
 removed

Symbolic storage techniques

• Matrix: MTBDD:

y1 x1 8 2 x2 y1 5 x2 y2 y2 y2 En Entr try in M x1

1

x2 y1

1

y2

2

x1y1x2y2

2

fM

M

(0,1) = 8 1 0001 8 (1,0) = 2 1 0010 2 (0,3) = 5 1 1 0101 5 (1,3) = 5 1 1 1 0111 5 (2,3) = 5 1 1 1 1101 5 (3,2) = 2 1 1 1 1110 2

Blocks of zeros Edge goes
 straight to zero node

Scalability & efficiency

• Model reduction techniques

− bisimulation, symmetry, …

• Abstraction (and refinement)

− “safe” approximation from a smaller model − analysis of infinite-state systems

• Approximate (statistical) probabilistic model checking

− Monte-Carlo simulation + sampling

Overview

• Quantitative verification

− probabilistic model checking

• Probabilistic models + logics

− discrete-time Markov chains + PCTL − continuous-time Markov chains + CSL − discrete stochastic models of biological systems

• PRISM: probabilistic model checker

− overview, modelling language, symbolic implementation

• Techniques for scalability, efficiency

− bisimulation, symmetry, abstraction, simulation

Bisimulation

• Classically, fundamental notion in concurrency theory

− generalised to probabilistic models, e.g.: − probabilistic bisimulation for CTMCs (lumping) [Buchholz’94] − preserves important classes of (temporal logic) queries

• Bisimulation minimisation

− construct and analyse smaller but equivalent quotient model − can be fully automated, using extensions of classic algorithm based on iterative partition splitting (but may be expensive) − however, for probabilistic models, cost of minimisation shown to be worthwhile in some cases [Katoen et al.’07]

• Other benefits

− can be applied compositionally (minimise components first) − can be combined with symbolic techniques [Wimmer et al.]

Symmetry reduction

• Exploit presence of replication within a model

− a simple but common case is component symmetry, i.e. multiple copies of identical processes

• State-level and model-level approaches exist

− state-level manipulates model (transition matrix) directly;
 model-level works on high-level modelling formalism − e.g. two approaches implemented for PRISM: − symbolic (MTBDD-based) model-level algorithm [CAV’06] − GRIP: language-level translation [Donaldson/Miller]

• Symmetry reduction yields a probabilistic bisimulation

− and usually much more efficient to perform the reduction − but not necessarily the smallest bisimulation, and may need manual identification of symmetries in model

Symmetry reduction

• Some results (simplified FGF model, CAV’06 approach)

− corresponds to “population-based” model (which may be difficult to model directly by hand for complex systems)

• Challenges:

− more complex types of symmetry required for systems biology

Abstraction

• Very successful in (non-probabilistic) model checking

− hide details irrelevant to the property of interest − essential for verification of large/infinite-state systems − yields smaller/finite model, but with some loss of precision

• How to construct abstractions for Markov chains?

− e.g. for DTMCs, can use abstract Markov chains (probabilities replaced with intervals) [Fecher/Leucker/Wolf] [Huth]

[0.5,1] [0,0.5] A B D C 0.5 2/3 1/3 0.25 0.25

Abstraction

• Abstraction for Markov chains

− abstract Markov chains for DTMCs can be seen as Markov decision processes (MDPs) − yields lower/upper bounds on quantitative properties − generalised to CTMDP abstraction of CTMCs
 [Katoen/Klink/Leucker/Wolf]


• Other approaches to abstraction for CTMCs

− Erlang-k interval processes [Katoen/Klink/Leucker/Wolf] − Poisson processes + prob. intervals; better lower bounds − sliding window abstraction [Henzinger/Mateescu/Wolf] − abstract different parts of state space for each time point

• Other approaches to analysing infinite-state CTMCs

− e.g. truncation of model for time-bounded properties − INFAMY [Hahn/Hermanns/Wachter/Zhang]

Abstraction refinement

• How to automatically construct suitable abstractions?

− one promising direction: abstraction refinement − inspired by counterexample-guided abstraction refinement (CEGAR) techniques for non-probabilistic model checking

• Has been adapted/extended to probabilistic models

− so far, mostly for Markov decision processes − RAPTURE [D’Argenio/Jeannet/Jensen/Larsen] − probabilistic CEGAR [Hermanns/Wachter/Zhang] − quantitative abstraction refinement [Kwiatkowska/Norman/Parker] − magnifying lens abstraction [de Alfaro/Roy] − MDP-based abstractions [Chadha/Viswanathan] − and more…

Quantitative abstraction refinement

• Challenges

− efficient refinement strategies/heuristics − how to adapt to CTMCs and time-bounded properties? − how to adapt to other types of abstractions for CTMCs?

[error<ε] Initial
 partition Bounds and strategies [error≥ε] model check abstract refine New
 partition Return bounds Abstraction Example results: Israeli/Jalfon self-stabilisation protocol

Approximate (statistical) model checking

• Approximate (statistical) probabilistic model checking

− discrete event (Monte Carlo) simulation + sampling

• Two distinct approaches…
• Estimation [Hérault et al.]

− approximate result for quantitative query such as P=? [ φ ] − plus a probabilistic guarantee regarding result precision − Prob( |pactual-pestimated| ≤ ɛ ) ≥ 1-δ − can also generate corresponding confidence intervals

• Hypothesis testing/acceptance sampling [Younes/Simmons]

− applied to boolean-valued queries such as P∼p [ φ ] − basic idea: stop sampling as soon as the result can be shown to be either true or false with high probability − sensitive to distance between bound p and actual answer − also extended to Bayesian approaches [Jha et al.]

Approximate (statistical) model checking

• Advantages

− much more scalable that conventional (numerical computation based) probabilistic model checking − (almost no scalability issues – no need to build model) − wider range of model types (anything that can be effectively simulated) and property types

• Disadvantages

− loss of precision: only approximate answers − lose ability to definitively establish causal relationships and identify best/worst-case scenarios − speed: possibly very high number of samples required to generate suitable accurate approximations − may be hard to estimate likelihood of rare events

Summary

• Probabilistic model checking

− automatic, exhaustive construction of probabilistic models − analysis of formally specified quantitative properties − efficient techniques and tools available, e.g. PRISM − applications: communication protocols, computer security, randomised algorithms, systems biology, …

• Challenges

− richer models: stochastic hybrid systems, game-based models − more expressive property specification languages − scalability and efficiency − efficient construction of “good” abstractions − how to exploit symmetries, high-level structure − combining simulation-based and numerical methods
