Is Coincidental Correctness Less Prevalent in Unit Testing? Wes Masri American University of Beirut Electrical and Computer Engineering Department Outline Definitions Weak CC vs. Strong CC Causes of Coincidental Correctness

slide-1
SLIDE 1

Is Coincidental Correctness Less Prevalent in Unit Testing?

Wes Masri

American University of Beirut

Electrical and Computer Engineering Department

slide-2
SLIDE 2

Outline

 Definitions – Weak CC vs. Strong CC  Causes of Coincidental Correctness  Prevalence of CC – previous study  Relation to Dependence Analysis  Impact on Coverage-based T

echniques – CBFL and TSR

 CC and Unit T

esting – Defects4J

 T

est Cases Breakdown – True Passing, Failing, Weak CC, Strong CC

 Propagation Analysis  Bug Classification

slide-3
SLIDE 3

Definitions (1)

Coincidental Correctness arises when the program produces the

correct output, while: 1) Reachability

  • - is met

The defect is executed 2) Infection

  • - is met

The program has transitioned into an infectious state 3) Propagation

  • - is not met

The infection has propagated to the output Weak CC Strong CC

2 definitions for a reason…

slide-4
SLIDE 4

Definitions (1I)

 CC might be perceived as a good thing!

 The program is working correctly… so why worry?

 Two Problems:

 Strong CC - results in overestimating the reliability of

programs: it hides defects that subsequently might surface following unrelated code modifications

 Weak CC & Strong CC - reduce the effectiveness of

coverage-based techniques

slide-5
SLIDE 5

Causes of Strong CC (1)

 Case when

The Infection fails to Propagate to the Output

 Consider x that takes on the values [1, 5], such that the program gets

infected when x = 4 s1 : y = x * 3;

  • There is a clear one-to-one mapping between the x values and y

values: {13, 26, 39, 4*12*, 515}

  • When x is infected, the corresponding y value, which is unique,

will successfully propagate the infection past s1

  • That is, the infection x=4 leads to the infection y=12.
slide-6
SLIDE 6

Causes of Strong CC (2)

s2 : if (x >= 3) { y = 1; } else { y = 0; }

 Here the mapping is {10, 20, 31, 4*1, 51}  There is no unique value of y that captures the infection  y=1 is not an infection since it also results from x=3 and x=5  The infection was nullified by the execution of s2  Constructs similar to s2 are pervasive  prevalence of strong CC

slide-7
SLIDE 7

Prevalence of CC

 From previous study:

 148 versions of ten Java programs (NanoXML and Siemens)  Test suite sizes ranged from 140 to 4130, with a total of 19,873

 Strong CC: 3,120 tests (15.7%)  Weak CC: 11,208 tests (56.4%)

 20 versions had more than 60% of their tests as strong CC  86 versions had more than 60% of their tests as weak CC.  One version had 99.3% of its tests as strong CC  Failure Checkers: mostly trivial… seeded bugs

slide-8
SLIDE 8

Strong CC and Dependence Analysis (1)

Forms of Dependence Analysis: Static Dynamic Strength-based

 Basic Assumption of Dynamic Dependence Analysis:

If two variables are connected by a sequence of dynamic data and/or control dependences, then information actually flows between them

 To empirically validate this assumption, we used an information theoretic

measure to answer the following questions:

 Does dynamic program dependence always imply information flow?  Is the Length of an Information Flow indicative of its Strength?  Which Dependences are Stronger? Data or Control?

slide-9
SLIDE 9

Strong CC and Dependence Analysis (II)

 Does dynamic program dependence always imply information flow?

In 90%+ of the cases, dynamic dependences did not channel any information!!! …Unexpected

0.01 0.1 1 10 100

0.0 0.6 1 .3 1 .9 2.6 3.2 3.8 4.5 5.1 5.8 6.4 Flow Strength (Entropy)

% Flows

Xerces JTidy Tomcat 3.0 Tomcat 3.2.1 Jigsaw NanoXML

slide-10
SLIDE 10

Strong CC and Dependence Analysis (III)

 Is the Length of an Information Flow indicative of its Strength?

Many long flows were strong Many short flows were weak …Unexpected

0.4 0.8 1.2 1.6 2

1 1 1 00 1 000 1 0000

Flow Length

Strength (Entropy)

Xerces NanoXML JTidy Tomcat 3.2.1 Jigsaw Tomcat 3.0

slide-11
SLIDE 11

Strong CC and Dependence Analysis (IV)

 Which Dependences are Stronger? Data or Control?

Flows due to data dependences alone are stronger, on average, than flows due to control dependences alone … rather expected…

5 10 15 20 25 30 35 40

Xerces Jtidy jigsaw Tomcat 3.0 Tomcat 3.2.1 NanoXM L

Entropy > 1.0

% Non-weak Flows Unrestricted flows DD-flows CD-flows

slide-12
SLIDE 12

Strong CC and Dependence Analysis (V)

In 90%+ of the cases, dynamic dependences did not channel any information!!!

Suggests that many infectious states might get cancelled and not propagate to the output, thus, leading to a potentially high rate of Strong CC

slide-13
SLIDE 13

Impact on Coverage-based Fault Localization

CC Underestimates the Suspiciousness of Faulty Program Elements

 Example: Tarantula suspiciousness metric

M(e) = F / (F + P)

e = faulty program element F = % of failing runs that executed e P = % of passing runs that executed e

Given n coincidentally correct tests, n should be taken out from P and added to F to arrive at : M’ (e) = F’ / (F’ + P’) It could be easily shown that M’ (e) ≥ M(e) That is, not accounting for CC would underestimate the suspiciousness of the faulty program element CC is a Safety reducing factor in CBFL

slide-14
SLIDE 14

Impact on T est Suite Reduction (I)

0% 10% 20% 30% 40% 50% 60% 70% 80% 90% 100% 50 100 150 200 250 300 350 400 % Defects # Tests BB BBE DUP ALL

JTidy, 1000 test cases, 5 defects, 24 failures 23 CC tests

slide-15
SLIDE 15

Impact on T est Suite Reduction (II)

0% 10% 20% 30% 40% 50% 60% 70% 80% 90% 100% 50 100 150 200 250 300 350 400 % Defects # Tests BB BBE DUP ALL

JTidy, 977 test cases, 5 defects, 24 failures 0 CC tests

slide-16
SLIDE 16

Impact on T est Suite Reduction (III)

0% 10% 20% 30% 40% 50% 60% 70% 80% 90% 100% 50 100 150 200 250 300 350 400 % Defects # Tests 0% 10% 20% 30% 40% 50% 60% 70% 80% 90% 100% 50 100 150 200 250 300 350 400 % Defects # Tests

slide-17
SLIDE 17

20% 30% 40% 50% 60% 70% 80% 90% 100% 50 100 150 200 250 300 350 400 % Defects # Tests BB BBE DUP ALL

Math, 1857 test cases, 5 defects, 42 failures 57 CC tests Impact on T est Suite Reduction (IV)

slide-18
SLIDE 18

Math, 1800 test cases, 5 defects, 42 failures 0 CC tests

20% 30% 40% 50% 60% 70% 80% 90% 100% 50 100 150 200 250 300 350 400 % Defects # Tests BB BBE DUP ALL

Impact on T est Suite Reduction (V)

slide-19
SLIDE 19

Impact on T est Suite Reduction (VI)

20% 30% 40% 50% 60% 70% 80% 90% 100% 50 100 150 200 250 300 3 % Defects # Tests 20% 30% 40% 50% 60% 70% 80% 90% 100% 50 100 150 200 250 300 350 400 % Defects # Tests

slide-20
SLIDE 20

Defects4J

 De facto benchmark in program repair research and other  Consists of 395 real bugs distributed over 6 libraries

Library Number of bugs Closure compiler 133 Apache Commons Math 106 Apache Commons Lang 65 Mockito 38 JodaTime 27 JFreeChart 26 Targeted in this presentation

Source: https://github.com/rjust/defects4j [] René Just, Darioush Jalali, Michael D. Ernst. Defects4J: a database of existing faults to enable controlled testing studies for Java programs. ISSTA 2014: 437-440.

slide-21
SLIDE 21

Identifying CC T ests within Defects4J: Why?

 CC is a confounding factor

 When evaluating new techniques, researchers using

Defects4J will be able to factor out the impact of Coincidental Correctness (by discarding CC tests or treating them as failing)

 Determining whether CC is as prevalent at the unit

testing level (than at higher levels of testing)

 If less prevalent  An argument for conducting CBFL and other coverage-based

techniques at the unit testing level

 An additional argument in favor of Test-Driven Development

slide-22
SLIDE 22

Lang Library

 Provides helper utilities for the java.lang API

 String manipulation methods  Basic numerical methods  Object reflection  Concurrency  …

 Number of defects: 65

Source: https://commons.apache.org/proper/commons-lang/

slide-23
SLIDE 23

Commons Math Library

 Provides mathematical and statistical components:

 Complex numbers  Matrices  …

 Number of defects: 106

Source: http://commons.apache.org/proper/commons-math/

slide-24
SLIDE 24

How to identify the CCs in Defect4J

Consult issue tracking system Add failure checkers (oracles) to the buggy version to detect Reachability and Infection Inspect difference between buggy and fixed version

Repeat 395 times!

slide-25
SLIDE 25

Buggy Version with oracles:

...else { subtract(tmp1, 0, x, xOffset, tmp2, 0); divide(y, yOffset, tmp2, 0, tmp1, 0); atan(tmp1, 0, tmp2, 0); result[resultOffset] = ((tmp2[0] <= 0) ? -FastMath.PI : FastMath.PI) - 2 * tmp2[0]; for (int i = 1; i < tmp2.length; ++i) { result[resultOffset + i] = -2 * tmp2[i]; } System.out.println("\nWeak Oracle 10"); if (result[resultOffset] != FastMath.atan2(y[yOffset], x[xOffset])) { System.out.println("\nStrong Oracle 10"); } } }

Buggy Version:

...else { subtract(tmp1, 0, x, xOffset, tmp2, 0); divide(y, yOffset, tmp2, 0, tmp1, 0); atan(tmp1, 0, tmp2, 0); result[resultOffset] = ((tmp2[0] <= 0) ? -FastMath.PI : FastMath.PI) - 2 * tmp2[0]; for (int i = 1; i < tmp2.length; ++i) { result[resultOffset + i] = -2 * tmp2[i]; } }

Augmenting buggy versions with oracles to identify CCs (trivial)

Fixed Version:

...else { subtract(tmp1, 0, x, xOffset, tmp2, 0); divide(y, yOffset, tmp2, 0, tmp1, 0); atan(tmp1, 0, tmp2, 0); result[resultOffset] = ((tmp2[0] <= 0) ? -FastMath.PI : FastMath.PI) - 2 * tmp2[0]; for (int i = 1; i < tmp2.length; ++i) { result[resultOffset + i] = -2 * tmp2[i]; } result[resultOffset] = FastMath.atan2(y[yOffset], x[xOffset]); } }

Math library, bug #10: DSCompiler.java

slide-26
SLIDE 26

Buggy Version with oracles:

if (str == null || searchStr == null) { return false; } boolean result = contains(str.toUpperCase(), searchStr.toUpperCase()); System.out.println("\nWeak Oracle 40"); boolean fixedResult = false; int len = searchStr.length(); int max = str.length() - len; for (int i = 0; i <= max; i++) { if (str.regionMatches(true, i, searchStr, 0, len)) { fixedResult = true; break; } } if (result != fixedResult) { System.out.println("\nStrong Oracle 40"); } return result;

Augmenting buggy versions with oracles to identify CCs (non-trivial)

Fixed Version:

if (str == null || searchStr == null) { return false; } int len = searchStr.length(); int max = str.length() - len; for (int i = 0; i <= max; i++) { if (str.regionMatches(true, i, searchStr, 0, len)) { return true; } } return false;

Lang library, bug #40: StringUtils.java Buggy Version:

if (str == null || searchStr == null) { return false; } boolean result = contains(str.toUpperCase(), searchStr.toUpperCase()); return result;

slide-27
SLIDE 27

T est Cases Breakdown

Lang analysis includes version 34 to 65 only 156 45 70 2018 500 1000 1500 2000 2500 Lang*

Weak CC Strong CC Failing True Passing

344 166 50 100 150 200 250 300 350 400 Math

Missing Weak CC Missing True Passing |Strong CC| > |Failing| |Strong CC| ~ |Failing| |Weak CC| > |Failing| 5449 tests 2289 tests

slide-28
SLIDE 28

CC propagation analysis

 Following metrics gathered from the moment the oracle

is reached (i.e., infection happens) till the test exits to get a sense of the propagation:

 Statements executed  Conditionals executed  Method calls executed  Modulo operation executed  Multiply operation executed  Divide operation executed

slide-29
SLIDE 29

Lang Library CC analysis: Statements executed

slide-30
SLIDE 30

Lang Library CC analysis: Conditional branches executed

slide-31
SLIDE 31

Lang Library CC analysis: Modulo

  • perations executed
slide-32
SLIDE 32

Lang Library CC analysis: Multiplication

  • perations executed
slide-33
SLIDE 33

Lang Library CC analysis: Division

  • perations executed
slide-34
SLIDE 34

Lang Library CC analysis: method calls

slide-35
SLIDE 35

Math Library CC analysis: Statements executed

Note: some outliers have been omitted from the bottom graph for visualization purposes

(x103)

slide-36
SLIDE 36

Math Library CC analysis: Conditional branches executed

Note: some outliers have been omitted from the bottom graph for visualization purposes

slide-37
SLIDE 37

Math Library CC analysis: Multiplication operations executed

Note: some outliers have been omitted from the bottom graph for visualization purposes

slide-38
SLIDE 38

Math Library CC analysis: Division

  • perations executed

Note: some outliers have been omitted from the bottom graph for visualization purposes

slide-39
SLIDE 39

Math Library CC analysis: method calls

Note: some outliers have been omitted from the bottom graph for visualization purposes

slide-40
SLIDE 40

Bug Classification

9% 34% 0% 46% 9% 3% 0% 0% 4% 31% 2% 43% 2% 7% 9% 1% 0% 5% 10% 15% 20% 25% 30% 35% 40% 45% 50% Cast/Reflection Corner case Heap space

  • ut of memory

Logic Null pointer Overflow Precision Constant error

Bug categories per library (% of total bugs in library)

Lang* Math Lang analysis includes bugs 34 to 65 only

slide-41
SLIDE 41

Logic Error Example (40%+)

double sumWts = 0; // Added Oracles double oracleSumWts = 0; for (int i = 0; i < weights.length; i++) { sumWts += weights[i]; if (i >= begin && i < (begin+length)) {

  • racleSumWts += weights[i];

} } System.out.println("\nWeak Oracle 41"); if (Double.compare(sumWts, oracleSumWts) != 0) { System.out.println("\nStrong Oracle 41"); } double sumWts = 0; // Buggy for (int i = 0; i < weights.length; i++) { sumWts += weights[i]; } double sumWts = 0; // Fixed for (int i = begin; i < begin + length; i++) { sumWts += weights[i]; }

slide-42
SLIDE 42

Corner Case Error Example (30%+)

double foo(double[] a, double[] b) { // Added Oracles final int len = a.length; System.out.println("\nWeak Oracle 3"); if (len == 1) { System.out.println("\nStrong Oracle 3"); } final double[] prodHigh = new double[len]; double foo(double[] a, double[] b) { // Buggy final int len = a.length; final double[] prodHigh = new double[len]; double foo(double[] a, double[] b) { // Fixed final int len = a.length; if (len == 1) { // Revert to scalar multiplication. return a[0] * b[0]; } final double[] prodHigh = new double[len];

slide-43
SLIDE 43

Null Pointer Check Example (10%+)

for (int i = 0; i < sList.length; i++) { // Added Oracles System.out.println("\nWeak Oracle 39"); if (sList[i] == null || rList[i] == null) { System.out.println("\nStrong Oracle 39"); } greater = rList[i].length() - sList[i].length(); … } for (int i = 0; i < sList.length; i++) { // Buggy greater = rList[i].length() - sList[i].length(); … } for (int i = 0; i < sList.length; i++) { // Fixed if (sList[i] == null || rList[i] == null) { continue; } greater = rList[i].length() - sList[i].length(); … }

slide-44
SLIDE 44

Is Coincidental Correctness Less Prevalent in Unit Testing?

Prevalent? YES Less Prevalent than in other Higher Levels of T esting? Don’t Know Yet
