Precision Measurements with Polyatomic Molecules Nick Hutzler Caltech Internal Fields Thanks Naftali, Alexander for EDM introduction and motivation! Atoms/molecules have extremely large fields Relativistic ~Z 2-3 enhancement
▪ Relativistic ~Z2-3 enhancement ▪ Up to 106 enhancement over lab fields
2
|↓ |↑
▪ Problem – constituents experiences zero average field!
▪ Atom/molecule states always have this symmetry in free space
▪ Solution: polarize
▪ Apply lab field to orient atom/molecule ▪ Interaction no longer averages to zero ▪ Sensitivity polarization P
▪ Requires mixing opposite parity states, ε > d/Δ
3
▪ Atoms
▪ ~ 100 THz (electronic) ▪ P ~ 10-3 @ 100 kV/cm
▪ Molecules
▪ ~ 10 GHz (rotational) ▪ P ~ O(1) @ 10 kV/cm
▪ “Molecules are 1000x more sensitive” ▪ Some molecules have parity doublets, <10 MHz
▪ Enables full polarization in small fields… and more!
4
Atoms ~ 100 THz Molecules ~ 10 GHz
J
Parity Doubling ~ 10 MHz
J+ J–
▪ Harvard, Yale, Northwestern ▪ Molecular beam spin precession in ThO ▪ Current best limit on the electron EDM
▪ |de| < 1.1 x 10-29 e cm ▪ Statistics limited ▪ ~100x eEDM improvement in past since 2006 National Academies report!
▪ Already probing the TeV scale – beyond the LHC
▪ ~3-30 TeV for 1 or 2 loop couplings to new CPV physics
▪ Molecules are worth it!
▪ Not just more sensitive, but more robust
ACME Collaboration, Nature 562, 355 (2018) www.electronedm.info
5
= 0 Time E B Time
E B
H = − dE − B
+ = B + dE - = B − dE
6
= 0 Time E B Time
E B
H = − dE − B
+ = B + dE + ??? - = B − dE +???
7
dE / B < 10-6
▪ Parity doublets enable full polarization and “internal comagnetometer states”
▪ A.k.a. “spectroscopic reversal”
▪ Huge advantages!
▪ Smaller fields ▪ EDM sensitivity saturated, independent of field ▪ Measure without field reversals ▪ Systematics amplified in other channels ▪ Enables ion trap measurements (JILA method)
▪ Just as important as sensitivity increase (in my opinion)
8
▪ Polarization requires ~1,000x smaller fields
▪ Simpler engineering, enhanced quality of life ▪ Directly suppresses geometric phases, motional fields, leakage currents, etc.
▪ (These are serious! n, Tl, …)
▪ Also suppresses many systematics for optically trapped species
▪ Polarization can be saturated
▪ EDM no longer depends on E field, most systematics would
9
▪ Perform measurement in two “flipped” molecular states ▪ Cancels field-related systematics with high fidelity
▪ Systematics amplified in field flipped channel
10
▪ Error ~ 10-27 e cm/mG
▪ Proof of systematic error suppression ▪ Resource for hunting systematics
11
EDM Asymmetry EDM Asymmetry
With molecule flip Without molecule flip
▪ JILA needs spectroscopic reversal since can’t flip E field in an ion trap ▪ Both ACME and JILA rely on them for systematic robustness
12
▪ Don’t exist in atoms (in the sense that I mean…) ▪ In diatomics, we have Λ (or Ω) doubling
▪ Projections of Lelec along internuclear axis are nearly degenerate ▪ Split by Coriolis-type interactions with rotation ▪ Similar in nuclei!
▪ Requires electronic orbital angular momentum
▪ Rules out lots of interesting species!
13
J
+ –
Rotation Lelec +𝚳 −𝚳
▪ Polyatomic molecules generically have parity doublets
▪ Effectively independent of electronic structure, atom choice ▪ Comparable complexity to diatomics (discussed here…)
▪ Only way to access parity doublets for many exciting species
▪ Ba, Ra, Yb, Hg, Tl, …
▪ Generically opens up many
▪ Only way to combine CPV sensitivity, parity doublets, and ultracold techniques
14
▪ Example: linear triatomic
▪ MOH, MCCH, …
▪ Three mechanical modes ▪ Bending mode is doubly degenerate ▪ Eigenstates have orbital angular momentum ℓ ▪ Coupling of ℓ to rotation creates parity doublet
▪ Typically ~ 10 MHz ▪ Independent of electronic structure!
▪ Symmetric tops – rotations about symmetry axis
▪ Splittings even smaller ▪ MCH3, MOCH3, …
▪ Doesn’t interfere with laser cooling
15
ℓ ℓ
Symmetric stretch Asymmetric stretch
Bend
▪ 106 molecules ▪ 10 s coherence ▪ Large enhancement(s) ▪ Robust error rejection ▪ Efficient control/readout ▪ 1 week averaging
16
Mnew phys ~ 1,000 TeV (!) Beyond the reach of conceivable accelerators
Even before implementing truly advanced quantum techniques, such as squeezing, interaction engineering, …
Figure adapted from A. J. Daley, Nature 501, 497 (2013)
So… how to build this?
17
18
Many people are working on this, with many recent and exciting results! Precision measurements, quantum chemistry, many-body, information, …
▪ Forces, including dissipative, from photon scattering momentum kicks
19
Yb Atoms
▪ Requires many (~105) cycles
decay ▪ Decay to other states stops the cooling process ▪ Internal vibrational, rotational levels are excited in decay ▪ For carefully chosen molecules, this is manageable ▪ Most of the leaders and pioneers in this area are in the room!
20
Ground Excited Other
Decay
Ground Excited “Atoms” “Molecules” Rotation, vibration, …
Laser Excitation
▪ Requires many (~105) cycles
decay ▪ Decay to other states stops the cooling process ▪ Internal vibrational, rotational levels are excited in decay ▪ For carefully chosen molecules, this is manageable ▪ Laser cooled and trapped molecules now exist!
▪ SrF (DeMille, 2014) ▪ CaF (Tarbutt 2017, Doyle 2017) ▪ YO (Ye, 2018)
21
Ground Excited Other
Decay
Ground Excited “Atoms” “Molecules” Rotation, vibration, …
Laser Excitation
▪ Generally works for molecules with metal- centered s orbital(s)
▪ Alkaline-earth (s2) ▪ Single bond to halogen (F)
▪ Orbital hybridization pushes electron away from chemical bond
▪ Decouples electronic, molecular excitations
▪ Works for many bonding partners – polyatomics!*
▪ Laser cooling comes from metal centered electron ▪ Shown with SrOH (Doyle, 2017)
22
*T. A. Isaev and R. Berger, PRL 116, 63006 (2016), *I. Kozyryev, et al., ChemPhysChem 17, 3641 (2016)
▪ CPV sensitivity also comes from electronic structure
▪ Core-penetrating s electrons ▪ Several laser-coolable options, including at this workshop! ▪ BaF, HgF, RaF, TlF YbF, …
▪ Polyatomic analogues have similar sensitivity
▪ CPV comes from metal center ▪ Explicitly shown for BaOH, RaOH, RaOH+, ThOH+, TlCN, YbOH (so far)
▪ Why polyatomics?
▪ Access to parity doublets! ▪ MF → MOH, MOCH3, …
23
Core-penetrating
CPV sensitivity
▪ ThO, WC, TaN, HfF+, … ▪ “Requires” Lelec > 0 ▪ Interferes with laser cooling
▪ YbF, BaF, RaF, TlF, … ▪ “Requires” Lelec = 0 ▪ No internal comagnetometers ▪ Similar story for assembled molecules (HgLi, YbCs, …)
24
▪ ThO, WC, TaN, HfF+, … ▪ “Requires” Lelec > 0 ▪ Interferes with laser cooling
▪ YbF, BaF, RaF, TlF, … ▪ “Requires” Lelec = 0 ▪ No internal comagnetometers ▪ Similar story for assembled molecules (HgLi, YbCs, …)
25
▪ YbOH is ideal candidate ▪ Previously existing spectroscopy ▪ Laser coolable ▪ Several calculations of Eeff (including Bhanu Das)
▪ Eeff = 23.4 GV/cm
99, 042512 (2019)
▪ Broad sensitivity to new physics via multiple stable, abundant isotopes
▪ eEDM (174), NMQM (173), NSM (171), AM (171), …
26
Science state
▪ Me @ Caltech ▪ John Doyle @ Harvard ▪ Tim Steimle @ ASU ▪ Amar Vutha @ Toronto
27
MQMs violate P, T, CP
28
▪ Nucleon EDM ▪ quark EDM/chromo-EDM ▪ CPV nuclear forces ▪ Strong CPV (θQCD) ▪ …
▪ Collective enhancement ▪ ≈ β2Z
29
Rotating EDM produces MQM
173YbOH NMQM Experiment @ Caltech
▪ 173Yb (I=5/2), quadrupole deformed ▪ Recent calculation supports 173YbOH ≈ 173YbF
▪ arXiv:1906.11487
▪ Cryogenic buffer gas beam experiment ▪ Laser cooling, trapping in future generations?
30
▪ Best, new-ish technology for intense, cold, and slow molecular beams ▪ >100x more intense, >3x slower than supersonic beams (“jets”)
▪ Usually much more! ▪ Especially for reactive or refractory species ▪ Not a jet source
▪ Currently used by ACME, CeNTREX, all molecule laser cooling experiments
▪ Critical to all of these
▪ Works for just about anything, atoms, small molecules, large biological molecules, …
Buffer Gas Fill Line
Hot YbOH 4 K Copper Cell Pulsed Laser
Yb(OH)3
31
▪ Enhance chemical production of YbOH in buffer gas beam
▪ Ablate Yb+Yb(OH)3 ▪ Excite Yb 1S0 → 3P1, 556 nm ▪ Yb(3P1) reacts with ??? to create YbOH
▪ ~10x beam signal increase
▪ Typically ~1010-11 out of cell ▪ More in future? Plenty of unreacted Yb…
▪ Demonstrated for 173, 174 ▪ Also works for bending mode! ~109-10 bending molecules directly out of source ▪ Should work for lots of things, especially Ba and Ra!
32
▪ DF, LIF, MODR, etc.
173,174YbOH
33
▪ Branching ratios for laser cooling measured ▪ Efficient optical pumping pathway into bending mode
▪ Slow beams created from 2 K sources ▪ Photon cycling, radiative forces, 1 D cooling observed
34
▪ If bonding partner doesn’t matter, why not make it
▪ Enhanced optical forces ▪ “Quantum logic” type
▪ …
▪ Only theory so far, but approach seems promising ▪ Molecules Functionalized with Optical Cycling Centers (MFOCCs)
▪ Wes Campbell, Anastassia Alexandrova, Justin Caram, John Doyle, Eric Hudson, NRH, Anna Krylov
35
Yb−C≡C−Ca Behaves like two cycling centers
PRA 100, 022502 (2019)
▪ Especially atoms in the middle of orbital filling ▪ Many interesting species! ▪ Cycling center could offer cooling, control, readout
36
37
38
Summary: Polyatomic molecules offer a unique way to combine molecular enhancement with experimental robustness from parity doublets in a way that is independent of specific atomic properties. We can therefore realize these with laser- coolable species, exotic species, and more. Thanks for your attention! Special thanks for the invitation Come visit us! www.hutzlerlab.com www.polyedm.com
