SLIDE 1

Pooling fidelity and phase recovery Joan Bruna, Arthur Szlam, and Yann LeCun

SLIDE 2

Neural networks:

(Simplest version) functions of the form

Lk ◦ Lk−1 ◦ ... ◦ L0,

each Lj is of the form

Lj(xj−1) = h(Ajxj − bj),

Aj is a matrix and bj is a vector
h is an elementwise nonlinearity.
Aj optimized for a given task, usually via gradient descent.

SLIDE 3

Convolutional neural networks:

The input xj has a grid structure, and Aj specializes to a convolution.
The pointwise nonlinearity is followed by a pooling operator.
Pooling introduces invariance (on the grid) at the cost of lower res-
lution (on the grid).

SLIDE 4

Pooling in neural networks:

Usually block lp:

[P(z)]i =

p

|zi1|p + |zi2|p + ... + |zis|p = ||zIi||p
In words: the ith coordinate of the output is the lp norm of the ith

block of z.

In convolutional nets, blocks of indices are usually small spatial blocks,
p is either 1, 2, or most usually, ∞.

SLIDE 5

Examples/History:

Hubel & Wiesel 1962

– neuroscientists’ description of lower level mammalian vision

Fukushima 1971: Neocognitron

– An artificial version. – Filters hand designed in first versions, later used Hebbian learning. – Each layer has the same architecture

SLIDE 6

LeCun 1988, many others: Convolutional nets

– Filters trained discriminatively (original versions), and for recon- struction and discrimination, (2005+). – Training end to end via backpropagation (the chain rule) and stochastic gradient descent. – currently state of the art in object recognition, localization, and detection in images, and in various speech recognition, localiza- tion, and detection tasks. – mathematically poorly understood. (not controversial) – poorly understood. (controversial)

SLIDE 7

some wild speculation:

sparse coding
piecewise linear maps
pooling is key! (sparsify/decorrelate then contract).
output of network should be invariant to things we don’t care about,

but sensitive to things we care about.

SLIDE 8

Have results of Mallat and co-authors:

Convnet with l2 pooling, specially chosen filters, and some other

modifications, is provably invariant to deformations while preserving signal energy.

what about sensitivity to things we care about?

SLIDE 9

The phase recovery problem:

Classical version: goal is to find a signal z ∈ Cd given the absolute

value of the (discrete) Fourier transform |F(z)|

With no additional information, this is not possible:
1. each coefficient can be rotated independently.
2. even if z is real, absolute value of Fourier is translation invariant.
3. In a strong sense, the majority of the information in signals we

know and love is in the Fourier phase, not the magnitude:

SLIDE 10

cow duck

SLIDE 11

phase of duck, abs of cow phase of cow, abs of duck

SLIDE 12

Much simpler: consider a real dictionary; “phase” is the signs of the

analysis coefficients.

If dictionary is orthogonal, can flip the sign of an inner product at

will.

If dictionary is overcomplete, interactions force rigidity:

SLIDE 13

Proposition 1 (Balan et al 2006,2013). Let F = (f1, . . . , fm) with fi ∈ Rn and set d(x, x′) = min(x − x′, x + x′), and λ−(G) and λ+(G) to be the lower and upper frame bounds of a set of vectors G. The mapping M(x) = {|x, fi|}i≤m satisfies ∀ x, x′ ∈ Rn , A d(x, x′) ≤ M(x) − M(x′) ≤ B d(x, x′) , (1) where A = min

S⊂{1...m}

λ2

−(FS) + λ2 −(FSc) ,

(2) B = λ+(F) . (3) In particular, M is injective if and only if for any subset S ⊆ {1, . . . , m}, either FS or FSc is an invertible frame.

SLIDE 14

Proof of “in particular” (assuming F is spanning):

Suppose for any subset S ⊆ {1, . . . , m}, either FS or FSc is spanning.

Fix x, x′ ∈ Rn with |fT

i x| = |fT i x′| for all i, and let S be the set

S = {i : sign(fT

i x) = sign(fT i x′)}.

If FS is spanning, x = x′; else x = −x′.

Suppose not; let S be the offending set of indices. Pick x = 0 such

that F T

S x = 0, and x′ = 0 such that F T Scx′ = 0. Then x + x′ and x − x′

have the same modulus.

SLIDE 15

An example for the l2 subspace case:

consider

F =

  

1 1/ √ 2 1/ √ 2 1/ √ 2 1 1/ √ 2 1 −1/ √ 2 1/ √ 2

  

with groups I1 = {1, 2}, I2 = {3, 4}, and I3 = {5, 6}

Is l2 pooling invertible here?

SLIDE 16

An example for the l2 subspace case:

consider

F =

  

1 1/ √ 2 1/ √ 2 1/ √ 2 1 1/ √ 2 1 −1/ √ 2 1/ √ 2

  

with groups I1 = {1, 2}, I2 = {3, 4}, and I3 = {5, 6}

Is l2 pooling invertible here?
no.

SLIDE 17

Proposition 2 (Cassaza et al 2013, BLS 2013). The ℓ2 pooling operator P2 satisfies ∀ x, x′; , A2d(x, x′) ≤ P2(x) − P2(x′) ≤ B2d(x, x′) , (4) where A2 = min

G∈Q2

min

S⊂{1...m}

λ2

−(GS) + λ2 −(GSc) ,

B2 = λ+(F) (5) In particular, P2 is injective (up to a global sign) if and only if for any subset S ⊆ {1, . . . , m}, either GS or GSc is an invertible frame for all G ∈ Q2. Here Q2 is the set of all block orthogonal transforms applied to F.

SLIDE 18

Proof of “in particular” (assuming F is spanning):

Suppose for any subset S ⊆ {1, . . . , m}, either GS or GSc is spanning

for every G ∈ Q2. – Fix x, x′ ∈ Rn with P2(x) = P2(x′). – Choose o.n. bases Gk for the subspace spanned by Fk so that the coordinates u = GT

k x and u′ = GT k x′ satisfy

∗ u′

i = ui = 0 for i ∈ {3, ..., d}

∗ u1 = u′

1 and |u2| = |u′ 2|

Now use the previous argument.

Suppose not; rotate into bad coordinates, use previous method. P2

is invariant to block rotations.

SLIDE 19

Corollary 3 (less than a week old). IF K > 2n and F has the property that any n columns are spanning, P2 is invertible (in particular, for random block orthogonal F with K > 2n).

SLIDE 20

Half rectification:

Let Ω = Ω(F, α) be the set of subsets S of {1, ..., m} such that some

x have fT

i x > α for i ∈ S and fT i x ≤ α for i ∈ Sc.

Proposition 4. Let A0 = minS∈Ω λ−(FS

VS). Then the half-rectification
perator Mα(x) = ρα(F T x) is injective if and only if A0 > 0. Moreover,

it satisfies ∀ x, x′ , A0x − x′ ≤ Mα(x) − Mα(x′) ≤ B0x − x′ , (6) with B0 = maxS∈Ω λ+(FS) ≤ λ+(F).

SLIDE 21

Corollary 5. Let d = 2. Then the rectified ℓ2 pooling operator R2 satisfies ∀ x, x′; , ˜ A2d(x, x′) ≤ R2(x) − R2(x′) ≤ B2d(x, x′) , (7) where ˜ Ap = inf

x,x′

min

F ′∈ Qp,x,x′

min

S⊂Sx∩Sx′

λ2

−(FSx∪Sx′\(Sx∩Sx′)) +

λ2

−(F ′ S) + λ2 −(F ′ Sc)

1/2

,

SLIDE 22

for l1, l∞: need to replace Q.
statements somewhat messier, not tight.
for random (block orthonormal) frames with K > 4n, invertibility with

probability 1.

SLIDE 23

Will now discuss some experiments. But first, need algorithms for phase recovery:

alternating minimization
phaselift [Candes et al] and phasecut [Walsdspurger et al]

SLIDE 24

As above, denote the frame {f1, ..., fm} = F and set F (−1) to be the

pseudoinverse of F;

let Fk be the frame vectors in the kth block, with Ik to be the indices
f the kth block.
Starting with an initial signal x0, update
1. y(n)

Ik

= (Pp(x))k

Fkx(n) ||Fkx(n)||p, k = 1 . . . K,

2. x(n+1) = F (−1)y(n).

SLIDE 25

alternating minimization
phaselift [Candes et al] and phasecut [Walsdspurger et al]

SLIDE 26

phaselift and phasecut both use the lifting trick of [Balan et al]:

consider matrix variable corresponding to xx∗.

absolute value constraints are linear when lifted.
many more variables
ugly nonconvex rank 1 constraint. phaselift and phase cut are differ-

ent relaxations of the lifted problem.

SLIDE 27

alternating minimization is not, as far as we know, guarantee to

converge to the correct solution, even when Pp is invertible.

phasecut and phaselift are gauranteed with high probability for the

(classical) phase recovery problem if have enough (random!) mea- surements.

In practice, if the inversion is easy enough, or if x0 is close to the

true solution, alternating minimization can work well. Moreover,

alternating minimization can be run essentially unchanged for each

ℓp; for half rectification, we only use the nonegative entries in y for reconstruction.

SLIDE 28

We would like to use the same basic algorithm for all settings to get

an idea of the relative difficulty of the recovery problem for different p,

but if our algorithm simply returns poor results in each case, differ-

ences between the case might be masked.

The alternating minimization can be very effective when well initial-

ized.

SLIDE 29

When given a training set of the data to recover, we use a simple

regression to find x0.

Fix a number of neighbors q (in the experiments below we use q = 10,

and suppose X is the training set).

Set G = Pp(X), and for a new point x to recover from Pp(x), find the

q nearest neighbors in G of Pp(x), and take their principal component to serve as x0 in the alternating minimization algorithm.

SLIDE 30

random data, random dictionary
phasecut+alternating minimization vs alternating minimization vs rec-

tified alternating minimization

50 100 150 200 250 300 350 400 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1 Number of samples vs reconstruction accuracy Number of samples mean

|rT x|2 ||r||2||x||2

phaselift+am linear am relu am

SLIDE 31

structured data with training samples, random dictionary
phasecut+am vs. phasecut vs. nn-regress am vs. am

50 100 150 200 250 300 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1 Number of samples vs reconstruction accuracy Number of samples mean

|rT x|2 ||r||2||x||2

phasecut phasecut+am am + nn init am 50 100 150 200 250 300 350 400 450 500 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1 Number of samples vs reconstruction accuracy Number of samples mean

|rT x|2 ||r||2||x||2

phasecut phasecut+am am + nn init am

MNIST PATCHES

SLIDE 32

alternating minimization with good intialization gives great results!
see also [Yang et al 2013] on phaselift with a sparse prior.
but this is trivial and much faster.

SLIDE 33

20 40 60 80 100 120 140 160 180 200 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1 Number of samples vs reconstruction accuracy Number of samples mean

|rT x|2 ||r||2||x||2

linear relu 20 40 60 80 100 120 140 160 180 200 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1 Number of samples vs reconstruction accuracy Number of samples mean

|rT x|2 ||r||2||x||2

20 40 60 80 100 120 140 160 180 200 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1 Number of samples vs reconstruction accuracy Number of samples mean

|rT x|2 ||r||2||x||2

linear relu 50 100 150 200 250 300 350 400 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1 Number of samples vs reconstruction accuracy Number of samples mean

|rT x|2 ||r||2||x||2

linear relu 50 100 150 200 250 300 350 400 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1 Number of samples vs reconstruction accuracy Number of samples mean

|rT x|2 ||r||2||x||2

50 100 150 200 250 300 350 400 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1 Number of samples vs reconstruction accuracy Number of samples mean

|rT x|2 ||r||2||x||2

linear relu

SLIDE 34

50 100 150 200 250 300 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1 Number of samples vs reconstruction accuracy Number of samples mean

|rT x|2 ||r||2||x||2
