POOL OAK PARK AND RIVER FOREST HIGH SCHOOL PROGRAM VERIFICATION SEPTEMBER 15, 2015 Design Update September 24, 2015 4 24 EXECUTIVE SUMMARY PROGRAM BUILDING PROGRAM 26 LOWER LEVEL PLAN 27 6 GROUND LEVEL PLAN 28 STAKEHOLDERS UPPER

slide-1
SLIDE 1

SEPTEMBER 15, 2015

POOL

OAK PARK AND RIVER FOREST HIGH SCHOOL

PROGRAM VERIFICATION

Design Update September 24, 2015

slide-2
SLIDE 2 OAK PARK AND RIVER FOREST HIGH SCHOOL

POOL PROGRAM VERIFICATION

SEPTEMBER 15, 2015

3 4 18 6 24 30

OAK PARK AND RIVER FOREST HIG EXECUTIVE SUMMARY SITE ANALYSIS STAKEHOLDERS OPERATIONS | SECURITY 8 ADAPTIVE P .E. 9 PHYSICAL EDUCATION 10 ATHLETICS 11 TRANSPORTATION 12 TECHNOLOGY 13 TOPS | WEST SUBURBAN 14 STUDENT ATHLETES 15 PARK DISTRICT 16 PROGRAM BUILDING PROGRAM 26 LOWER LEVEL PLAN 27 GROUND LEVEL PLAN 28 UPPER LEVEL PLAN 29 DIAGRAMS POOL 32 POOL SUPPORT 34 P .E. LOCKER ROOMS 36 ATHLETIC LOCKER ROOMS 37 FAMILY CHANGING 38 ALUMNI ROOM | CONCESSIONS 39

40

POOL EQUIPMENT LIST
slide-3
SLIDE 3 OAK PARK AND RIVER FOREST HIGH SCHOOL

POOL PROGRAM VERIFICATION

SEPTEMBER 15, 2015

21

STADIUM STADIUM LAKE LAKE STREET STREET FIELDS FIELDS BALL FIELDS BALL FIELDS TENNIS COURTS TENNIS COURTS
slide-4
SLIDE 4

22

SITE ANALYSIS

R7 ZONING NORTH 45’ HEIGHT LIMITATION (55’ WITH ADDITIONAL SETBACK) 20’ FRONT YARD SETBACK 25’/20% REAR YARD SETBACK 10’ SIDE SETBACK 45% LOT COVERAGE (11) PARKING STALLS SCOVILLE AVENUE LAKE STREET PEDESTRIAN MALL ALLEY RIGHT TURN ONLY DROP OFF LANE RIGHT TURN ONLY GATE GATE BRIDGE ABOVE CHURCH STADIUM EXISTING BUILDING
slide-5
SLIDE 5 OAK PARK AND RIVER FOREST HIGH SCHOOL

POOL PROGRAM VERIFICATION

SEPTEMBER 15, 2015

23

The proposed aquatics center runs parallel with Lake Street with an east- west building orientation to optimize energy efficiency. The alley between the existing building and parking garage could remain to preserve the existing underground utilities and allow vehicular access between the existing building and the pool addition for buses, ambulances and other school support vehicles. A second floor pedestrian bridge could span over the service drive which would provide Student access to the new facility. This bridge would align with a new interior corridor to be constructed in the existing building between the East Pool/Weight Room and the South
  • Gym. Security gates would be installed at the east and west ends of the
alley to control access. At the east end of the site, a drop off lane could be created along the addition entrance. Scoville Avenue would provide
  • ne-way access travelling south and terminate with a right turn only on
Lake Street. At the west end of the site, (10) parking stalls and (1) ADA parking stall could be created to support the school’s passenger buses, vans and security vehicles. Parking stalls could be screened from Lake Avenue with the building or landscaping elements. The building could step from the south to the north to open up views of the east Church and west Stadium from Lake Street. Opportunities for views into the facility from Lake Street can be explored to allow the community to see the activity taking place inside the facility. PROPOSED LOCATION OF BRIDGE CONNECTION TO EXISTING BUILDING LOWER LEVEL UPPER LEVEL GROUND LEVEL
slide-6
SLIDE 6 OAK PARK AND RIVER FOREST HIGH SCHOOL

POOL PROGRAM VERIFICATION

SEPTEMBER 15, 2015

27

1 3 4 5 5 5 7 6 LAYOUT OF SPACES : 1 ELEVATOR, FREIGHT 2 ACCESS CORRIDOR 3 STAIRS 4 POOL FILTRATION ROOM 5 CHEMICAL STORAGE 6 SURGE TANK 7 MECHANICAL ROOM : BOILER/ ER ER/C /CHI HILL LLER ER N

LOWER LEVEL

DASHED LINE REPRESENTS EXTENT OF POOL DECK ABOVE 2
slide-7
SLIDE 7

28

1 2 3 4 5 6 7 8 9 3 4

PROGRAM

N

GROUND LEVEL

27 23 30 3 4 6 7 1 3 2 2 8 9 12 13 14 15 17 16 16 12 13 18 19 20 21 10 11 22 28 29 31 24 LAYOUT OF SPACES : 1 ELEVATOR, PASSENGER 2 ACCESS CORRIDOR 3 STAIRS 4 SCOREKEEPER 5 COACHES OFFICE 6 DRYLAND 7 FAMILY CHANGING/ALL GENDER 8 MAIN ENTRANCE LOBBY / SECURITY 9 TOWEL DISTRIBUTION ROOM 10 TOWEL STORAGE ROOM 11 LAUNDRY ROOM 12 ATHLETE TOILETS 13 P .E. TOILETS 14 CUSTODIAL ROOM 15 P .E. MENS LOCKER ROOM 16 P .E. SHOWERS 17 P .E. WOMENS LOCKER ROOM 18 ATHLETIC SHOWERS 19 ATHLETIC TOILETS 20 ATHLETICS MENS LOCKER ROOM 21 ATHLETICS WOMENS LOCKER ROOM 22 B & G STORAGE 23 ATHLETIC STORAGE 24 COMMUNITY STORAGE 25 COACHES MENS LOCKER ROOM 26 COACHES WOMENS LOCKER ROOM 27 FUTURE 3M DIVING BOARD 28 ELECTRICAL SERVICE ROOM 29 IDF | AV ROOM 30 ELEVATOR, FREIGHT 31 SCOREKEEPER STORAGE 32 DRYLAND STORAGE 33 COMPETITION STARTING BLOCKS 34 AQUATICS DIRECTOR 35 ATHLETE SEATING 36 ADA LIFT 37 TRANSFER WALL AND RAMPS 38 1M DIVING BOARD 39 THERAPY STAIR 40 CONNECTING BRIDGE ABOVE 35 1 2 5 36 36 37 25 26 34 18 19 24 24 32 33 38 38 14 40 39
slide-8
SLIDE 8 OAK PARK AND RIVER FOREST HIGH SCHOOL

POOL PROGRAM VERIFICATION

SEPTEMBER 15, 2015

29

N

UPPER LEVEL

10 3 4 9 2 1 3 5 7 8 11 14 9 LAYOUT OF SPACES : 1 ELEVATOR 2 ELEVATOR, FREIGHT 3 STAIR 4 SPECTATOR SEATING - PERMANENT TIERED 5 CONNECTING BRIDGE TO BUILDING 6 EDUCATIONAL ROOF GARDEN 7 CONCESSIONS 8 CONCESSIONS STORAGE 9 MECHANICAL ROOM : AHU 10 COOLING TOWER 11 ALUMNI ROOM 12 PUBLIC TOILETS 13 SPECTATOR SEATING - RETRACTABLE 14 ACCESS CORRIDOR 15 P .E. STORAGE 16 CUSTODIAL ROOM 6 12 13 15 16
slide-9
SLIDE 9

32

DIAGRAMS

POOL

COMPETITION | DIVING | WARMUP (9) 25 YARD COMPETITION LANES, WARM UP LANES, SHALLOW ADAPTIVE P .E. CAPACITY :
  • AREA OF WATER IS 12,755 SF
  • MAX OCCUPANTS = 255
  • POOL PERIMETER > 300 LF
, REQUIRES (2) ACCESSIBLE MEANS OF ENTRY MATERIALS:
  • HORIZONTAL SURFACES - 1X1 CERAMIC TILE
  • VERTICAL SURFACES - 1X1 CERAMIC TILE
  • HAND HOLD - CERAMIC TILE
  • WATERLINE - 1X1 CERAMIC TILE
  • LANE MARKERS - BLACK 1X1 CERAMIC TILE
  • WALL TARGETS - BLACK 2X2 CERAMIC TILE
  • DIVE TARGETS - BLACK 2X2 CERAMIC TILE
  • SAFETY LANE LINE - BLACK 2X2 CERAMIC TILE
  • BULKHEAD - STAINLESS STEEL OR FIBERGLASS
  • DIVING STANDS - ALUMINUM
CONSIDERATIONS:
  • MYRTHA POOL SYSTEM
  • LIGHTING - LED OR FLUORESCENT
  • LIGHTING - DIRECT OR INDIRECT
  • (9) LANES FOR COMPETITION
  • MOVABLE OR MOTORIZED BULKHEAD
  • (2) 1M DIVING BOARDS + STANDS
  • (1) 3M DIVING BOARD + STAND - FUTURE
  • STARTING BLOCK/TIMING SYSTEM CAPABILITIES AT BULKHEAD
  • ADA ACCESS - POOL LIFTS AND TRANSFER WALL
  • DIVING RIGGING SYSTEM
  • DIVING SPARGING SYSTEM
  • DIVING WATER AGITATION
  • AUDIO-VIDEO SYSTEM W/ POOL DECK AND SPECTATOR MONITORS
  • CAMERA AND DVR SYSTEM FOR DIVING AND SWIMMING
  • LED SCOREBOARD AT SOUTHWEST CORNER FACING SPECTATORS
  • OBSERVATION WINDOW AT FILTRATION ROOM
  • TIMER DISPLAYS INTEGRATED WITH BUILDING
  • UNDERWATER CAMERAS OR SPEAKERS
(21) 25 YARD PRACTICE CROSS LANES, SHALLOW ADAPTIVE P .E. P .E 1 1 STARTING BLOCKS STARTING BLOCKS 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 ADAPTIVE P.E. 1M 1M 1M 1M 3M FUTURE 2 3 4 5 6 7 8 9 6’ WIDE MOVABLE BULKHEAD 6’ WIDE MOVABLE BULKHEAD 75’ (25 YARD) 75’ (25 YARD) 1 2 3 4 17 18 19 20 21 75’ (25 YARD) ADAPTIVE P.E.
slide-10
SLIDE 10 OAK PARK AND RIVER FOREST HIGH SCHOOL

POOL PROGRAM VERIFICATION

SEPTEMBER 15, 2015

33

(12) 25 YARD PRACTICE CROSS LANES, (4) SHALLOW PRACTICE LANES (3) WATER POLO COURTS, SHALLOW ADAPTIVE PE COMMUNITY USE WATER POLO PRACTICE | ADAPTIVE P .E. 50M WATER POLO COMPETITION 1 STARTING BLOCKS 2 3 4 5 6 7 8 9 10 11 12 ADAPTIVE P.E. 1M 1M 1M 45’ 45’ 45’ 1M 1M 1M 1M 1M 82’ NFHSA 57’ NFHSA 6’ WIDE MOVABLE BULKHEAD 6’ WIDE MOVABLE BULKHEAD 6’ WIDE MOVABLE BULKHEAD 6’ WIDE MOVABLE BULKHEAD STARTING BLOCKS 164’-1/2” 1 2 3 4 1 2 3 4 5 6 7 8 9 (9) 50 METER LANES
slide-11
SLIDE 11

34

DIAGRAMS

POOL DECK

STARTING BLOCK GUTTER: STEP PARAPET PROVIDES A VISUAL REFERENCE POINT ABOVE THE WATER LEVEL. USED ON TURNING ENDS OF RACE COURSE. IDEAL FOR POOLS WITH BULKHEADS “FAST” BECAUSE OF OVERFLOW DESIGN. ACCOMMODATES ANY POOL SHAPE. DECK LEVEL DESIGN ALLOWS EASIER ACCESS. PROVIDES A VISUAL REFERENCE POINT ABOVE THE WATER LEVEL. IDEAL ALONGSIDE A PARAPET GUTTER OPTION A GUTTER: DECK LEVEL OPTION B GUTTER: ROLLOUT WITH HANDHOLD

POOL PROFILE GUTTER PROFILES

16’ 20’ 16’ 18’ 14’ 45’ 45’ 51’ 170’- 1/2” 24’ 5’ 3’-3” VERIFY W/ BULKHEAD DEPTH 4’ 8’ 14’
  • MIN. AREA FOR
14’ DIVING WELL 12’ 45’ 45’ 51’ 24’ CAPACITY :
  • AREA OF POOL DECK IS 8,867 SF
  • MAX 295 OCCUPANTS
MATERIALS:
  • FLOORS: 1X1 OR 2X2 CERAMIC TILE
  • EPOXY GROUT
  • TRENCH DRAINS: PLASTIC COVER OR STAINLESS STEEL
  • GUTTER: PLASTIC OR STAINLESS STEEL
CONSIDERATIONS:
  • 28”-30” WIDE PARAPET FOR STARTING BLOCKS
  • 14” WIDE PERIMETER GUTTER
  • LANE REEL STORAGE ON DECK BEHIND DIVING BOARDS
  • ADA ACCESS: POOL LIFTS AND TRANSFER WALL
  • THERAPY STAIR
10’ MIN

DRYLAND

MATERIALS:
  • WALLS: STRUCTURAL GLAZED FACING TILE OR GROUND FACE CMU
  • ACCENT WALLS: SOLID SURFACE
  • FLOORS: POURED EPOXY OR RUBBER SPORTS
  • CEILING: EXPOSED
  • DOOR FRAMES: FRP
, GALV . HM OR ALUMINUM
  • DOORS: FRP
, GALV HM OR ALUMINUM DRYLAND STORAGE CORRIDOR 6’ CONSIDERATIONS:
  • HORIZONTAL SLIDING GLASS WALL OR GLASS GARAGE DOOR
  • DIRECT ACCESS TO CORRIDOR, POOL DECK, STORAGE
slide-12
SLIDE 12 OAK PARK AND RIVER FOREST HIGH SCHOOL

POOL PROGRAM VERIFICATION

SEPTEMBER 15, 2015

35

ATHLETE SEATING SPECTATOR SEATING COACHES | SCOREKEEPER

12’ 6’ (4) 3-TIER ALUMINUM, DOUBLE FOOTBOARD BLEACHERS, EACH 21’ LONG W/ TILT ‘N ROLL KIT CAPACITY : 168 OCCUPANTS MATERIALS: ALUMINUM CONSIDERATIONS: DUAL USE AT DRYLAND COLORS OR GRAPHICS ADDITIONAL BENCH STORAGE CAPACITY : 450 OCCUPANTS MATERIALS: ALUMINUM OR PLASTIC CONSIDERATIONS: TIERED PERMANENT SEATING USE CLOSED RETRACTABLE SEATING AS DIVIDER OPERABLE GLASS PARTITION OR STRUCTURAL GLASS GUARD CANTILEVER NORTH DRYLAND OVER ALLEY SEPARATE FAN UNIT TO SERVE SPACE POOL DECK BELOW PERMANENT TIERED SEATING RETRACTABLE BLEACHERS TO PROVIDE ADDITIONAL DRYLAND TRAINING SPACE POOL BELOW POOL DECK POOL MATERIALS:
  • WALLS: STRUCTURAL GLAZED FACING TILE OR GROUND FACE CMU
  • ACCENT WALLS: SOLID SURFACE OR PORCELAIN TILE
  • FLOORS: POURED EPOXY
  • CEILING: 2X2 VINYL FACED SAT
, EXPOSED AT SCOREKEEPER
  • TOILET PARTITIONS: SOLID COLOR REINFORCED COMPOSITE
  • BENCHES: SOLID SURFACE
  • ADA BENCH: SOLID SURFACE
  • LOCKERS: SOLID PHENOLIC OR HDPE
  • DOOR FRAMES: FRP
, GALV . HM OR ALUMINUM
  • DOORS: FRP
, GALV HM OR ALUMINUM
  • CASEWORK: PLASTIC LAMINATE
  • COUNTERTOPS: SOLID SURFACE
  • OPERABLE WINDOW FOR SCOREKEEPER
POOL DECK MEN’S COACHES WOMEN’S COACHES SCOREKEEPER COACHES OFFICE AQUATICS OFFICE CORRIDOR P .E. STORAGE COOLING TOWER SCOREKEEPER STORAGE IDF/AV ELECTRICAL
slide-13
SLIDE 13

36

DIAGRAMS

P .E. LOCKER ROOMS

CONSIDERATIONS:
  • (68) 2-TIER 18X18X72 LOCKERS
  • PADLOCK HASP FOR LOCKS
  • (32) SHOWER HEADS
  • (4) WATER CLOSETS/URINALS AND (2) LAVS
  • (1) DRINKING FOUNTAIN W/ BOTTLE FILL STATION
  • MARKERBOARD OR TACKBOARD
  • SUIT SPINNERS, PROVIDE DRAIN
  • CASEWORK/SHELVING FOR TOWELS
  • WASHER/DRYER PROVIDED BY OWNER
  • (1) STAFF MEMBER TO DISTRIBUTE TOWELS/SUITS TO MEN AND WOMEN
  • TOILET ACCESSORIES BY OWNER
  • HAND/HAIR DRYERS
  • SHOWER CURTAINS OR PARTITIONS
  • CHANGING MIRROR
  • COMBINATION LAVS OR INDIVIDUAL LAVS
  • FLOOR DRAINS AT LOCKER ROOM
  • INDIVIDUAL SHOWER CONTROLS AND MASTER MIXING VALVE
  • ELECTRIC STRIKE/CARD READER ON DOORS
  • MENS LOCKER ROOM = 48 OCCUPANTS PER PE CLASS
  • WOMENS LOCKER ROOM = 48 OCCUPANTS PER PE CLASS
MATERIALS:
  • WALLS: STRUCTURAL GLAZED FACING TILE OR GROUND FACE CMU
  • ACCENT WALLS: SOLID SURFACE OR PORCELAIN TILE
  • WET WALLS: STRUCTURAL GLAZED FACING TILE
  • FLOORS: POURED EPOXY
  • CEILING: 2X2 VINYL FACED SAT
  • TOILET PARTITIONS: SOLID COLOR REINFORCED COMPOSITE
  • TRENCH DRAINS: STAINLESS STEEL
  • BENCHES: SOLID SURFACE
  • ADA BENCH: SOLID SURFACE
  • LOCKERS: SOLID PHENOLIC OR HDPE
  • DOOR FRAMES: FRP
, GALV . HM OR ALUMINUM
  • DOORS: FRP
, GALV HM OR ALUMINUM POOL DECK CORRIDOR SHOWERS DRYING WOMEN’S LOCKER ROOM SHOWERS MEN’S LOCKER ROOM DRYING CUSTODIAL LAUNDRY TOWEL STORAGE TOWELS TOILETS TOILETS TOILET TOILET TRANSFER WALL THERAPY STAIR
slide-14
SLIDE 14 OAK PARK AND RIVER FOREST HIGH SCHOOL

POOL PROGRAM VERIFICATION

SEPTEMBER 15, 2015

37

ATHLETIC LOCKER ROOMS

CAPACITY :
  • MENS LOCKER ROOM = 40 OCCUPANTS
  • WOMENS LOCKER ROOM = 40 OCCUPANTS
MATERIALS:
  • WALLS: STRUCTURAL GLAZED FACING TILE OR GROUND FACE CMU
  • ACCENT WALLS: SOLID SURFACE OR PORCELAIN TILE
  • WET WALLS: STRUCTURAL GLAZED FACING TILE
  • FLOORS: POURED EPOXY
  • CEILING: 2X2 VINYL FACED SAT
  • TOILET PARTITIONS: SOLID COLOR REINFORCED COMPOSITE
  • TRENCH DRAINS: STAINLESS STEEL
  • BENCHES: SOLID SURFACE
  • ADA BENCH: SOLID SURFACE
  • LOCKERS: SOLID PHENOLIC OR HDPE
  • DOOR FRAMES: FRP
, GALV . HM OR ALUMINUM
  • DOORS: FRP
, GALV HM OR ALUMINUM CONSIDERATIONS:
  • (21) 2-TIER 18X18X72 LOCKER
  • PADLOCK HASPS FOR LOCKS
  • (10) SHOWER HEADS
  • (2) WATER CLOSETS/URINALS AND (1) LAV
  • (1) DRINKING FOUNTAIN W/ BOTTLE FILL STATION
  • MARKERBOARD OR TACKBOARD
  • SUIT SPINNERS, PROVIDE DRAIN
  • TOILET ACCESSORIES BY OWNER
  • HAND/HAIR DRYERS
  • SHOWER CURTAINS OR PARTITIONS
  • CHANGING MIRROR
  • COMBINATION LAVS OR INDIVIDUAL LAVS
  • FLOOR DRAINS AT LOCKER ROOM
  • INDIVIDUAL SHOWER CONTROLS AND MASTER MIXING VALVE
  • ELECTRIC STRIKE/CARD READER ON DOORS
CORRIDOR SHOWERS DRYING WOMEN’S LOCKER ROOM SHOWERS DRYING MEN’S LOCKER ROOM POOL DECK TRANSFER WALL THERAPY STAIR
slide-15
SLIDE 15

38

DIAGRAMS

FAMILY CHANGING

CAPACITY :
  • FAMILY CHANGING A = 8 OCCUPANTS
  • FAMILY CHANGING B = 8 OCCUPANTS
MATERIALS:
  • WALLS: STRUCTURAL GLAZED FACING TILE OR GROUND FACE CMU
  • ACCENT WALLS: SOLID SURFACE OR PORCELAIN TILE
  • WET WALLS: STRUCTURAL GLAZED FACING TILE
  • FLOORS: POURED EPOXY
  • CEILING: 2X2 VINYL FACED SAT
  • BENCHES: SOLID SURFACE
  • ADA BENCH: SOLID SURFACE
  • LOCKERS: SOLID PHENOLIC OR HDPE
  • DOOR FRAMES: FRP
, GALV . HM OR ALUMINUM
  • DOORS: FRP
, GALV HM OR ALUMINUM CONSIDERATIONS:
  • (8) 5-TIER 12X12X12 LOCKERS
  • PADLOCK HASPS FOR LOCKS OR BUILT-IN LOCKS
  • SUIT SPINNERS - PROVIDE DRAIN
  • CASEWORK/SHELVING FOR TOWELS
  • TOILET ACCESSORIES BY OWNER
  • HAND/HAIR DRYERS
  • FLOOR DRAINS IN LOCKER AREA
  • CHANGING MIRROR
  • SHOWER CURTAIN OR SHOWER DOOR
  • CHANGING TABLES IN EACH STATION
FAMILY CHANGING A CORRIDOR FAMILY CHANGING B
slide-16
SLIDE 16 OAK PARK AND RIVER FOREST HIGH SCHOOL

POOL PROGRAM VERIFICATION

SEPTEMBER 15, 2015

39

ALUMNI ROOM | CONCESSIONS

CAPACITY :
  • ALUMNI ROOM = 49 OCCUPANTS
  • CONCESSIONS = 3 OCCUPANTS
  • MEN’S TOILET = ASSUME 270 OCCUPANTS
  • WOMENS TOILET = ASSUME 270 OCCUPANTS
ALUMNI ROOM MATERIALS:
  • WALLS: STRUCTURAL GLAZED FACING TILE OR GROUND FACE CMU, STOREFRONT
  • ACCENT WALLS: SOLID SURFACE OR PORCELAIN TILE
  • FLOORS: TERRAZZO TILE
  • CEILING: 2X4 SAT W/ CENTER SCORE
  • CASEWORK: PLASTIC LAMINATE
  • COUNTERTOPS: SOLID SURFACE
  • DOOR FRAMES: FRP
, GALV . HM OR ALUMINUM
  • DOORS: FRP
, GALV HM OR ALUMINUM CONSIDERATIONS:
  • ALUMNI ROOM: MARKERBOARD/TACKBOARD/SMART BOARD
  • ALUMNI ROOM: TV
, AV SYSTEM - TIE INTO POOL SYSTEM
  • ALUMNI ROOM: MOVABLE TABLES AND CHAIRS
  • CONCESSIONS: DETERMINE WHAT WILL BE SOLD
  • CONCESSIONS: APPLIANCES BY OWNER
  • TOILET ROOM: (5) WATER CLOSETS/URINALS AND (3) LAVS
  • TOILET ROOM: ACCESSORIES BY OWNER
  • (2) DRINKING FOUNTAINS W/ BOTTLE FILL STATION
  • PROVIDE ACCESS TO EDUCATIONAL GARDEN
  • GLASS PARTITION AT CORRIDORS
ALUMNI ROOM POOL BELOW MECHANICAL - AHU MENS TOILET WOMENS TOILET BRIDGE TO BUILDING CONCESSIONS
  • WALLS: PORCELAIN TILE
  • WET WALLS: PORCELAIN TILE
  • FLOORS: TERRAZZO TILE OR POURED EPOXY
  • CEILING: 2X2 VINYL FACED SAT
  • TOILET PARTITIONS: SOLID COLOR REINFORCED COMPOSITE
CONCESSIONS MATERIALS:
  • WALLS: STRUCTURAL GLAZED FACING TILE OR GROUND FACE CMU,
  • FLOORS: TERRAZZO TILE
  • CEILING: 2X2 VINYL FACED
  • CASEWORK: PLASTIC LAMINATE, WIRE SHELVING
  • COUNTERTOPS: SOLID SURFACE
  • DOOR FRAMES: FRP
, GALV . HM OR ALUMINUM
  • DOORS: FRP
, GALV HM OR ALUMINUM
  • OVHD COILING DOOR: STAINLESS STEEL
STORAGE CUSTODIAL 10’ MIN 16’ POOL DECK BELOW
slide-17
SLIDE 17

SEPTEMBER 15, 2015

POOL

OAK PARK AND RIVER FOREST HIGH SCHOOL

PROGRAM VERIFICATION

Design Update September 24, 2015 Critical Project Milestones 10.2015 Legat Architects to Proceed with Design 02.2016 Complete Schematic Design 05.2016 Complete Design Development 07.2016 Start Demolition of Parking Structure 09.2016 Complete Construction Documents 09.2016 O btain Village Permits and Approvals 09.2016 Begin Foundations and Site Work 11.2016 Begin Vertical Construction 08.2018 Grand O pening of New Aquatic Center

slide-18
SLIDE 18

SEPTEMBER 15, 2015

POOL

OAK PARK AND RIVER FOREST HIGH SCHOOL

PROGRAM VERIFICATION

Design Update September 24, 2015
