Polyglot data science the force awakens with F#, R and D3.js Evelina Gabasova @evelgab Tomas Petricek @tomaspetricek Part I F# with type providers fslab.org : Doing data science using F# The data science workflow Data access with type
SLIDE 2
SLIDE 3
: Doing data science using F# fslab.org
The data science workflow Data access with type providers Interactive analysis with .NET and R libraries Visualization with HTML/PDF charts and reports High-quality open-source libraries
SLIDE 4
LINQ before it was cool :-)
var res = StockData.MSFT .Where(stock => stock.Close stock.Open > 7.0) .Select(stock => stock.Date)
Looking under the cover
Extension methods take Func<T1, T2> delegates Immutable because it returns a new
IEnumerable
Functional design allows method chaining
SLIDE 5
LINQ before it was cool :-)
StockData.MSFT |> Array.filter (fun stock > stock.Close stock.Open > 7.0) |> Array.map (fun stock > stock.Date)
Looking under the cover
Pipeline operator for composing functions Lambda functions written using fun Immutable lists, sequences, arrays, etc.
SLIDE 6
Charting libraries for F#
- cross platform, HTML-based
(recommended)
- flexible but Windows-only library
Other options: and XPlot F# Charting FnuPlot R provider
For latest information
See
- the F# data science
homepage FsLab.org
SLIDE 7
Charting with XPlot
Draw sin for values from to :
2π
[| 0.0 .. 0.1 .. 6.3 |] |> Array.map (fun x > x, sin x) |> Chart.Line
Uses Google Charts behind the scenes:
0.0 1.5 3.0 4.5 6.0 1.0 0.5 0.0 0.5 1.0
SLIDE 8
What are type providers?
SLIDE 9
Type provider patterns
Providers for a specific data source
let wb = WorldBankData.GetDataContext() wb.Countries.India.Indicators.``Population, total``
Parameterized provider for a data format
type Rss = XmlProvider<"data/bbc.xml"> Rss.Load(url).Channel.Description
SLIDE 10
TASK: Star Wars movie prots
Star Wars rating and box office 18 94 1,980 1,990 2,000 2,010 2,020 600,000,000 1,200,000,000 1,800,000,000 2,400,000,000 Year Box office
SLIDE 11
github.com/evelinag/polyglot-data- science
SLIDE 12
Part II
Visualization with D3.js
SLIDE 13
The Star Wars social network
SLIDE 14
SLIDE 15
SLIDE 16
D3.js visualizations
made easier
Gallery of examples
SLIDE 17
D3.js social network visualization
Force-directed network layout
SLIDE 18
Part III
Analyzing social networks with R
SLIDE 19
Social network analysis
Who is the most central character? How to the movies compare between themselves?
SLIDE 20
The R language
"domain-specific" language for statistical analysis
SLIDE 21
Very quick R intro
# assignment x < 1 x = 1 # variable and function names x x.y read.csv
SLIDE 22
Very quick R intro: pipeline
|> turns into %>%
install.packages("magrittr") library(magrittr) xs < c(1,2,3,4,5,6,7,8,9,10) xs %>% mean
SLIDE 23
Network analysis with igraph
igraph website igraph documentation
install.packages("igraph") library(igraph)
SLIDE 24
Creating igraph network
library(igraph) g < graph(edges)
edges = list of nodes n1, n2, n3, n4, n5, ... represents (n1, n2), (n3, n4), ...
SLIDE 25
Calculating degree
d < degree(graph)
SLIDE 26
F#
- pen RProvider.igraph
let degree = R.degree(network)
SLIDE 27
F#
export JSON into list of edges
R
perform the network analysis
SLIDE 28
Degree
SLIDE 29
Degree
SLIDE 30
Degree
SLIDE 31
Degree
Degree(v) = Number of links v ↔ v′ v ≠ v′
SLIDE 32
Betweenness
SLIDE 33
Betweenness
SLIDE 34
Betweenness
SLIDE 35
Betweenness
SLIDE 36
Betweenness
SLIDE 37
Betweenness
= Number of shortest paths between a and b through v Sv S = Number of shortest paths between a and b Betweenness(v = )ab Sv S
SLIDE 38
Betweenness
= Number of shortest paths between a and b through v Sv S = Number of shortest paths between a and b Betweenness(v) = ∑
ab
Sv S
SLIDE 39
Network structure
How do the the movies differ? Size Density Clustering coefficient
SLIDE 40
Density
SLIDE 41
Density
SLIDE 42
Density
Density = Existing connections Potential connections = Existing connections N(N − 1)
1 2
SLIDE 43
Clustering coefcient
SLIDE 44
Clustering coefcient
SLIDE 45
Clustering coefcient
SLIDE 46
Clustering coefcient
SLIDE 47
Clustering coefcient
SLIDE 48
Clustering coefcient
SLIDE 49
Clustering coefcient
= Number of neighbours of v Kv = Number of links between neighbours of v Ev Clustering(v) = Ev ( − 1)
1 2 Kv Kv
SLIDE 50
Clustering coefcient
= Number of neighbours of v Kv = Number of links between neighbours of v Ev Clustering(network) = 1 N ∑
v
Ev ( − 1)
1 2 Kv Kv
SLIDE 51
Size
Number of characters 10 20 30 40 Episode 1 Episode 2 Episode 3 Episode 4 Episode 5 Episode 6 Episode 7 Number of characters
SLIDE 52
Density
Network density 15 20 25 30 35 Episode 1 Episode 2 Episode 3 Episode 4 Episode 5 Episode 6 Episode 7 Density (%)
SLIDE 53
Clustering coefficient
Clustering coefficient (transitivity) 0.40 0.48 0.56 0.64 0.72 Episode 1 Episode 2 Episode 3 Episode 4 Episode 5 Episode 6 Episode 7 Clustering coefficient
SLIDE 54
CONCLUSIONS
SLIDE 55
non-profit books and tutorials
cross-platform community data science
F# Software Foundation
commercial support open-source contributions machine learning web and cloud consulting user groups research
www.fsharp.org
SLIDE 56
The Learning Pyramid
SLIDE 57
Community chat and Q&A
#fsharp on Twitter StackOverow F# tag
Open source on GitHub
Visual F# repo F# Compiler and core libraries F# Incubation project space FsLab Organization repository github.com/Microsoft/visualfsharp github.com/fsharp github.com/fsprojects github.com/fslaborg
More resources
Scott Wlaschin's
SLIDE 58
Scott Wlaschin's fsharpforfunandprofit.com
F# Books and Resources
fsharp.org/about/learning.html
