UK-PI Meeting University of Manchester 6th March 2019

Plans for Production Sites

APA Production Plan

• Definition of institutional responsibilities for APA production components
• to be concluded by March
• UK starts APA production July 2020, site preparation underway
• In US
• Start preparing sites for APA wiring centers in 2019
• Tailor cost estimate in P6 to the individual APA wiring centers before

CD2/3 review (definition of personnel and associated costs)

• Winders production in 2020 (2 @ Yale, 2 @ Chicago with help from PSL)
• Start APA production Jan 2021
• Hold individual reviews of APA wiring centers ~June 2019 to assess

space layout, crane equipment, safety procedures, staffing plan (Preliminary Reviews)

• Hold individual Production Readiness Reviews

APA Production

Production of APAs for Detector #1

• US-APA production (76 APAs): Jan 4, 2021 – Dec 7, 2023
• UK-APA production (76 APAs): Jul 6, 2020 – Nov 6, 2023

APA Production/year

Production Site 2020 2021 2022 2023 Daresbury 6 24 26 20 Yale 10 13 7 Chicago 10 13 7 PSL 3 7 6 TOT 6 47 59 40

• Need to cold test 10% of APA production
• Need to investigate options for local storage if early shipping to SD is not possible

6/3/2019 UK-PI mtg - Alan Grant 4

Daresbury Laboratory DUNE Factory

• Inner hall site of the SRS accelerator identified

as factory location

• Purpose built factory room
• Factory to have 4 winding machines, 10

process carts

• Separate shipping area in renovated plant

room

• Dedicated swing arm pillar cranes for each

winding machine

6/3/2019 UK-PI mtg - Alan Grant 5

Daresbury Laboratory DUNE Factory Layout.

6/3/2019 UK-PI mtg - Alan Grant 6

Raw material taken in through this entrance (2D plan).

Access to high level from road.

High level area for shipping preparation. Low level area APA lifting zone. Fixed platform and swing jib crane for moving frames between areas.

Movement of Materials & APA’s

6/3/2019 UK-PI mtg - Alan Grant 7

APA frames loaded into process carts here. Entrance into preparation area. Pre Processing Area – Comb bases & mesh panel fitting

Pre Processing Area

6/3/2019 UK-PI mtg - Alan Grant 8

Small part assembly / general work area. comb base and mesh panel fitting. Small part / jig storage. Emergency Exit Prep area 210m^2 Access to Winding area

Pre Processing Area - cont

6/3/2019 UK-PI mtg - Alan Grant 9

Winder - 1 Winder - 2 Winder - 3 Winder - 4 Emergency Exit Parking for completed APA’s waiting for transfer to shipping area. Door position shown incorrectly Winder area 638m^2 Plenty of wall space for off line prep work

Factory Area Layout

6/3/2019 UK-PI mtg - Alan Grant 10

Lifting zone to platform. Fixed platform Overhead crane to cover this area. Post processing / packing & shipping

• area. 237m^2

Swing jib crane for loading / unloading trucks from the road. Packing crate (size

• f existing PSL

crate).

Packing & Shipping Area

Platform to shipping area Roof Beam supports

Plan View of Factory

6/3/2019 UK-PI mtg - Alan Grant 11

12 Production Factory Area Identified – 2016

Crane height approx 7.2m Available Area approx 22m x 37m central hall. Serviced by 15ton crane.

6/3/2019 UK-PI mtg - Alan Grant 12

Inner Hall 2016

6/3/2019 UK-PI mtg - Alan Grant 13

6/3/2019 UK-PI mtg - Alan Grant 14

Some funding released for DUNE Pre Construction

• Concrete e-Beam Bunker removal complete
• Removal radial and ancillary cranes complete
• Factory room materials ordered
• Cranes – 5 off ordered
• Shipping room refurbishment well advanced
• Quotations expected in coming weeks for
• Factory room assy of building
• Factory room services
• Platform to shipping room
• Floor renovation – factory and shipping area

Preparation Work

Inner Hall – Sept 2018

6/3/2019 UK-PI mtg - Alan Grant 15

6/3/2019 UK-PI mtg - Alan Grant 16

Shipping area being prepared

Exit door to road Entrance door from factory to shipping area

6/3/2019 UK-PI mtg - Alan Grant 17

Access to Road for Transport Vehicle

6/3/2019 UK-PI mtg - Alan Grant 18

Storage – Wall & Roof Panels

Delivery March

APA production site @ Yale’s Wright Laboratory

The Vault as it appears today

The Vault as it appears today

The APA Factory in the Vault

6/3/2019 UK-PI mtg - Alan Grant 35

Questions
