PhysX Vehicles 1 PhysX Collision and Dynamics SDK (now) owned by Nvidia Most common physics library used in games for this course Includes lots of vehicle specific features, which we strongly recommend using We used to allow

slide-1
SLIDE 1

PhysX Vehicles

1

slide-2
SLIDE 2

PhysX

  • Collision and Dynamics SDK (now) owned by Nvidia
  • Most common physics library used in games for this

course

  • Includes lots of vehicle specific features, which we

strongly recommend using

  • We used to allow rigid body physics libraries but

required building driving model from scratch

  • Getting a good driving model is by far the biggest

challenge for teams, and was often holding back game quality significantly

slide-3
SLIDE 3

Basics of PhysX Vehicle SDK

  • Essential tasks

– Set up library – Create some meshes – Allocate simulation data – Allocate actor and add to world – Per frame : Setup inputs to drive and steering – Per frame : Wheel raycasts – Per frame : Tick simulation

  • Caveat : I have not personally built anything with this
  • Sample code : PhysX-SDK/Sample/SampleVehicle
slide-4
SLIDE 4

Initialization

PxAllocatorCallback* allocator = &gDefaultAllocatorCallback; mFoundation = PxCreateFoundation(PX_PHYSICS_VERSION, *allocator, getSampleErrorCallback()); mPhysics = PxCreatePhysics(PX_PHYSICS_VERSION, *mFoundation, scale, recordMemoryAllocations, mProfileZoneManager);

  • PxPhysics

– Base context for all operations

slide-5
SLIDE 5

Initialization

PxCookingParams params(scale); params.meshWeldTolerance = 0.001f; params.meshPreprocessParams = PxMeshPreprocessingFlags(PxMeshPreprocessingFlag::eWELD_VERTICES | PxMeshPreprocessingFlag::eREMOVE_UNREFERENCED_VERTICES | PxMeshPreprocessingFlag::eREMOVE_DUPLICATED_TRIANGLES); mCooking = PxCreateCooking(PX_PHYSICS_VERSION, *mFoundation, params);

  • PxCooking

– Utility class for creating meshes in physics – PhysX vehicles uses meshes for all objects in vehicle system

slide-6
SLIDE 6

Initialization

mScene = mPhysics->createScene(sceneDesc); mScene.setGravity(PxVec3(0.0f, -9.81f, 0.0f)); mMaterials = getPhysics().createMaterial(staticFriction, dynamicFriction, restitution); PxRigidStatic* plane = PxCreatePlane(*mPhysics, PxPlane(PxVec3(0,1,0), 0), *mMaterial); mScene->addActor(*plane);

  • PxScene

– Container for all object in simulation – Global world properties (i.e. gravity) – Any objects not in vehicle system can be added straight to this with minimal extra work – Probably going to want to add at least one static object

slide-7
SLIDE 7

Initialization

PxInitVehicleSDK(physics); PxVec3 up(0,1,0); PxVec3 forward(0,0,1); PxVehicleSetBasisVectors(up,forward); //Set the vehicle update mode to be immediate velocity changes. PxVehicleSetUpdateMode(PxVehicleUpdateMode::eVELOCITY_CHANGE);

  • Setup vehicle support
  • Few essential parameters need to be set
  • No context object, just free functions
slide-8
SLIDE 8

Mesh creation

PxConvexMeshDesc convexDesc; convexDesc.points.count = numVerts; convexDesc.points.stride = sizeof(PxVec3); convexDesc.points.data = verts; convexDesc.flags = PxConvexFlag::eCOMPUTE_CONVEX | PxConvexFlag::eINFLATE_CONVEX; PxConvexMesh* convexMesh = NULL; PxDefaultMemoryOutputStream buf; if(cooking.cookConvexMesh(convexDesc, buf)) { PxDefaultMemoryInputData id(buf.getData(), buf.getSize()); convexMesh = physics.createConvexMesh(id); }

slide-9
SLIDE 9

Set up simulation data

void createVehicle4WSimulationData (const PxF32 chassisMass, PxConvexMesh* chassisConvexMesh, const PxF32 wheelMass, PxConvexMesh** wheelConvexMeshes, const PxVec3* wheelCentreOffsets, PxVehicleWheelsSimData& wheelsData, PxVehicleDriveSimData4W& driveData, PxVehicleChassisData& chassisData) { //Extract the chassis AABB dimensions from the chassis convex mesh. const PxVec3 chassisDims=computeChassisAABBDimensions(chassisConvexMesh); //The origin is at the center of the chassis mesh. //Set the center of mass to be below this point and a little towards the front. const PxVec3 chassisCMOffset=PxVec3(0.0f,-chassisDims.y*0.5f+0.65f,0.25f); //Now compute the chassis mass and moment of inertia. //Use the moment of inertia of a cuboid as an approximate value for the chassis moi. PxVec3 chassisMOI ((chassisDims.y*chassisDims.y + chassisDims.z*chassisDims.z)*chassisMass/12.0f, (chassisDims.x*chassisDims.x + chassisDims.z*chassisDims.z)*chassisMass/12.0f, (chassisDims.x*chassisDims.x + chassisDims.y*chassisDims.y)*chassisMass/12.0f); //A bit of tweaking here. The car will have more responsive turning if we reduce the //y-component of the chassis moment of inertia. chassisMOI.y*=0.8f; //Let's set up the chassis data structure now. chassisData.mMass=chassisMass; chassisData.mMOI=chassisMOI; chassisData.mCMOffset=chassisCMOffset; //Compute the sprung masses of each suspension spring using a helper function. PxF32 suspSprungMasses[4]; PxVehicleComputeSprungMasses(4,wheelCentreOffsets,chassisCMOffset,chassisMass,1,suspSprungMasses); //Extract the wheel radius and width from the wheel convex meshes. PxF32 wheelWidths[4]; PxF32 wheelRadii[4]; computeWheelWidthsAndRadii(wheelConvexMeshes,wheelWidths,wheelRadii); //Now compute the wheel masses and inertias components around the axle's axis. //http://en.wikipedia.org/wiki/List_of_moments_of_inertia PxF32 wheelMOIs[4]; for(PxU32 i=0;i<4;i++) { wheelMOIs[i]=0.5f*wheelMass*wheelRadii[i]*wheelRadii[i]; } //Let's set up the wheel data structures now with radius, mass, and moi. PxVehicleWheelData wheels[4]; for(PxU32 i=0;i<4;i++) { wheels[i].mRadius=wheelRadii[i]; wheels[i].mMass=wheelMass; wheels[i].mMOI=wheelMOIs[i]; wheels[i].mWidth=wheelWidths[i]; } //Disable the handbrake from the front wheels and enable for the rear wheels wheels[PxVehicleDrive4WWheelOrder::eFRONT_LEFT].mMaxHandBrakeTorque=0.0f; wheels[PxVehicleDrive4WWheelOrder::eFRONT_RIGHT].mMaxHandBrakeTorque=0.0f; wheels[PxVehicleDrive4WWheelOrder::eREAR_LEFT].mMaxHandBrakeTorque=4000.0f; wheels[PxVehicleDrive4WWheelOrder::eREAR_RIGHT].mMaxHandBrakeTorque=4000.0f; //Enable steering for the front wheels and disable for the front wheels. wheels[PxVehicleDrive4WWheelOrder::eFRONT_LEFT].mMaxSteer=PxPi*0.3333f; wheels[PxVehicleDrive4WWheelOrder::eFRONT_RIGHT].mMaxSteer=PxPi*0.3333f; wheels[PxVehicleDrive4WWheelOrder::eREAR_LEFT].mMaxSteer=0.0f; wheels[PxVehicleDrive4WWheelOrder::eREAR_RIGHT].mMaxSteer=0.0f; //Let's set up the tire data structures now. //Put slicks on the front tires and wets on the rear tires. PxVehicleTireData tires[4]; tires[PxVehicleDrive4WWheelOrder::eFRONT_LEFT].mType=TIRE_TYPE_SLICKS; tires[PxVehicleDrive4WWheelOrder::eFRONT_RIGHT].mType=TIRE_TYPE_SLICKS; tires[PxVehicleDrive4WWheelOrder::eREAR_LEFT].mType=TIRE_TYPE_WETS; tires[PxVehicleDrive4WWheelOrder::eREAR_RIGHT].mType=TIRE_TYPE_WETS; //Let's set up the suspension data structures now. PxVehicleSuspensionData susps[4]; for(PxU32 i=0;i<4;i++) { susps[i].mMaxCompression=0.3f; susps[i].mMaxDroop=0.1f; susps[i].mSpringStrength=35000.0f; susps[i].mSpringDamperRate=4500.0f; } susps[PxVehicleDrive4WWheelOrder::eFRONT_LEFT].mSprungMass=suspSprungMasses[PxVehicleDrive4WWheelOrder::eFRONT_LEFT]; susps[PxVehicleDrive4WWheelOrder::eFRONT_RIGHT].mSprungMass=suspSprungMasses[PxVehicleDrive4WWheelOrder::eFRONT_RIGHT]; susps[PxVehicleDrive4WWheelOrder::eREAR_LEFT].mSprungMass=suspSprungMasses[PxVehicleDrive4WWheelOrder::eREAR_LEFT]; susps[PxVehicleDrive4WWheelOrder::eREAR_RIGHT].mSprungMass=suspSprungMasses[PxVehicleDrive4WWheelOrder::eREAR_RIGHT]; //Set up the camber. //Remember that the left and right wheels need opposite camber so that the car preserves symmetry about the forward direction. //Set the camber to 0.0f when the spring is neither compressed or elongated. const PxF32 camberAngleAtRest=0.0; susps[PxVehicleDrive4WWheelOrder::eFRONT_LEFT].mCamberAtRest=camberAngleAtRest; susps[PxVehicleDrive4WWheelOrder::eFRONT_RIGHT].mCamberAtRest=-camberAngleAtRest; susps[PxVehicleDrive4WWheelOrder::eREAR_LEFT].mCamberAtRest=camberAngleAtRest; susps[PxVehicleDrive4WWheelOrder::eREAR_RIGHT].mCamberAtRest=-camberAngleAtRest; //Set the wheels to camber inwards at maximum droop (the left and right wheels almost form a V shape) const PxF32 camberAngleAtMaxDroop=0.001f; susps[PxVehicleDrive4WWheelOrder::eFRONT_LEFT].mCamberAtMaxDroop=camberAngleAtMaxDroop;
slide-10
SLIDE 10

Simulation data setup

PxVehicleWheelsSimData* wheelsSimData=PxVehicleWheelsSimData::allocate(4); PxVehicleDriveSimData4W driveSimData; PxVehicleChassisData chassisData; createVehicle4WSimulationData (chassisMass,chassisConvexMesh, 20.0f,wheelConvexMeshes4,wheelCentreOffsets4, *wheelsSimData,driveSimData,chassisData);

  • Three key classes
  • Wheel - Suspension, radius, etc..
  • Chassis - Body of the vehicle
  • Drive - How are power and steering applied
slide-11
SLIDE 11

Setup examples

const PxVec3 chassisCMOffset=PxVec3(0.0f,-chassisDims.y*0.5f+0.65f,0.25f); chassisData.mCMOffset=chassisCMOffset;

  • Chassis centre of mass

PxVehicleSuspensionData susps[4]; for(PxU32 i=0;i<4;i++) { susps[i].mMaxCompression=0.3f; susps[i].mMaxDroop=0.1f; susps[i].mSpringStrength=35000.0f; susps[i].mSpringDamperRate=4500.0f; } for(PxU32 i=0;i<4;i++) { wheelsData.setSuspensionData(i,susps[i]); //... } PxVehicleEngineData engine; engine.mPeakTorque=500.0f; engine.mMaxOmega=600.0f;//approx 6000 rpm driveData.setEngineData(engine);

  • Suspension spring parameters
  • Engine properties
slide-12
SLIDE 12

Setup actor and drivetrain instance

PxRigidDynamic* vehActor = physics.createRigidDynamic(PxTransform(PxIdentity)); for(PxU32 i=0;i<numWheelGeometries;i++) { PxShape* wheelShape=vehActor->createShape(*wheelGeometries[i],*wheelMaterial); wheelShape->setQueryFilterData(vehQryFilterData); wheelShape->setSimulationFilterData(wheelCollFilterData); wheelShape->setLocalPose(wheelLocalPoses[i]); } // Need to add chassis as well //... PxVehicleDrive4W* car = PxVehicleDrive4W::allocate(4); car->setup(&physics,vehActor,*wheelsSimData,driveSimData,0); mScene.addActor(*vehActor);

  • Previous object were all static data, need an instance

as well

  • Actor is set of rigid bodies for wheel
  • Drive is instance of drivetrain
  • Actor and drivetrain get linked
  • Actor added to scene
slide-13
SLIDE 13

Per-frame actions

  • Input setup

PxVehicleDrive4WRawInputData carRawInputs; carRawInputs.setAnalogAccel(mGamepadAccel); carRawInputs.setAnalogBrake(mGamepadCarBrake); carRawInputs.setAnalogSteer(mGamepadCarSteer); PxVehicleDrive4WSmoothAnalogRawInputsAndSetAnalogInputs (gCarPadSmoothingData,gSteerVsForwardSpeedTable, carRawInputs,timestep,isInAir,(PxVehicleDrive4W&)focusVehicle); if(NULL==mSqWheelRaycastBatchQuery) { mSqWheelRaycastBatchQuery=mSqData->setUpBatchedSceneQuery(scene); } PxVehicleSuspensionRaycasts(mSqWheelRaycastBatchQuery,mNumVehicles,mVehicles, mSqData->getRaycastQueryResultBufferSize(),mSqData->getRaycastQueryResultBuffer());

  • Wheel raycasts
slide-14
SLIDE 14

Per-frame actions (cont’d)

  • Update simulation

PxVehicleUpdates(timestep,gravity,*mSurfaceTirePairs, numVehicles,vehicles,vehicleWheelQueryResults); scene->simulate(mStepSize, NULL, scratchBlock, scratchBlockSize);

slide-15
SLIDE 15

Conclusions

  • Use the PhysX vehicle library unless you have a really

good reason not to

– Spoiler : you don’t have a good reason

  • Mechanics of setup are complex, don’t be afraid to steal

the PhysX sample code

  • The driving model in the PhysX sample app is now the

baseline, need to make it better if you want good marks

  • n the driving portion of things
