REPUBLIC OF THE PHILIPPINES DEPARTMENT OF AGRICULTURE PHILIPPINE FIBER INDUSTRY DEVELOPMENT AUTHORITY Presented by: REMEDIOS V. ABGONA, PhD Chief PhilFIDA-Fiber Utililization and Technology Division PIA FIBER PRODUCTION POTENTIAL


slide-1
SLIDE 1

REPUBLIC OF THE PHILIPPINES DEPARTMENT OF AGRICULTURE

PHILIPPINE FIBER INDUSTRY DEVELOPMENT AUTHORITY Presented by: REMEDIOS V. ABGONA, PhD Chief PhilFIDA-Fiber Utililization and Technology Division

slide-2
SLIDE 2

REPUBLIC OF THE PHILIPPINES DEPARTMENT OF AGRICULTURE PHILIPPINE FIBER INDUSTRY DEVELOPMENT AUTHORITY

PIÑA FIBER PRODUCTION

IDENTIFIED PLANTATION AREAS South Cotabato Bukidnon Camarines Norte Cavite PLANTATION AREA (Ha) 14, 150 18, 200 2, 400 2, 760 POTENTIAL FIBER PRODUCTION (tons/yr) 15, 496 19, 931 1, 480 1, 695

slide-3
SLIDE 3

REPUBLIC OF THE PHILIPPINES DEPARTMENT OF AGRICULTURE PHILIPPINE FIBER INDUSTRY DEVELOPMENT AUTHORITY

IDENTIFIED PLANTATION AREAS

Camarines Norte Bukidnon South Cotabato Cavite

slide-4
SLIDE 4

REPUBLIC OF THE PHILIPPINES DEPARTMENT OF AGRICULTURE PHILIPPINE FIBER INDUSTRY DEVELOPMENT AUTHORITY

(Queen) Formosa

PINEAPPLE VARIETIES

Queen pineapple plants mainly grow in Australia, the Philippines and South Africa. Pineapple plants in this group are smaller and produce smaller fruit that weighs between 1 and 6

  • pounds. The fruit is juicy

and flavorful but tends to be cone-shaped, which results in excessive waste if this variety is used for commercial canning. It does keep well, and is harvested for sale as fresh fruit. The foliage on these plants tends to be medium green, although the “Ripley” cultivar leaves have a red tint.

slide-5
SLIDE 5

REPUBLIC OF THE PHILIPPINES DEPARTMENT OF AGRICULTURE PHILIPPINE FIBER INDUSTRY DEVELOPMENT AUTHORITY

Red Spanish

PINEAPPLE VARIETIES

The Red Spanish pineapple group usually grow in Florida, Mexico, Puerto Rico, Venezuela and the West

  • Indies. These tend to be larger

plants with very spiny gray- green or purple-green foliage. The fruit has a rounded shape and generally weighs between 3 and 6 pounds, although the “Valera Amarilla” cultivar can produce fruit that weighs up to 9 pounds. In the Philippines, particularly in Aklan, pineapple leaves are sources of hand-woven fabric.

slide-6
SLIDE 6

REPUBLIC OF THE PHILIPPINES DEPARTMENT OF AGRICULTURE PHILIPPINE FIBER INDUSTRY DEVELOPMENT AUTHORITY

(Hawaiian)

PINEAPPLE VARIETIES

Grown in hot climates around the world, Smooth Cayenne pineapple plants tend to be more susceptible to disease than

  • ther
  • varieties. However, the leaves

do not have the spiny edges

  • f
  • ther

types. The juicy, flavorful fruit generally weighs between 2 and 10 pounds. The “Giant Kew” cultivar is an unusual member

  • f this group, with pineapples

that can weigh as much as 22 pounds. Most

  • f

these pineapple plant varieties are grown commercially for canning or sale as fresh fruit.

slide-7
SLIDE 7

REPUBLIC OF THE PHILIPPINES DEPARTMENT OF AGRICULTURE PHILIPPINE FIBER INDUSTRY DEVELOPMENT AUTHORITY

CHARACTERIZATION PROPERTIES OF PINEAPPLE FIBER

Fiber sample Cell length (mm.) Cell diameter (µ) Lumen width (µ) Wall thickness(µ) Formosa-Deco (Cam. Sur) Hawaiian-Deco (Isabela) Red Spanish-Liniwan Red Spanish-Bastos 5.18 5.40 5.23 5.18 5.77 7.80 6.39 6.90 1.61 3.54 2.00 2.34 2.08 2.13 2.21 2.29

  • A. MORPHOLOGICAL PROPERTIES OF PINEAPPLE FIBER
slide-8
SLIDE 8

REPUBLIC OF THE PHILIPPINES DEPARTMENT OF AGRICULTURE PHILIPPINE FIBER INDUSTRY DEVELOPMENT AUTHORITY

CHARACTERIZATION PROPERTIES OF PINEAPPLE FIBER

  • B. PHYSICAL PROPERTIES OF PINEAPPLE FIBER

Fiber sample Tensile strength (Kgf/g.m.) Elongation (%)

Formosa-Deco (Cam. Sur) Hawaiian-Deco (Isabela) Red Spanish-Liniwan(Aklan) Red Spanish-Bastos(Aklan) 14.14 21.99 33.19 23.68 7.14 4.13 4.54 4.10

slide-9
SLIDE 9

REPUBLIC OF THE PHILIPPINES DEPARTMENT OF AGRICULTURE PHILIPPINE FIBER INDUSTRY DEVELOPMENT AUTHORITY

CHARACTERIZATION PROPERTIES OF PINEAPPLE FIBER

  • C. CHEMICAL PROPERTIES OF PINEAPPLE FIBER

Fiber sample Moisture (%) Ash ( %) Solubilities in (%): Lignin (%) Celluloses (%): Alc-ben 1%NaO H Hot H2O Holo Alpha Hemi Formosa (Cam. Sur) Hawaiian (Isabela) Red Spanish-Liniwan Red Spanish-Bastos 11.24 7.86 9.52 9.23 0.58 0.95 0.77 0.91 2.46 3.04 2.21 2.84 13.14 17.43 16.98 22.13 0.88 2.29 3.76 4.65 7.68 3.98 8.81 10.73 88.49 89.77 84.87 81.74 75.22 74.64 65.57 58.18 13.32 13.66 13.49 14.98

slide-10
SLIDE 10

REPUBLIC OF THE PHILIPPINES DEPARTMENT OF AGRICULTURE PHILIPPINE FIBER INDUSTRY DEVELOPMENT AUTHORITY

PIÑA FIBER PRODUCTION

Manual

  • r

Scraping Mechanical

Extraction Methods

slide-11
SLIDE 11

REPUBLIC OF THE PHILIPPINES DEPARTMENT OF AGRICULTURE PHILIPPINE FIBER INDUSTRY DEVELOPMENT AUTHORITY

Harvesting Scraping outer layer with broken porcelain (to extract bastos fiber) Scraping inner layer with coconut shell (to extract liniwan fibers) Washing Pounding Drying

MANUAL/SCRAPING

slide-12
SLIDE 12

REPUBLIC OF THE PHILIPPINES DEPARTMENT OF AGRICULTURE PHILIPPINE FIBER INDUSTRY DEVELOPMENT AUTHORITY

MANUAL/SCRAPING

  • Process: scraping
  • Output/day: 204.3 g
  • Recovery: 0.681 g/leaf
  • Product: 27% fine (liniwan) fiber

73% coarse (bastos) fiber

slide-13
SLIDE 13

REPUBLIC OF THE PHILIPPINES DEPARTMENT OF AGRICULTURE PHILIPPINE FIBER INDUSTRY DEVELOPMENT AUTHORITY

Traditional Products

Handloom Weaving

Fashion Dresses

Barong Tagalog

MANUAL/SCRAPING

slide-14
SLIDE 14

REPUBLIC OF THE PHILIPPINES DEPARTMENT OF AGRICULTURE PHILIPPINE FIBER INDUSTRY DEVELOPMENT AUTHORITY

Product/Province 2008 2009 2010 2011 2012 2013 2014 2015 2016 2017 PIÑA FIBER

13,669 7,214 3,958 6,256 15,015 6,504 3,850 7,956 5,794 6,043

Hand-Scraped

6,443 2,433 2,562 2,889 5,887 4,082 3,850 4,321 1,446 1,489

Liniuan Aklan

298 294 287 315 283 257 77 62 40 61

Camarines Norte 2/

4,600 20

  • Bastos

Aklan

1,168 1,524 1,490 1,474 1,429 1,025 439 459 456 657

Antique

  • 1

Palawan

377 595 785 1,100 4,175 2,800 3,334 3,800 950 770

ANNUAL PRODUCTION OF PIÑA FIBER AND OTHER PIÑA PRODUCTS, 2008-2017 (in kilogram)

1/ produced from pineapple plantations established fro fruit production 2/3,023 kg, in Camarines Norte were damaged by fire on August 24, 2009

slide-15
SLIDE 15

REPUBLIC OF THE PHILIPPINES DEPARTMENT OF AGRICULTURE PHILIPPINE FIBER INDUSTRY DEVELOPMENT AUTHORITY

Product/Province 2008 2009 2010 2011 2012 2013 2014 2015 2016 2017 PIÑA FIBER Brushed

  • 720
  • KNOTTED PIÑA

FIBER

853 996 927 992 939 670 287 279 262 372

(Aklan) Liniuan

222 216 222 217 215 157 59 46 30 45

Bastos

631 780 705 775 724 513 228 233 232 327

ANNUAL PRODUCTION OF PIÑA FIBER AND OTHER PIÑA PRODUCTS, 2008-2017 (in kilogram)

slide-16
SLIDE 16

REPUBLIC OF THE PHILIPPINES DEPARTMENT OF AGRICULTURE PHILIPPINE FIBER INDUSTRY DEVELOPMENT AUTHORITY

Product/Province 2008 2009 2010 2011 2012 2013 2014 2015 2016 2017 PIÑA CLOTH (in meter) (Aklan) Plain

10,679 11,604 9,553 12,227 9,912 7,434 3,052 2,281 1,531 2,250

Piña-Seda

39,679 56,557 48,776 43,133 42,702 29,46 12,854 8,509 15,120 27,314

Piña-Seda Sinuksok

10,220 15,639 18,846 22,352 21,790 13,898 5,271 5,154 1,750 620

Piña-Seda Stripe

  • 14
  • 5
  • 15

Piña-Seda Checkered

37 18

  • 75

Piña-Seda Scattered Pili

  • 100

Piña w/ cotton

  • 11
  • 9
  • ANNUAL PRODUCTION OF PIÑA FIBER AND OTHER PIÑA PRODUCTS, 2008-2017

(in kilogram)

slide-17
SLIDE 17

REPUBLIC OF THE PHILIPPINES DEPARTMENT OF AGRICULTURE PHILIPPINE FIBER INDUSTRY DEVELOPMENT AUTHORITY

MECHANICAL METHOD

FIDA DESIGNED MULTI-FIBER DECORTICATING MACHINE

slide-18
SLIDE 18

REPUBLIC OF THE PHILIPPINES DEPARTMENT OF AGRICULTURE PHILIPPINE FIBER INDUSTRY DEVELOPMENT AUTHORITY

MULTI-FIBER DECORTICATING MACHINE

The Multi-Fiber decorticating machine was designed and developed by the Fiber Industry Development Authority It is an improvement of the traditional raspador decorticator used for ramie fiber extraction

slide-19
SLIDE 19

REPUBLIC OF THE PHILIPPINES DEPARTMENT OF AGRICULTURE PHILIPPINE FIBER INDUSTRY DEVELOPMENT AUTHORITY

MULTI-FIBER DECORTICATING MACHINE

The machine is designed to extract different fiber crops such as abaca, pineapple, maguey, sisal, ramie and banana With the Multi-Fiber Decorticating Machine, pineapple fibers can now be extracted efficiently and effectively

slide-20
SLIDE 20

REPUBLIC OF THE PHILIPPINES DEPARTMENT OF AGRICULTURE PHILIPPINE FIBER INDUSTRY DEVELOPMENT AUTHORITY

MULTI-FIBER DECORTICATING MACHINE

Decorticating Drum Feeding Chute Spring Adjuster Chassis Engine

Cover

Clearance Adjuster Pneumatic Tire Telescopic Leg

slide-21
SLIDE 21

REPUBLIC OF THE PHILIPPINES DEPARTMENT OF AGRICULTURE PHILIPPINE FIBER INDUSTRY DEVELOPMENT AUTHORITY

MULTI-FIBER DECORTICATING MACHINE

SPECIFICATIONS

Dimension, mm : 2400 x 1500 x 1100 (LWH) Weight : 350 kg approximately Power Requirement : 7 HP diesel engine Labor Requirement : two (2) persons Fuel Requirement : 4 liters/day

slide-22
SLIDE 22

REPUBLIC OF THE PHILIPPINES DEPARTMENT OF AGRICULTURE PHILIPPINE FIBER INDUSTRY DEVELOPMENT AUTHORITY

MULTI-FIBER DECORTICATING MACHINE

Patent No. (Invention) : 1-2005-000391 Date Filed : 8/8/2005 Title : Machine and Process for Extraction of Pineapple and Banana Fibers

INTELECTUAL PROPERTY RIGHTS

slide-23
SLIDE 23

REPUBLIC OF THE PHILIPPINES DEPARTMENT OF AGRICULTURE PHILIPPINE FIBER INDUSTRY DEVELOPMENT AUTHORITY

MECHANICAL METHOD

FIDA Designed Mobile Multi-fiber Decorticating Machine*

Abaca - 10 kg/hr Maguey- 7kg/hr Pineapple- 1.5kg/hr Banana-3kg/hr

Features:

Capacity: Quality of fiber produced: Excellent-good cleaning

  • No. of operators: 2

* This machine is already registered with Intellectual Property Office (IPO)

Dimensions, mm: 2400 x 1500 x 1100 (LWH) Weight: 350 kg approx

slide-24
SLIDE 24

REPUBLIC OF THE PHILIPPINES DEPARTMENT OF AGRICULTURE PHILIPPINE FIBER INDUSTRY DEVELOPMENT AUTHORITY

PINEAPPLE FIBER EXTRACTION PROCESS

1st Decortication (leaves) 2nd Decortication (fiber) Wash Pounding/Drying Tip Cutting Baling

slide-25
SLIDE 25

REPUBLIC OF THE PHILIPPINES DEPARTMENT OF AGRICULTURE PHILIPPINE FIBER INDUSTRY DEVELOPMENT AUTHORITY

DECORTICATION METHOD

Harvesting Extraction Extraction Washing Pounding Drying

slide-26
SLIDE 26

REPUBLIC OF THE PHILIPPINES DEPARTMENT OF AGRICULTURE PHILIPPINE FIBER INDUSTRY DEVELOPMENT AUTHORITY

MACHINE PERFORMANCE

Output : 10.5 kg Recovery : 1.3 – 1.5 kg Product : Decorticated Pineapple Fiber

slide-27
SLIDE 27

REPUBLIC OF THE PHILIPPINES DEPARTMENT OF AGRICULTURE PHILIPPINE FIBER INDUSTRY DEVELOPMENT AUTHORITY

MECHANICAL METHOD

Philippine Tropical Fabrics in Compliance to RA 9242 Office Uniforms

Products

slide-28
SLIDE 28

REPUBLIC OF THE PHILIPPINES DEPARTMENT OF AGRICULTURE PHILIPPINE FIBER INDUSTRY DEVELOPMENT AUTHORITY

Products

slide-29
SLIDE 29

REPUBLIC OF THE PHILIPPINES DEPARTMENT OF AGRICULTURE PHILIPPINE FIBER INDUSTRY DEVELOPMENT AUTHORITY

Products

slide-30
SLIDE 30

REPUBLIC OF THE PHILIPPINES DEPARTMENT OF AGRICULTURE PHILIPPINE FIBER INDUSTRY DEVELOPMENT AUTHORITY

Products

slide-31
SLIDE 31

REPUBLIC OF THE PHILIPPINES DEPARTMENT OF AGRICULTURE PHILIPPINE FIBER INDUSTRY DEVELOPMENT AUTHORITY

Products

slide-32
SLIDE 32

REPUBLIC OF THE PHILIPPINES DEPARTMENT OF AGRICULTURE PHILIPPINE FIBER INDUSTRY DEVELOPMENT AUTHORITY

Products

slide-33
SLIDE 33

REPUBLIC OF THE PHILIPPINES DEPARTMENT OF AGRICULTURE PHILIPPINE FIBER INDUSTRY DEVELOPMENT AUTHORITY

Products

slide-34
SLIDE 34

REPUBLIC OF THE PHILIPPINES DEPARTMENT OF AGRICULTURE PHILIPPINE FIBER INDUSTRY DEVELOPMENT AUTHORITY

Product/Province 2008 2009 2010 2011 2012 2013 2014 2015 2016 2017 2018 PINEAPPLE FIBER Decorticated 1/

7,226 4,061 1,396 3,367 9,128 2,422

  • 3,635

4,273 4,554 7,600

Isabela

  • 3
  • Camarines Norte

7,226 4,058 1,396 3,267 8,976 2,422 500 3,630 4,273 2,070 700

Cavite

  • 100

100

  • 5

75

  • Rizal
  • 52
  • South Cotabato
  • 2,004

5,000

Bukidnon

  • 480

1,900

ANNUAL PRODUCTION OF DECORTICATED PINEAPPLE FIBER, 2008-2018 (in kilogram)

1/ produced from pineapple plantations established for fruit production 2/3,023 kg, in Camarines Norte were damaged by fire on August 24, 2009

slide-35
SLIDE 35

REPUBLIC OF THE PHILIPPINES DEPARTMENT OF AGRICULTURE PHILIPPINE FIBER INDUSTRY DEVELOPMENT AUTHORITY

1000 2000 3000 4000 5000 6000 7000 8000 9000 10000

Decorticated Pineapple Fiber Production, kg

2008 2009 2010 2011 2012 2014 2015 2016 2017 2018

slide-36
SLIDE 36

REPUBLIC OF THE PHILIPPINES DEPARTMENT OF AGRICULTURE PHILIPPINE FIBER INDUSTRY DEVELOPMENT AUTHORITY

PRODUCTION OF HAWAIIAN PINEAPPLE FIBER PER DAY

Hired labor for gathering of pineapple leaves

Particulars Amount, Php Sale 3,150.00 10.5kg @ Php 300/kg 3,150.00 Production Cost 2,356.56 Fixed Cost 103.56

1Depreciation

: 83.29

2Repair & Maint.

: 26.02 Variable Cost 2,253.00

1Labor

1,800.00 Harvesting/Hauling : 3 workers @ Php 300/day 900.00 Decortication : 2 workers @ Php 300/day 600.00 Washing/Drying/Tip Cutting : 1 worker @ Php 300 300.00

2Hauling of Leaves

200.00

3 Transport of Fiber

: 10.5kg @ Php 58.00/kg

4Diesel Fuel

4 L @ Php 52/L (Provincial Rate as of October 2018) 208.00

5 Plastic Wrapper

9.00

6Plastic Rope, 1/8” diameter

9.45

7Water

PhP 21.00/10.5 kg/fiber 21.00

8 Packing Tape, Php 3.15

3.15 Daily Net Income, Php/day 793.44 Return on Investment (ROI), % 33.67 Production Cost/Kg 224.43

slide-37
SLIDE 37

REPUBLIC OF THE PHILIPPINES DEPARTMENT OF AGRICULTURE PHILIPPINE FIBER INDUSTRY DEVELOPMENT AUTHORITY

PRODUCTION OF HAWAIIAN PINEAPPLE FIBER PER YEAR

PARTICULARS ANNUAL UTILIZATION, DAYS 150 200 250 288

Fixed Cost Per Year 39,900.00 39,900.00 39,900.00 39,900.00 Depreciation 30,400.00 30,400.00 30,400.00 30,400.00 Repair and Maintenance 9,500.00 9,500.00 9,500.00 9,500.00 Variable Cost Per Year 337,590.00 450,120.00 562,650.00 648,172.80 Labor 270,000.00 360,000.00 450,000.00 518,400.00 Hauling of Leaves 30,000.00 40,000.00 50,000.00 57,600.00 Transport of Fiber Diesel Fuel 31,200.00 41,600.00 52,000.00 59,904.00 Plastic Wrapper 1,350.00 1,800.00 2,250.00 2,592.00 Plastic Rope 1,417.50 1,890.00 2,362.50 2,721.60 Water 3,150.00 4,200.00 5,250.00 6,048.00 Packaging Tape 472.50 630.00 787.50 907.20 Total Operating Cost, Php/yr 377,490.00 490,020.00 602,550.00 688,072.80 Decorticating Capacity, kg/yr 1,575.00 2,100.00 2,625.00 3,024.00 Annual Gross Income, Php/yr 472,500.00 630,000.00 787,500.00 907,200.00 Annual Net Income, Php/yr 95,010.00 139,980.00 184,950.00 219,127.20 Percentage of Net Income over Production Cost, % 25.17 28.57 30.69 31.85 Payback Period, yrs 3.97 3.50 3.26 3.14

slide-38
SLIDE 38

REPUBLIC OF THE PHILIPPINES DEPARTMENT OF AGRICULTURE PHILIPPINE FIBER INDUSTRY DEVELOPMENT AUTHORITY

PRODUCTION OF HAWAIIAN PINEAPPLE FIBER

Assumptions

Machine Cost is Php 190,000.00 Repair and Maintenance Cost is 5% of Investment Cost Depreciation is computed using the straight line formula with 20% salvage value Machine life is 5 years Price of dried decorticated pineapple fiber is PhP 300/kg Diesel fuel is PhP 50/L Agricultural Wage in South Cotabato as of May 2018 is PhP 290/day

slide-39
SLIDE 39

REPUBLIC OF THE PHILIPPINES DEPARTMENT OF AGRICULTURE PHILIPPINE FIBER INDUSTRY DEVELOPMENT AUTHORITY

PRODUCERS OF PINEAPPLE DECORTICATED FIBER

Association/Cooperative Contact Person Contact Number Maduvika Farmers’ Multi-Purpose Cooperative, Sta. Ana, Cagayan Willy Alog Manager 0936-6171323 Labo Progressive MPC

  • Brgy. Malasigui, Labo,

Camarines Norte

  • Mr. Mario Espeso
  • Gen. Manager

(054)585-2455 585-2230 447-6565 Shalom Fiber Growers Association

  • Brgy. Mampayag, Manolo Fortich,

Bukidnon

  • Engr. Joie Caesar Gaid

Manager 0917-1573486 T’boli Farm Growers Multi-Purpose Coop. Edwards, T’boli, South Cotabato

  • Mr. Adolfo D. Tanco Jr.

Manager (083)237-1104 09089896044 Adventurer’s Multi-Purpose Cooperative Polomolok, South Cotabato

  • Ms. Jane Torreon

Manager 0995-2765972

slide-40
SLIDE 40

REPUBLIC OF THE PHILIPPINES DEPARTMENT OF AGRICULTURE PHILIPPINE FIBER INDUSTRY DEVELOPMENT AUTHORITY

END OF PRESENTATION.

Thank You!
