Chair of Network Architectures and Services Department of Informatics Technical University of Munich Performance Implications of Packet Filtering with Linux eBPF Dominik Scholz , Daniel Raumer, Paul Emmerich, Alexander Kurtz, Krzysztof Lesiak

slide-1
SLIDE 1

Chair of Network Architectures and Services Department of Informatics Technical University of Munich

Performance Implications of Packet Filtering with Linux eBPF

Dominik Scholz, Daniel Raumer, Paul Emmerich, Alexander Kurtz, Krzysztof Lesiak and Georg Carle

Chair of Network Architectures and Services Department of Informatics Technical University of Munich

slide-2
SLIDE 2

History of Extended Berkeley Packet Filter (eBPF)

Recent Hot Topic

  • 1992: BPF developed for UNIX
  • Packet filtering, e.g. tcpdump
  • 2014: eBPF introduced into Linux Kernel
  • Network monitoring
  • Network traffic manipulation
  • Non-networking purposes
  • Tracing
  • Security auditing
  • . . .
  • Since then:
  • Continuous (performance) improvements [1]
  • “super powers have finally come to Linux” [2]
  • Offloading support, e.g. Netronome SmartNIC [3]
  • At Host Dataplane Acceleration Tutorial @ SIGCOMM 2018 [4]

[1] A thorough introduction to eBPF, https://lwn.net/Articles/740157/ [2] Brendan Gregg, BPF: Tracing and More, https://www.youtube.com/watch?v=JRFNIKUROPE [3] NetroNews, August 2018, http://hosted.verticalresponse.com/183413/a79f667b58/1413119999/c60e793082/ [4] ACM SIGCOMM 2018 Morning Tutorial on Host Dataplane Acceleration (HDA), https://conferences.sigcomm.org/sigcomm/2018/tutorial-hda.html

  • D. Scholz, D. Raumer, P

. Emmerich, A. Kurtz, K. Lesiak, G. Carle — Performance Implications of Packet Filtering with Linux eBPF 2

slide-3
SLIDE 3

Outline

Extended Berkeley Packet Filter Use Case: Packet Filtering Case Study I: eXpress Data Path (XDP) Case Study II: Socket-attached Filtering Conclusion

  • D. Scholz, D. Raumer, P

. Emmerich, A. Kurtz, K. Lesiak, G. Carle — Performance Implications of Packet Filtering with Linux eBPF 3

slide-4
SLIDE 4

Extended Berkeley Packet Filter (eBPF)

What is it?

  • User space program
  • Run in virtual machine in kernel space (“sandboxed”)
  • Dynamically interpreted (default) or compiled just-in-time (JIT)

Limitations

  • Static verification
  • No backward jumps (loops)
  • Maximum of 4096 instructions

Cannot compromise/block kernel

  • Data access: key-value stores (maps)
  • Memory region set up before program is loaded
  • Key size, value type, max. number of entries predetermined

Secure data access between user space and kernel space

  • D. Scholz, D. Raumer, P

. Emmerich, A. Kurtz, K. Lesiak, G. Carle — Performance Implications of Packet Filtering with Linux eBPF 4

slide-5
SLIDE 5

Study: Packet Filtering

Layers of Packet Filters

NIC Driver OS Apps Hardware level Network level System level Application level HW-filter DMA Poll routines NAPI Network stack Transport prot. Applications

  • Hardware offloading and filtering
  • Dedicated platforms based on FPGAs or SmartNICs

High-performance, ideal for coarse filtering (DoS)

  • D. Scholz, D. Raumer, P

. Emmerich, A. Kurtz, K. Lesiak, G. Carle — Performance Implications of Packet Filtering with Linux eBPF 5

slide-6
SLIDE 6

Study: Packet Filtering

Layers of Packet Filters

NIC Driver OS Apps Hardware level Network level System level Application level HW-filter DMA Poll routines NAPI Network stack Transport prot. Applications

  • Before network stack processing

Dropping packets with low overhead in software

  • Hardware offloading and filtering
  • Dedicated platforms based on FPGAs or SmartNICs

High-performance, ideal for coarse filtering (DoS)

  • D. Scholz, D. Raumer, P

. Emmerich, A. Kurtz, K. Lesiak, G. Carle — Performance Implications of Packet Filtering with Linux eBPF 5

slide-7
SLIDE 7

Study: Packet Filtering

Layers of Packet Filters

NIC Driver OS Apps Hardware level Network level System level Application level HW-filter DMA Poll routines NAPI Network stack Transport prot. Applications

  • Hooks into packet processing of network stack
  • e.g. iptables or nftables

Requires root access, system-specific knowledge

  • Before network stack processing

Dropping packets with low overhead in software

  • Hardware offloading and filtering
  • Dedicated platforms based on FPGAs or SmartNICs

High-performance, ideal for coarse filtering (DoS)

  • D. Scholz, D. Raumer, P

. Emmerich, A. Kurtz, K. Lesiak, G. Carle — Performance Implications of Packet Filtering with Linux eBPF 5

slide-8
SLIDE 8

Study: Packet Filtering

Layers of Packet Filters

NIC Driver OS Apps Hardware level Network level System level Application level HW-filter DMA Poll routines NAPI Network stack Transport prot. Applications

  • Traffic addressed for a specific application

Application “knows best”, high penalty for dropping packets

  • Hooks into packet processing of network stack
  • e.g. iptables or nftables

Requires root access, system-specific knowledge

  • Before network stack processing

Dropping packets with low overhead in software

  • Hardware offloading and filtering
  • Dedicated platforms based on FPGAs or SmartNICs

High-performance, ideal for coarse filtering (DoS)

  • D. Scholz, D. Raumer, P

. Emmerich, A. Kurtz, K. Lesiak, G. Carle — Performance Implications of Packet Filtering with Linux eBPF 5

slide-9
SLIDE 9

Use Case: Packet Filtering

Common Scenario – State of the Art

NIC Driver OS Apps Hardware level Network level System level Application level Centralized Firewall e.g. iptables, nftables HW-filter DMA Poll routines NAPI Network stack Transport prot. Applications

  • Traffic addressed for a specific application

Application “knows best”, high penalty for dropping packets

  • Hooks into packet processing of network stack
  • e.g. iptables or nftables

Requires root access, system-specific knowledge

  • Before network stack processing

Dropping packets with low overhead in software

  • Hardware offloading and filtering
  • Dedicated platforms based on FPGAs or SmartNICs

High-performance, ideal for coarse filtering (DoS)

  • D. Scholz, D. Raumer, P

. Emmerich, A. Kurtz, K. Lesiak, G. Carle — Performance Implications of Packet Filtering with Linux eBPF 6

slide-10
SLIDE 10

Use Case: Packet Filtering

Performance Baseline

16 32 64 128 256 512 0.5 1 1.5 Number of Rules [#] Processed Packets [Mpps] nftables iptables

Maximum packet rate

  • D. Scholz, D. Raumer, P

. Emmerich, A. Kurtz, K. Lesiak, G. Carle — Performance Implications of Packet Filtering with Linux eBPF 7

slide-11
SLIDE 11

Use Case: Packet Filtering

Performance Baseline

16 32 64 128 256 512 0.5 1 1.5 Number of Rules [#] Processed Packets [Mpps] nftables iptables

Maximum packet rate

20 40 nftables 20 40 Relative Probability [%] iptables 20 40 60 80 100 120 140 160 180 200 20 40 Latency [µs] No Firewall

Latency distribution at 0.03 Mpps

  • D. Scholz, D. Raumer, P

. Emmerich, A. Kurtz, K. Lesiak, G. Carle — Performance Implications of Packet Filtering with Linux eBPF 7

slide-12
SLIDE 12

Use Case: Packet Filtering

Performance Baseline

16 32 64 128 256 512 0.5 1 1.5 Number of Rules [#] Processed Packets [Mpps] nftables iptables

Maximum packet rate

20 40 nftables 20 40 Relative Probability [%] iptables 20 40 60 80 100 120 140 160 180 200 20 40 Latency [µs] No Firewall

Latency distribution at 0.03 Mpps

Performance sufficient for today’s applications?

Limitations: Centralized, complex ruleset, requiring root access

  • D. Scholz, D. Raumer, P

. Emmerich, A. Kurtz, K. Lesiak, G. Carle — Performance Implications of Packet Filtering with Linux eBPF 7

slide-13
SLIDE 13

Use Case: Packet Filtering (using Commodity Hardware)

Possibilities with eBPF

NIC Driver OS Apps Hardware level Network level System level Application level XDP HW-filter DMA Poll routines NAPI Network stack Transport prot. Application FWs Application FWs Application FWs Applications

eXpress Data Path

  • First line of defense
  • Coarse but efficient filtering

Protection against DoS attacks

  • D. Scholz, D. Raumer, P

. Emmerich, A. Kurtz, K. Lesiak, G. Carle — Performance Implications of Packet Filtering with Linux eBPF 8

slide-14
SLIDE 14

Case Study I: eXpress Data Path (XDP)

Overview

Source: https://www.iovisor.org/technology/xdp

  • D. Scholz, D. Raumer, P

. Emmerich, A. Kurtz, K. Lesiak, G. Carle — Performance Implications of Packet Filtering with Linux eBPF 9

slide-15
SLIDE 15

Case Study I: eXpress Data Path (XDP)

Measurement Setup

XDP LoadGen

◭ ◮ ◭ ◮

  • XDP program:
  • Drop if port is blacklisted
  • Otherwise, forward to outgoing interface

Excludes network stack

  • Load generator:
  • MoonGen [7]
  • Generates n UDP flows
  • Just-in-time compiler enabled
  • Traffic pinned to single core
  • Hyper-threading and Turbo Boost disabled

[7] https://github.com/emmericp/MoonGen

  • D. Scholz, D. Raumer, P

. Emmerich, A. Kurtz, K. Lesiak, G. Carle — Performance Implications of Packet Filtering with Linux eBPF 10

slide-16
SLIDE 16

Case Study I: eXpress Data Path (XDP)

Performance Baseline

2 4 6 8 10 12 14 5 10 15 Offered Rate [Mpps] Processed Packets [Mpps] 10GbE line-rate 90% dropped 50% dropped 10% dropped

Packet filtering performance

  • Drop everything: 10 Mpps
  • Drop x-Percent: 6.4 Mpps to 7.2 Mpps
  • D. Scholz, D. Raumer, P

. Emmerich, A. Kurtz, K. Lesiak, G. Carle — Performance Implications of Packet Filtering with Linux eBPF 11

slide-17
SLIDE 17

Case Study I: eXpress Data Path (XDP)

Performance Baseline

2 4 6 8 10 12 14 5 10 15 Offered Rate [Mpps] Processed Packets [Mpps] 10GbE line-rate 90% dropped 50% dropped 10% dropped

Packet filtering performance

2 4 6 8 10 20 40 60 80 100 Offered Rate [Mpps] CPU load [%] idle kernel ixgbe bpf helper bpf prog

Whitebox measurement – Profiling

  • Drop everything: 10 Mpps
  • Drop x-Percent: 6.4 Mpps to 7.2 Mpps
  • Kernel < 5% CPU time

5 to 10 times performance increase compared to in-kernel filtering

  • D. Scholz, D. Raumer, P

. Emmerich, A. Kurtz, K. Lesiak, G. Carle — Performance Implications of Packet Filtering with Linux eBPF 11

slide-18
SLIDE 18

Case Study I: eXpress Data Path (XDP)

Latency

1 2 3 4 5 6 7 100 101 102 103 Offered Rate [Mpps] Latency [log(µs)] 50th 90th 99th 99.9th 99.99th

Latency percentiles (90 % passing traffic)

5 10 0.4 Mpps 5 10 Relative Probability [%] 3.9 Mpps 50 100 150 200 250 300 350 400 450 500 5 10 Latency [µs] 6.25 Mpps

852 853 854 1

Outlier

Selected histrograms

Comparison

  • iptables: 55µs (median), 110µs (99.99th %ile)
  • nftables: 82µs (median), 154µs (99.99th %ile)
  • D. Scholz, D. Raumer, P

. Emmerich, A. Kurtz, K. Lesiak, G. Carle — Performance Implications of Packet Filtering with Linux eBPF 12

slide-19
SLIDE 19

Use Case: Packet Filtering (using Commodity Hardware)

Possibilities with eBPF

NIC Driver OS Apps Hardware level Network level System level Application level Socket eBPF HW-filter DMA Poll routines NAPI Network stack Transport prot. Application FWs Application FWs Application FWs Applications

Application Firewall

  • Socket attached filtering
  • Application (developer) can extract desired traffic

Fine-grained and flexible filtering

  • D. Scholz, D. Raumer, P

. Emmerich, A. Kurtz, K. Lesiak, G. Carle — Performance Implications of Packet Filtering with Linux eBPF 13

slide-20
SLIDE 20

Case Study II: Socket Attached Filtering

Application Firewall

Steps

  • Write filter in C
  • Add eBPF virtual machine to socket
  • Run filter in virtual machine

Drop or forward to application

  • D. Scholz, D. Raumer, P

. Emmerich, A. Kurtz, K. Lesiak, G. Carle — Performance Implications of Packet Filtering with Linux eBPF 14

slide-21
SLIDE 21

Case Study II: Socket Attached Filtering

Application Firewall

Steps

  • Write filter in C
  • Add eBPF virtual machine to socket
  • Run filter in virtual machine

Drop or forward to application

Technical Implementation

  • BPF Compiler Collection
  • systemd socket activation

Added command-line interface and wrapper functions [8] E.g. port-knocking simple to implement

[8] https://github.com/AlexanderKurtz/alfwrapper

  • D. Scholz, D. Raumer, P

. Emmerich, A. Kurtz, K. Lesiak, G. Carle — Performance Implications of Packet Filtering with Linux eBPF 14

slide-22
SLIDE 22

Case Study II: Socket Attached Filtering

Application Firewall

Steps

  • Write filter in C
  • Add eBPF virtual machine to socket
  • Run filter in virtual machine

Drop or forward to application

Technical Implementation

  • BPF Compiler Collection
  • systemd socket activation

Added command-line interface and wrapper functions [8] E.g. port-knocking simple to implement

What have we gained?

  • Application developer knows best
  • Rule-set shipped with application
  • Independent of system administrator
  • Small rule-set per application/socket
  • Not interfering with rule-set of another socket

Optimized for application Reduced complexity, less error-prone

[8] https://github.com/AlexanderKurtz/alfwrapper

  • D. Scholz, D. Raumer, P

. Emmerich, A. Kurtz, K. Lesiak, G. Carle — Performance Implications of Packet Filtering with Linux eBPF 14

slide-23
SLIDE 23

Case Study II: Socket Attached Filtering

Measurement Setup

Differences

  • Application interested in throughput
  • (Stateful) applications more difficult to benchmark
  • D. Scholz, D. Raumer, P

. Emmerich, A. Kurtz, K. Lesiak, G. Carle — Performance Implications of Packet Filtering with Linux eBPF 15

slide-24
SLIDE 24

Case Study II: Socket Attached Filtering

Measurement Setup

Differences

  • Application interested in throughput
  • (Stateful) applications more difficult to benchmark

Solution

  • iperf as load generator
  • Benchmark using loopback device
  • D. Scholz, D. Raumer, P

. Emmerich, A. Kurtz, K. Lesiak, G. Carle — Performance Implications of Packet Filtering with Linux eBPF 15

slide-25
SLIDE 25

Case Study II: Socket Attached Filtering

Measurement Setup

Differences

  • Application interested in throughput
  • (Stateful) applications more difficult to benchmark

Solution

  • iperf as load generator
  • Benchmark using loopback device

10 20 30 40 50 60 1 2 3 4 MTU [kB] Throughput [GB/s] Baseline

Baseline transmission speeds

  • D. Scholz, D. Raumer, P

. Emmerich, A. Kurtz, K. Lesiak, G. Carle — Performance Implications of Packet Filtering with Linux eBPF 15

slide-26
SLIDE 26

Case Study II: Socket Attached Filtering

Performance

Interface filtering

  • Simple operation
  • Whitelisting: Matching rule at x-th position

20 40 60 80 100 25 50 75 100 x-th Rule Matching Traffic [#]

  • Rel. Throughput [%]

65536 MTU 9000 MTU 1500 MTU 1280 MTU

  • D. Scholz, D. Raumer, P

. Emmerich, A. Kurtz, K. Lesiak, G. Carle — Performance Implications of Packet Filtering with Linux eBPF 16

slide-27
SLIDE 27

Case Study II: Socket Attached Filtering

Performance

Interface filtering

  • Simple operation
  • Whitelisting: Matching rule at x-th position

20 40 60 80 100 25 50 75 100 x-th Rule Matching Traffic [#]

  • Rel. Throughput [%]

65536 MTU 9000 MTU 1500 MTU 1280 MTU Subnet filtering

  • Complex operation
  • Limits number of rules

5 10 15 20 25 50 75 100 x-th Rule Matching Traffic [#]

  • Rel. Throughput [%]

65536 MTU 9000 MTU 1500 MTU 1280 MTU

  • D. Scholz, D. Raumer, P

. Emmerich, A. Kurtz, K. Lesiak, G. Carle — Performance Implications of Packet Filtering with Linux eBPF 16

slide-28
SLIDE 28

Conclusion

eBPF allows to break up traditional packet filtering

  • Adds flexibility
  • High-performance
  • But: limitations

Many applications can benefit from eBPF

NIC Driver OS Apps Hardware level Network level System level Application level XDP Socket eBPF HW-filter DMA Poll routines NAPI Network stack Transport prot. Application FWs Application FWs Application FWs Applications

  • D. Scholz, D. Raumer, P

. Emmerich, A. Kurtz, K. Lesiak, G. Carle — Performance Implications of Packet Filtering with Linux eBPF 17

slide-29
SLIDE 29

Conclusion

eBPF allows to break up traditional packet filtering

  • Adds flexibility
  • High-performance
  • But: limitations

Many applications can benefit from eBPF

Future developments

  • Improvements for eBPF just-in-time compiler
  • Hardware accelerators and offloading capabilities
  • P4 programming language

NIC Driver OS Apps Hardware level Network level System level Application level XDP Socket eBPF HW-filter DMA Poll routines NAPI Network stack Transport prot. Application FWs Application FWs Application FWs Applications

  • D. Scholz, D. Raumer, P

. Emmerich, A. Kurtz, K. Lesiak, G. Carle — Performance Implications of Packet Filtering with Linux eBPF 17
