Energy Codes are Going Beyond Energy Savings; How Can You Participate in a World with Storage and EVs Monday Morning 1030am Session Energy Codes are Going Beyond Energy Savings; How Can You Participate in a World with Storage and EVs Monday
Monday Morning 1030am Session
Monday February 24, 2020 Scottsdale, AZ RESNET Conference 2020
I am Jim Meyers In energy efficiency industry 25 years ICC - IECC Residential Energy Code Development Committee (2021 IECC) Past experience - HERS Rater-Trainer-Quality Assurance, building insulation association (western states), commercial energy audits, building modeling software development
3
In construction & EE industry 16 yrs In the utility industry for 8 yrs Currently manage SRP’s ENERGY STAR homes and EV programs. Past experience - HERS Rater, BPI analyst, Certified Energy Manager, Arizona state manager for DOE’s weatherization program.
4
Cities and states are adopting ordinances Climate action plans are materializing across the nation Utilities are piloting and setting programs in place to support Storage and EVs How can Raters support these efforts, and what are the
5
Nationally and Globally
6
The global electric-vehicle (EV) industry continues to expand rapidly. However, regional performance varies, with some EV markets approaching near-mainstream status, while others remain stuck in neutral. Overall, global EV-sales volumes are becoming large enough to create substantial profit pools for well-positioned suppliers and
negative impact on traditional OEM profit margins.
7
McKinsey – August 2019
EV sales grew to more than 2M units globally in 2018 Increase of 63% a year Penetration rate of 2.2% EVs still only a fraction
8
9
1,966.6 MWh
That’s a lot of energy (cumulative)
5 states
With residential storage targets in policy
Residential storage deployments growth
10
1,966.6 MWh
That’s a lot of energy (cumulative)
5 states
With residential storage targets in policy
Residential storage deployments growth
11
EPRI 2020
14
15
The European EV market saw moderate growth (an increase of 90,000 units), with a mixed picture at the country level. Norway 40 percent (market share) Sweden 7 percent France, Germany, UK, US ~ 2 percent Tesla sold 367,500 Model 3 cars in 2019
16
Shanghai Gigafactory 3
18
Edison Electric Institute
NAHB – Eye on Housing
Code requirements today
19
IBC 406.2.7 Electric vehicle charging
vehicle charging stations shall be installed in accordance with NFPA 70. Electric vehicle charging system equipment shall be listed and labeled in accordance with UL 2202. Electric vehicle supply equipment shall be listed and labeled in accordance with UL 2594. Accessibility to electric vehicle charging stations shall be provided in accordance with Chapter 11.
21
SECTION R327 STATIONARY STORAGE BATTERY SYSTEMS R327.1 General. Stationary storage battery system shall comply with the provisions of this section. R327.2 Equipment listings. Stationary storage battery systems shall be listed and labeled for residential use in accordance with UL 9540. Exceptions:
allowed to be installed outdoors or in detached sheds ….
provided that the installation complies with Section 625.48 of NFPA 70.
22
R327.3 Installation. Stationary storage battery systems shall be installed in accordance with the manufacturer’s instructions …, and shall not be installed within habitable space of a dwelling unit. R327.4 Electrical installation. Stationary storage battery systems shall be installed in accordance with NFPA 70. Inverters shall be listed and labeled in accordance with UL 1741 or provided as part of the UL 9540
R327.5 Ventilation. Indoor installations of stationary storage battery systems that include batteries that produce hydrogen or other flammable gases during charging shall be provided with ventilation in accordance with Section M1307.4.
23
NFPA 70 – National Electric Code (NEC)
Article 625 Electrical Vehicle Charging System. Developing in the 2011 NEC, with UL 2202-2009 Standard for Electric Vehicle Charging System Equipment, and further in the 2014 NEC, with the addition of UL 2594-2013 Standard for Electric Vehicle Supply Equipment, the detail associated with Electric Vehicle Charging Systems has been increasing. The 2017 NEC covers safety requirements for charging and for connecting the charging equipment to the EV through either a conductive, inductive or wireless power transfer.
24
25
listing for the vehicle. Energy Raters should be aware of the need for ventilation to prevent the accumulation of off-gasses that may occur during charging, or during a thermal runaway event.
2018 IRC – Why is ventilation important for EV’s or ESS?
With tight homes the possibility of trapping the gasses is high.
The sufficient diffusion and dilution of hydrogen gas from gas- emitting batteries prevents a hazardous condition.
During the charging process certain batteries emit hydrogen gas, which is colorless, odorless, tasteless, nontoxic, and flammable.
At atmospheric pressure, the flammable range for hydrogen is 4-75% by volume in air.
Follow manufacturer instructions along with C&S.
26
How cities are expediting the process
27
▪
ClimateMayors.org
▪
Usmayors.org
▪
C40 CITIES – C40.org
Adopted the 2018 IECC – increased efficiency Develop stretch code and incentives Continue to increase building code to net-zero energy for new buildings by 2035, electrification next Increased charging requirements for one- and two-family dwellings to
29
At least one required garage receptacle 208/240-volt 50-ampere minimum dedicated branch circuit ready Exception: Additions and alterations to existing one- or two-family dwellings and townhouses are exempt from the EV charging requirement
30
All new single-family dwellings, two-family dwellings and townhomes Required to provide infrastructure to accommodate the future Electric Vehicle Supply Equipment Electrical capacity for a 40- ampere 240-volt branch circuit Absent an attached or detached garage, an underground electrical conduit shall be provided between the dwelling and the designated parking space for the dwelling
31
Single family parking, garage, carport, at least one parking space shall be EV Ready Multifamily also required – depending upon number parking spaces EV Ready 208/240 volt, 40-amp outlet including conduit and wiring and panel
32
New one- and two-family dwellings and town-houses with attached private garages. Each dwelling unit, install a listed raceway (nominal 1-inch diameter) Dedicated 208/240-volt branch circuit. The race way shall terminate in close proximity to the proposed location of an EV charger. Three options Conduit Only, EVSE-Ready Outlet,
33
Ordinance underway in the city New one- and two-family dwellings and town-houses with attached private garages. Dedicated 208/240-volt 50-ampere branch circuit outlet One outlet per dwelling unit Exception – when the addition of 50-amp circuit exceeds 200 amp panel capacity
34
To be Published this year
35
Definitions: ELECTRIC VEHICLE SUPPLY EQUIPMENT (EVSE). The conductors, including the ungrounded, grounded, and equipment grounding conductors, and the Electric Vehicle connectors, attachment plugs, and all other fittings, devices, power outlets, or apparatus installed specifically for the purpose of transferring energy between the premises wiring and the Electric Vehicle.
36
Definitions: EV CAPABLE SPACE. Electrical panel capacity and space to support a minimum 40-ampere, 208/240-volt branch circuit for each EV parking space, and the installation of race ways, both underground and surface mounted, to support the EVSE. EV READY SPACE. A designated parking space which is provided with one 40-ampere, 208/240-volt dedi- cated branch circuit for EVSE servicing Electric Vehicles The circuit shall terminate in a suitable termination point such as a receptacle, junction box, or an EVSE, and be located in close proximity to the proposed location of the EV parking spaces.
37
R404.2 (IRC N1104.2) Electric Vehicle (EV) charging for new construction. New construction shall facilitate future installation and use of Electric Vehicle Supply Equipment (EVSE) R404.2.1 (IRC N1104.2.1) One- to two-family dwellings and townhouses. Provide at least one EV Ready Space. The branch circuit shall be identified as “EV Ready” in the service panel and the termination marked as “EV Ready”.
38
R404.2.2 (IRC N1104.2.2) Multifamily dwellings. EV Ready Capable Spaces shall be provided Calculation of percent spaces The service panel or subpanel circuit directory shall identify as “EV Capable” or “EV Ready”. Raceway location shall be permanently and visibly marked as “EV Capable”.
39
R404.2.2 (IRC N1104.2.2) Multifamily dwellings. EV Ready Capable Spaces shall be provided Calculation of percent spaces The service panel or subpanel circuit directory shall identify as “EV Capable” or “EV Ready”. Raceway location shall be permanently and visibly marked as “EV Capable”.
40
How are utilities participating with EVs and storage
41
42
43
External Forces
management
leadership
44
SRP EV Strategic Principles
availability is increasing
commercial programs over the next few years.
45
ENERGY STAR Homes program (May 2020)
Any questions? jmeyers@swenergy.org Terry.Rother@srpnet.com
