SLIDE 1
Parallel File Systems
John White
Lawrence Berkeley National Lab
Topics
- Defining a File System
- Our Specific Case for File Systems
- Parallel File Systems
- A Survey of Current Parallel File
Systems
- Implementation
Parallel File Systems John White Lawrence Berkeley National Lab - - PowerPoint PPT Presentation
Parallel File Systems John White Lawrence Berkeley National Lab - - PowerPoint PPT Presentation
Parallel File Systems John White Lawrence Berkeley National Lab Topics Defining a File System Our Specific Case for File Systems Parallel File Systems A Survey of Current Parallel File Systems Implementation What is a
SLIDE 2
SLIDE 3
What is a File System?
- Simply, a method for ensuring
▪ A Unified Access Method to Data ▪ Organization (in a technical sense…) ▪ Data Integrity ▪ Efficient Use of Hardware
SLIDE 4
The HPC Application (our application)
- Large Node Count
- High IO Code (small file operations)
- High Throughput Code (large files fast)
- You Can Never Provide Too Much Capacity
SLIDE 5
What’s the Problem With Tradition?
- NFS/CIFS/AFP/NAS is slow
▪
Single point of contact for both data and metadata
▪
Protocol Overhead
▪
File based locking
▪
We want parallelism from the application to disk
- We Need a Single Namespace
- We Need Truly Massive Aggregate Throughput
(stop thinking MB/s)
- Bottlenecks are Inherent to Architecture
- Most Importantly:
SLIDE 6
- Researchers Just Don’t Care
▪ They want their data available everywhere ▪ They hate transferring data (this bears repeating) ▪ Their code wants the data several cycles ago ▪ If they have to learn new IO APIs, they commonly
won't use it, period
▪ An increasing number aren’t aware their code is
inefficient
SLIDE 7
Performance in Aggregate: A Specific Case
- File System capable of Performance of 5GB/s
- Researcher running an analysis of past stock ticker
data ▪ 10 independent processes per node, 10+ nodes, sometimes 1000+ processes ▪ Was running into “performance issues”
- In Reality, code was hitting 90% of peak performance
▪ 100s of processes choking each other ▪ Efficiency is key
SLIDE 8
Parallel File Systems
- A File System That Provides
▪ Access to Massive Amounts of Data at Large Client
Counts
▪ Simultaneous Client Access at Sub-File Levels ▪ Striping at Sub-File Levels ▪ Massive Scalability ▪ A Method to Aggregate Large Numbers of Disks
SLIDE 9
Popular Parallel File Systems
- Lustre
▪
Purchased by Intel
▪
Support offerings from Intel, Whamcloud and numerous vendors
▪
Object based
▪
Growing feature list
∼ Information Lifecycle Management ∼ “Wide Area” mounting support ∼ Data replication and Metadata clustering planned
▪
Open source
∼ Large and growing install base, vibrant community ∼ “Open” compatibility
SLIDE 10
Popular Parallel File Systems
- GPFS
▪
IBM, born around 1993 as Tiger Shark multimedia file system
▪
Support direct from vendor
▪
AIX, Linux, some Windows
▪
Ethernet and Infiniband support
▪
Wide Area Support
▪
ILM
▪
Distributed metadata and locking
▪
Matured storage pool support
▪
Replication
SLIDE 11
Licensing Landscape
- GPFS (A Story of a Huge Feature Set at a Huge Cost)
▪ Binary ∼ IBM licensing
- Per Core
▪ Site-Wide
- Lustre
▪ Open ▪ Paid Licensing available tied to support offerings
SLIDE 12
Striping Files
SLIDE 13
SAN – All nodes have access to storage fabric, all LUNs
SLIDE 14
Direct Connect – A separate storage cluster hosts and exports via common fabric
SLIDE 15
Berkeley Research Computing
- Current Savio Scratch File System
▪ Lustre 2.5 ▪ 210TB of DDN 9900 ∼ ~10GB/s ideal throughput ▪ Accessible on all nodes
- Future
▪ Lustre 2.5 or GPFS 4.1 ▪ ~1PB+ Capacity ▪ ~20GB/s throughput ▪ Vendor yet to be determined
SLIDE 16
Berkeley Research Computing
- Access Methods
▪ Available on every node ∼ POSIX ∼ MPIIO ▪ Data Transfer ∼ Globus Online
- Ideal for large transfers
- Restartable
- Tuned for large networks and long distance
- Easy to use graphical interface online
∼ SCP/SFTP
- Well known
- Suitable for quick and dirty transfers
SLIDE 17
Current Technological Landscape
- Tiered Storage (Storage Pools)
▪ When you have multiple storage needs within a single namespace ∼ SSD/FC for for jobs, metadata (Tier0) ∼ SATA for capacity (Tier1) ∼ Tape for long-term/archival (Tier2)
- ILM
▪ Basically, perform actions on data per a rule set ∼ Migration to Tape ∼ Fast Tier 0 storage use case ∼ Purge Policies
- Replication
▪ Dangers of metadata operations ▪ Long term storage
