Paper Motivation

• Fixed geometric structures of CNN models

– “CNNs are inherently limited to model geometric

transformations”

• Higher-level features combine lower-level

features at fixed positions as a weighted sum

• Pooling chooses the dominating features /

averages features at fixed positions

Tomas Jenicek, CMP, CVUT 3

Invariance to Geometric Transformations

• Learned from data

augmentation

• Using transformation-

invariant features and algorithms

• “Unknown or complex

geometric transformations not learned or modeled”

Tomas Jenicek, CMP, CVUT 4

Standard Convolution and RoI Pooling

• Convolution samples feature map at fixed

locations

• RoI pooling reduces the spatial resolution at a

fixed ratio

• “The higher the layer, the less desired

behaviour”

Tomas Jenicek, CMP, CVUT 5

Deformable Convolution

• Adds 2D offset to the regular grid sampling

locations

• Free form deformation of the sampling grid

Tomas Jenicek, CMP, CVUT 6

Deformable Convolution

• Offsets are learned from the preceding feature

maps via additional convolutional layers

Tomas Jenicek, CMP, CVUT 7

Deformable RoI Pooling

• Adds 2D offset to each bin position in the regular

bin partition

• Adaptive part localization for objects with different

shapes

Tomas Jenicek, CMP, CVUT 8

Deformable RoI Pooling

• Offsets are learned from the preceding feature

maps via additional RoI and a fully connected layer

Tomas Jenicek, CMP, CVUT 9

Deformable Position-Sensitive RoI Pooling

• Differs by having a different set of feature maps

for each bin position

Tomas Jenicek, CMP, CVUT 10

Deformable Convolution and RoI Pooling Summary

• Inference: offsets depend on the input features
• Learning: offsets are learned from data
• Filters are differentiable

Tomas Jenicek, CMP, CVUT 11

Method Details

• Offsets are fractional → bilinear interpolation
• For (PS) RoI pooling, normalized offsets must

be used

• The number of additional parameters

– Convolution and RoI pooling: – PS RoI pooling:

• Learning rate for offsets can be different

Tomas Jenicek, CMP, CVUT 12

PS RoI Offsets Examples

• One 3x3 deformable PS RoI pooling layer
• Input: a bounding box with a label

Tomas Jenicek, CMP, CVUT 13

PS RoI Offsets Examples

Tomas Jenicek, CMP, CVUT 14

Conv Offsets Examples

• Three consecutive

3x3 deformable convolutional layers = 9^3 points

Tomas Jenicek, CMP, CVUT 15

Conv Example – Man and a Goat

• Blue dots – standard

convolution sample locations

• Red dots – deformable

convolution sample locations

• For 1, 2 and 3 consequent

layers

Tomas Jenicek, CMP, CVUT 16

Conv Example – Man and a Goat

• Center of convolution on a

man, sky and grass

• For 3 consequent layers

Tomas Jenicek, CMP, CVUT 17

Conv Example – Man and a Goat

• The magnitude of offsets
• For 3 consequent layers –

res5a, res5b and res5c

Tomas Jenicek, CMP, CVUT 18

Conv Example – Man and a Goat

• The anisotropic scale HSV

visualization

• Red – horizontal, Green –

vertical

• For 3 consequent layers

Tomas Jenicek, CMP, CVUT 19

Conv Example – Man and a Goat

• Offsets

HSV visual.

• For 3

layers

Tomas Jenicek, CMP, CVUT 20

Conv Example – Cars

• The magnitude of offsets
• For 3 consequent layers
• The foreground-

background separation can be seen

Tomas Jenicek, CMP, CVUT 21

Affine Transformation Approximation

• The “unknown and complex” transformation was approximated by

an affine transformation

• Format is MEAN (STD), the first is vertical axis
• Unit is pixels in the feature map
• Other tested images had similar results

Man and a Goat Cars Mean squared error 3.1 (1.5) 2.7 (1.4) Scale 3.4, 3.7 (0.8, 1.1) 2.9, 3.6 (1.0, 1.1) Translation 0.8, 0.0 (1.3, 0.2) 0.3, 0.0 (1.2, 0.1) Rotation

• 0.1 (0.0)
• 0.1 (0.0)

Shear 0.0 (0.0) 0.0 (0.0)

Tomas Jenicek, CMP, CVUT 22

Statistics of Learned Scale - Effective Dilation

• The mean of the distances between all adjacent

pairs of sampling locations in the deformable convolution filter

Tomas Jenicek, CMP, CVUT 23

Remarks

• The shift is a function of feature maps and not

constrained by any (e.g. affine) transformation

• surprisingly no need for shift regularization

Tomas Jenicek, CMP, CVUT 24

Relation to Deformable Part Models

• Maximizing the similarity of parts while minimizing the inter-

part connection cost

• Inference can be converted to CNN, learning not end-to-end
• Deformable convolutions: no spatial relations between

parts, unlimited in modeling deformations

Tomas Jenicek, CMP, CVUT 25

Relation to Spatial Transform Networks

• 1. Localization net
• Input: feature map
• Output: affine transformation
• 2. Grid generator
• Generate a sampling grid according to transformation
• 3. Sampler

Tomas Jenicek, CMP, CVUT 26

Relation to Spatial Transform Networks

• Can be inserted between any two layers
• Deformable convolutions:

– No global parametric transformation – Easier training

Tomas Jenicek, CMP, CVUT 27

Relation to Atrous / Dilated Convolutions

• Exponential expansion of the receptive field
• Deformable convolutions: input-dependent and

learnable dilated convolution

• Both can replace filters with larger receptive field

while constraining their connectivity

Tomas Jenicek, CMP, CVUT 28

Relation to Active Convolution

• Learning the shape of convolution during training
• Deformable convolutions: input-dependent
• ffsets

Tomas Jenicek, CMP, CVUT 29

Relation to Dynamic Filter Network

• Weights for convolution are generated from the

input feature map

• Deformable convolutions: the same but for
• ffsets

Tomas Jenicek, CMP, CVUT 30

Their Task

• Semantic segmentation
• Object detection

Tomas Jenicek, CMP, CVUT 31

Their Setup

SoA object detection and semantic segmentation CNNs:

• 1. Deep network generates feature maps

– Replace last 3 conv layers with deformable

• 2. Shallow task specific network generates results

– Replace (PS) RoI pooling with deformable

Convolutions and offsets are learned simultaneously

Tomas Jenicek, CMP, CVUT 32

Results

• Object detection

– VOC 07: 82.3 vs. 79.6 mAP@0.5 – COCO: 56.8 vs. 54.3 mAP@0.5

• Semantic segmentation

– Cityscapes: 75.2 vs. 70.3 mIoU – VOC 12: 75.9 vs. 70.7 mIoU

• Others’ results

– COCO (with Soft-NMS): 62.8 mAP@0.5

Tomas Jenicek, CMP, CVUT 33

Paper Evaluation – Formal Objections

• Page 2 formula (2) - notation is

misleading since depends on

• Page 3 paragraph 3 – scalar gamma further

scales normalized offsets, empirically set to 0.1

• Page 5 figure 4 – figure is misleading, the
• utput feature map has depth (C+1)

Tomas Jenicek, CMP, CVUT 34

Paper Evaluation - Subjective Objections

• Page 3 paragraph 1 and 2 – notation

is ambiguous

• Max pooling application is missing

Tomas Jenicek, CMP, CVUT 35

References

• Jaderberg, Max, Karen Simonyan, and Andrew Zisserman. "Spatial

transformer networks." Advances in Neural Information Processing

• Systems. 2015.
• Jeon, Yunho, and Junmo Kim. "Active Convolution: Learning the Shape of

Convolution for Image Classification." arXiv preprint arXiv:1703.09076 (2017).

• Yu, Fisher, and Vladlen Koltun. "Multi-scale context aggregation by dilated

convolutions." arXiv preprint arXiv:1511.07122 (2015).

• Felzenszwalb, Pedro F., et al. "Object detection with discriminatively

trained part-based models." IEEE transactions on pattern analysis and machine intelligence 32.9 (2010): 1627-1645.

• De Brabandere, Bert, et al. "Dynamic filter networks." Neural Information

Processing Systems (NIPS). 2016.
