Paper ID # NC01 Design and Development of a Microcontroller Based Automatic Blood Flow Monitoring and Controlling System Authored by

• Md. Sumon Ali and Muhibul Haque Bhuyan

Department of EEE, Southeast University

Presented By

• Md. Suman Ali

Outline of the Presentation

• Objectives
• Introduction
• Working Method
• Description of the Work
• Future Work

Objectives of the Work

The objectives of the research are:

• To find the drawback of existing blood flow

controllers

• To design an automated blood flow monitor which

is able to measure blood flow rate

• To build a low cost blood flow controller

Introduction

• The requirement for health care are rapidly rising with the

continuous growing of the world population.

• Tremendous success in medical technology has been
• bserved

with the rapid advancement

• f

sensor microcontrollers, and computers’ prompt development.

• Numerous technological innovation designs are taken for the

advantage of medical service improvement.

• The actual goal of this kind of function is to assist the daily

life of a patient through building an automated and price efficient blood tracking method.

• Automatic blood flow is developed to assist the doctor or

nurse to monitor and control the blood flow rate.

Overview of the System

Microcontroller

Smartphone Blood Bottle Bluetooth Module Keypad Stepper Motor Optical Sensor Signal Amplifier Flow Controller Alpha Numeric LCD Power Supply

Circuit Diagram

Hardware Arrangement of the System

Completed Project

Working Principle

• Microcontroller is used as the controlling unit.
• The developed flow sensor is attached to the neck of the

blood bottle.

• The output signal from the flow sensor is amplified and

then feed to microcontroller’s interrupt pin to calculate drop interval.

• A high precision blood flow controller is attached with

blood delivery pipe.

• If any mismatch detected, the microcontroller sends

control signal to blood flow controller in order to correct.

Sensor Output

IR Photo-detector Output Amplified Sensor Signal

Advantages

Potential cardiac arrest reduces Reduced hyper sensitivity Less wastage of time Reduced severe dehydration Less possibility of Edema Low cost device

Calculation and Result

No. Set value Drop/min Actual value Drop/min Settling Time (sec) 1 30 30 75 2 60 60 20 3 130 131 33 4 150 150 62 5 200 199 85

Relation between Set value drop/min & actual drop/min

Conclusion

• The objectives of designing and implementing a low-cost

automated blood control device using smart phone for medical application successfully achieved.

• In terms of performance and reliability, this project has

provided an accurate method of blood flow controlling compared to the existing researches.

Future Works

Some additional features may be added to this system:

• PID controller can be added to make fast

and accurate controller.

• IoT technology may be used here
• Heart pulse rate sensor
• Blood pressure sensor
• Other type of fluid flow can be measured
