Overview Webinar

Grassland Project Protocol V2.0 February 24, 2017

This material is based upon work supported by the Natural Resources Conservation Service, U.S. Department of Agriculture, under number 69-3A75-16-025

Agenda

• 1. Background
• 2. Presentation of v2.0 updates
• 3. Registry software updates
• 4. Audience questions

BACKGROUND

Section 1

Climate Action Reserve

• 501(c)3 nonprofit, founded in 2001
• Voluntary offset registry, and approved Offset

Project Registry for CARB

• Adopted 18 offset project protocols in the US

and Mexico

• More than 87M credits issued to voluntary and

compliance offset projects

Background

• July 22, 2015: GPP v1.0 adopted
• September 2015: Awarded USDA NRCS Conservation

Innovation Grant for outreach, implementation, pilot projects, and protocol update

• Spring 2016: Released Project Development Handbook,

conducted stakeholder outreach

• July 2016: Listed 2 pilot projects in Colorado
• September 2016: Initiated protocol update
• January 2017: GPP v2.0 Adopted by Reserve Board

[hold for project map]

GPP overview

• Avoided conversion of grassland to cropland
• Eligibility:

– Financial threshold as proxy for conversion pressure – Suitability threshold to limit projects to arable land

• Quantification:

– Baseline avoided loss of soil C, as well as emissions from cultivation – Project emissions from grazing, compost, fuels, etc. – Calculation tool is provided by the Reserve

GPP overview (con’t)

• Permanence ensured through conservation

easement, or transfer to federal ownership

• Project area must be grassland for at least 10

years prior to the project

• Verification can be conducted remotely
• Multiple projects can be managed together as a

“Cooperative”

• Flexible verification schedules
• Crediting period is up to 50 years

UPDATES FROM V1.0 TO V2.0

Section 2

GPP v2.0 highlights

Major changes in bold

• Allow for irrigation of project area
• New start date option
• New options for suitability threshold
• New ecosystem health assessments
• Removed accounting for shrubs
• Reduced buffer pool contribution for accredited

land trusts

• Updated soil texture class names
• Minor language improvements

Terminology change

“Project Developer” is now “Project Owner”

• GPP v1.0 used “Project Developer” as a legal

term, referring to the entity with ownership of the GHG emission reductions

• v1.0 usage caused confusion among users
• “Project Owner” has the same definition

Irrigation allowed in project

Irrigation now allowed during project

• GPP v1.0 prohibits irrigation of the project area
• Stakeholders suggested that moderate irrigation can

improve rangeland health without significant drawbacks

• v2.0 allows for irrigation

– Any increases in electricity emissions related to pumping must be accounted for – Also need to account for N2O emissions from leaching, volatilization, and run-off

New start date option

New option allows project submittal to define start date

– Very common approach for forestry – Project is “submitted” when the form is uploaded and the “submit” button is clicked in the registry software

• Only applicable before the project easement is recorded
• Easement must still be in place prior to completion of

initial verification

• Simplifies cooperative management

– Submit all cooperative projects at once and they will all have the same start date

Suitability threshold options updated

Replaced national default with two options:

– Option 1: Default value by Major Land Resource Area – Option 2: Local assessment

• Stakeholder feedback that national default was too restrictive for some

areas

• Staff analysis concluded that national default was too low for some

areas and too high for others

• Staff conducted GIS analysis of the Land Capability Classification of

existing cropland, controlling for irrigation

• Non-irrigated threshold by default
• Irrigated threshold available if project can prove access to irrigation in

the baseline

91% 94% 50% 80% 50% 93% 86% 97% 90% 91% 92% 93% 95% 89% 50% 84% 86% 93% 52% 87% 94% 67% 87% 95% 97% 90% 91% 84% 95% 88% 89% 93% 75% 76% 86% 90% 90% 60% 74% 78% 50% 92% 93% 92% 92% 83% 93% 92% 98% 61% 78% 93% 94% 93% 85% 87% 96% 98% 95% 98% 98% 96% 97% 94% 86% 58% 90% 82% 84% 84% 94% 98% 82% 92% 89% 92% 97% 74% 93% 91% 90% 67% 84% 97% 83% 97% 91% 92% 50% 92% 77% 97% 88% 85% 97% 94% 92% 91% 50% 50% 94% 91% 82% 95% 93% 96% 87% 50% 77% 94% 83% 63% 98% 85% 75% 85% 87% 90% 97% 89% 90% 78% 95% 61% 99% 93% 97% 97% 73% 98% 85% 70% 90% 98% 94% 63% 94% 91% 85% 98% 98% 80% 97% 50% 88% 83% 90% 96% 93% 89% 90% 93% 86% 94% 88% 85% 94% 92% 93% 90% 83% 89% 85% 98% 91% 77% 85% 96% 78% 93% 88% 83% 93% 98% 93% 85% 83% 78% 78% 86% 78% 90% 93% 93% 66% 78% 85% 83% 94% 66% 94% 94% 66% 94% 94% 66% 78% 77% 66% 66%

Non-irrigated results

Irrigated results

99% 95% 97% 97% 97% 97% 99% 99% 78% 98% 97% 96% 93% 95% 99% 97% 94% 97% 99% 99% 94% 96% 97% 98% 96% 93% 95% 87% 88% 99% 93% 73% 95% 96% 94% 75% 99% 97% 94% 87% 98% 75% 96% 92% 87% 95% 75% 99% 95% 99% 73% 97% 99% 95% 92% 95% 99% 99% 97% 99% 99% 99% 95% 99% 99% 99% 99% 73% 99% 99%

Ecosystem health assessments

Periodic ecosystem health assessments now required for eligibility

– Follow the BLM Rangeland Health Assessment protocol – Assessments at least every 6 years – Seriously degraded lands must show improvement

• Allows for a long-term view of the health of the project

area, ensuring stability of belowground carbon pools

• Can help identify non-event-related reversals
• Assessment can be completed with minimal training and
• nly a few hours of site activity

https://jornada.nmsu.edu/monit-assess/manuals/assessment

Rangeland Health Assessment protocol

• Ecological Site Description for reference

conditions for 17 different metrics

• Assess each metric on a scale of deviation
• Adaptive management to

improve degraded areas

• Ineligible for reporting period if

condition worsened over time for avoidable reasons

https://jornada.nmsu.edu/monit-assess/manuals/assessment

None to slight Slight to moderate Moderate Moderate to extreme Extreme

Accounting for shrubs removed

Woody shrubs removed from v2.0 quantification

• Optional pool in GPP v1.0
• GPP v1.0 does not properly account for shrubs in

the context of fire and reversals

• Over two years of outreach, zero stakeholders

have expressed interest in accounting for shrubs

• Adds significant effort and complexity to

quantification and verification

• Could be re-worked and added back in the future

Risk of financial failure updated

Buffer pool contribution updated: RiskFF = 0% where the Project Owner is accredited land trust

• V1.0 applies 10% RiskFF for projects without the

Recorded PIA, subordination clause Type I

• Land Trust Accreditation Commission requires

proof of financial resources to support the easement into the future, including legal costs

• Accredited land trusts can, categorically, be

viewed as a stable counterparties for the PIA

• V2.0 applies 0% risk to these organizations

Soil texture class names updated

Renamed the three soil texture classes

• V1.0 names can be confusing with the various

qualifiers used in the soil survey

– E.g., “Sandy loam” = “Sand”

• Recommended by contractors

GPP v1.0 GPP v2.0 Sand = Coarse Loam = Medium Clay = Fine

REGISTRY SOFTWARE UPDATES

Section 3

Registry software updates

• New account type: “Project Owner” (PO)

– Used by Cooperative participants who are the “Project Owner” as defined in the protocol

• Reduced fee
• Limited functionality

– Cooperative Developers use “Project Developer” account type

• Cooperative developer submits and manages projects

– Cooperative ID assigned by the Reserve Administrator – Selects a PO for each project – CRTs will be issued to the PO by automatic forward transfer

• Common buffer pool among project types

AUDIENCE QUESTIONS

Section 4

Thank you!

Join us at the following events: Contact: max@climateactionreserve.org (213) 785-1233

Event Location Date

Navigating the American Carbon World

San Francisco, CA April 19-21

Northwest Grazing Conference

Pendleton, OR May 10-11

Montana Grassland Workshop

TBD, MT TBD (summer)
