IEEE 1149.1 JTAG

Boundary Scan Standard

Shaahin Hessabi Department of Computer Engineering Sharif University of Technology Adapted, with modifications, from lecture notes prepared by the book authors

Slide 2 of 36 Sharif University of Technology Lecture 28: Boundary Scan

Outline

 Bed-of-nails tester  Motivation for boundary scan standard  System view of boundary scan hardware  Elementary scan cell  Test Access Port (TAP) controller  Boundary scan instructions  Summary

Slide 3 of 36 Sharif University of Technology Lecture 28: Boundary Scan

Bed-of-Nails Tester Concept

Slide 4 of 36 Sharif University of Technology Lecture 28: Boundary Scan

Bed-of-Nails Tester

Slide 5 of 36 Sharif University of Technology Lecture 28: Boundary Scan

Motivation for Standard

 Bed-of-nails printed circuit board tester gone

• We put components on both sides of PCB &

replaced DIPs with flat packs to reduce inductance

 Nails would hit components

• Reduced spacing between PCB wires

 Nails would short the wires

• PCB Tester must be replaced with built-in test

delivery system -- JTAG does that

• Need standard System Test Port and Bus
• Integrate components from different vendors

 One chip has test hardware for other chips  Test bus identical for various components

Slide 6 of 36 Sharif University of Technology Lecture 28: Boundary Scan

Purpose of Standard

 Lets test instructions and test data be serially fed into a CUT

• Allows reading out test results
• Allows RUNBIST command as an instruction

 Too many shifts to shift in external tests

 JTAG can operate at chip, PCB, & system levels  Allows control of tri-state signals during testing  Lets other chips collect responses from CUT  Lets system interconnect be tested separately from components  Lets components be tested separately from wires

Slide 7 of 36 Sharif University of Technology Lecture 28: Boundary Scan

System Test Logic

Slide 8 of 36 Sharif University of Technology Lecture 28: Boundary Scan

Instruction Register Loading with JTAG

Slide 9 of 36 Sharif University of Technology Lecture 28: Boundary Scan

System View of Interconnect

Slide 10 of 36 Sharif University of Technology Lecture 28: Boundary Scan

Boundary Scan Chain View

Slide 11 of 36

Elementary Boundary Scan Cell

2.

Scan mode: Shift DR = 1

First scan FF is driven by TDI, Last scan FF drives TDO 3.

Capture mode: Shift DR = 0

4.

Update mode: Mode-control = 1

Sharif University of Technology Lecture 28: Boundary Scan

1.

Normal mode: Mode-control = 0

Slide 12 of 36 Sharif University of Technology Lecture 28: Boundary Scan

Serial Board / MCM Scan

Slide 13 of 36 Sharif University of Technology Lecture 28: Boundary Scan

Parallel Board / MCM Scan

Slide 14 of 36 Sharif University of Technology Lecture 28: Boundary Scan

Independent Path Board / MCM Scan

Slide 15 of 36 Sharif University of Technology Lecture 28: Boundary Scan

Tap Controller Signals

 Test Access Port (TAP) includes these signals:

• Test Clock Input (TCK) -- Clock for test logic

 Can run at different rate from system clock

• Test Mode Select (TMS) -- Switches system from

functional to test mode

• Test Data Input (TDI) -- Accepts serial test data

and instructions -- used to shift in vectors or one

• f many test instructions
• Test Data Output (TDO) -- Serially shifts out test

results captured in boundary scan chain (or device ID or other internal registers)

• Test Reset (TRST) -- Optional asynchronous TAP

controller reset

Slide 16 of 36 Sharif University of Technology Lecture 28: Boundary Scan

Tap Controller State Diagram

Slide 17 of 36

States of TAP Controller

 Test-Logic-Reset: normal mode  Run-Test/Idle: wait for internal test such as BIST  Select-DR-Scan: initiate a data-scan sequence  Capture-DR: load test data in parallel  Shift-DR: load test data in series  Exit1-DR: finish phase-1 shifting of data  Pause-DR: temporarily hold the scan operation (e.g., allow the

bus master to reload data)

 Exit2-DR: finish phase-2 shifting of data  Update-DR: parallel load from associated shift registers

Note: Controls for IR are similar to those for DR.

Sharif University of Technology Lecture 28: Boundary Scan

Slide 18 of 36 Sharif University of Technology Lecture 28: Boundary Scan

Tap Controller Timing

Slide 19 of 36 Sharif University of Technology Lecture 28: Boundary Scan

TAP Controller Power-Up Reset Logic

Slide 20 of 36

Boundary Scan Instructions

Slide 21 of 36

Major Modes of Operation

 Non-invasive mode: standard provides resources guaranteed to

be independent of system logic

• These resources enable asynchronous communication with the outside

world (serially read in test data and instructions or serially read out test results)

• Activities are invisible to the normal IC behavior

 Pin-permission modes: takes control of the IC I/O pins, thus

disconnecting the system logic from the outside world.

• Allow testing of the system interconnect separately from component

testing, and also allow testing of components separately from system interconnect testing.

• The testing activities totally disrupt the normal IC behavior.

Sharif University of Technology Lecture 28: Boundary Scan

Slide 22 of 36 Sharif University of Technology Lecture 28: Boundary Scan

SAMPLE / PRELOAD Instruction-- SAMPLE

Purpose:

1.

Get snapshot of normal chip output signals

2.

Put data on boundary scan chain before next instruction

Slide 23 of 36 Sharif University of Technology Lecture 28: Boundary Scan

SAMPLE / PRELOAD Instruction -- PRELOAD

Slide 24 of 36 Sharif University of Technology Lecture 28: Boundary Scan

EXTEST Instruction

 Purpose: Test off-chip circuits and board-level interconnections

Slide 25 of 36

Execution of EXTEST Instruction

Phase 1: Shift-DR (Chip1)

Sharif University of Technology Lecture 28: Boundary Scan

Phase 2: Update-DR (Chip1) Capture-DR (Chip2) Phase 3: Shift-DR (Chip2)

Slide 26 of 36

Execution of INTEST Instruction

Phase 1: Shift-DR

Sharif University of Technology Lecture 28: Boundary Scan

Phase 2: Update-DR Purpose: 1. Shifts external test patterns onto component

• 2. External tester shifts component responses out

Slide 27 of 36

Execution of INTEST Instruction (cont’d)

Phase 3: Capture-DR

Sharif University of Technology Lecture 28: Boundary Scan

Phase 4: Shift-DR

Slide 28 of 36 Sharif University of Technology Lecture 28: Boundary Scan

RUNBIST Instruction

 Purpose: Allows you to issue BIST command to component through JTAG hardware  Optional instruction  Lets test logic control state of output pins 1. Can be determined by pin boundary scan cell

• 2. Can be forced into high impedance state

 BIST result (success or failure) can be left in boundary scan cell or internal cell

• Shift out through boundary scan chain

 May leave chip pins in an indeterminate state (reset required before normal operation resumes)

Slide 29 of 36 Sharif University of Technology Lecture 28: Boundary Scan

CLAMP Instruction

 Purpose: Forces component output signals to be driven by

boundary-scan register

 Bypasses the boundary scan chain by using the one-bit

Bypass Register

 Optional instruction  May have to add RESET hardware to control on-chip logic

so that it does not get damaged (by shorting 0’s and 1’s onto an internal bus, etc.)

Slide 30 of 36 Sharif University of Technology Lecture 28: Boundary Scan

IDCODE Instruction

 Purpose: Connects the component device identification register serially between TDI and TDO

• In the Shift-DR TAP controller state

 Allows board-level test controller or external tester to read out component ID  Required whenever a JEDEC identification register is included in the design

Slide 31 of 36 Sharif University of Technology Lecture 28: Boundary Scan

Device ID Register --JEDEC Code

27 12 Part Number (16 bits) 11 1 Manufacturer Identity (11 bits) ‘1’ (1 bit)

31 28 Version (4 bits)

MSB LSB

Slide 32 of 36 Sharif University of Technology Lecture 28: Boundary Scan

USERCODE Instruction

 Purpose: Intended for user-programmable components

(FPGA’s, EEPROMs, etc.)

• Allows external tester to determine user programming of component

 Selects the device identification register as serially connected between

TDI and TDO

 User-programmable ID code loaded into device identification register

• On rising TCK edge

 Required when Device ID register included on user-programmable

component

Slide 33 of 36 Sharif University of Technology Lecture 28: Boundary Scan

HIGHZ Instruction

 Purpose: Puts all component output pin signals into high-

impedance state

 Control chip logic to avoid damage in this mode  May have to reset component after HIGHZ runs  Optional instruction

Slide 34 of 36 Sharif University of Technology Lecture 28: Boundary Scan

BYPASS Instruction

 Purpose: Bypasses scan chain with 1-bit register

Slide 35 of 36 Sharif University of Technology Lecture 28: Boundary Scan

Optional / Required Instructions

Instruction BYPASS CLAMP EXTEST HIGHZ IDCODE INTEST RUNBIST SAMPLE / PRELOAD USERCODE Status Mandatory Optional Mandatory Optional Optional Optional Optional Mandatory Optional

Slide 36 of 36 Sharif University of Technology Lecture 28: Boundary Scan

Summary

 Boundary Scan Standard has become absolutely essential;

• No longer possible to test printed circuit boards with

bed-of-nails tester

• Not possible to test multi-chip modules at all without it
• Supports BIST, external testing with ATE, and

boundary scan chain reconfiguration as BIST pattern generator and response compacter

• Now getting widespread usage
• Use scanedu for practicing with JTAG concepts
