Re liab le Quality Po we r fo r ENHANCED GEOTHERM AL SYSTEM S ENHANCED GEOTHERM AL SYSTEM S PROJECTS AND CHALENGES PROJECTS AND CHALENGES STRASBOURG 2006 STRASBOURG 2006 ORMAT Time, the only true test of reliability AJM Oct 2004

SLIDE 1

AJM Oct 2004

Re liab le Quality Po we r fo r

ENHANCED GEOTHERM AL SYSTEM S ENHANCED GEOTHERM AL SYSTEM S

ORMAT

Time, the only true test of reliability

PROJECTS AND CHALENGES PROJECTS AND CHALENGES STRASBOURG 2006 STRASBOURG 2006

SLIDE 2

1982-2006 : ORMAT’S WORLDWIDE GREEN ENERGY FROM 250 KW MODULE TO 125 MW POWER PLANTS

2 0 0 0 6 0 M W G e o t h e r m a l P o w e r P la n t a t M o k a i , N E W Z E A L A N D 1 7 3 1 2 .6 M W p la n t c o m p ris in g o f tw o O E C u n its ( 1 9 8 9 ) 1 0 5 3 T a raw e ra , N e w Z e a la n d T a raw e ra , N e w Z e a la n d 100 200 300 400 500 600 700 800 1983 1985 1987 1989 1991 1993 1995 1997 1999 2001 2003 2005

SLIDE 3

ORMAT’s GREEN POWER PLANTS

Accumulated installed generating capacity

200 400 600 800 1000 1200 1400 1983 1985 1987 1989 1991 1993 1995 1997 1999 2001 2003 2005 2007

2000 60 MW Geothermal Power Plant at Mokai, NEW ZEALAND 1731

SLIDE 4

Recovered Energy Generation (REG) Power Plants Geothermal Power Plants Remote Power Units

Global Presence Meeting the Needs of Customers in 71 Countries

Symbols indicate type of equipment installed in each country

SLIDE 5

Recovered Energy Generation Gas Compressors on Pipelines

Company Profile Main Areas of Activities

Geothermal Power Plants Recovered Energy Generation Cement Plants Remote Power Units Recovered Energy Generation from Industrial Processes

SLIDE 6

25 50 75 100 125 150

Technology and small units Technology and large solar Geothermal power units Geothermal EPC and BOP Geothermal IPP

1882

1970 1980 1990 2000

BOP & Waste Heat Small units & D/G

Sales $ Million

How Did We Get Here ?

TOTAL INVESTMENT IN R&D: MORE THAN US$100M

Developer , Owner and Operator

SLIDE 7

2006 : 150 MW IN CONSTRUCTION

4.6 MW Enagas Spain
2.9 MW Geox ,Germany
15MW Desert Peak II, USA
6 MW Goulds, USA
10 MW Galena, USA
10 MW Ormesa, USA
3 MW Heber USA
5 MW Steamboat, USA
10 MW Imperial Valey,USA
6.9 MW Denizli Turkey
6.9 MW Mokai 1A, NZ
5 MW Momotombo, Nicaragua
8 MW Hawaii, USA and
100 MW additional installations

Construction of Mokai II 45 MW ( 2004)

SLIDE 8

MOKAI 100 MW GEOTHERMAL POWER PLANT

100 MW air cooled geothermal power plant, operating from steam and brine at 17 bara / 204 o C and 100% geothermal fluid reinjection

SLIDE 9

SLIDE 10

Wairakei power station

SLIDE 11

WAIRAKEI GEOTHERMALBINARY PROJECT

SUMMARY OF TECHNICAL DATA

Heating media Brine from the 1st flash

– Temperature 127º C – Flow 2800 T/ Hr Cooling media ambient air – design temperature 11º C Output – Net system output 16.6 MW – Generated Gwhr in the 1’st year 139,6 Gwhr – Availability 1’st year 96 %

SLIDE 12

1537 Feed Pump Collector Purge System Condensate Tank & Pump Preheater Vaporizer Turbine H.P. Generator Turbine L.P. Recuperator Diffuser

1.5 1.5 – – 25 25 MW AIR COOLED ORMAT ENERGY CONVERTER MW AIR COOLED ORMAT ENERGY CONVERTER

SLIDE 13

WAIRAKEI NEW ZEALAND Ormat Energy Converter 20 MW

SLIDE 14

THE PHILOSOPHY ( 1982)

1061

SLIDE 15

PUNA 30 MW COMBINED CYCLE GEOTHERMAL POWER PLANT

SLIDE 16

24 MW GEOTHERMAL POWER PLANT ZUNIL, GUATEMALA 1999

1730

SLIDE 17

35 MW ROTOKAWA POWER PLANT

35 MW air cooled geothermal cycle power plant, operating with steam and brine

at 27 bara / 225 o C

100% geothermal fluid reinjection
Built as a turnkey EPC for Rotokawa Generation Ltd.

1251

SLIDE 18

OLKARIA GEOTHERMAL III

SLIDE 19

17 MW MIRAVALLES GEOTHERMAL

SLIDE 20

GEOTHERMAL DRILLING

SLIDE 21

GEOTHERMAL WATER PUMPING

SLIDE 22

ORMAT’s EXECUTED PROJECTS

HEATING MEDIA

Hot water
Steam
Hot oils

COOLING MEDIA

Ambient air
Water
Temperature: 80….225º C
Pressure : 1……27 bar (a)
Temperature: 80….280º C
30……. +40º C
5……….35º C

SLIDE 23

1189

125 MW UPPER MAHIAO - THE PHILIPPINES

Distributed Renewable Grid Connected Base Load Power

SLIDE 24

ORMAT ENERGY CONVERTER 250kW AIR COOLED CHP PLANT

SLIDE 25

1658

MANUFACTURING

Organic Vapor Turbine Assembly

SLIDE 26

1658

MANUFACTURING

Heat Exchangers Workshop

SLIDE 27

HATSHOBARU Kyushu Electric, Japan

2 MW ORMAT ENERGY CONVERTER

SLIDE 28

HATCHOBARU (Kyushu Electric, Japan), 2003 HATCHOBARU (Kyushu Electric, Japan), 2003

2 MW AIR COOLED ORMAT ENERGY CONVERTER

SLIDE 29

AVAILABILITY OF INDIVIDUAL

Ormat Energy Converters

97.6 % 3 2005 Mokai II 99.1 % 1 2000 Rogner 96.7 % 10 1993 Puna 99.1 % 20 1987 Ormesa II 98.7 % 1 1999 HZ -Lengfurt 98.2 % 6 2000 Mokai I 97.5 % 2 2005 Wairakei

98. 8 %

2 1998 Ngawha 98.6 % 3 1997 Rotokawa I 98.1 % 12 1993 Heber 98.5 % 2 1989 TOI 96.7 % 9 1986 Steamboat

Availability Number

OEC’s Commissioning Year Power Plant

SLIDE 30

Data : Courtesy of Tuaropaki Power Company

5 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100 105 110 MW Jul-05 Aug-05 Sep-05 Oct-05 Nov-05 Dec-05 Jan-06 Feb-06 Mar-06 Apr-06

Mokai 100 MW PERFORMANCE

SLIDE 31

DECENTRALIZED PRIVATE POWER GENERATION

SLIDE 32

ORMAT’S POWER PLANT ADVANTAGES

It is a tool capable to easily accommodate changes in

reservoir enthalpy and operating conditions such as temperature and pressure

Modular development, additional units may be added later

and single units can be moved to other sites.

Air cooling enabling 100 % reinjection of the geothermal

fluid

Track record for sustaining the pressure and temperature in

the reservoir and avoiding subsidence

Simple to operate and maintain
Very high availability and low cost maintenance projects
Know how capability and knowledge incorporating 40 years
f experience in manufacturing ORC based power

generations systems.

SLIDE 33

End End

Hile l L e gm ann, Hile l L e gm ann, M arke ting M anage r M arke ting M anage r Orm at I ndustrie s L td Orm at I ndustrie s L td
