Optimizing Performance of Concrete Structures with Zinc Coated Reinforcing Steel Shannon Pole, EIT October 18, 2016 International Zinc Association Outline The Corrosion Problem Batch Galvanized Mitigation Solutions Zinc in

slide-1
SLIDE 1

International Zinc Association

Optimizing Performance of Concrete Structures with Zinc Coated Reinforcing Steel

Shannon Pole, EIT

October 18, 2016

slide-2
SLIDE 2

International Zinc Association

Outline

  • The Corrosion Problem
  • Batch Galvanized
  • Mitigation Solutions
  • Zinc in Concrete
  • Continuous Galvanized
  • Research and Current Projects
  • Next Steps
slide-3
SLIDE 3

International Zinc Association

International Zinc Association

  • Trade association that represents the

interests of the zinc industry

slide-4
SLIDE 4

International Zinc Association

Corrosion

  • Affects

– Roads, bridges, buildings, airplanes, machinery, automobiles

  • $2.2 trillion -> corrosion costs worldwide
  • $660 billion -> possible savings
  • 3.3% US GDP -> corrosion mitigation
  • Zinc provides the best corrosion protection
slide-5
SLIDE 5

International Zinc Association

The USA Bridge Problem

  • 604000 bridges across the USA

– 48% state owned

  • 2/3 built 26+ years ago
  • 50-80% maintenance funds for bridge decks
  • 25-30% of corrosion could be eliminated

– If proper materials are used and maintained

slide-6
SLIDE 6

International Zinc Association

Road Salt in North America

slide-7
SLIDE 7

International Zinc Association

Galvanized Reinforcing Steel

Built in 1995 Built in 1990

slide-8
SLIDE 8

International Zinc Association

Batch Galvanized Bridges

Tappen Zee Bridge, New York Boca Chica Bridge, Florida Curtis Road Bridge, Michigan Athens Road Bridge, Pennsylvania

slide-9
SLIDE 9

International Zinc Association

Corrosion of Black Bar

  • Initially – Cosmetic Staining
  • Later – Structural Weakening
slide-10
SLIDE 10

International Zinc Association

Corrosion of Black Bar

Fe FeO Fe3O4 Fe2O3 Fe(OH)2 Fe(OH)3 Fe(OH)3‧3 H2O

1 2 3 4 5 6 Volume (cm3）

slide-11
SLIDE 11

International Zinc Association

Corrosion of Black Bar

  • In concrete, steel corrosion can cause major

deterioration

  • Corrosive elements, diffuse through the

concrete matrix to reach rebar

slide-12
SLIDE 12

International Zinc Association

Corrosion Model

ß Protection à

slide-13
SLIDE 13

International Zinc Association

Zinc Protection

Zn++ 2(OH)- 2e- Zinc Steel Zn Zn++ + 2e- 2e- + H2O +1/2 O2 2(OH)-

Zi Zinc nc Pa Paint

slide-14
SLIDE 14

International Zinc Association

Zinc in Concrete

  • Passivated by formation of a layer of

adherent crystals

– Calcium Hydroxyzincate (CHZ)

  • Reaction begins upon contact with wet

cement solution

– Ceases once concrete hardens

  • Surface film stabilizes the zinc

– Second level of barrier protection

slide-15
SLIDE 15

International Zinc Association

Migration of Zinc

Partial dissolution of the galvanized coating and zinc corrosion product migrating into the cement matrix. Migration of zinc-rich corrosion products away from the bar/matrix interface and well into the cement matrix. 1000x 100x

slide-16
SLIDE 16

International Zinc Association

Bond Strength in Concrete

slide-17
SLIDE 17

International Zinc Association

Load-Slip Characteristics

50 100 150 200 250

Slip ( m)

10 20 30 40 50 60 70 80 90 100

Load (kN)

Black Steel Galvanized Steel Epoxy Coated Steel

Galvanized Reduced slip for galvanized bars Black Epoxy

slide-18
SLIDE 18

International Zinc Association

Zinc Protection

  • Passivation Reaction Product (CHZ)
  • Barrier Coating
  • Cathodic Protection
  • High Chloride Threshold (2-4x black steel)
  • Corrosion Product Migration

– Concrete Matrix Densification – No stress generated at rebar surface

  • Low pH Tolerance (Carbonation protection)
slide-19
SLIDE 19

International Zinc Association

Batch Galvanized Coating

ASTM A767 Standard Specification for Zinc-Coated (Galvanized) Steel Bars for Concrete Reinforcement

slide-20
SLIDE 20

International Zinc Association

Batch Galvanized Process

slide-21
SLIDE 21

International Zinc Association

Continuous Galvanized Coating

Pure Zinc Layer Thin Fe2Al5-xZnx Layer ASTM A1094 - Standard Specification for Continuous Hot-Dip Galvanized Steel Bars for Concrete Reinforcement

slide-22
SLIDE 22

International Zinc Association

Improved Corrosion Resistance

Coating Type Average Depth of Loss to Passivation (um) Annealed (Intermettalic) 1.18 Pure Zinc 0.45

  • Pure Zinc corrodes at a slower rate than Iron-

Zinc Intermettalic

  • Less zinc consumed to form CHZ passivation

layer

  • Less zinc required to provide corrosion

resistance

slide-23
SLIDE 23

International Zinc Association

Zn (eta) phase current density = 2.38 A/cm2 ( ______ line) Zeta (Zn-Fe) phase current density = 3.98 A/cm2 ( _ _ _ line) Therefore Zn 1.7 times more corrosion resistant than Zn-Fe in the concrete corrosion cell pH=13 NaOH

How does the 50 µm In-Line coating corrosion resistance compare to the 85μm General Galvanized coating? Results of potentiodynamic polarization tests

slide-24
SLIDE 24

International Zinc Association

Continuous Galvanized Rebar

  • Durable, Flexible Coating

– Fabricate after coating

  • Pure Zinc

– Improved corrosion resistence

  • Low cost

– Less material, shipping, weight, etc.

slide-25
SLIDE 25

International Zinc Association

Formability

slide-26
SLIDE 26

International Zinc Association

USA trademark application 85882085 made by IZA

ASTM A1055 - pending Standard Specification for Zinc and Epoxy Dual-Coated Steel Reinforcing Bars

slide-27
SLIDE 27

International Zinc Association

Duplex Bar Formability

slide-28
SLIDE 28

International Zinc Association

Continuous Galvanized Process

slide-29
SLIDE 29

International Zinc Association

Rollers into Induction Heater

slide-30
SLIDE 30

International Zinc Association

From Heater to Zinc Bath

slide-31
SLIDE 31

International Zinc Association

Zinc Bath

slide-32
SLIDE 32

International Zinc Association

Bath through Air Knife to Quench

slide-33
SLIDE 33

International Zinc Association

Continuously Galvanized

slide-34
SLIDE 34

International Zinc Association

Quality Assurance

slide-35
SLIDE 35

International Zinc Association

Installing Galvanized Rebar

Same as Black rebar:

  • Overlap links
  • Handling procedures
  • Field Bending Possible

Optional:

  • Touch-up field cut ends
slide-36
SLIDE 36

International Zinc Association

Route 66 Bridge

slide-37
SLIDE 37

International Zinc Association

University of Waterloo

  • Tomb stone samples

– Sound – Transverse & Longitudinal Cracks

  • Cyclical ponding

– 21% chloride brine

  • No visible corrosion
slide-38
SLIDE 38

International Zinc Association

Corrosion Current - Sound

slide-39
SLIDE 39

International Zinc Association

Corrosion Current - Transverse

slide-40
SLIDE 40

International Zinc Association

Corrosion Current - Longitudinal

slide-41
SLIDE 41

International Zinc Association

Shenzhen Metro Line No. 11, Shenzhen, China

  • Currently under construction
  • Opening later this year
  • Fastest Metro line in Shenzhen with speeds of 120 km/h
  • Galvanized rebar is being produced by Xiamen Newsteel
slide-42
SLIDE 42

International Zinc Association

G7 Beijing–Ürümqi Expressway

Connects the cities of Beijing, China, and Ürümqi, Xinjiang. When complete, it will be 2,540 km (1,580 mi) in length. Galvanized rebar is being produced by Xiamen New Steel

slide-43
SLIDE 43

International Zinc Association

Comparison versus Black Bar

1 2 3 4 5 6 7 Black Epoxy Galvanized MMFX Stainless CGR* Bluebar*

FHWA, 2012 *estimated

slide-44
SLIDE 44

International Zinc Association

USA Production

  • AZZ Galvanizing

– Fall 2016 – Oklahoma

  • South Atlantic Reinforcing

– Air Wipe Method

slide-45
SLIDE 45

International Zinc Association

Continuous Galvanized Rebar

Low Cost Tough Corrosion Resistant Formable For more Information and Samples contact: Shannon Pole spole@zinc.org
