Optical Mapping Data: Data Generation and Algorithms

Sample Preparation Sequencing Assembly Analysis

Fragments Reads Contigs

What is an Optical Map?

GGCTTCCGACCACCACAACCGAATTATGAAGGATACCGAA 6,19,35

Optical maps are ordered, genome-wide, high- resolution restriction maps.

• Much longer than reads. For example, the average

map size for goat covers 360,000 bp

• Now commercially available

. Isolated DNA Microfludic device DNA is elongated and cleaved

• n the optical mapping surface

Epiflourescence microscope with CCD camera

6 3 3 4 9

6 3 3 4 9 6 3 9 4

Genome wide optical map

“There is [..] a critical need for the continued development and public release of software tools for processing optical mapping data ..”

• GigaScience 2014

Goal: tool to align the contig to a segment of an

• ptical map

Sample Preparation Sequencing Assembly Analysis

Genome-wide

• ptical map

contigs

Optical Map Data

• Previous approaches use dynamic programming
• Burrows-Wheeler Transform (BWT) would

improve time efficiency

• Challenges in applying BWT: (1) Sizing error and

(2) alphabet size

Challenges

6 3 9 4 5 4 9.5 6

Actual optical map values Optical map obtained from experiment

1 1 0.5 2

SIZING ERROR

• Previous approaches use dynamic programming
• Burrows-Wheeler Transform (BWT) would

improve time efficiency

• Challenges in applying BWT: (1) Sizing error and

(2) alphabet size

Challenges

6 3 9 4 5 4 9.5 6

Actual optical map values Optical map obtained from experiment

1 1 0.5 2

SIZING ERROR

• Previous approaches use dynamic programming
• Burrows-Wheeler Transform (BWT) would

improve time efficiency

• Challenges in applying BWT: (1) Sizing error and

(2) alphabet size

Challenges

! 𝑣𝑜𝑗𝑟𝑣𝑓 𝑔𝑠𝑏𝑕𝑛𝑓𝑜𝑢 𝑡𝑗𝑨𝑓𝑡 >

• 16,000

Twin

Sample Preparation Sequencing Assembly Analysis

Contigs

Optical Map Data

Alignment of contigs to optical map Genome-wide

• ptical map

Contig 1 Contig 2 Contig 3 Contig 5 Contig 4

Twin Algorithm

• 1. In silico digest contigs into optical maps.

TTTCCGACCACTTTTCCGAATTATGACCGAA 4,13,24

Twin Algorithm

• 1. In silico digest contigs into optical maps.
• 2. Build FM-index* and auxiliary data structures
• n the genome-wide optical map.

* a data structure that allows compression

• f the input text while still permitting fast

substring queries

BWT and FM-index

A suffix array (SA) of string S is an array of the suffixes

• f S sorted into alphabetical order.

1 acaaacgn 2 caaacgn 3 aaacgn 4 aacgn 5 acgn 6 cgn 7 gn 8 n 3 aaacgn 4 aacgn 1 acaaacgn 5 acgn 2 caaacgn 6 cgn 7 gn 8 n

acaaacgn

BWT and FM-index

A suffix array (SA) of string S is an array of the suffixes

• f S sorted into alphabetical order.

The suffix array clusters all the occurrences of every pattern together into a contiguous range!

1 acaaacgn 2 caaacgn 3 aaacgn 4 aacgn 5 acgn 6 cgn 7 gn 8 n 3 aaacgn 4 aacgn 1 acaaacgn 5 acgn 2 caaacgn 6 cgn 7 gn 8 n

acaaacgn

A suffix array (SA) of string S is an array of the suffixes

• f S sorted into alphabetical order.

The suffix array clusters all the occurrences of every pattern together into a contiguous range!

1 acaaacgn 2 caaacgn 3 aaacgn 4 aacgn 5 acgn 6 cgn 7 gn 8 n 3 aaacgn 4 aacgn 1 acaaacgn 5 acgn 2 caaacgn 6 cgn 7 gn 8 n

acaaacgn

BWT and FM-index

1 acaaacgn 2 caaacgn 3 aaacgn 4 aacgn 5 acgn 6 cgn 7 gn 8 n 3 aaacgn 4 aacgn 1 acaaacgn 5 acgn 2 caaacgn 6 cgn 7 gn 8 n

acaaacgn

A suffix array (SA) of string S is an array of the suffixes

• f S sorted into alphabetical order.

The suffix array clusters all the occurrences of every pattern together into a contiguous range!

BWT and FM-index

3 aaacgn 4 aacgn 1 acaaacgn 5 acgn 2 caaacgn 6 cgn 7 gn 8 n 1 acaaacgn 2 caaacgn 3 aaacgn 4 aacgn 5 acgn 6 cgn 7 gn 8 n

acaaacgn

A suffix array (SA) of string S is an array of the suffixes

• f S sorted into alphabetical order.

The suffix array clusters all the occurrences of every pattern together into a contiguous range!

BWT and FM-index

The Burrows-Wheeler Transform (BWT) is a permutation

• f the string such that BWT[i] = S[SA[i] - 1].

3 aaacgnac 4 aacgnaca 1 acaaacgn 5 acgnacaa 2 caaacgna 6 cgnacaaa 7 gnacaaac 8 nacaaacg

acaaacgn

BWT and FM-index

c a n a a a c g

Extract last column of SA

The Burrows-Wheeler Transform (BWT) is a permutation

• f the string such that BWT[i] = S[SA[i] - 1].

rankK(i): return the number of K’s in S[1,i]

3 aaacgnac 4 aacgnaca 1 acaaacgn 5 acgnacaa 2 caaacgna 6 cgnacaaa 7 gnacaaac 8 nacaaacg

acaaacgn

BWT and FM-index

c a n a a a c g 1 2 3 1

BWT rank

The Burrows-Wheeler Transform (BWT) is a permutation

• f the string such that BWT[i] = S[SA[i] - 1].

rankK(i): return the number of K’s in S[1,i]

3 aaacgnac 4 aacgnaca 1 acaaacgn 5 acgnacaa 2 caaacgna 6 cgnacaaa 7 gnacaaac 8 nacaaacg

acaaacgn

BWT and FM-index

c a n a a a c g 1 2 3 1

BWT rank ranka[5] = 2

The Burrows-Wheeler Transform (BWT) is a permutation

• f the string such that BWT[i] = S[SA[i] - 1].

FM-index is the compressed version of the BWT and rank.

3 aaacgnac 4 aacgnaca 1 acaaacgn 5 acgnacaa 2 caaacgna 6 cgnacaaa 7 gnacaaac 8 nacaaacg

acaaacgn

BWT and FM-index

c a n a a a c g 1 2 3 1

BWT rank

Twin Algorithm

• 1. In silico digest contigs into optical maps.
• 2. Build FM-index and auxiliary data structures
• n the genome-wide optical map.
• 3. Using the FM-index we find all alignments

between the optical map and the in silico digested contigs.

• Modified FM-index Backward Search Algorithm

FM-Index Backward Search

A recursive algorithm for finding substrings using rank and BWT

rank[c] rank[a] rank[a]

Modified FM-Index Backward Search

• Sizing error and alphabet size are challenges

to overcome

• We cannot afford a brute force enumeration
• f the alphabet at each step in the

backward search

• Novelty for optical maps: Wavelet Tree

Wavelet Tree

A Wavelet Tree converts a string into a balanced binary-tree of bit vectors, where a 0 replaces half of the symbols, and a 1 replaces the other

• half. This definition is applied recursive

{A,C,G,T} is encoded as {0,0,1,1}

ACGTATATAGGAAGA 001101010110010

Wavelet Tree

{A,C,G,T} is encoded as {0,0,1,1}

ACGTATATAGGAAGA 001101010110010

Wavelet Tree

No ambiguity!

Wavelet Tree

ACGTATATAGGAAGA 001101010110010 ACAAAAAA 01000000

{A,C} is encoded as {0,1}

Wavelet Tree

ACGTATATAGGAAGA 001101010110010 ACAAAAAA 01000000

{G,T} is encoded as {0,1}

GTTTGGG 0111000 1

Which symbols in {A, G} exist in input string?

To match x we need to find all the substrings within the range x +/- y, for tolerance y.

Modified FM-Index Backward Search

To match 9 we need to find all the substrings within the range [6, 12] , for tolerance 3.

Modified FM-Index Backward Search

2,11,10,23,53,3,5,10,14,9,11 0, 1, 0, 1, 1,0,0, 0, 1,0, 1 Genome wide

• ptical map

Modified FM-Index Backward Search

2,11,10,23,53,3,5,10,14,9,11 0, 1, 0, 1, 1,0,0, 0, 1,0, 1

To match 9 we need to find all the substrings within the range [6, 12] , for tolerance 3.

2,10,3,5,10,9 0, 1,0,0, 1,1 11,23,53,14,11 0, 1, 1, 0, 0 2,3,5 0,0,1 10,9,10 0,1, 0 2,3 0,1 5 1 11,14,11 0, 1, 0 23,53 0, 1

Modified FM-Index Backward Search

2,11,10,23,53,3,5,10,14,9,11 0, 1, 0, 1, 1,0,0, 0, 1,0, 1

To match 9 we need to find all the substrings within the range [6, 12] , for tolerance 3.

2,10,3,5,10,9 0, 1,0,0, 1,1 11,23,53,14,11 0, 1, 1, 0, 0 2,3,5 0,0,1 10,9,10 0,1, 0 2,3 0,1 5 1 11,14,11 0, 1, 0 23,53 0, 1

A recursive algorithm for finding substrings using rank and BWT

rank[c] rank[a] rank[a]

Modified FM-Index Backward Search

Wavelet Tree Query

Twin Algorithm

• 1. In silico digest contigs into optical maps.
• 2. Build FM-index and auxiliary data structures
• n the genome-wide optical map.
• 3. Using the FM-index we find all alignments

between the optical map and the in silico digested contigs.

• 4. Output the alignments in PSL format.

TWIN Test Datasets

TWIN Results

Twin is the first alignment method that is capable of handling large genome sizes

• The only index-based tool and is orders of

magnitude faster than existing approaches (patent pending)

• Pine tree (20 Gb) would take ~84 machine years

with SOMA but a couple hours with Twin

TWIN: Optical Map Aligner

CORRECTING ERRORS IN GENOMES

Mis-assembly in Genomes

Mis-assembly: Significantly large insertion, deletion, inversion, or rearrangement that is the result of decisions made by the assembly program

Correct assembly Rearrangement Deletion Insertion A R R B A R R B A R B A R R B R

Extensive vs. Local Mis-assemblies

Extensive Mis-assembly: 1 kbp in size and regions align to different strands or different chromosomes. Local Mis-assembly: smaller in size and on the same strand and same chromosome.

De Bruijn Graph of a Genome

Example Genome: ABCDEFGHICDEFGKL Example Genome: ABCDEFGHICDEFGKL

1 3 2 ABC BCD CDE DEF EFG FGK GKL FGH GHI HIC ICD

De Bruijn Graph of a Genome

ABC BCD CDE DEF EFG FGK GKL

Example Genome: ABCDEFGHICDEFGKL Example Genome: ABCDEFGHICDEFGKL

De Bruijn Graph of a Genome

ABC BCD CDE DEF EFG FGK GKL

Example Genome: ABCDEFGHICDEFGKL Resulting Erroneous Genome: ABCDEFGKL

1

Sample Preparation Sequencing Assembly Analysis

Fragments Reads Contigs

misSEQuel* Refined Contigs Reads Contigs

*(Muggli, Puglisi, Ronen, Boucher, ISMB 2015)

Sample Preparation Sequencing Assembly Analysis

Fragments Reads Contigs

Optical Map Data

misSEQuel Algorithm

• 1. Align sequence reads to contigs using a

standard alignment tool.

GGCTTCCGACCACCACAAATGGATTATGAAGGATATATGGA

misSEQuel Algorithm

• 1. Align sequence reads to contigs using a

standard alignment tool.

GGCTTCCGACCACCACAAATGGATATGAAGGATATATGGATTATGAAGGATATA

GGCTTCCGACCACCACAAATGGATTATGAAGGATATATGGA

misSEQuel Algorithm

• 1. Align sequence reads to contigs using a

standard alignment tool.

GGCTTCCGACCACCACAAATGGATTATGAAGGATATATGGA

misSEQuel Algorithm

• 1. Align sequence reads to contigs using a

standard alignment tool.

GGCTTCCGACCACCACAAATGGATATGAAGGATATATGGATTATGAAGGATATA

GGCTTCCGACCACCACAAATGGATTATGAAGGATATATGGA 1 9

misSEQuel Algorithm

• 1. Align sequence reads to contigs using a

standard alignment tool.

• 2. Build the red-black positional de Bruijn graph

based on the alignment.

Sample Preparation Sequencing

ACGTAGAATCGACCATG GGGACGTAGAATACGAC ACGTAGAATACGTAGAA

Reads Fragments Next Generation Sequencing (NGS)

ACGTAGAATCGACCATGGGGACGTAGAATACGA

Paired-End Reads / Mate-Pair Reads

Sample Preparation

Sequencing

Fragments

Read Mate Pair Concordance

A R R B A R R B A R R B Correct assembly Rearrangement Inversion

Read Depth

A R R B A R B R R R A B Correct assembly Insertion Deletion

Red-Black Positional De Bruijn Graph

I. Choose a value of 𝑙 and Δ . II. Each positional 𝑙-mer (sk) is an edge between two positional 𝑙–mers: prefix and suffix of sk. III. Positional 𝑙–mers, sk-1 and sk-1’, are glued if sk-1 and sk-1’ have the same label and their distances differ by at most Δ. IV. A sk-1 is red if the read depth is two standard deviations from the mean or there is a significant number of disconcordinate read alignments; otherwise, it is black.

A positional 𝑙-mer is a 𝑙-mer with an approximate position.

Positional Red Black de Bruijn Graph

Reads aligned to contigs: Positional k-mers with read depth: Positional Red Black de Bruijn Graph:

misSEQuel Algorithm

• 1. Align sequence reads to contigs using a

standard alignment tool.

• 2. Build the red-black positional de Bruijn graph

based on the alignment.

• 3. Remove all bulges and whirls for the red-

black positional de Bruijn graph.

misSEQuel Algorithm

• 1. Align sequence reads to contigs using a

standard alignment tool.

• 2. Build the red-black positional de Bruijn graph

based on the alignment.

• 3. Remove all bulges and whirls for the red-

black positional de Bruijn graph.

Correct assembled contigs Mis-assembled contigs A R R B A R R B A R B A R R B R A R R B

…

misSEQuel Algorithm

• 1. Align sequence reads to contigs using a

standard alignment tool.

• 2. Build the red-black positional de Bruijn graph

based on the alignment.

• 3. Remove all bulges and whirls for the red-

black positional de Bruijn graph.

• 4. Contig refinement using optical map

alignment.

Optical Map Alignment

NheI = G^CTAGC

• E. Coli optical map segment

A R R B

NheI = G^CTAGC

“GCTAGC”

Optical Map Alignment

B A R R

NheI = G^CTAGC

Correctly Assembled Contigs Align

B A R R

NheI = G^CTAGC

A R B R R

Mis-assembled Contigs Don’t Align

NheI = G^CTAGC

A R B R R

Mis-assembled Contigs Don’t Align

Results on Tularensis

Results on Tularensis

Results on Tularensis

Results on Tularensis

Results on Tularensis

Results on Tularensis

Results on Tularensis

Results on Tularensis

Results on Tularensis

Results on Pine

B B A R R

Improve Prediction

A R R R

B

Improve Prediction

A R R R Deletion between two aligned regions
