Optical core solution for FA Machine manufacturer SEIWA OPTICAL - PowerPoint PPT Presentation

Optical core solution for FA Machine manufacturer SEIWA OPTICAL CO., LTD Company Profile SEIWA OPTICAL CO., LTD Company name Company address Head Office 12-17, Yayoi 4-chome,Nakano-ku Tokyo 164-0013 JAPAN TEL : 81-3-3383-6301 , FAX


  1. Optical core solution for FA Machine manufacturer SEIWA OPTICAL CO., LTD

  2. Company Profile SEIWA OPTICAL CO., LTD ・ Company name ・ Company address ● Head Office 12-17, Yayoi 4-chome,Nakano-ku Tokyo 164-0013 JAPAN TEL : 81-3-3383-6301 , FAX : 81-3-3381-6304 E-mail : sales@seiwaopt.co.jp ・ Minister Isao Okazaki ・ Date of foundation 1964.10 / 03 ・ Capital \99,000,000- ・ Employees 112 People Uenohara Plant ・ Business 1.Microscope 2.Machine Vision (Optical, Illuminating, Video Instruments and equipment related) 3.FPD Equipment (Equipment related to LCD products) 4.Exposure equipment (PDP Production Equipment) 5.Laser system Kansai Plant(1) (form the design of special made optical units to the production /Sales) 6.Other new developed products ( LED equipment,environmental business ) ■ Tokyo Plant : Nakano-ku Tokyo ■ Technology center : Nakano-ku Tokyo ■ Kansai Plant(1) : Koyamichi, Hirakata-shi Osaka ■ Kansai Plant(2) : Tsudayamate, Hirakata-shi Osaka ■ Uenohara Plant : Uenohara-shi Yamanashi-ken Kansai Plant(2)

  3. SEIWA GROUP OFFICE Company CORECTMEDIAS CO.,LTD (est. 1964) 32-12, Yayoi-cho 2 chome, Nakano-ku, Tokyo 164-0013 JAPAN Tel.03-3382-6611 Fax.03-3382-666 Company SEIWA OPTICAL AMERICA INC. (est. 2000) 3042 Scott Blvd., Santa Clara, CA 95054, U.S.A. Tel. +1-408-844-8008 Fax. +1-408-844-8944 URL. www.seiwaamerica.com Contact :Mr.Alon Takashima E-mail: takashima@seiwaamerica.com Company SEIWA OPTICAL KOREA INC. (est. 2003) #401 Dansung B/D 1-23, Yangjae-Dong Seocho-Gu, Seoul 137-130, Korea TEL. +82-2(571)3723 FAX. +82-2(571)3725 Contact :Mr.Kim Jeong-Ki, Mr. Oh Chang-hyu E-mail:kimjk@seiwakorea.com(Mechanical eng.), E-mail:ohch@seiwakorea.com(Electronic eng.) Company SEIWA OPTICAL TAIWAN INC. (est. 2004) 12F, No.140, Hoping Rd., Hsin-chu, Taiwan R.O.C. Tel. +886-3-5283215 Fax. +886-3-5283995 Contact: Mr.Bryan Lin E-mail:bryan@seiwaopt.com.tw Company SEIWA OPTICAL SHANGHAI CO,LTD (est. 2011) Room 635, 6 F, №789 Zhaojiabang Road,Xuhui,Shanghai, China TEL: +86-021-612568351 Fax: +86-021-61256899 E-mail: jinjiyan@seiwaopt.co.jp Company SEIWA OPTICAL EUROPE GmbH (est. 2011) Schubertstrasse 14, D-60325 Frankfurt/M, Germany TEL. +49-69-7408-7847 E-mail: info@seiwaeurope.com Company SEIWA OPTICAL SINGAPORE PTE LTD (est. 2013) 105 Cecil Street #07-01, the Octagon, Singapore 069534 TEL. +65 3157 1527 E-mail: info@seiwaopt.com.sg

  4. Company History Highlights 1947: Suzuki Taro established optical manufacturing facility  1955: Established Seiwa Optical Co., Ltd. and initiated sales  of stereo microscope unit 1979: Announced the development of zoom lens, Concurrently  initiated Opto-Electronics by integrating electronic devices 1989: Released the world’s longest working distance,  apochromatic objective lens 1990: Completion of Correct Show Room  1994: Established R&D center in Tokyo  1997: Started launch of digital microscopes  2004: Developed and delivered the world’s largest 100inch  level PDP Exposure system 2005: Developed and delivered the world’s fastest 42inch  x8panels PDP Exposure System. 2013: Released both sided, front & back exposure system  2014: Release of fully motorized, digital microscope 

  5. Microscope ・ Semiconductor inspection Optical head ・ Laser optical head ・ Confocal microscope ・ NUV objective lens ・ IR objective lens ・ Digital microscope ・ Binocular stereo microscope ・ Biological microscope ・ Metal logical ・ Measurement scope ・ Infrared light scope ・ Jewel scope ・ Contact Scope ・ Color Monitor Scope

  6. Machine Vision ・ Alignment optical system ・ Inspection optical system ・ Image measurement ・ High definition optical unit ・ UV/IR optical system ・ Vacuum optical system ・ Image processing system ・ System soft ware ・ Video equipment ・ Optical device(lens, prism, mirror, homogenizer, etc)

  7. FPD Equipment ・ Exposure ( PDP , CF CF , TFT , Wafer ) ・ Laser system (FPD , LSI) ・ Repair system ( FPD) ・ Inspection system ・ Panel Attachment system (PDP , LCD , OLED ) ・ Setup adjustment system ・ TAB/FPC manufacturing inspection system

  8. Partner with Engineers in latest field. Head aligner Solar cell output system Optical connector LED process Optical End scope Laser repair communication Operation scope Exposure system Biological microscope FPD AOI inspection LASIK for eye Measurement system Medical SEIWA Stepper Die bonder Semi OPTICAL CSP Flip chip bonder Wire bonder Chip Mounter Film thickness meter JISSO conductor Screen printer 3D inspection Micro ball repair welding Nano PCB Nano in printer Screen printer Micro robot PCB exposure technology Vacuum alignment optical system X-ray check system Inkjet printer Direct imager

  9. Die Bonder Semi conductor Line up Low distortion within zoom range Low magnification coaxial zoom micro scope (Click type magnification setting) wide field coaxial zoom microscope *Sample image ( inner focus ) Die Bonder

  10. Wire Bonder Semi conductor Line up Bonding High-speed alignment unit * Sample image Wire Bonder

  11. Chip Mounter Semi conductor Line up Variable magnification lens. High- resolution Low distortion * Sample image and Compact. Low magnification micro lens. Chip Mounter

  12. Flip Chip Bonder JISSO Line up Dual view (top and bottom) optical system. * Sample image Flip Chip Bonder

  13. Probe Station JISSO Line up This microscope is a high-resolution instrument and is ideal as a probe station for the semiconductor industry and for LCD assembly. Option : Laser repair Super Scope Microscope PS-888 * Sample image Probe Station object lens (UV/Visible /IR)

  14. LED Chip Sorter JISSO Line up Complete uniformity of focus area Compact zoom Click type magnification setting and inner focus loading is possible. * Sample image LED Chip Sorter

  15. Wafer Inspection System FPD Installed Products High accuracy ・ High-definition lens Line Device length 64mm Available It is the best for inspecting specular patterns and glass substrates . * Sample image SVL series Wafer Inspection System Telecentric Lens Tube for line sensor.

  16. Screen Printer FPD Line up Dual view (top and bottom) optical system(2camera type) Both top and bottom images are inverted or those copy images. * Sample image Dual view (top and bottom) Screen Printer optical system(1camera type)

  17. Laser Scriber FPD (Alignment position) Line up High – resolution and low distortion lens * Sample image Laser Scriber Optics for Laser Scriber Coaxial illumination tube

  18. Optics for LASIK Medical (Laser(-assisted) in situ karatomileusis) Line up Cornea laser operation * Sample image LASIK

  19. Thanks & Best Regards SEIWA OPTICAL CO.,LTD
