SLIDE 1
1 DCI Dublin | 11/2019
The Friedhelm Loh Group – a successful business
2 DCI Dublin | 11/2019
A strong family
12,000
employees worldwide
1,500
patents
80
international subsidiaries
2.6 bn
euros turnover
Operational Stream New Liquid Cooling Technologies Introduced by - - PowerPoint PPT Presentation
Operational Stream New Liquid Cooling Technologies Introduced by - - PowerPoint PPT Presentation
Operational Stream New Liquid Cooling Technologies Introduced by Rittal Clive Partridge Tech Support Rittal Limited UK and Ireland DCI Dublin | 11/2019 1 A strong family The Friedhelm Loh Group a successful business 80 12,000
SLIDE 2
SLIDE 3
1961
Founded
Rittershausen The nucleus of Rittal
80 subsidiaries 40 agents and distributors worldwide 13 production sites
9,300
employees
3 DCI Dublin | 11/2019
Rittal
Facts and figures
SLIDE 4
250,000
m² production space worldwide
200,000
cooling units per annum
15,000
enclosures each day
Urbana (US) Plymouth (UK) Valeggio (IT) Bangalore (IN) Shanghai (CN) São Paulo (BRA) Songdo (KOR)
Close to our customers
Volume production on three continents
4 DCI Dublin | 11/2019
Haiger Herborn: Hof Rittershausen Wissenbach (all based in Germany)
SLIDE 5
F.L.G. – The Group. I 06/2017 5 5 DCI Dublin | 11/2019
In this presentation you’ll find out about these solutions:
The revolutionary BLUEe plus packaged DX cooling unit The space saving LCU - DX (Liquid Cooling Unit) The LCP (Liquid Cooling Package) split DX units The LCP (Liquid Cooling Package) Chilled Water Hybrid The LCP (Liquid Cooling Package) Chilled water new additions OCP Cooling using LCP Technology
SLIDE 6
F.L.G. – The Group. I 06/2017 6 6 DCI Dublin | 11/2019
Rittal IT Systems – Cooling - Portfolio
Low Density Mid Density High Density
LCP Plus 55kW – Water based LCP Plus 30kW – Water based With Hot or Cold aisle containment system Inline Cooling DX and Water with aisle containment system CRAC system / Direct Free air Fan solutions 55kW 3kW 15kW 30kW 55kW
SLIDE 7
7 DCI Dublin | 11/2019
New Edge DC and Industry 4.0 Cooling solutions Rittal Blue e + packaged Dx cooling units – For smaller applications…….
▪ Highly efficient Blue e plus Cooling unit ▪ Load reactive, speed controlled fans ▪ 3 operating modes, active/hybrid/passive ▪ Heat-pipe technology to spread load over whole coil ▪ Autosensing mains power for world-wide applications ▪ UL approved ▪ Availiable versions from 1.2 to 5.6 kW ▪ IoT monitoring over Ethernet ▪ Portable ▪ Ducts cool air to front 19” cold section
SLIDE 8
8 DCI Dublin | 11/2019
New Edge DC and Industry 4.0 Cooling solutions Rittal Blue e + cooling units for even larger applications
▪ Same product can be used, in conjunction with clever ducting for much larger applications such as containerised solutions
SLIDE 9
9 DCI Dublin | 11/2019
▪ Same product can be used, in conjunction with clever ducting for much larger applications such as containerised solutions
New Edge DC and Industry 4.0 Cooling solutions Rittal LCU - DX cooling units
▪ LCU-DX split unit ▪ 3kW and 6 kW versions ▪ Specifically for IT ▪ With or without redundancy ▪ Variable speed fans inverter controlled compressors ▪ Space saving design ▪ Fits into 800 x 1000 racks ▪ Closed air loop for greater efficiency ▪ Ideal for DCiB applications
SLIDE 10
10 DCI Dublin | 11/2019
New Edge DC and Industry 4.0 Cooling solutions Rittal LCU split Dx cooling units for IT applications - Video
SLIDE 11
11 DCI Dublin | 11/2019
New Edge, Conventional DC’s and Industry 4.0 Cooling solutions Rittal LCP split DX cooling units with higher capacities
▪ LCP-DX split unit ▪ 12 and 20 kW versions ▪ Small footprint only 300 mm wide ▪ 1000 or 1200 mm deep ▪ Variable speed fans, inverter controlled compressor ▪ ‘Sidecar’ baying to racks ▪ In-Rack closed air loop for greater efficiency ▪ In-Row for CAC or HAC’s
SLIDE 12
12 DCI Dublin | 11/2019
New Edge, Conventional DC’s and Industry 4.0 Cooling solutions Rittal 35 kW LCP-DX with Free Cooling
▪ 2 variants, DX or DX- Water (FC) hybrid ▪ Up to 35kW cooling capacity ▪ Variable speed fans ▪ ‘Sidecar’ baying to racks ▪ In-Row for CAC or HAC’s ▪ Hot Swappable Fans ▪ Can be top or bottom fed ▪ Condenser options ▪ 600 w 2000h 1200d
SLIDE 13
13 DCI Dublin | 11/2019
New Edge, Conventional DC’s and Industry 4.0 Cooling solutions Rittal LCP split Dx cooling units 35 kW LCP-DX with Free Cooling
▪ Multi mode operation for improved Opex costs ▪ Full free cooling for low ambients ▪ Mixed for interseasonal ambients ▪ Full compressor mode for high ambients
SLIDE 14
14 DCI Dublin | 11/2019
New Edge, Conventional DC’s and Industry 4.0 Cooling solutions Rittal LCP split Dx cooling units for IT applications - Video
SLIDE 15
15 DCI Dublin | 11/2019
▪ LCP Water cooled units for higher densities of IT ▪ 30 up to 55 kW versions in a small footprint 300 x 1200 ▪ Variable speed fans and modulated water valve for increased economy ▪ ‘Sidecar’ baying to racks ▪ In-Rack closed air loop for greater efficiency ▪ In-Row for CAC or HAC’s ▪ New additions to range giving full capacity even with water/glycol mix ▪ Easy access to water modules at rear ▪ Can be top or bottom fed
New Edge DC and Industry 4.0 Cooling solutions Rittal LCP Water/Glycol units
SLIDE 16
16 DCI Dublin | 11/2019
▪ Good PUE‘s can be achieved utilising free cooling
New Edge DC and Industry 4.0 Cooling solutions For Water cooled systems a greater degree of infrastructure is required
▪ Supported by Chiller plant during excessivly hot days
SLIDE 17
17 DCI Dublin | 11/2019
New Edge DC and Industry 4.0 Cooling solutions LCP CW Hybrid – Water cooled rear door assembly
▪ Existing Racks may be upgraded by replacing the standard rear door ▪ 10 and 20 kW variants for 600 and 800 wide Rittal Racks ▪ Racks require no repositioning ▪ Water flow and return pipework is required via a chiller ▪ No electrical power required ▪ Integrated fans within the load provide the correct air volumetric flow ▪ Heat pipe ensures the heat is distributed over the whole coil surface ▪ Full accessibility to rack rear is ensured ▪ Cool air from the existing
SLIDE 18
18 DCI Dublin | 11/2019
SLIDE 19
19 DCI Dublin | 11/2019
OCP and Liquid Cooling solutions
▪ Coming Soon from Rittal ▪ Various cooling solutions for OCP Racks ▪ Based on LCP (DX or CW) technology to deliver targeted cooling ▪ Need for OCP and Conventional to co- exist in some legacy DC’s ▪ In conjunction with Aisle Containment ▪ As yet not many ‘OCP Ready’ DC’s in
- peration (KAO in Harlow in first in UK)
▪ YouTube link to Rittal OCP Racks
SLIDE 20
20 DCI Dublin | 11/2019
New Edge DC and Industry 4.0 Cooling solutions Liquid-Cooled Solutions
SLIDE 21
21 DCI Dublin | 11/2019
Satisfied customers are the best reference
Successful companies put their trust in Rittal Solutions
SLIDE 22
DCI Dublin | 11/2019 22
Thank You for your time and please drop by to our Stand at the show
