On Visual Studies I

707.031: Evaluation Methodology Winter 2015/16

Eduardo Veas

Research Projects

• Augmented Data
• RT assistance and instructions
• record/replay instructions from an expert
• assist non-expert with instructions
• LOD for real-time instructions
• Augmented Knowledge Spaces
• Use space to organize and interact with

technology

• Investigate novel technologies.

2

The Human Vision

3

How it works (when it does)

Model Human Processor

4

Source: Card et al 1983

5

Perception vs. Cognition


Perception

• Eye, optical nerve,

visual cortex

• Basic perception
• First processing
• (edges, planes)
• Not conscious
• Reflexes

Cognition

• Recognizing objects
• Relations between
• bjects
• Conclusion drawing
• Problem solving
• Learning

Model Human Processor (3): Perception

• encodes input in a physical

representation

• stored in temp. visual /

auditory memory

• new frames in PM activate

frames in WM and possibly in LTM

• Unit percept: input faster

than Tp combines

6

Human Visual System

• 6.5 mio cones

– dense in the center – 3 cone types (rgb) – 3 opponent color channels (bw, rg, by)

• Fovea: 27 times the

density

– responsible for sharp central vision

• 118.5 mio rods

– black/white

7

Color perception

8

Title Text

9

Color Reception, Composition

• We have three distinct color receptors (cones)

– three-dimensionality of the color space – that‘s why we have three primary colors – also evident in color models, e.g., RGB and CMY

• Color composition

– additive (e.g., RGB)

• light
• white: all three cones stimulated


with same intensity,
 at high brightness

– subtractive

• pigment (e.g., CMYK)

10

Color Perception

Blahblahblah……… 3 opponent color channels (bw, rg, by). There are 6 colors arranged perceptually as

• pponent pairs along 3 axes (Hering ’20):

L = long, M = medium, S = short wavelength receptors

11

Simultaneous Brightness Contrast

• The perceived brightness of an object is

relative to it‘s background

12

Color

• Color vision is irrelevant to much of

normal vision!

– does not help to perceive layout of objects – how they are moving – what shape they are

• Color breaks camouflage (Tarnung)
• Tells about material properties (judging

quality of food)

13

Color Blindness

• 10% of males, 1% of females (probably due to X-

chromosomal recessive inheritance)

• Most common: red-green weakness / blindness
• Reason: lack of medium or long wavelength

receptors, or altered spectral sensitivity (most common: green shift)

Normal Color Perception Deuteranopia (no green receptors) Protanopia (no red receptors)

14

Ishihara Color Blindness Test

15

Ishihara Color Blindness Test

16

Ishihara Color Blindness Test

17

Ishihara Color Blindness Test

18

Ishihara Color Blindness Test

19

Ishihara Color Blindness Test

20

Ishihara Color Blindness Test

Visual Perception

21

A construction site

Human Visual System

• 6.5 mio cones

– dense in the center – 3 cone types (rgb) – 3 opponent color channels (bw, rg, by)

• Fovea: 27 times the

density

– responsible for sharp central vision

• 118.5 mio rods

– black/white

22

23

Human Visual System

• Vision: sequence of fixations and

saccades

– fixations: maintaining gaze on single location (200-600 ms) – saccades: moving between different
 locations (20-100 ms)

• Vision not similar to a camera

– More similar to a dynamic and


• ngoing construction project

What decides where we look?

24

• n inherited knowledge

Visual Saliency: perceptual selection

• perceptual

quality that makes some items in the world stand out from their neighbors (Itti)

• bottom-up and top-

down contributions

25

Computed Saliency vs Eye Tracked Attention

26

Feature Integration

27

Reconstructing objects

28

Feature Integration Theory

IDENTIFY PRIMITIVES COMBINE PRIMITIVES PERCEIVE OBJECT COMPARE MEMORY MEMORY PREATTENTIVE STATE FOCUSED ATTENTION PERCEPTUAL COGNITIVE Legibility

Spatial interpretation

Navigation Noticeability Density Clutter

29

Feature Integration Theory II

Preattentive Processing

• Properties detected by the low-level visual

system

– very rapid – very accurate – processed in parallel

• 200-250 milliseconds
• Independent of the number of distractors!
• Opposite: sequential search (processed serially)

30

Pre attentive features

31

Fast attractors

Difference in Hue

32

Examples online!

33

Difference in Curvature / Shape

34

Not Valid for Combinations

• Conjunction Targets – no unique visual property
• target: red, circle
• distractor objects have both properties

35

Some Preattentive Properties

• rientation

length closure size curvature density hue hue flicker direction of motion

36

Tasks

• target detection

– detect the presence or absence of a target

• boundary detection

– detect a texture boundary between two groups of elements, where all

• f the elements in each group have a common visual property
• region tracking

– track one or more elements with a unique visual feature as they move in time and space

• counting and estimation:

– users count or estimate the number of elements with a unique visual feature.

37

Tasks

Number Estimation Boundary Detection

38

Hierarchy of Preattentive Features

Examples online!

39

Theories of Preattentive Processing

• Not known for sure how it works
• Several theories:

– http://www.csc.ncsu.edu/faculty/healey/PP/index.html

EYE TRACKING

40

Eye-Tracking

• Measurement and study of eye movements

41

Functions of eye movement

• get the fovea to the

interesting information (fixations)

• keep image stationary in

spite of movements of the

• bject or from the head

(smooth pursuit)

• prevent objects from

perceptually fading (refresh, microsaccades)

42

Eye Tracking as Measure of Human Behavior

• aim: identify patterns in the deployment of visual

resources when performing a task

• combining features into perception requires

focus of attention

• the more complicated, confusing or interesting,

the longer it takes to “form a picture”

43

Tracked Eye Movements

44

Task Typical mean fixation duration (ms) Mean saccade size (degrees) Silent Reading 225-250 2 (8-9 letter spaces) Oral Reading 275-325 1.5 (6-7 letter spaces) Scene Perception 260-330 4 Visual Search 180-275 3

Additional measurements: Eye Tracking

• Fixation: dwell time on a given area
• Saccade: quick movement of the eye between

two points

• Scan path: directed path of saccades and fixations
• How to use these measurements?

45

Additional measurements: Eye Tracking

Processing measures

– Fixation count – Location of fixations – Duration of fixations – Cumulative fixation time – Cluster analysis (attention sinks) – AOI / normalized dividing by all fixations

46

Additional measurements: Eye Tracking

Search measures

• Scanpath length (distance

between gaze point samples, ending at target)

• Spatial density

(distribution of gazepoints and scanpaths)

• Number of saccades

47

Eye Tracking Experiments

48

Title Text

Eye Tracking Experiment: Phase I

• 1. Learn about ET knowledge, find relevant

previous ET studies

• 3. Research design: establish research question and

analysis metrics

• 4. Pilot: [go to next page] and return to 1 if

needed

49

Eye Tracking Experiment: Phase II

• Prepare your data
• Test hardware
• Prepare room and setup
• Pilot [return to draft?]
• Execute
• Calibration
• Training
• Calibration ?
• Testing
• Analyze

50

Eye Tracker Experiment: research questions

• Noticeability: time till the

first fixation on object of interest.

• Attention: fixation

duration, dwell time on the object of interest

• Reaction: time between

fixation and click

51

Eye Tracker Experiment: preparations

• Setup testing

environment

• Design tasks and

matched analysis metrics

• Design study battery:

(intro, calibration, training, [calibration], test, questionnaires)

52

Eye Tracker Calibration

• Device
• Characterize the

user’s eyes

• Match internal model

(cornea, fovea)

• User
• Look and follow

targets

• Experimenter
• keep cool and repeat

when needed

53

Example:DAIMsVSM

54

Title Text

How do we highlight objects in AR?

2 VEAS - MENDEZ - FEINER - SCHMALSTIEG

• CAN WE BE MORE SUBTLE?

3

How do we highlight objects in AR?

DIRECTING ATTENTION AND INFLUENCING MEMORY WITH VISUAL SALIENCY MODULATION

Eye Tracking: Example

Directing Attention and Influencing Memory with Visual Saliency Modulation [veas et al. 2011]

• Characterize bottom-up attention: driven by exogenous
• cues. (100 ms ~ 250ms)
• Measure deployment of attention before and after

applying a SMT.

• Measure deployment of memory after experiencing

stimuli (modulated and not)

57

Eye Tracking: Example

Directing Attention and Influencing Memory with Visual Saliency Modulation

• Motivation: contend that saliency modulated

stimuli affects the deployment of mental resources, bottom-up (attention), top-down (memory)

• If modulation is subtle enough, the effect is not

perceivable

58

Experiments

• 1. Awareness of modulation

does it work imperceptibly?

• 2. Attention direction

does it successfully attract attention to the selected regions?

• 3. Memory influence

does it successfully increase recall ?

11 VEAS - MENDEZ - FEINER - SCHMALSTIEG

Experiments

60

Awareness first pilot Awareness second pilot Attention Condition 1 Attention Condition 2 Memory Condition 1 Memory Condition 2 Awareness formal study Thresholds Regions for modulation Modulated Videos

Eye Tracking Example

Formal awareness study

– 20 clips @ levels (0, 3, 4, 5) = 80 video-level-pairs, each watched by 4 participants – 16 participants – Analysis: related samples (0-3, 0-4, 0-5)

• Wilcoxon tests: no difference for any of the pairs

61

Additional measurements: Eye Tracking

• ATTENTION EXPERIMENT
• Does the SMT successfully direct visual attention

to selected regions?

– 40 participants, between-subjects. Conditions: unmodulated, modulated, – (20 regions × 20 participants) = 400 trials per condition = 800 trials total.

62

Results

63

Additional measurements: Eye Tracking

• ATTENTION EXPERIMENT: HYPOTHESES

Filter: camera panning away from FRs.

• H1: The time before the first fixation on the FRs will be

smaller for modulated videos than for the original ones.

• H2: The fixation time in the FRs will be higher for modulated

videos than for the original ones.

• H3: The percentage of participants with at least one fixation on

the FR will be higher for modulated videos than for the original

• nes.

64

Institut für Maschinelles Sehen und Darstellen ‹#›

Eduardo Veas Evaluation-Validation

Additional measurements: Eye Tracking

• MEMORY EXPERIMENT: METHOD

Additional measurements: Eye Tracking

• MEMORY EXPERIMENT: HYPOTHESES

–H4: There is no significant difference in recall hits between the unmodulated and the modulated input for HR

• bjects.

–H5: There is a significant difference in recall hits between the unmodulated and the modulated input for LR objects.

66

Research Positions

• AR projects @ KC.
• Virtual coffee
• build IoT coffee machine
• add sensors and intelligence to appliance
• Augmened Knowledge Spaces
• Use space to organize and interact with

technology

• Investigate novel technologies.

67

Readings

• [Irwin] Fixation Location and Fixation Duration as

Indices of Cognitive Processing

• [Pernice & Nielsen] How to Conduct Eyetracking

Studies

• Saccades and microsaccades during visual fixation,

exploration, and search: Foundations for a common saccadic generator

• Tobii eye tracking whitepaper
• [Veas etal] Directing attention and influencing memory

with saliency modulation

68
