OMNeT++ Community Summit, 2015

Beyond INET 3.0

Levente Mészáros IBM Research - Zurich, Switzerland – September 3 - 4, 2015

Overview

Network node architecture refactoring Cross-layer communication and optimization Mobility refactoring

Kernel Socket API Link Layer Network Layer Transport Layer UDP IPv4 TCP Application Ethernet 802.11 IPv6 PPP VLAN

Real World Network Node Architecture

• Real world

applications often use different kind of sockets and protocols simultaneously

Current Network Node Architecture 1

tcpApp[] udpApp[] pingApp[] tunApp[] udp tcp ipv4 ppp[] tun[] wlan[] eth[]

• Nodes currently have

separate submodule vectors for different kinds of applications

• What if an application

wants to use TCP and UDP simultaneously?

Current Network Node Architecture 2

tcpApp[] udpApp[] pingApp[] tunApp[] udp tcp ipv4 ppp[] tun[] wlan[]

?

eth[]

• TUN application are

currently connected to TUN interfaces only

• TUN applications are

useless without being connected to other protocols

• Should we connect

them to TCP, UDP, IPv4, or all of them?

Current Network Node Architecture 3

tcpApp[] udpApp[] pingApp[] tunApp[] udp tcp ipv4 ppp[] tun[] wlan[] ipv6 eth[]

• Dual network stack

needs extra dispatch mechanism towards network protocols

• Where should the

dispatch mechanism be?

• In general, protocols
• f adjacent OSI layers

should be in many-to- many relationship ?

TCP Applications

tcpApp[] udpApp[] pingApp[] tunApp[] udp tcp ipv4 ppp[] tun[] wlan[] eth[]

• Limitation: TCP

applications exclusively and directly connect to TCP

• Dispatch from TCP

towards applications is built into TCP

• Dispatch from IPv4

towards TCP is built into IPv4

UDP Application

tcpApp[] udpApp[] pingApp[] tunApp[] udp tcp ipv4

• Limitations: UDP

applications exclusively and directly connect to UDP

• Dispatch from UDP

towards applications is built into UDP

• Dispatch from IPv4

towards UDP is built into IPv4

ppp[] tun[] wlan[] eth[]

Ping Application

tcpApp[] udpApp[] pingApp[] tunApp[] udp tcp ipv4

• Network layers

currently have separate gates for ping applications (pingIn, pingOut)

• IPv4 needs to do

special ICMP packet handling to reach ping applications

ppp[] tun[] wlan[] eth[]

New Network Node Architecture

app[] udp tcp ipv4 ppp[] tun[] wlan[] ipv6 dispatcher dispatcher dispatcher eth[]

• Added separate

packet dispatchers between OSI layers

• Eliminated dispatch

mechanisms from individual protocols

Protocol Registration Mechanism

app[] udp tcp ipv4 ppp[] tun[] wlan[] ipv6 dispatcher dispatcher dispatcher eth[]

• Protocols have to

register themselves in the dispatcher (protocolId, gate)

registers

Interface Registration Mechanism

app[] udp tcp ipv4 ppp[] tun[] wlan[] ipv6 dispatcher dispatcher dispatcher eth[]

• Interfaces also have to

register themselves in the dispatcher (interfaceId, gate)

registers

Simpler Network Node Architectures

app udp ipv4 eth udp ipv4 app[] udp ipv4 app[] dispatcher dispatcher dispatcher eth eth[]

• Dispatchers are
• ptional
• Modules can still

be organized in

• ther ways

IPv4 Network Layer Architecture

dispatcher ip icmp igmp arp

• IPv4 network layer also uses a

dispatcher internally

• ARP and IP don't exchange

packets, thus no connection between them

TCP Application

app[] udp tcp dispatcher dispatcher dispatcher ipv4 ipv6 ppp[] tun[] wlan[] eth[]

• TCP application still

uses a TCPSocket to send and receive packets

• Dispatcher learns

where sockets are, based on socket open and close commands

UDP Application

app[] udp tcp dispatcher dispatcher dispatcher ipv4 ipv6 ppp[] tun[] wlan[] eth[]

• UDP application still

uses a UDPSocket to send and receive packets

• Dispatcher routes

packets based on the destination protocol

• Destination protocol is

determined from control info and packet class

Ping Application

app[] udp tcp dispatcher dispatcher dispatcher ipv4 ipv6 ppp[] tun[] wlan[] eth[]

• Ping application uses

a raw IPv4Socket to send and receive ICMP echo packets

• There's no special

network layer gate for ping applications

Ethernet Application

app[] udp tcp dispatcher dispatcher dispatcher ipv4 ipv6 ppp[] tun[] wlan[] eth[]

• Ethernet applications

can directly communicate using ethernet sockets

MANET Routing Application

app[] udp tcp ipv4 ppp[] tun[] wlan[] ipv6 dispatcher dispatcher dispatcher eth[]

• MANET routers now

share the same network node architecture

• Routing application

can be replaced from INI file

• Routing applications

can still use all kinds

• f sockets

routing[]

Tunnel Application

app[] udp tcp dispatcher dispatcher ipv4 ipv6 ppp[] tun[] wlan[] eth[]

• Tunnel application

simultaneously opens a TUN device and a raw IPv4Socket

Tunnel Application 1

app[] udp tcp dispatcher dispatcher ipv4 ipv6 ppp[] tun[] wlan[] eth[]

• Node receives packet

from network

Tunnel Application 2

app[] udp tcp dispatcher dispatcher ipv4 ipv6 ppp[] tun[] wlan[] eth[]

• Node receives packet

from network

• IPv4 forwards packet

to TUN interface

Tunnel Application 3

app[] udp tcp dispatcher dispatcher ipv4 ipv6 ppp[] tun[] wlan[] eth[]

• Node receives packet

from network

• IPv4 forwards packet

to TUN interface

• Application receives

packet from TUN interface

Tunnel Application 4

app[] udp tcp dispatcher dispatcher ipv4 ipv6 ppp[] tun[] wlan[] eth[] ppp[] tun[] eth[]

• Node receives packet

from network

• IPv4 forwards packet

to TUN interface

• Application receives

packet from TUN interface

• Application sends

packet inside another IPv4 packet

Standard Host 1

Standard Host 2

Overview

Network node architecture refactoring Cross-layer communication and optimization Mobility refactoring

Cross-layer design

Link Layer Network Layer Transport Layer Application Layer Physical Layer

• Quality of

service parameters

• Resource
• ptimization

parameters

• Link

quality indication

• Physical

channel conditions

Current Cross-Layer Communication

• Applications send UDP packets on a specific interface by

setting the interfaceId in UDPControlInfo

• Currently applications cannot even specify type of service

parameter to control the quality of service functionality

New Cross-Layer Communication

Link Layer Network Layer Transport Layer Application Layer Physical Layer

• Packets

collect various request tags

• Packets

collect various indication tags

• As packets go through the layers

MACAddressRequest

• source
• destination

QualityOfServiceRequest

• tos

TransmissionRequest

• power
• channel

InterfaceIndication

• id

MACAddressIndication

• source
• destination

ReceptionIndication

• power
• channel

InterfaceRequest

• id

Packet

Tag Examples

Overview

Network node architecture refactoring Cross-layer communication and optimization Mobility refactoring

Current Mobility Models 1

• There are mobility models

that do static positioning

• There are mobility models

that move nodes around

• How to combine these

models?

Current Mobility Models 2

• There are group mobility

models with built-in differences for individual nodes

• How to reuse existing models

for group mobility?

• How to model a docking ship

with passengers moving around?

Current Mobility Models 3

• Sometimes positioning and
• rientation are best expressed

in separate mobility models (e.g. satellites)

• Sometimes elevation may be

derived from the position on the surface of the Earth (e.g. a moving vehicle)

Mobility Superposition

• Support combining different positioning and
• rientation models using superposition
• Support start/end time (limits) for mobility models

time positioning & orientation initial individual perturbation group superposition

Coordinate Systems

• Geographic

coordinate system such as WGS-84

• Abstract Cartesian

coordinate system

• How to express coordinates inside buildings around a city?
• How to express antenna orientation of a vehicle separately?

Questions and Answers

Levente Mészáros

Thank you for your kind attention!

IBM Research - Zurich, Switzerland – September 3 - 4, 2015
