Office hours (today) 2-3 (rather than 2-4) Todays Lecture Thyreophora (continued) Stegosauria Ankylosauria Shared, derived traits (synapomorphies) General characteristics Diet Brains Locomotion Armor Distribution Taphonomy Gastonia

slide-1
SLIDE 1

Office hours (today) 2-3 (rather than 2-4)

slide-2
SLIDE 2

Today’s Lecture

Thyreophora (continued) Stegosauria Ankylosauria Shared, derived traits (synapomorphies) General characteristics Diet Brains Locomotion Armor Distribution Taphonomy

Gastonia

slide-3
SLIDE 3

Genosauria Thyreophora Stegosauria

Scutellosaurus 4 ft long Early Jurassic, North America Scelidosaurus 13 ft long Early Jurassic, England

Basal Thyreophorans

bipedal to quadrupedal

  • steoderms

Sister Groups

slide-4
SLIDE 4

Ankylosaurus Late Cretaceous

slide-5
SLIDE 5

Ankylosauria Ankylosauridae Nodosauridae

Ankylosaurus Late Cretaceous

Loss fenestra Armour fused to lower jaw Broad pelvis Wide gut Dorsal osteoderms

Ankylosauria = GROUP Ankylosaurs = GROUP Ankylosauridae Ankylosaurids

} SUBGROUP Quick Note:

Sauropelta Early Cretaceous

slide-6
SLIDE 6

Ankylosauridae

early to late Cretaceous

Nodosauridae

mid-Jurassic to late Cretaceous

slide-7
SLIDE 7

Minmi Ankylosauria Basal Ankylosauria

Scelidosaurus Stegosauria Ankylosauridae Nodosauridae

Southern continents (Australia) Ankylosaur/Nodosaur traits Direct evidence of diet fragments of plant vascular tissues seeds leaves Spike-like scutes on hips

(Minmi)

slide-8
SLIDE 8

Ankylosauridae Shared, derived characteristics Well armoured, but fewer spines Tail CLUB Shorter, knobbier skull than Nodosaurs Squamosal horns In some species: asymmetrically arranged scutes (variable)

Ankylosaurus Late Cretaceous

slide-9
SLIDE 9

Other derived traits: Dorsal crossbow Frightened complexion Pink Eveningwear Mantis-Human rider Ankylosauridae

slide-10
SLIDE 10

Nodosauridae

Sauropelta Early Cretaceous

Shared, derived characteristics Spines are emphasized No tail club Longer, thinner skull than Ankylosaurs No squamosal horns Symmetrically arranged scutes Acromial process for heavily muscled foreleg

slide-11
SLIDE 11

Other derived traits: Piloted, rocket propelled manta ray Nodosauridae

slide-12
SLIDE 12

Size

Edmontonia Nodosaurid Late Cretaceous Euoplocephalus Ankylosaurid Late Cretaceous Sauropelta Nodosaurid Early Cretaceous Ankylosaurus... 6-9 meters Ankylosaurid Late Cretaceous

slide-13
SLIDE 13

Ankylosauria: Genosaurs i.e. they’d better have CHEEKS. Premaxillae (cropping) ~ attachment of beak (ramphotheca), Diastem, cheek teeth Cheeks are very emphasized in Ankylosauria Deep, inset, cheek teeth

Euoplocephalus Ankylosaurid Late Cretaceous

slide-14
SLIDE 14

Diet Wide, short vs. Narrow, long Ankylosaurids Nodosaurids ‘White’ Rhino ‘Black’ Rhino Generalist-feeders Selective-feeders

slide-15
SLIDE 15
slide-16
SLIDE 16

Ankylosaurus Stegosaurus Diet

5 fenestrae in basal Dinosaurs Nares Antorbital Orbit Upper Temporal Lower Temporal 2-3 in Ankylosaurs (note: variable) Nares Orbit (sometimes) lower temporal Tarchia

slide-17
SLIDE 17

Euplocephalus Ankylosaurid Late Cretaceous

Tooth Morphology

Hand-shaped Small overall Smaller in Ankylosaurids Early Ankylosaurs have conical teeth on their premaxillae

Diet

slide-18
SLIDE 18

Sauropelta Edmontonia Ankylosaurus Euoplacephalus

1 cm

slide-19
SLIDE 19

Edmontonia Euoplocephalus Complex secondary palate Theories: Resonating chamber Smell Moisten dry air Structural brace for complex jaw movements Evidence: Teeth: microscopic wear patterns: suggest pivoting

  • f lower jaw
slide-20
SLIDE 20

Edmontonia Euoplocephalus

http://www.youtube.com/watch?v=nSe0IUQ-FCs

slide-21
SLIDE 21
slide-22
SLIDE 22

How to be an Herbivore: 101 Small and picky Big and indescriminant

Small & Picky Big & Indiscriminate

slide-23
SLIDE 23

Zebra => Wildebeest => Thompson’s Gazelle

slide-24
SLIDE 24

Euoplocephalus Ankylosaurid Late Cretaceous Sauropelta Nodosaurid Early Cretaceous

G U T S

Wide hindquarters viewed from above Suggests Rear-Fermentation No Gastroliths (like Stegosaurids) ~except Panoplosaurus

slide-25
SLIDE 25

G U T S

Fore-Gut Fermenters (cows) Ruminants Hind-Gut Fermenters (horses) Caeco-colic Fermenters (us)

slide-26
SLIDE 26

Diet Enlarged Hyoid... => Long tongue

slide-27
SLIDE 27

http://www.youtube.com/watch?v=Yn2vlmsZwjA

Brain

slide-28
SLIDE 28

Brains

slide-29
SLIDE 29

Movement

slide-30
SLIDE 30

Minmi Gastonia

Movement

Euoplocephalus

Ankylosaurids less derived more derived

slide-31
SLIDE 31

Pawpawsaurus Sauropelta

Nodosaur's less derived more derived

Edmontonia

slide-32
SLIDE 32

Projection of scapula (shoulder blade) - acromial process Correlates with a well-muscled shoulder Shared, derived, character (synapomorphy) of Nodosauridae Limbs: pillar-like (compare to Rauisuchians ~ pillar erect)

Nodosauridae

slide-33
SLIDE 33

Euoplocephalus

Ankylosaurids

Upper arm crest especially well-developed Indicated high power strokes with forearms Why? Positioning for tail swings ala Stegosaurids? Digging? ‘Running’?

slide-34
SLIDE 34

‘Power-Pelvis’

slide-35
SLIDE 35
slide-36
SLIDE 36
slide-37
SLIDE 37

Cranial Acessories Ankylosaurs: Squamosal horns

slide-38
SLIDE 38

Armour: Passive defense against predators Male-male competition; elements of armour may have been used to ‘look bigger’

  • showy structures/competition structures- like antlers in mammals

Armour has imprints of blood vessels: likely covered in skin, could be flushed with blood Active Defense Nodosaurids: should spines Ankylosaurids: Tail clubs

Edmontonia

slide-39
SLIDE 39

Sauropelta Nodosaurid Edmontonia Nodosaurid Dyoplosaurus Nodosaurid

slide-40
SLIDE 40
slide-41
SLIDE 41

Euoplocephalus

slide-42
SLIDE 42

http://www.youtube.com/watch?v=2rFPfbb5nSI

Gastonia

slide-43
SLIDE 43
slide-44
SLIDE 44
slide-45
SLIDE 45
slide-46
SLIDE 46

Ancient Greek: Ouroboros

Cyclicality

slide-47
SLIDE 47
slide-48
SLIDE 48
slide-49
SLIDE 49
slide-50
SLIDE 50
slide-51
SLIDE 51
slide-52
SLIDE 52

Taphonomy

Sauropelta

slide-53
SLIDE 53

Edmontonia Sauropelta

slide-54
SLIDE 54

Pinacosaurus
