SLIDE 1
OFDMA Backscatter: Boosted Capacity Low Power IoT System
▪ Renjie Zhao ▪ 2017年6月
Page. e.2
Internet of Things(IoT)
OFDMA Backscatter: Boosted Capacity Low Power IoT System Renjie - - PowerPoint PPT Presentation
OFDMA Backscatter: Boosted Capacity Low Power IoT System Renjie - - PowerPoint PPT Presentation
OFDMA Backscatter: Boosted Capacity Low Power IoT System Renjie Zhao 2017 6 Internet of Things(IoT) Page. e.2 Page. Page. e.3 e.3 Wi-Fi Alliance: surpass 15 billion by end of 2016 More re Wi Wi-Fi Dev i Devic ices
SLIDE 2
SLIDE 3
Page. e.3 Page. e.3
SLIDE 4
Wi-Fi Alliance: surpass 15 billion by end of 2016
More re Wi Wi-Fi Dev i Devic ices
Page. e.4
SLIDE 5
Page. e.5
Wi-Fi is power hungry
2 or 3 hours
SLIDE 6
Page. e.6
Why is Wi-Fi Power Consuming?
Digital (Baseband) Analog (RF) Power scaled with Moore’s law O(10 uW) No such scaling O(100 mW)
SLIDE 7
Page. e.7
Passive Wi-Fi
Idea: Use only digital baseband
Single Plugged-in Device Passive Device
NSDI '16 Passive Wi-Fi: Bringing Low Power to Wi-Fi Transmissions
Commodity receiver
Singl ingle t tone ne sign ignal Backs ckscat catter sign ignal Singl ingle t tone ne sign ignal
Power Frequency
SLIDE 8
Page. e.8
802.11b
SLIDE 9
Page. e.9
OFDM IS POPULAR SCHEME
SLIDE 10
Page. e.10 10
OFDM SPECTRUM
subcarrier
SLIDE 11
Page. e.11 11
g g
802.11g PHYSICAL PARAMETTERS
SLIDE 12
Page. e.12 12
tag1 tag2 tag48
SLIDE 13
Page. e.13 13
··· ···
tag1 tag2 tag48 OR
Singl ingle t tone ne sign ignal Backs ckscat catter sign ignal
OFDM symbol
SLIDE 14
Page. e.14 14
OR
SLIDE 15
Page. e.15 15
··· ···
tag1 tag2 tag48 OR
Singl ingle t tone ne sign ignal Backs ckscat catter sign ignal
OFDM symbol
SLIDE 16
Page. e.16 16
preamble header + MAC header downlink data MSDU PSDU MPDU = PPDU ( ) pseudo data sending clear wave tail and pad bits
Set up link For backscatter
SLIDE 17
Page. e.17 17
··· ···
tag1 tag2 tag48 OR
SLIDE 18
Page. e.18 18
··· ···
tag1 tag2 tag48 OR
SLIDE 19
Page. e.19 19
··· ···
tag1 tag2 tag48 OR
SLIDE 20
Page. e.24 24 T-R coordination Subcarrier allocation Carrier generate Synchronization Frequency shifting Synchronization T-R coordination Modulation Data acquisition Transmitter IoT Device Receiver
…
SLIDE 21
Page. e.25 25
MORE CAPACITY
▪ OFDMA system ▪ CSMA/CA
SLIDE 22
Page. e.26 26
CSMA/CA
▪ Packet mode method of multiple access method using in Wi-Fi. ▪ Coexistence with other ISM devices. ▪ Medium sensing is power hungry transmitter
SLIDE 23
Page. e.27 27
MORE CAPACITY
▪ OFDMA system ▪ CSMA/CA ▪ Cognitive radio
SLIDE 24
Page. e.28 28
Cognitive radio
Flash and antifuse technologies low power PLL
SLIDE 25
Page. e.29 29
SLIDE 26
Page. e.30 30
Cognitive radio
▪ Flexible clock PLL ▪ Also sensing medium (allocation) transmitter
Flash and antifuse technologies low power PLL 5uW
SLIDE 27
Page. e.31 31
EVALUATION
SLIDE 28
Page. e.32 32
EVALUATION
SLIDE 29
Page. e.33 33
FUTURE WORK
▪ Joint debugging communication performance ▪ IC design power consumption ▪ REAL OFDM backscatter
SLIDE 30
Page. e.34 34
OUR CONTRIBUTION
▪ 1.Introduce the first OFDMA backscatter system. ▪ 2.Conbine several techniques for low frequency band
- ccupation.
▪ Frequency shifting backscatter; single side band; bi-directional communication.
▪ 3.Design a network stack frame to implement.
▪ Cognitive radio; CSMA/CA.
▪ 4.Build a prototype based on commodity devices.
SLIDE 31
Page. e.35 35
COMPARISON
System
Passive Wi-Fi[1] FS- Backscatter[2] HitchHike[3] Inter- Backscatter[4] Our system
Throughput (Kbps) 1000/11000 50 200/300 2000 100/250 Range (m) 30 3.6 54/34 27 20 Power consumption (μW) 14.5/59.2 45 33 28 ～30 Capacity (/channel) 1 1 1 1 48 Band occupation 1+1* 2 2 1+1* 1 Mirror signal Y Y N N N Commodity device N Y Y Y Y
*1+1 means besides the channel frequency band occupied by the data signal the system also occupies another frequency band for the original signal.
SLIDE 32
Q&A
