Object Oriented Programming COP3330 / CGS5409

 Intro to Data Structures

• Vectors
• Linked Lists
• Queues
• Stacks

 C++ has some built-in methods of storing

compound data in useful ways, like arrays and structs.

 Collectively known as Ab

Abstrac stract t Da Data ta Typ ypes es, as they describe the nature of what is stored, along with the expected operations for accessing the data, without specifying the details of implementation

 C++ classes allow a nice mechanism for

implementing such data types

 Provides an interface (the public section) for

the necessary operations

 The actual implementation details are internal

and hidden.

 Data structure that stores items of the same

type, and is based on storage in an array

 By encapsulating an array into a class (a

vector class), we can

• Use dynamic allocation to allow the internal array to

be flexible in size

• Handle boundary issues of the array (error checking

for out-of-bounds indices).

 Advantages: Random access - i.e. quick

locating of data if the index is known.

 Disadvantages: Inserts and Deletes are

typically slow, since they may require shifting many elements to consecutive array slots

 Collections of data items linked together with

pointers, lined up "in a row".

 Typically a list of data of the same type, like

an array, but storage is arranged differently.

 Made up of a collection of "nodes", which are

created from a self-referential class (or struct).

 Self-referential class: a class whose member data

contains at least one pointer that points to an

• bject of the same class type.

 Each node contains a piece of data, and a pointer

to the next node.

 Nodes can be anywhere in memory (not restricted

to consecutive slots, like in an array).

 Nodes generally allocated dynamically, so a

linked list can grow to any size, theoretically (within the boundaries of the program's memory).

 An alternative to array-based storage.  Advantages: Inserts and Deletes are typically fast.

Require only creation of a new node, and changing of a few pointers.

 Disadvantage: No random access. Possible to build

indexing into a linked list class, but locating an element requires walking through the list.

 Notice that the advantages of the array (vector) are

generally the disadvantages of the linked list, and vice versa

 First In Last Out (FILO)  Insertions and removals can occur from "top"

position only

 Analogy - a stack of cafeteria trays. New

trays are always placed on top. Trays also picked up from the top.

 A stack class will have two primary

• perations:

 push -- adds an item onto the top of the

stack

 pop -- removes the top item from the stack  Typical application areas include compilers,

• perating systems, handling of program

memory (nested function calls)

 First In First Out (FIFO)  Insertions at the "end" of the queue, and

removals from the "front" of the queue.

 Analogy - waiting in line for a ride at an

amusement park. Get in line at the end. First come, first serve.

 A queue class will have two primary operations:  enqueue -- adds an item into the queue (i.e. at

the back of the line)

 dequeue -- removes an item from the queue (i.e.

from the front of the line).

 Typical application areas include print job

scheduling, operating systems (process scheduling).

 Some abstract types, like Stacks and Queues,

can be im impl plemented mented with a vector or with a linked list.

 A stack can use a linked list as its underlying

storage mechanism, for instance, but would limit the access to the list to just the "push" and "pop" concepts (insert and remove from

• ne end).

 A non-linear collection of data items, also

linked together with pointers (like a linked list).

 Made up of self-referential nodes. In this

case, each node may contain 2 or more pointers to other nodes.

 Typical example: a binary tree  Each node contains a data element, and two

pointers, each of which points to another node.

 Very useful for fast searching and sorting of data,

assuming the data is to be kept in some kind of

• rder.

 Binary search - finds a path through the tree,

starting at the "root", and each chosen path (left

• r right node) eliminates half of the stored

values.

 Creates a template doubly linked list of List()

type, composed of Listnode() type nodes.

 Listnode.h -- Template ListNode class

definition.

 List.h -- Template List class definition.

#ifndef LISTNODE_H #define LISTNODE_H template< typename T > class List; template< typename T > class ListNode { friend class List< T >; // make List a friend public: ListNode( const T & ); // constructor T getData() const; // return data in node private: T data; // data ListNode< T > *nextPtr; // next node in list };

// constructor template< typename T > ListNode< T >::ListNode( const T &info ): data( info ), nextPtr( 0 ) { } // end ListNode constructor // return copy of data in node template< typename T > T ListNode< T >::getData() const { return data; } // end function getData #endif

#ifndef LIST_H #define LIST_H #include <iostream> #include "Listnode.h" // ListNode class definition template< typename T > class List { public: List(); // constructor ~List(); // destructor void insertAtFront( const T & ); void insertAtBack( const T & ); bool removeFromFront( T & ); bool removeFromBack( T & ); bool isEmpty() const; void print() const; private: ListNode< T > *firstPtr; // pointer to first node ListNode< T > *lastPtr; // pointer to last node ListNode< T > *getNewNode( const T & ); };

// default constructor template< typename T > List< T >::List() : firstPtr( 0 ), lastPtr( 0 ) { } // end List constructor // destructor template< typename T > List< T >::~List() { if ( !isEmpty() ) // List is not empty { cout << "Destroying nodes ...\n"; ListNode< T > *currentPtr = firstPtr; ListNode< T > *tempPtr; while ( currentPtr != 0 ) // delete remaining nodes { tempPtr = currentPtr; cout << tempPtr->data << '\n'; currentPtr = currentPtr->nextPtr; delete tempPtr; } // end while } // end if cout << "All nodes destroyed\n\n"; } // end List destructor

/ insert node at front of list template< typename T > void List< T >::insertAtFront( const T &value ) { ListNode< T > *newPtr = getNewNode( value ); // new node if ( isEmpty() ) // List is empty firstPtr = lastPtr = newPtr; // new list has only one node else // List is not empty { newPtr->nextPtr = firstPtr; // point new node to previous 1st node firstPtr = newPtr; // aim firstPtr at new node } // end else } // end function insertAtFront

// insert node at back of list template< typename T > void List< T >::insertAtBack( const T &value ) { ListNode< T > *newPtr = getNewNode( value ); // new node if ( isEmpty() ) // List is empty firstPtr = lastPtr = newPtr; // new list has only one node else // List is not empty { lastPtr->nextPtr = newPtr; // update previous last node lastPtr = newPtr; // new last node } // end else } // end function insertAtBack

// delete node from front of list template< typename T > bool List< T >::removeFromFront( T &value ) { if ( isEmpty() ) // List is empty return false; // delete unsuccessful else { ListNode< T > *tempPtr = firstPtr; // hold tempPtr to delete if ( firstPtr == lastPtr ) firstPtr = lastPtr = 0; // no nodes remain after removal else firstPtr = firstPtr->nextPtr; // point to previous 2nd node value = tempPtr->data; // return data being removed delete tempPtr; // reclaim previous front node return true; // delete successful } // end else } // end function removeFromFront

// delete node from back of list template< typename T > bool List< T >::removeFromBack( T &value ) { if ( isEmpty() ) // List is empty return false; // delete unsuccessful else { ListNode< T > *tempPtr = lastPtr; // hold tempPtr to delete if ( firstPtr == lastPtr ) // List has one element firstPtr = lastPtr = 0; // no nodes remain after removal else { ListNode< T > *currentPtr = firstPtr; while ( currentPtr->nextPtr != lastPtr ) // locate second-to-last element currentPtr = currentPtr->nextPtr; // move to next node lastPtr = currentPtr; // remove last node currentPtr->nextPtr = 0; // this is now the last node } // end else value = tempPtr->data; // return value from old last node delete tempPtr; // reclaim former last node return true; // delete successful } // end else } // end function removeFromBack

// is List empty? template< typename T > bool List< T >::isEmpty() const { return firstPtr == 0; } // end function isEmpty // return pointer to newly allocated node template< typename T > ListNode< T > *List< T >::getNewNode( const T &value ) { return new ListNode< T >( value ); } // end function getNewNode

// display contents of List template< typename T > void List< T >::print() const { if ( isEmpty() ) { // List is empty cout << "The list is empty\n\n"; return; } // end if ListNode< T > *currentPtr = firstPtr; cout << "The list is: "; while ( currentPtr != 0 ) { // get element dat cout << currentPtr->data << ' '; currentPtr = currentPtr->nextPtr; } // end while cout << "\n\n"; } // end function print #endif
