Nuclear medicine in general practice Dr Reza Garzan MD, FRACP, FAANMS Myocardial perfusion study Bone scans in general practice Thyroid scans in general practice Gamma camera Detection of gamma rays Myocardial perfusion Imaging How

slide-1
SLIDE 1

Nuclear medicine in general practice

Dr Reza Garzan MD, FRACP, FAANMS

slide-2
SLIDE 2
  • Myocardial perfusion study
  • Bone scans in general practice
  • Thyroid scans in general practice
slide-3
SLIDE 3

Gamma camera

slide-4
SLIDE 4

Detection of gamma rays

slide-5
SLIDE 5

Myocardial perfusion Imaging

slide-6
SLIDE 6

How is it performed?

Rest/Stress protocol : Radiopharmaceutical injected at rest and then post stress. Same day or two day protocol

slide-7
SLIDE 7

Radiopharmaceuticals

Tc-99m Sestamibi (MIBI)

  • Sestamibi (MIBI) : Lipophilic agent, diffuses from blood

into the myocardial cell and is retained in mitochondria

  • Tc-99m : Short physical half life of 6hrs , good energy

gamma rays ( better quality pictures)

slide-8
SLIDE 8

Radiopharmaceuticals

Thallium (TI-201):

  • Behaves physiologically much like K ion, and is transported

across the myocardial cell membrane via Na-K ATPase

  • Long half life and low energy photons, so much less commonly

used nowadays

slide-9
SLIDE 9

Modes of stress

  • Exercise
  • Pharmacologic
  • Vasodilator ( Adenosine, Dipyridamole) :

Dilate the coronary arteries, but the stenosed vessels are not able to dilate as much as normal coronary arteries are able to. Contraindicated in asthma and severe COPD.

  • Dobutamine : Sympathomimetic
slide-10
SLIDE 10

ACCF/ASNC/ACR/AHA/ASE/SCCT/SCMR/SNM 2009 Appropriate Use Criteria for Cardiac Radionuclide Imaging

J Am Coll Cardiol. 2009;53(23):2201-2229. doi:10.1016/j.jacc.2009.02.013

slide-11
SLIDE 11
slide-12
SLIDE 12

Ischemic cascade

slide-13
SLIDE 13
slide-14
SLIDE 14

What information do we get from MPS?

  • Perfusion (rest and stress)
  • Wall motion (rest and stress), systolic

function, LVEF

  • Symptoms
  • If exercise, exercise capacity
  • ECG changes
slide-15
SLIDE 15

Cardiac planes

slide-16
SLIDE 16
  • 67-year-old-man, with episodes of chest pain

at rest

slide-17
SLIDE 17
slide-18
SLIDE 18
slide-19
SLIDE 19
  • 74- year-old, with DM and exertional chest

and throat pain, unable to complete exercise stress test

slide-20
SLIDE 20
slide-21
SLIDE 21
  • Moderate to large amount of reversible

ischemia in LAD territory

slide-22
SLIDE 22
slide-23
SLIDE 23

Small MI in distal LAD territory

slide-24
SLIDE 24

Prognostic value of normal ( low -risk) and moderately to severely abnormal (high-risk) myocardial perfusion SPECT in estimating annual rates of cardiac death and nonfatal myocardial infarction

slide-25
SLIDE 25
slide-26
SLIDE 26
  • Bone Scans
slide-27
SLIDE 27
  • Radiotracer injected, ( Tc-99m HDP)
  • Early phase images immediately ( presence or

absence of hyperaemia/normal or abnormal vascularity)

  • Delayed phase images in about 3-4 hrs (
  • steoblastic activity)
slide-28
SLIDE 28

Common applications of bone scans in general practice

  • Stress fractures
  • Sports injuries
  • Suspected fractures with normal x-ray
  • Arthritis/assessment of facet joint arthropathy
  • Osteomyelitis
  • Staging and restaging of prostate, breast and

lung cancers

  • Metabolic bone disease e.g. Paget’s disease
  • Assessment of painful THR and TKR
slide-29
SLIDE 29

Normal whole body bone scan

slide-30
SLIDE 30

Case 1

  • 50 year old female, pain in bilateral hands ,

history of fall 4 days back on outstretched

  • hands. Xray : normal
slide-31
SLIDE 31

Blood flow and blood pool images

slide-32
SLIDE 32

Delayed images

slide-33
SLIDE 33

SPECT/CT

slide-34
SLIDE 34
  • Fracture of bilateral trapezium
slide-35
SLIDE 35
  • 76 year-old female, active walker, pain in

the left foot since 3/52, ? Stress Fx

Case 2

slide-36
SLIDE 36

Blood flow and blood pool images

slide-37
SLIDE 37

Blood pool images

slide-38
SLIDE 38

SPECT/CT

slide-39
SLIDE 39
  • Active arthritis of tarsometatarsal joint
slide-40
SLIDE 40
  • 85-year-old female, Chronic ulcer in the

left foot, close to 1st MTP joint.

Case 3

slide-41
SLIDE 41

Blood pool images

slide-42
SLIDE 42

Delayed images

slide-43
SLIDE 43

SPECT/CT

slide-44
SLIDE 44
  • Osteomyelitis of the distal left 1st

metatarsal bone

slide-45
SLIDE 45
  • 47 -year-old male, right 2nd metatarsal

pain after a long walk

Case 4

slide-46
SLIDE 46

Blood flow and blood pool images

slide-47
SLIDE 47

Delayed images

slide-48
SLIDE 48

SPECT/CT

slide-49
SLIDE 49
  • Stress fracture of distal right 2nd

metatarsal

slide-50
SLIDE 50
  • 52 year old female, with back pain for

investigation

Case 5

slide-51
SLIDE 51

Delayed SPECT/CT images

slide-52
SLIDE 52
  • Intensely increased radiotracer uptake in

the left L5/S1 facet joint, consistent with left L5/S1 facet joint arthropathy

  • Can be useful for investigation of cervical

facet joint arthropathy too.

slide-53
SLIDE 53

Case 6

  • 68-year-old man with right foot and heel pain

after long walk.

slide-54
SLIDE 54
slide-55
SLIDE 55
slide-56
SLIDE 56
  • Right Achilles tendon enthesopathy
slide-57
SLIDE 57

Thyroid scans

  • Thyrotoxicosis
  • Assessment of thyroid nodules
slide-58
SLIDE 58

Radiopharmaceutical : Tc-99m Pertechnatate ( TcO4)

slide-59
SLIDE 59
  • 69 year-old man presenting with

thyrotoxicosis

slide-60
SLIDE 60
slide-61
SLIDE 61
  • Hot autonomous functioning nodule
slide-62
SLIDE 62
  • 65 year-old female, presenting with

thyrotoxicosis

slide-63
SLIDE 63
slide-64
SLIDE 64
  • Graves’ disease
  • Positive TSH receptor antibodies can confirm

the diagnosis

slide-65
SLIDE 65
  • 30-year-old female presenting with post-

partum hyperthyroidism

slide-66
SLIDE 66
slide-67
SLIDE 67
slide-68
SLIDE 68

Thank you!
