Network Reliability and Interoperability Council VII

NRIC Council Meeting

Focus Group 4 Broadband Mary Retka, Chair Reference Model Architectures for the Deployment of Residential Internet Access Service December 6, 2004

1

Network Reliability and Interoperability Council VII

Focus Group 4 Charter

“The Council shall present recommendations to increase the deployment of high-speed residential Internet access service. The Council shall include Best Practices and service features that are, and will be, technology-neutral. The Council’s recommendations shall be prepared in such a way as: (1) to ensure service compatibility; (2) to facilitate application innovation; and (3) to improve the security, reliability and interoperability of both residential user systems and service provider systems. ”

2

Network Reliability and Interoperability Council VII

Focus Group 4 Participants

• Albert Young, Cox
• Art Reilly, Cisco
• Brett Kilbourne, UTC
• Charlie Cerino, Comcast
• Dave McDysan, MCI
• Dave Wangrow, Motorola
• Dave Waring, Telcordia
• David Young, Verizon
• Doug Cooper, Catena/Cienna
• Jeff Hubbard, Qwest
• Jim Johnson, Bell South
• Jim Katzman, AOL
• Jim Runyon, Lucent
• John Colombo, Verizon
• John Chapa, SBC
• John Kenyon, Hughes Network Systems
• Kenny Kopta, Sprint
• Kevin Kearns, APCO
• Leo Palumbo, AT&T
• Lori Messing McGarry, CTIA
• Mark Behee, Motorola
• Mary Retka, Qwest
• Mike Petry, MCI
• Pete Youngberg, Sprint
• Randy Sharpe, Alcatel
• Tolga Ors, Intelsat
• Tom Soroka, USTA
• Victor Devito, AT&T
• Carl Postuma, Lucent
• Tim Walden, CenturyTel
• Jim Mollenkopf, Current Technologies
• Doug McMurray, IDACOMM
• Brian White, CenturyTel
• Roger DeVille, CenturyTel
• Fouad Brahim Boumakh, Digital Wireless

3

Network Reliability and Interoperability Council VII

Scope

• NRIC VII Focus Group 4 will identify and develop reference

model architectures illustrating all current generally available alternatives to provision high speed residential Internet access service.

• These reference models will be the most commonly known

methods for high-speed residential Internet Access deployment.

• The reference models, reflecting today’s existing environment,

are to be segmented by the type of infrastructure deployed

• These reference models will depict only those components of the

architecture required to provide high-speed residential Internet access service.

• While some of the reference models may be geographically

bounded, others will not be geographically bounded.

4

Network Reliability and Interoperability Council VII

Methodology

• Reviewed the work of the NRIC VI FG on

Broadband and agreed to use it as a baseline and move forward from there with our new charter.

• Developed the definition of Residential Internet

Access

• Developed the Master Reference Model and defined

the demarcation points for this effort to be on the network side of the connection to the customer and at the connection point to the Internet

• Subgroups developed models of the architectures.

5

Network Reliability and Interoperability Council VII

Residential Internet Access

• The term Residential Internet Access encompasses the many

different commercially available ways for Residential Consumers to access the Internet.

• The use of this term in the context of this deliverable is not

application specific.

• Residential Internet Access is considered to be a pathway from the

subscriber to the public Internet.

• Broadband technology should be viewed in terms of having

sufficient bandwidth to provide satisfactory performance while accommodating a wider range of customers, applications and technological requirements.

• It is viewed to be always-available access technology so long as the

user’s Internet device is turned on, and requires no additional user activity to function.

• It has sufficient bandwidth to support multiple applications

simultaneously.

• The area of concentration for this focus group is to offer

recommendations to further advance the domestic use of broadband technology for Residential Internet Access.

6

Network Reliability and Interoperability Council VII

Master Reference Model

Customer Demarcation Interface Internet Demarcation Interface

Connection ISP ASP * *For purposes Of 3rd deliverable ISP ISP Internet Customer Premises Broadband Aggregation & Transport

Enables the Connection To the Internet Provides Routing, Aggregation, Protocol Management & Signal Carriage Link to Transport and Aggregation Devices (Stationary or Mobile) Initiates, Packetizes & Holds the Data Connection Session

7

Network Reliability and Interoperability Council VII

Sample Reference Model DSL

Customer Demarcation Interface Internet Demarcation Interface

ISP

Connection ISP

*For purposes Of 3rd deliverable

ISP ISP Internet Customer Premises Broadband Aggregation & Transport

Enables the Connection To the Internet Provides Routing, Aggregation, Protocol Management & Signal Carriage Link to Transport and Aggregation Devices (Stationary or Mobile) Initiates, Packetizes & Holds the Data Connection Session CO DSLAM Remote DSLAM Broadband Access Server

L2TP Network Server

L2TP Access Concetrator

BAS LNS LAC

Broadband Access Server (i.e. ATM, MPLS, FR) Packets Data from End user, Aggregates Multiple User packets and Transmits to the Internet and vice versa DSLAM Combines Multiple Services onto a single transport & vice versa

ASP*

This depicts 2 Options to connect to the Internet

Fiber Copper

Connection may be fiber or copper

8

Network Reliability and Interoperability Council VII

Sample Reference Model Cable

Customer Demarcation Interface Internet Demarcation Interface

Connection ISP ASP* ISP ISP Internet Customer Premises Broadband Aggregation & Transport

Enables the Connection To the Internet Provides Routing, Aggregation, Protocol Management & Signal Carriage Link to Transport and Aggregation Devices

(Stationary Or Mobile) Initiates, Packetizes & Holds the Data Connection Session Router Routes Data traffic to and from Internet Cable Modem & Splitter feeding

• ther CPE devices

CMTS Cable Router Customer Ground Block Fiber Run & Optical Splitter RF Line Extension Cable Optical Transmitters/ Receivers Fiber Node Tap Cable System Channel Combiner Coax Fiber Data

RF Distribution

*For purposes Of 3rd deliverable

9

Network Reliability and Interoperability Council VII

Sample Reference Model Mobile Wireless Data

Customer Demarcation Interface Internet Demarcation Interface

Enables the Connection To the Internet Provides Transmission, Channel Control & Management (Mobile) Initiates, Packetizes & Holds Data Connection Session

Aggregation & Transport

Radio Access Network

Broadband

Core Network Provides Authentication, Authorization, Accounting, Routing, and Session Control Router / Firewall Wireless Packet Network Operator IP Core Network

Customer Equipment

Mobile Subscriber

Connection

ISP ISP ISP

Internet

ASP* For purposes

• f 3rd

deliverable

10

Network Reliability and Interoperability Council VII

Next Steps

• Based on these models, the Focus Group has

already begun the next effort to identify Best Practices that facilitate the deployment of a high speed residential Internet access service

• architecture. The deliverable is due on June 24,

2005

• A sub group has determined the status of our

existing broadband Best Practices. We have begun to set the path for the development of our new Best Practices.
