Nova Project Update, OpenStack Summit Berlin Melanie Witt - - PowerPoint PPT Presentation

Nova

Project Update, OpenStack Summit Berlin

Melanie Witt irc:melwitt Red Hat

November 2018

What is Nova?

• Compute service
• Nova provides the compute

controller fabric for the base OpenStack IaaS deployment

Project background

• Founded during the Austin release of OpenStack
• 255 contributors for latest release (Rocky) [1]

Latest user survey adoption numbers:

• Deployed: 94% of clouds in production indicate

they are using this project

[1] http://stackalytics.com/?release=rocky&metric=marks&module=nova-group

http://specs.openstack.org/openstack/nova-specs/priorities/rocky-priorities.html

• Piloted a new review process
• Changed spec freeze from milestone 1 => milestone 2
• Overall positive, helped complete some blueprints that had repeated re-approvals over previous

cycles

• Comparison of blueprint completion stats

Rocky Review Runways

Queens Rocky Max approved 53 72 Final completed 42 59 Completion percentage 79.2% 81.9%

https://docs.openstack.org/releasenotes/nova/rocky.html

• Using new Neutron port binding API to minimize network downtime during live migrations
• Volume-backed servers are no longer reporting ‘root_gb’ usage
• Several nova-network specific REST APIs were removed
• New ‘nova-manage db purge’ command, ‘nova-manage db archive_deleted_rows --purge’
• New option ‘nova-manage cell_v2 update_cell --disable’ to disable scheduling to a cell
• Trusted image certificates are supported
• New ‘nova-manage placement heal_allocations’ command for CachingScheduler users to

populate placement ahead of migration to FilterScheduler

• Placement service now supports granular RBAC policy rules configuration

OpenStack Rocky Features

cell1

OpenStack Rocky Features

Console token authorization moved from nova-consoleauth service ➡ database backend

cell2 nova-novncproxy nova-consoleauth nova-compute nova-compute nova-compute nova-compute

Queens

DB DB cell1 cell2 nova-novncproxy nova-compute nova-compute nova-compute nova-compute

Rocky

DB DB nova-novncproxy

➡ Other improvements (microversion highlights)

OpenStack Rocky Features

Microversion Description 2.61 Exposes flavor extra-specs in the flavors API GET/POST/PUT 2.62 Adds host and hostId to the instance actions API GET 2.63 Adds support for the trusted_image_certificates parameter 2.64 Adds policy and rules to the server groups API GET/POST 2.65 Adds support for aborting live migrations in queued or preparing status

http://specs.openstack.org/openstack/nova-specs/priorities/stein-priorities.html

• Cycle Priorities (<= Queens) ➡ Runways (Rocky) ➡ Runways + Cycle Themes (Stein)
• Multi-cell operational enhancements

○ Handling of a down or poor performing cell ○ Cross-cell cold migration

• Improved boot from volume experience

○ Specify volume type at server create ○ Attach/detach root volume ○ Volume-backed server rebuild

• Compute hosts able to upgrade and exist with nested resource providers for multiple vGPU

types

OpenStack Stein

https://specs.openstack.org/openstack/nova-specs/specs/stein/index.html ➡ Other improvements

• Placement extraction
• Bandwidth-aware scheduling
• Unified limits + oslo.limit for quota
• Restore ability to set overcommit ratios per aggregate
• Configuration of maximum number of volumes allowed to attach to a single server
• Support for emulated virtual TPM (Trusted Platform Module)
• NUMA-aware live migration
• AMD SEV-encrypted instances (Secure Encrypted Virtualization)

OpenStack Stein

Cross-Project Work

• Cinder

○ New re-image API for volume-backed rebuild

• Neutron

○ Bandwidth-aware scheduling

■ Guaranteed Minimum Bandwidth - Feature Demo (Thu 15, 5:10pm - 5:50pm)

• Keystone

○ Unified limits + oslo.limit

■ Enforcing Quota Consistently with Unified Limits (Wed 14, 5:30pm - 5:40pm)

• Ironic

○ Use conductor groups to partition nova-compute services

Cross-Project Work (continued)

• Cyborg

○ Accelerator management

■ Related presentation: Cyborg: Accelerate Your Cloud! (Thu 15, 2:30pm - 3:10pm)

• Multiple projects

○ Transfer ownership of resources

■ Forum session: Change of ownership of resources (Thu 15, 1:40pm - 2:20pm)

• Accelerator management
• NUMA modeling with placement

○ Example: vGPU + NUMA

• Affinity modeling with placement

○ Late-affinity check cannot work with multi-cell and split message queues

• Partitioning/sharding/consumer-key in placement

○ What app am I? ○ What edge site/deployment/cluster am I in?

• Proper handling of shared storage

Beyond Stein

How to give feedback

• Report bugs
• Start a conversation in the openstack-dev@ and/or openstack-operators@ mailing lists

■ Soon to be only openstack-discuss@ on December 3

○ Tell us how you or your users are using the compute service ○ What is missing? ○ What are your barriers to entry? ○ What deployment tooling do you need, i.e. nova-manage?

How to give feedback

• Attend Forum sessions

○ Cells v2 updates (Tue 13, 11:00am - 11:40am) ○ NFV/HPC Pain Points (Wed 14, 11:00am - 11:40am) ○ Boot from volume (BFV) improvements (Wed 14, 11:50am - 12:30pm) ○ Getting Operators' bugfixes upstreamed (Wed 14, 5:10pm - 5:50pm) ○ Concurrency limits for service instance creation (Thu 15, 11:40am - 12:20pm) ○ Change of ownership of resources (Thu 15, 1:40pm - 2:20pm) ○ Update on placement extraction from nova (Thu 15, 2:30pm - 3:10pm)

• Forum session etherpads

○ https://wiki.openstack.org/wiki/Forum/Berlin2018

How to contribute

https://docs.openstack.org/nova/latest/contributor/index.html

• Subscribe to the openstack-dev mailing list and filter on [nova]

○ Soon to be openstack-discuss on December 3

• Chat with us at #openstack-nova in freenode IRC
• Attend some weekly meetings: https://wiki.openstack.org/wiki/Meetings/Nova
• Help with bug triage

○ How-to docs: https://wiki.openstack.org/wiki/Nova/BugTriage ○ Forum session: Bug triage: Why not all the community? (Thu 15, 9:00am - 9:40am)

• Attend the Nova - Project Onboarding (Tue 13, 1:40pm - 2:20pm)

How to contribute

• Help with code reviews
• Help cleanup the docs; if something does not make sense or is missing, tell us - or better yet

push a patch to fix it

• Try to break things and report bugs
• Perform scale testing and identify bottlenecks - and report them
• Propose bug fix backports to the stable branches

@OpenStack

Q&A

Thank you!
