Nov. 19 , 2018 1 Introduction Dynamic Range Goal: Find the - - PowerPoint PPT Presentation

Maritza Delgado, Alexander Himmel, Deywis Moreno.

1

• Nov. 19 , 2018

Introduction

Goal: Find the maximum number of true photons with different time windows and quantum efficiency.

• Data

generated by module SPCounter_module.cc, based

• n

SimPhotonCounter_module.cc.

• Sample: Beam Neutrinos

prodgenie_nu_dune10kt_1x2x6_323_20171227T183346_merged1.root

• The first step was to identify the maximum number of true photons by each

Optical Detector per event from PhotonsLite.

2

Dynamic Range

3

• The second step was to do each histogram of maximum number of true

photons, considering:

• Different time Windows:

+ 1ns + 6ns + 12ns + 1µs + 3µs

• The scale factors calculation with the quantum efficiency of each

effective detector areas of 15, 30, 45, and 60 cm2.

• The third step was to determine the maximum number of true photons in

the scale ADC (10 ADC/PE).

• The last step was to identify 99% of the events, and fraction of saturated

events.

4

Area (cm2) QE QE/4 /0.03 15 0,01063 0,088583 30 0,021231 0,176925 45 0,031847 0,265392 60 0,042462 0,35385

*One Optical Detector have 4 Channels. *0.03 is the ScintPreScale parameter

The scale factor was determined using the effective detector areas and QE values.

https://indico.fnal.gov/event/16848/contribution/4/material/slides/0.pdf

5

TIME 1ns 6ns 12 ns 1µs 3µs Maximum Photons (ADC) 11563 66600 95000 228000 332500 Max Photons 99% (ADC) 1562 9000 12500 30000 43750

99% (3µs)

6

TIME 1ns 6ns 12 ns 1µs 3µs Maximum Photons (ADC) 23125 133000 185000 456000 647500 Max Photons 99% (ADC) 3125 17500 25000 60000 87500

99% (3µs)

7

TIME 1ns 6ns 12 ns 1µs 3µs Maximum Photons 35150 199500 277500 678000 971250 Max Photons 99% 4625 26250 37500 92500 131250

99% (3µs)

8

TIME 1ns 6ns 12 ns 1µs 3µs Maximum Photons (ADC) 45950 266000 370000 906500 1295000 Max Photons 99% (ADC) 6250 35000 50000 123500 175000

99% (3µs)

9

1ns 6ns 12ns 1us 3us >12bits 0.2% 3.3% 6% 19% 23% >14bits 0% 0.3% 0.5% 2.5% 5% >16bits 0% 0.06% 0.06% 0.3% 0.3% >18bits 0% 0% 0% 0% 0.06%

12bits= 4096 14 bits = 16384 16 bits = 65536 18bits = 262144

Saturated events

10

12bits= 4096 14 bits = 16384 16 bits = 65536 18bits = 262144

1ns 6ns 12ns 1us 3us >12bits 0.4% 10% 13% 28% 34% >14bits 0.06% 1% 2% 8% 13.4% >16bits 0% 0.06% 0.2% 1% 1.8% >18bits 0% 0% 0% 0.06% 0.1% Saturated events

11

12bits= 4096 14 bits = 16384 16 bits = 65536 18bits = 262144

1ns 6ns 12ns 1us 3us >12bits 1.3% 15% 20% 38% 42% >14bits 0.06% 2.2% 4% 14% 19% >16bits 0% 0.18% 0.3% 1.9% 3.3% >18bits 0% 0% 0.06% 0.1% 0.3% Saturated events

12

12bits= 4096 14 bits = 16384 16 bits = 65536 18bits = 262144

1ns 6ns 12ns 1us 3us >12bits 1.8% 19.4% 24% 42.2% 48.5% >14bits 0.2% 3.5% 6.2% 18.8% 23.4% >16bits 0% 0.3% 0.5% 2.8% 5.2% >18bits 0% 0% 0.06% 0.3% 0.35% Saturated events

Conclusions.

13

+ It is important to analyze how many true photons arrive at the optical detector in different time windows, and to control a possible saturation of the electronics. + Physics requirements: dynamic range needs to be sufficiently high that no more than 10% of events have channels which saturate. * The digitalization (6ns , 12ns) need 14 bits of dynamic range. * The integration electronics (1µs, 3µs) need 16 bits of dynamic range. + Next step is to identify if is possible reconstruct energy with saturating Channels.

14

Esp Especially ly to to Al Alex ex Hi Himmel el and and Dew ewis Mor Moreno.

15

0.2% Saturated events in 16 bits.
