NORTHWESTERN GEOPLEX

Safety Value Quality

Agenda

§ Company Overview § Our Services § Contract Summary § OEM/Partner’s List § Client List

Khartoum, Sudan Kampala, Uganda Luanda, Angola Point Noire, Congo Lagos, Nigeria Port Harcourt, Nigeria Accra Ghana Abidjan, CDI

Countries we currently Operate

N’,Djamena

• Ghana- Northwestern Geoplex
• Nigeria- Geoplex Drillteq
• Uganda- TerraDyne
• Chad- Geoplex Chad
• Congo- Geoplex Congo

INDIGENOUS

12+

YEARS OF OPERATIONS

6+

COUNTRIES

Company Overview : Who we are…

4

v An indigenous Ghanaian Company v Majority shares owned by Northwestern Solutions v Provide various Engineered Services to help the client increase production. v We have developed various value-added alliances leading to high quality at lower rates. v We comply with the implementation of Local Content Objectives.

Company Overview : Who we are…

5

§ MWD-LWD-DD Services § Cased and Open Hole Electric Wireline Services § Slickline Services § Cementing and Coiled Tubing Services § Gyro Services (E-line, Memory, GWD) § Well Testing Services § TCP and DST Services § Completion and Production Services

Our Services

§ Rig and Pulling unit Services § Floating, Production, Storage & Offloading Services § Integrated Project Management Service § Oilfield Support Services

6

• Baker Hughes Based Measurement While Drilling

(MWD) Systems

• Logging While Drilling (LWD) Services
• Resistivity/GR/APWD- OnTrak
• Density Neutron- LithoTrak
• Acoustic LWD- SoundTrak
• Formation Pressure While Drilling- TestTrak
• Formation Sampling While Drilling – FastTrak
• Geosteering- Azitrak
• Steerable Motors (available in various hole sizes)
• Rotary Steerable Systems- AutoTrak
• Dumb Iron Rental (Mags and Non-Mags)
• Gyro- Drop, Wireline and GWD

MWD-LWD-DD Services

7

MWD-LWD-DD Services- History With ENI (Jobs)

S/NO RIG CLIENT WELL HOLE SECTION JOB MOBILIZATION JOB COMPLETED 1 HPEB120 ENI EBOCHA-23 12 1/4" & 8.5" 17-Jun-12 4-Sep-12 2 HPEB119 ENI MBEDE-28DIR 16" & 12 1/4" 14-Jul-12 9-Sep-12 3 OES-TEAMWORK ENI OGBAINBIRI 1ST2 26, 16", 12 1/4" & 8 1/2'' 8-Nov-12 27-Dec-12 4 OES-TEAMWORK ENI TINPA - B 26, 16", 12 1/4" & 8 1/2'' 7-Mar-13 13-May-13 5 HPEB119 ENI SAMABIRI 12 26, 16", 12 1/4" & 8 1/2'' 19-Nov-14 30-Sep-13 6 SAIPEM 10K ENI EBERAN 3 26, 16", 12 1/4" & 8 1/2'' 5-Oct-14 15-Nov-13 7 OES-TEAMWORK ENI AZUZUAMA 4 ST 8 1/2" 5-Oct-13 16-Jan-14 8 SAIPEM 10K ENI ETAN 3 26, 16", 12 1/4" & 8 1/2''

24-Nov-13 16-Jan-14

9 HPEB 119 ENI SAMABIRI E 4 ST 2 8 1/2" and 6"

22-Apr-14 2-Jun-14

10 OES INTEGRITY ENI Ogbainbiri Deep F 26, 16", 12 1/4" & 8 1/2''

19-Sep-18 20-Nov-18

11 HILONG 19 ENI ISOKO SOUTH 2ST 26, 16", 12 1/4" & 8 1/2

14-Dec-19

8

MWD-LWD-DD Services

S/N SERVICE AWARD TYPE EFFECTIVE DATE EXPIRY DATE SIGNED DATE

1 Directional Survey Service CONTRACT Jun-12 Jun-14 Jun-12 2 Directional Survey Service CONTRACT Oct-11 Oct-13 Oct-11 3 PROVISION OF DIRECTIONAL DRILLING SERVICES FOR JV CONTRACT Aug-19 Aug-21 Aug-19

MWD-LWD-DD Services- History With ENI (Contracts)

9

MWD-LWD-DD Services- History With ENI (Contracts)

10

Electric Wireline Services

• Dual Induction Log
• Dual and Micro Laterolog
• Litho Density Log
• Dual Detector Neutron Porosity Log
• Spectral Gamma-Ray Log
• Gamma-Ray Log
• Full Waveform Acoustic Log
• Acoustic Borehole Imager
• Four Arm Caliper
• Four Arm Dipmeter Log
• Acoustic Borehole Imager
• Formation Tester and Sampling Tool
• GR-CCL Correlation
• Plug and Packer Setting
• Cement Bond Evaluation Log (CBL/VDL)
• Pipe Recovery (Back-off, Split Shot , DCST)
• Tubing Cut (RCT-Mechanical Cutters-Chemical)
• Corrosion Logging
• Noise Logging
• Casing and Through Tubing Perforation
• Tractor Conveyance
• Reservoir Saturation Measurements (RPM)
• Production Logging (Reservoir Saturation

Measurements)

• Quartz Gauge Pressure Measurement

Cased Hole Services Open Hole Services

11

Electric Wireline Services- History With ENI (Contracts)

Wireline Services

S/N SERVICE AWARD TYPE EFFECTIVE DATE EXPIRY DATE SIGNED DATE 1 Wireline Logging Services PO-4600030331 27-Jan-17 28-Jan-17 31-Jan-17 2 Wireline Logging Services PO-4600030329 12-Feb-17 16-Feb-17 30-Jan-17 3 Wireline Logging Services PO-4600030332 29-Jan-17 2-Feb-17 31-Jan-17 4 Wireline Logging Services Blanket Order - 5000011749 19-Jan-17 31-Jan-17 22-Jan-17 5 Wireline Logging Services PO-4600030366 17-Feb-17 21-Feb-17 30-Jan-17 6 Wireline Logging Blanket Order 19-Jan-18

• 7

Wireline Logging Purchase Order 18-Apr-17

12

Electric Wireline Services- History With ENI (Contracts)

13

Slickline Services

• Slickline Well Completion
• BHP Survey/Slickline Zone Change Out
• Wax Cutting/Swabbing/Slickline Fishing
• Communications Check/Gaslift Valve Change Out
• Slickline Re-completions/Open and Close SSD
• SC-SSV Change Out/Storm Chokes
• Slickline Well Depths Measurements
• Plug Setting and Pulling
• Memory Production Logging Services
• Memory Slim Cement Bond Logging Tool

14

Cementing Services

TWIN TRIPLEX PUMPS 10Kpsi Pressure Rating

MIXING SYSTEM CENTRIFUGAL Mixing Pump @ 50psi/110bpm AUTOMATIC DENSITY CONTROL

Continuous / Batch Mixing mode to 22 +/- 0.1 ppg

DISCHARGE

3" x 10,000 PSI working pressure

EMERGENCY MIXING SYSTEM

10-12 barrel per minute

MIXING TANK 7 barrels with RCM TERRAIN Offshore/Land /Swamp

Cementing Unit Specs

15

Coiled Tubing Services

SAFETY ZONE II APPROVED

TUBING SIZE 1-1/2” (1-1/4”- 3-1/2” CAPABLE) INJECTOR INTERMITTENT LIFTING CAPACITY 90,000LBS INJECTOR INTERMITTENT LIFTING CAPACITY 80,000LBS CONTINUOUS SNUBBING CAPACITY 40,000LBS TERRAIN Offshore/Land /Swamp

16

Cementing and Coiled Tubing Services- History With ENI (Contracts)

Cementing and Pumping Services

1

Cementing & Pumping

Contract

• 4-Jul-18

2

Chicksan Pipes, Fittings and Services

Contract(Blancket Order 5000013303) Jun-18 Dec-18 Aug-18

3

Dewatering Pumps/Hose

Contract(Blancket Order 5000013304) Jun-18 Dec-18 Aug-18

4

Cementing and Pumping services

Contract(Blancket Order 5000012876) Jun-18 Dec-18 Aug-18

5

PROVISION OF CEMENTING & PUMPING SERVICES , OBIANBIRI & OBIAFU SW DEEP WELL CONTRACT Sep-18 Sep-20 Sep-18

6

PROVISION OF CEMENTING AND PUMPING SERVICES TO OBIAFU DEEP WELL CONTRACT [APPENDIX A & A2, BLANKET ORDER, TECHNICAL SPECIFICATIONS, APPENDIX D] Feb-19 Jan-20 Feb-19

7

PROVISION OF CEMENTING AND PUMPING SERVICES TO OBIAFU DEEP WELL CONTRACT [APPENDIX A & A2, BLANKET ORDER, TECHNICAL SPECIFICATIONS, APPENDIX D] Aug-19 Aug-21 Aug-19

8

PROVISION OF CEMENTING AND PUMPING SERVICES FOR NAOC JV OPERATION IN LAND AND SWAMP AREA LOI Jul-19 Jul-19

17

Cementing and Coiled Tubing Services- History With ENI (Contracts)

• 1

8

Well Testing Services

• Surface Well Testing

ü Tested over 20 wells for

NAOC Land and Swamp in 2019 ü Tested all XOM Wells in Nigeria in 2019

• Reservoir Sampling Analysis
• Multiphase Well Testing and

Monitoring

• Early Production Facilities

• 1

9

Well Testing Services - History With ENI (Contracts)

20

• Our seamless partnership with Yinson

Acacia Limited has allowed us to deliver Floating Production Storage and Off- loading (FPSO) services flawlessly to our esteem clients.

FPSO and Offshore Support Vessel Services

21

Tubular Maintenance & Inspection Services

22

Riser Maintenance & Inspection services

• Disassembly, Reassembly and Installation of Risers
• Sand Blasting of Risers Body and Auxiliary Lines for Inspection

& Full Body Painting

• Ultra-High Pressure Water blasting of Risers body and

components prior to painting

• Welding repairs and fabrication of Risers
• Removal, Inspection and Replacement of Riser Line Seals
• Dimensional Inspection of Riser Lines
• Inspection and Replacement of Riser Collars, Thrust Collars

and Plates

• Inspection of Riser Coatings

23

Riser Maintenance & Inspection services

§ Schlumberger – Open Hole Logging § Baker Hughes– DD, LWD, MWD § Weatherford – Whip-stock and Completions § Scientific Drilling – Gyro § Exceed- Integrated Project Management § Yinson – FPSO § Welltec – Tractor Services and Well Intervention suites § General Electric – Risers, Gauges, BOP § TTGM - OCTG We choose the best as our partners and alliance.

Industry Partnership & Alliances

2 § NAOC § Transocean § Total § Chevron § Shell § ExxonMobil § Oando § NPDC § NDPR § Addax § Seplat § Sterling Global § Waltersmith § SEEPCO § SHEBAH § Frontier Oil

IOC & NOC Clients Supported

§ Midwestern § Oilflow § Welltec § Sahara § SNEPCO

26

Thank you
