Normal forms for planar string diagrams Antonin Delpeuch, Jamie Vicary SYCO 2 Background: word problem in higher categories ? = Background: word problem in higher categories ? = Theorem (Makkai, 2005) The word problem for cells of a
SLIDE 2
SLIDE 3
Background: word problem in higher categories
= ?
Theorem (Makkai, 2005)
The word problem for cells of a finitely generated strict n-category is decidable. Idea of the proof: the configuration space of a given diagram is finite.
SLIDE 4
Background: word problem in higher categories
= ?
Theorem (Makkai, 2005)
The word problem for cells of a finitely generated strict n-category is decidable. Idea of the proof: the configuration space of a given diagram is finite. As an algorithm, this is vastly inefficient.
SLIDE 5
The planar case
u v . . . . . . . . . . . . . . . u v . . . . . . . . . . . . . . . ≃
SLIDE 6
The planar case
u v . . . . . . . . . . . . . . . u v . . . . . . . . . . . . . . . →R
L←
SLIDE 7
The planar case
u v . . . . . . . . . . . . . . . u v . . . . . . . . . . . . . . . →R
L←
Theorem
→R is convergent (terminating and confluent) on connected diagrams.
SLIDE 8
Confluence of right exchanges
Lemma
→R is locally confluent.
u v w u v w u v w u v w u v w u v w
R R R R R R
SLIDE 9
Confluence of right exchanges
Lemma
→R is locally confluent.
u v w u v w u v w u v w u v w u v w
R R R R R R
=
SLIDE 10
Termination
u v v u u v v u u v Termination fails in general, but:
Theorem
→R terminates in O(n3) for connected diagrams of size n.
SLIDE 11
Proof of termination
First, in the case of linear diagrams:
SLIDE 12
Proof of termination
First, in the case of linear diagrams:
SLIDE 13
Proof of termination
First, in the case of linear diagrams:
SLIDE 14
Proof of termination
First, in the case of linear diagrams:
SLIDE 15
Proof of termination
First, in the case of linear diagrams: collapsible funnel
SLIDE 16
Upper bound on derivation length
From this decomposition, we obtain inductively the following bound:
Lemma
→R terminates on linear graphs of length n in O(n3). The bound is attained for spiral-shaped diagrams:
SLIDE 17
Upper bound on derivation length
From this decomposition, we obtain inductively the following bound:
Lemma
→R terminates on linear graphs of length n in O(n3). The bound is attained for spiral-shaped diagrams:
SLIDE 18
Upper bound on derivation length
From this decomposition, we obtain inductively the following bound:
Lemma
→R terminates on linear graphs of length n in O(n3). The bound is attained for spiral-shaped diagrams:
SLIDE 19
Upper bound on derivation length
From this decomposition, we obtain inductively the following bound:
Lemma
→R terminates on linear graphs of length n in O(n3). The bound is attained for spiral-shaped diagrams:
SLIDE 20
Upper bound on derivation length
From this decomposition, we obtain inductively the following bound:
Lemma
→R terminates on linear graphs of length n in O(n3). The bound is attained for spiral-shaped diagrams:
SLIDE 21
Upper bound on derivation length
From this decomposition, we obtain inductively the following bound:
Lemma
→R terminates on linear graphs of length n in O(n3). The bound is attained for spiral-shaped diagrams:
SLIDE 22
Upper bound on derivation length
From this decomposition, we obtain inductively the following bound:
Lemma
→R terminates on linear graphs of length n in O(n3). The bound is attained for spiral-shaped diagrams:
SLIDE 23
Upper bound on derivation length
From this decomposition, we obtain inductively the following bound:
Lemma
→R terminates on linear graphs of length n in O(n3). The bound is attained for spiral-shaped diagrams:
SLIDE 24
Upper bound on derivation length
From this decomposition, we obtain inductively the following bound:
Lemma
→R terminates on linear graphs of length n in O(n3). The bound is attained for spiral-shaped diagrams:
SLIDE 25
Upper bound on derivation length
From this decomposition, we obtain inductively the following bound:
Lemma
→R terminates on linear graphs of length n in O(n3). The bound is attained for spiral-shaped diagrams:
SLIDE 26
Upper bound on derivation length
From this decomposition, we obtain inductively the following bound:
Lemma
→R terminates on linear graphs of length n in O(n3). The bound is attained for spiral-shaped diagrams:
SLIDE 27
Upper bound on derivation length
From this decomposition, we obtain inductively the following bound:
Lemma
→R terminates on linear graphs of length n in O(n3). The bound is attained for spiral-shaped diagrams: Number of steps for a spiral with n vertices: n
3
SLIDE 28
General case
Connected graph G
SLIDE 29
General case
Connected graph G Spanning tree G ′
SLIDE 30
General case
Connected graph G Spanning tree G ′ Linear envelope
SLIDE 31
General case
Connected graph G Spanning tree G ′ Linear envelope O(n3) exchanges, each of them taking O(n) time to perform: word problem solved in O(n4).
SLIDE 32
Direct algorithm to compute normal forms
By induction on the number of edges. First case: the diagram has a leaf.
SLIDE 33
Direct algorithm to compute normal forms
By induction on the number of edges. First case: the diagram has a leaf. ◮ remove this leaf;
SLIDE 34
Direct algorithm to compute normal forms
By induction on the number of edges. First case: the diagram has a leaf. ◮ remove this leaf; ◮ normalize the diagram recursively;
SLIDE 35
Direct algorithm to compute normal forms
By induction on the number of edges. First case: the diagram has a leaf. ◮ remove this leaf; ◮ normalize the diagram recursively; ◮ add the leaf back at the unique height making the diagram normalized.
SLIDE 36
Direct algorithm to compute normal forms
Second case: the diagram has a face
SLIDE 37
Direct algorithm to compute normal forms
Second case: the diagram has a face ◮ Find an eliminable edge in the face and remove it;
SLIDE 38
Direct algorithm to compute normal forms
Second case: the diagram has a face ◮ Find an eliminable edge in the face and remove it;
SLIDE 39
Direct algorithm to compute normal forms
Second case: the diagram has a face ◮ Find an eliminable edge in the face and remove it; ◮ normalize the graph recursively;
SLIDE 40
Direct algorithm to compute normal forms
Second case: the diagram has a face ◮ Find an eliminable edge in the face and remove it; ◮ normalize the graph recursively; ◮ add the edge back.
SLIDE 41
Direct algorithm to compute normal forms
Second case: the diagram has a face ◮ Find an eliminable edge in the face and remove it; ◮ normalize the graph recursively; ◮ add the edge back. Each step removes one edge and requires linear time in the number
- f vertices, so word problem solved in O(nm).
SLIDE 42
Linear time solution
Theorem
Isotopy of connected planar maps can be decided in linear time (Hopcroft and Wong, 1974)
? =
SLIDE 43
Linear time solution
Theorem
Isotopy of connected planar directed maps can be decided in linear time.
? =
SLIDE 44
Linear time solution
Theorem
Isotopy of connected string diagrams can be decided in linear time.
? =
SLIDE 45
Disconnected case
Theorem
Isotopy of string diagrams can be decided in quadratic time.
SLIDE 46
References
- A. Delpeuch and J. Vicary.
