NMEA2000 Starter Kit Product Introduction Part Number: ZDIGN2KIT NMEA2000 Starter Kit UPC:081159830670 September 2017 Digital Yacht UK Tel + 44 1179 55 44 74 SRP 65.00 ex vat www.digitalyachtamerica.com Introduction & Market Dear


slide-1
SLIDE 1

Product Introduction

NMEA2000 Starter Kit

September 2017 Digital Yacht UK Tel + 44 1179 55 44 74 www.digitalyachtamerica.com Part Number: ZDIGN2KIT UPC:081159830670 SRP £65.00 ex vat

NMEA2000 Starter Kit

slide-2
SLIDE 2

Introduction & Market

Dear Partner Nearly every new marine electronics product has an NMEA2000 interface now, but it is still “black magic” to many boat owners and even fairly technical users struggle to understand NMEA2000 and what is needed to make products work correctly together. With our large range of AIS, often the first add-on device to make a boat owner think about NMEA2000, we are regularly asked “what do I need to make it work?” This prompted us to create a cost effective and smart NMEA2000 Starter Kit that is ideal for smaller boats but can also be easily expanded in the future. There are other starter kits on the market, but none offer three device connection, metal connectors and a smart 4-Way T-Piece at such a good price. By utilising the NMEA2000 standard “Micro C” type connectors, users can easily add and expand to this Starter Kit as their installation grows or simply buy two or more kits for a larger install, still cheaper than buying the parts separately. The Digital Yacht team TEL + 44 1179 55 44 74

Product Summary SRP £65.00 ex VAT UPC 081159830670 PART NUMBER ZDIGN2KIT Everything you need to create a simple, three device NMEA2000 network

slide-3
SLIDE 3

NMEA2000 Starter Kit Features

  • Everything you need in one box
  • Smart 4-Way T-Piece “Backbone”
  • 1m (3ft) Power Cable with in-line fuse
  • 1m (3ft) “Drop Cable”
  • Pair of removable network terminators
  • Allows three devices to be connected
  • Standard “Micro C” connectors make it

very easy for future network expansion

  • Metal connectors and reduced T-Piece

connections, improve reliability

slide-4
SLIDE 4

What’s in the Box ?

1m Drop Cable 4-Way T-Piece Backbone 1m Power Cable with in-line fuse Male Female Terminator Terminator

slide-5
SLIDE 5

Small Boat Installation

  • Typical Starter Kit Install where three

connections are used to connect together; § Small Chart Plotter § AIS § Smart Speed and Depth Transducer

slide-6
SLIDE 6

Extended Installation

Two Starter Kits joined together for larger installation

slide-7
SLIDE 7

Tech Specs

Feature Power

  • 9v to 16v Network Supply Voltage
  • All cabling and connectors rated at 3A

Connections

  • 4x “Micro C” A coding 5 pin female drop connections
  • 2x “Micro C” A coding 5 pin 1xMale + 1xFemale backbone connections
  • 2x 120ohm Network Terminators 1xMale and 1xFemale
  • 1x 1m Power Cable Male with 3A in-line Fuse (20mm)
  • 1x 1m “Drop Cable” Male to Female

Physical

  • Assembled 20.5 x 11 x 2 cm
  • Weight 250g
  • Protection IPx7

Physical Dimensions Ordering information: www.digitalyachtamerica.com sales@digitalyachtamerica.com TEL + 44 1179 55 44 74
