New Directions for Network Verification Aurojit Panda, Katerina Argyraki, Mooly Sagiv, Michael Schapira, Scott Shenker Brief Summary of This Talk Context : Proliferation of network verification tools. Build on assumption that the

slide-1
SLIDE 1

New Directions for Network Verification

Aurojit Panda, Katerina Argyraki, Mooly Sagiv, Michael Schapira, Scott Shenker

slide-2
SLIDE 2

Brief Summary of This Talk

  • Context:
  • Proliferation of network verification tools.
  • Build on assumption that the network state is immutable.
  • Immutable = Data packets do not change behavior of network
slide-3
SLIDE 3

Brief Summary of This Talk

  • Context:
  • Proliferation of network verification tools.
  • Build on assumption that the network state is immutable.
  • Immutable = Data packets do not change behavior of network
  • My point:
  • Many network elements have mutable state
  • Verifying mutable networks requires new techniques
  • Two technical challenges: Modeling and Scaling
slide-4
SLIDE 4

Outline

  • Background on networks.
  • Background on network verification.
  • Verifying mutable networks.
slide-5
SLIDE 5

Classical Networking

Switch Switch Switch

  • Networks provide end-to-end connectivity.
  • Just contain host and switches.
  • All interesting processing at the hosts.

Alice Bob Trent Mallory

Ted Stevens was right

slide-6
SLIDE 6

Real Networks have Middleboxes!

Switch Switch Switch Alice Bob Trent Mallory

slide-7
SLIDE 7

Real Networks have Middleboxes!

Firewall Switch Switch Switch Alice Bob Trent Mallory

  • Security (firewalls, IDSs,…).
slide-8
SLIDE 8

Real Networks have Middleboxes!

Firewall Cache Switch Switch Switch Alice Bob Trent Mallory

  • Security (firewalls, IDSs,…).
  • Performance (caches, load balancers,…).
slide-9
SLIDE 9

Real Networks have Middleboxes!

Firewall Proxy Cache Switch Switch Switch Alice Bob Trent Mallory

  • Security (firewalls, IDSs,…).
  • Performance (caches, load balancers,…).
  • New functionality (proxies,…).
slide-10
SLIDE 10

Outline

  • Background on networks.
  • Background on network verification.
  • Verifying mutable networks.
slide-11
SLIDE 11

Reachability Invariants

  • Focus on reachability invariants
  • Most important in practice, simple to state but already hard

Balancer Firewall Firewall Mallory S1 S2

slide-12
SLIDE 12

Reachability Invariants

  • Focus on reachability invariants
  • Most important in practice, simple to state but already hard

Balancer Firewall Firewall Mallory S1 S2 Can S2 receive packets of type T from Mallory?

slide-13
SLIDE 13

Reachability Invariants

  • Focus on reachability invariants
  • Most important in practice, simple to state but already hard

Balancer Firewall Firewall Mallory S1 S2 Can S2 receive “infected” packets from Mallory?

slide-14
SLIDE 14

Reachability Invariants

  • Focus on reachability invariants
  • Most important in practice, simple to state but already hard

Balancer Firewall Firewall Mallory S1 S2 Can S2 receive packets from Mallory without a connection?

slide-15
SLIDE 15

Abstractions for Invariants

  • Operators want to specify packet types using abstractions:
slide-16
SLIDE 16

Abstractions for Invariants

  • Operators want to specify packet types using abstractions:
  • “infected”
slide-17
SLIDE 17

Abstractions for Invariants

  • Operators want to specify packet types using abstractions:
  • “infected”
  • from “authenticated user”
slide-18
SLIDE 18

Abstractions for Invariants

  • Operators want to specify packet types using abstractions:
  • “infected”
  • from “authenticated user”
  • from a given application
slide-19
SLIDE 19

Abstractions for Invariants

  • Operators want to specify packet types using abstractions:
  • “infected”
  • from “authenticated user”
  • from a given application
  • How these types are determined in a network varies
slide-20
SLIDE 20

Abstractions for Invariants

  • Operators want to specify packet types using abstractions:
  • “infected”
  • from “authenticated user”
  • from a given application
  • How these types are determined in a network varies
  • Invariants should not depend on these details
slide-21
SLIDE 21

Network Verification Today

  • Switches: Forwarding rules in switches.

HSA, Veriflow, NetKAT, etc.

slide-22
SLIDE 22

Network Verification Today

  • Switches: Forwarding rules in switches.

HSA, Veriflow, NetKAT, etc.

  • SDN Controller: Code generating these rules.

Vericon, FlowLog, etc.

slide-23
SLIDE 23

Network Verification Today

  • Switches: Forwarding rules in switches.

HSA, Veriflow, NetKAT, etc.

  • SDN Controller: Code generating these rules.

Vericon, FlowLog, etc.

  • Firewalls: Verify firewall configuration.

Fang, Margrave, etc.

slide-24
SLIDE 24

Existing Assumptions/Limitations

Switches

  • Limited computational model (rule-based forwarding).
  • Immutable, functionality only changes with new rules.
  • Limited set of invariants enforced by networks.
slide-25
SLIDE 25

Existing Assumptions/Limitations

Switches

  • Limited computational model (rule-based forwarding).
  • Immutable, functionality only changes with new rules.
  • Limited set of invariants enforced by networks.

Controllers

  • All state and actions are centralized. (Globally ordered)
  • Data plane itself is immutable.
slide-26
SLIDE 26

Existing Assumptions/Limitations

Switches

  • Limited computational model (rule-based forwarding).
  • Immutable, functionality only changes with new rules.
  • Limited set of invariants enforced by networks.

Controllers

  • All state and actions are centralized. (Globally ordered)
  • Data plane itself is immutable.

Firewalls

  • Treated as if they contain Immutable state.
  • Assume a particular (simple) computational model.
slide-27
SLIDE 27

Existing Assumptions/Limitations

Switches

  • Limited computational model (rule-based forwarding).
  • Immutable, functionality only changes with new rules.
  • Limited set of invariants enforced by networks.

Controllers

  • All state and actions are centralized. (Globally ordered)
  • Data plane itself is immutable.

Firewalls

  • Treated as if they contain Immutable state.
  • Assume a particular (simple) computational model.

Violated by many middleboxes

slide-28
SLIDE 28

Outline

  • Background on networks.
  • Background on network verification.
  • Verifying mutable networks.
slide-29
SLIDE 29

Verification of Mutable Networks

  • Naive approach
  • Verify a program equivalent to the entire network.
slide-30
SLIDE 30

Verification of Mutable Networks

  • Naive approach
  • Verify a program equivalent to the entire network.
  • Feasibility is not clear
  • Large, proprietary code bases (Bro ~102K lines of code).
slide-31
SLIDE 31

Verification of Mutable Networks

  • Naive approach
  • Verify a program equivalent to the entire network.
  • Feasibility is not clear
  • Large, proprietary code bases (Bro ~102K lines of code).
  • Scalability is crucial
  • Networks contain several 1000 middleboxes or more.
slide-32
SLIDE 32

Modeling Middleboxes

slide-33
SLIDE 33

Modeling Middleboxes

Classify Packet

Determines what application sent a packet, etc. Complex, proprietary processing.

slide-34
SLIDE 34

Modeling Middleboxes

Classify Packet Update Packet

Determines what application sent a packet, etc. Complex, proprietary processing. Updating payload is complex (compression, etc.) Updating header is simple (fixed format).

slide-35
SLIDE 35

Modeling Middleboxes

Classify Packet Update State Update Packet

Determines what application sent a packet, etc. Complex, proprietary processing. Could be simple (remember packets)

  • r complex (update many hash tables).

Updating payload is complex (compression, etc.) Updating header is simple (fixed format).

slide-36
SLIDE 36

Modeling Middleboxes

Classify Packet Update State Update Packet Forward Packet

Determines what application sent a packet, etc. Complex, proprietary processing. Could be simple (remember packets)

  • r

Updating payload is complex (compression, etc.) Updating header is simple (fixed format). Always simple: forward or drop packets.

slide-37
SLIDE 37

Modeling Middleboxes

Classify Packet Update State Update Packet Forward Packet

Determines what application sent a packet, etc. Complex, proprietary processing. Could be simple (remember packets)

  • r

Updating payload is complex (compression, etc.) Updating header is simple (fixed format). Always simple: forward or drop packets.

Oracle: Specify data dependencies and outputs

slide-38
SLIDE 38

Modeling Middleboxes

Classify Packet Update State Update Packet Forward Packet

Determines what application sent a packet, etc. Complex, proprietary processing. Could be simple (remember packets)

  • r

Updating payload is complex (compression, etc.) Updating header is simple (fixed format). Always simple: forward or drop packets.

Oracle: Specify data dependencies and outputs Forwarding Model: Specify Completely

slide-39
SLIDE 39

Example

Classify Packet Update State Update Packet Forward Packet Oracle: Specify data dependencies and outputs Forwarding Model: Specify Completely

slide-40
SLIDE 40

Example

Classify Packet Update State Update Packet Forward Packet Oracle: Specify data dependencies and outputs Forwarding Model: Specify Completely

Outputs Is packet infected. Dependencies See all packets in connection (flow).

slide-41
SLIDE 41

Example

Classify Packet Update State Update Packet Forward Packet Oracle: Specify data dependencies and outputs Forwarding Model: Specify Completely

Outputs Is packet infected. Dependencies See all packets in connection (flow). if (infected) { infected_connections.add(packet.flow) }

slide-42
SLIDE 42

Example

Classify Packet Update State Update Packet Forward Packet Oracle: Specify data dependencies and outputs Forwarding Model: Specify Completely

Outputs Is packet infected. Dependencies See all packets in connection (flow). if (packet.flow not in infected_connections) { forward (packet); } if (infected) { infected_connections.add(packet.flow) }

slide-43
SLIDE 43

Scaling Verification

slide-44
SLIDE 44

Scaling Verification

  • Middleboxes are “flow-parallel”
slide-45
SLIDE 45

Scaling Verification

  • Middleboxes are “flow-parallel”
  • State is partitioned between “flows.”
slide-46
SLIDE 46

Scaling Verification

  • Middleboxes are “flow-parallel”
  • State is partitioned between “flows.”
  • This enables “compositional verification”
slide-47
SLIDE 47

Scaling Verification

  • Middleboxes are “flow-parallel”
  • State is partitioned between “flows.”
  • This enables “compositional verification”
  • 30,000 middlebox networks verified in 5 minutes
slide-48
SLIDE 48

Compositional Verification

mbox mbox mbox mbox mbox mbox mbox mbox mbox mbox mbox mbox

slide-49
SLIDE 49

Compositional Verification

mbox mbox mbox mbox mbox mbox mbox mbox mbox mbox mbox mbox

slide-50
SLIDE 50

Compositional Verification

mbox mbox mbox mbox mbox mbox mbox mbox mbox mbox mbox mbox

  • Invariants talk about pairs of hosts.
  • When flow-parallel, need-only verify path.
slide-51
SLIDE 51

Conclusion

  • Real networks:
  • Contain mutable middleboxes.
  • Used to enforce rich connectivity invariants.
  • Network verification needs to evolve to handle this.
  • Several challenges
  • Right level of abstraction for specifying middleboxes.
  • Scalability, by leveraging compositional verification.
  • Future: Tractability of verification.

Some pictures taken from the Noun Project

slide-52
SLIDE 52

Backup

slide-53
SLIDE 53

Does State Mutation Matter

  • Do we even need to look at state evolution?
  • Check invariant for all possible states.
  • Approach used in tools like Margrave.
  • # of states is small (just whether connection established).
  • False positives, some states may never occur.
slide-54
SLIDE 54

Does State Mutation Matter

Firewall

  • Do we even need to look at state evolution?
  • Check invariant for all possible states.
  • Approach used in tools like Margrave.
  • # of states is small (just whether connection established).
  • False positives, some states may never occur.

Firewall a b b → a ⇐ ⇒ ⌥conn(a → b) a → b ⇐ ⇒ ⌥conn(b → a) conn(a → b) Connection started by a to b. Requires a to send packet to b, and b to respond Can a packet from 'a' reach 'b'?
