NCR FASTLANE SELFSERV™ CHECKOUT R6N

(NARROW CORE)

Date

NCR Confidential

• Optimized footprint for credit/debit only operation
• Narrow core enclosure conserves valuable floor space
• Advanced XR7 processor technology (same as R6L/R6/

SS90)

• Weight-based security – 1,2 and 3 bag packing areas
• 1ST/2ST Printer with drop-and-go paper loading
• High performance RealScan 79e Bi-optic imager with
• ptional PickList Assist and Produce Assurance capability

NCR FastLane SelfServ Checkout R6N

Overview - Narrow Card Only Model

NCR Confidential

NCR FastLane SelfServ™ Checkout

Narrow Core Configuration Components

NCR Confidential

15” Projected Capacitive Multi-Touch Display XR7 All-in-One RealScan79e Bi-optic Imager Receipt Printer Security Scale Configurable Bag Racks Payment Device LED Tri-Light uNav Keypad Device Speakers Coupon Bin

3

NCR SelfServ™ 90 NCR Narrow Core

• Designed for small to

medium baskets

• 1, 2 or 3 bag option
• RealScan™ 79e Bi-

Optic Imager (Scanner/Scale) with Produce Assurance and Picklist Assist (optional)

• Integrated self service

printer

• Designed for small

baskets

• Wall, pedestal or

countertop

• Compact, modular

security scale

• ptional

For shoppers on the go

Card-only solutions

R6N SS90

Positioning Card only self checkout for small to medium baskets Card only self checkout for small baskets Form factor Narrow Compact Mount options Floor standing Pedestal, Countertop, Wall Multi-touch display 15” Projected Capacitive 15” Projected Capacitive Bag options 1, 2, 3, or No Bag 1 or No Bag Weight-based security Yes – Security Scale Yes – Modular Security Scale

Printer 1-sided or 2-sided 1-sided Scanner

RS 79e Bi-optic All-imaging or RS 78 Bi-optic Laser/Hybrid 2D Imaging Presentation Scanner Produce Scale RS 78 / 79e with Scale option RS 7812 Modular Scale option*

NCR FastLane SelfServ Checkout

SCO Hardware Platform Comparison

* Produce scale not available with security scale on SS90

R6N SS90

Lane / Tri-light option Pole mounted LED Lane /Tri-light Low profile Uni-light or LED tri-light Integrated speakers Yes Yes Hand held scanner option Yes Yes Sensormatic EAS option Yes Yes Checkpoint EAS option Yes Yes Coupon Bin option Yes Yes uNAv option Yes No Integrated UPS option Yes No Custom color options Yes No

NCR FastLane SelfServ Checkout

SCO Hardware Platform Comparison

R6N SS90

Motherboard Monaco (XR7) Monaco (XR7) Chipset Intel Q87 Express Intel Q87 Express Processor Intel Celeron or Core i3 Intel Celeron, Core i3, or Core i5 Storage 120GB SSD 120GB SSD Memory 4GB to 16GB 4GB to 16GB Operating Systems Windows POS Ready 2009 Yes (32-bit) Yes (32-bit) Windows POS Ready 7 Yes (32-bit) Yes (32-bit) Windows 7 Professional Yes (32-bit) Yes (32-bit) Windows 10 Embedded Yes (64-bit) Yes (64-bit)

NCR FastLane SelfServ Checkout

SCO Hardware Platform Comparison

Thank You

NCR Confidential 8
