National Workshop On Wastewater Recycling and Presentation of Urban Water Awards 2011-12

Topic: Industry Prospective on use of Recycles wastewater March 7, 2014

Overview of Presentation

26/03/2014 2

Water : Indian Scenario Wastewater Recycle and Reuse Opportunities Success Stories – Industry CII TWI Vision & Purpose

Water: Indian Scenario

1

26/03/2014 4

Water Scenario-India

► Indian industries consumed about

50 billion cubic meters of water

► Large population of people lack

access to safe water

Water Scarcity- Is a Crisis looming ahead?

► Fresh water available per capita

per annum in India has dropped from 5,200 m3 to 1,820 m3 in 01 According to WHO, mortality is high due to water borne diseases

Surface Water-Polluted Ground Water-Depleted Rainfall - Wasted Industry -Growing Water Reqd- Increasing Water Recycle- ? ? ? Quality of water- Poor Health Issue- Increasing India’s water future- ??? Population – Increasing Demand – Increasing Consumption-Increasing

► Establishment of UMPPs

will further strain the thin water resources

Would the next world war would be over water ?

India is water stressed measured both in terms of quantity and quality

• Most of the country receives nearly all its rainfall in

less than about 1% of the time of an entire year.

• More than 80 percent of river basins are facing

stress and scarcity

• Groundwater depletion and deterioration

depleting at a rate far greater than what natural cycles can replenish (even > 1 m/ year)

09/10/2013 5

• Groundwater quality fast deteriorating

 emerging geo-contaminants  non-point source pollutants like nitrates

• Less than 1/3rd of our total sewage gets treated
• About 50% of riverine length shows high pollution

measured in terms of BOD alone

• Over 20% of transmissible diseases in India are

related to unsafe water

09/10/2013 6

India is water stressed measured both in terms of quantity and quality

7

As a result !

1000 2000 3000 4000 5000 6000 1951 1961 1971 1981 1991 2001 2011 2025 2050

Per capita available water resource Per capita utilizable water resource (GW and SW)

Water stress line (1700) Water scarcity line (1000)

Per capita water availability (m3/capita)

Climatic variability is an add-on stressor. Regions face growing demand-supply gaps. Conflicting demands over a shrinking resource

Industrial Water Demand

Industry & Energy

26/03/2014 8 20 40 60 80 100 120 140 160

2010 2025 2050

56 BCM 100 BCM 151 BCM

Wastewater generation from different types of industries and achievable reuse

98 50 40 40 25 15 12 20 40 60 80 100 120 Per Cent reuse achievable

Industry Average volume of wastewater per unit

• r product

Thermal power plant 155 x 10

3 L/h/MW

Pulp & paper 250 x 10

3 L/tonne

Iron & Steel 150x 10

3 L/tonne

Pharmaceutical 4.5x 10

3 L/Kg

Distillery 15 L/L of alcohol Textile 250 L/Kg Cloth Tannery 34 L/Kg of raw hides

Wastewater Treatment : Present Scenario

26/03/2014 10

• Industrial

 13000 MLD generated by 1,35,000 polluting industries  60% is treated (large & medium industries)

• Domestic

 23000 MLD generated (300 Class I Cities and 345 Class II towns)  Only 6000 MLD is treated

Source: CPCB

Wastewater Recycle & Reuse Opportunities

2

Recycle & Reuse opportunities

Use of sewage & effluent water for low and high end applications Use of sewage & effluent water for high end applications Reuse of treated water as water curtain, floor washings, dual pipe line for toilet flushing etc.

• High End Application

 Cooling Water Make-up  Boiler Feed  Process Water

• Low End Application

 Gardening  Floor Washing  Toilet Flushing

26/03/2014 13

Looking for alternative sources

Well Water Surface Water Municipal Water Internal WW Reuse RO Reject RO Permeate Boiler Blow Down ZLD Distillate MBR Effluent Additional Treatment?

Treated Water

Municipal Treated WW Can use many sources of lower quality water * * With proper system design and treatment

Recycling Initiatives of Indian Industry

• Segregates waste streams at source and perform

primary/ secondary treatment, locally as appropriate

 TDS and Organic Load  Color

• Reuse of treated water locally as far as possible

 Cost Effective  Reduce of fresh water intake

• Installed common tertiary treatment plant for

further treatment and reuse

26/03/2014 14

26/03/2014 15

Screening/ Grit Removal Sedimentation Clarification Biological Clarification Thickening / Digestion / Solids Reduction Dewatering Disinfection Instrumentation & Control Filtration Residuals Management Odor Control Water Path Sludge Path Others RO

Full range of technologies for primary, secondary and advanced wastewter treatment & reuse

Success Stories3

Case Study-I

• Conservation of Ground

Water

• Reuse of 220m3/day of

Secondary Treated Wastewater

 Installed full fledged tertiary treated water system using submerged UF-RO membrane  Utilized for non-potable purposes

• Fresh water savings of

73000m3/year

26/03/2014 17

Zero Water Discharge

• Effluent Generation of ~

800m3/day

 Process

• Component Washing
• Paint Booth

 Utilities

• Cooling Tower
• Filter Backwash

 Sewage

• Percentage of Treated

Effluent in Daily Consumption

 35% in Process  Rest Green Belt Development

26/03/2014 18

CII-TWI and USAID India partnership

• Objective

To Promote Water Use Efficiency across Urban Sector to Address Climate Change

• Activities undertaken

 Water audits in Industry, buildings /hospitals  Pre-feasibility studies for utilizing municipal sewage  Identification of doable projects on reuse of sewage  Information Dissemination and Capacity Building Programs

19 09/10/2013

CII-TWI USAID Enhances Ecosystems model

20

CLIMATE CHANGE APPROACHES

Minimizing Impact

• Demand Management
• Scale up to other Cities

ECOSYSTEM SECURITY IMPACT ON WATER RESOURCE MINIMIZE IMPACT SUSTAINABLE WATER RESOURCE WATER AUDITS (Industry and buildings) SEWAGE REUSABILITY

Good Case Studies on Reduce, Reuse & Recycle

Demand & Supply side management

Focus Area: Urban Sector

Project activities are linked to a larger goal

Conducting of Water Audits

• Industry, Buildings, Municipality (27 in number)

 Jaipur, Faridabad, and Pune

09/10/2013 21

state-of-the-art instruments world-class software systems

Benefits of the CII-TWI USAID India project

• Established water balance and baselines on water use

and wastewater through audits

 Specific water use  Wastewater generation

• Sensitized industry, builders and local governments
• n water use efficiency

 3 workshops/ roundtables : Jaipur, Pune & Faridabad  > 1500 employees and staff of government, industry & building

09/10/2013 22

23 16/11/2012

Training at Rajasthan Police Academy Workshop in Faridabad Training at Manu yantralaya - Industry Training at School in Jaipur

………benefits

• Identification of doable projects (municipality-

industry interface)

 2 - 3 projects in each of the three cities.  Potential of reusing sewage is as high as 70 percent through low-to-medium cost interventions

• Know how on state-of-the-art technologies

 20 – 30 water saving strategies classified into low cost high impact, medium cost, and high cost strategies

09/10/2013 24

CII Vision & Purpose

4

CII-Triveni Water Institute

Adopts a holistic approach:

• Multi-Sectoral: 4

sectors, and 6 cross cutting dimensions

• Multi-Locational

26

While focuses its activities on closing the demand and supply gaps, it aims to produce results on- ground in the short-term, and use as a catalyst

09/10/2013

Vision: enable India make substantial progress towards achieving water security by 2022

Purpose and Activities

27 09/10/2013

Core purpose of TWI

To transform water conservation and management in India by changing the mind-set and behavior of stakeholders resulting in more effective and sustainable water management practices at the grassroots level.

Internal Governance

Vision and Purpose Advisory services Projects, Policy Advocacy Training & Education

Events, Information dissemination

Way Forward

• Incentive for Industry – Recycling Wastewater
• Pilot Projects on Wastewater Recycling Supported

by Government

 Interface Municipality & Industry  Guidelines

• Promotion of best practices of water management

in industry

• Technology Fund

 Promoting and Incubating Water Efficient Technology

• Water Audit in Industry

26/03/2014 28
