SLIDE 1
Risk Assessment
Added:
- Team Meetings next semester - rank 9
○ New schedules next semester ○ Will be more difficult to meet as a team frequently
MSD P16512 - Simple Ink Jetting Station Detailed Design Review - - PowerPoint PPT Presentation
MSD P16512 - Simple Ink Jetting Station Detailed Design Review - - PowerPoint PPT Presentation
MSD P16512 - Simple Ink Jetting Station Detailed Design Review 12/10/2015 Risk Assessment Added: Team Meetings next semester - rank 9 New schedules next semester Will be more difficult to meet as a team frequently Subsystems
SLIDE 2
SLIDE 3
Subsystems
Motion 1. X-axis 2. Y-axis 3. Z-axis 4. Motion Control Print Head 5. Print Head Adjustment 6. Print Head Docking Station 7. Bucket Reservoir 8. UV Curing 9. Work Surface
- 10. XEROX Print Head Driver
(Image Loader Board)
SLIDE 4
X-axis from Igus
- Place order at end of this semester
- r start of next semester
- Purchasing Procedures
○ Should team follow standard MSD purchasing procedure?
SLIDE 5
X-axis - Visual of Scanning Length
SLIDE 6
Y-axis - Feasibility Test
- The y-axis from the P14551 Senior Design project
- Wanted to ensure that the axes could
○ Handle the weight they are expected support ○ Operate with the required accuracy
- Y-axis passed Feasibility Test and we utilize it in our system
- However the motion bed has some play in it and the team
plans to add reinforcements to make the axis more robust
SLIDE 7
Y & Z CAD
- The pitch of the Z axis lead screw
was 2 millimeters / revolution
- The pitch of Y axis lead screw
was 3 millimeters / revolution
- The motors driving the system
are capable of 200 steps per revolution
- However, since these motors can
microstep, the aforementioned limitation is more than compensated for
SLIDE 8
Y & Z axes (contd.)
Side View Back View
SLIDE 9
Encoders
- Will utilize a linear encoder
- n the X-axis
- Motor on the Y & Z axes
have rotary encoder built in
- HEDS-97X series Digital
Output Small Optical Encoder
- Heidenhain Position read out
- Image Loader Board
Software
SLIDE 10
Schematics
SLIDE 11
SLIDE 12
SLIDE 13
Print Head Tubing
SLIDE 14
Bucket Reservoir
- Bucket reservoir and top
fill plate are no longer required with the syringe/tubing system
○ Both replaced with standoffs
- Syringes can be clipped
to these standoffs
SLIDE 15
Print Head Mounting
SLIDE 16
UV Protecting glasses
- $ 19.95/pack of 4
- Includes side shielding
- Order 2 packs of 4
SLIDE 17
UV Protected tubing
- ~ $10-20/ 10 feet
SLIDE 18
UV Curing Cost Summary
System components: $175.22 Light control circuit: $16.71 UV protecting materials: $73.40 Total: $ 265.33
SLIDE 19
UV Curing CAD
SLIDE 20
Entire System CAD
SLIDE 21
Entire System CAD (contd.)
SLIDE 22
Entire System CAD (contd.)
SLIDE 23
BOM
SLIDE 24
BOM - continued Total = $8,172.42 Savings = $7,104.95 Cost = $1,107.82
SLIDE 25
Project Plan
SLIDE 26
Project Plan
SLIDE 27
