slide-1
SLIDE 1

Movies as Programs

Leif Andersen

slide-2
SLIDE 2

Accessibility

(prominent code)

(some code)

slide-3
SLIDE 3
slide-4
SLIDE 4
slide-5
SLIDE 5
slide-6
SLIDE 6
slide-7
SLIDE 7
slide-8
SLIDE 8
slide-9
SLIDE 9
slide-10
SLIDE 10
slide-11
SLIDE 11

One down

slide-12
SLIDE 12

One down 19 more to go…

slide-13
SLIDE 13
slide-14
SLIDE 14
slide-15
SLIDE 15

We Need Automation

slide-16
SLIDE 16

e Landscape

Tool Example Experience

Plugin-Ins

Blender Script, AE Script

UI Automation

(Macros) Apple Script

Shell Scripts

FFmpeg, AVISynth

slide-17
SLIDE 17

e Landscape

Tool Example Experience

Plugin-Ins

Blender Script, AE Script

UI Automation

(Macros) Apple Script

Shell Scripts

FFmpeg, AVISynth

slide-18
SLIDE 18

e Landscape

Tool Example Experience

Plugin-Ins

Blender Script, AE Script

UI Automation

(Macros) Apple Script

Shell Scripts

FFmpeg, AVISynth

slide-19
SLIDE 19

e Landscape

Tool Example Experience

Plugin-Ins

Blender Script, AE Script

UI Automation

(Macros) Apple Script

Shell Scripts

FFmpeg, AVISynth

slide-20
SLIDE 20

We have a problem…

slide-21
SLIDE 21

We have a problem… We want to solve it in the problem domain's own language…

slide-22
SLIDE 22

We have a problem… We want to solve it in the problem domain's own language…

DSLs are the

"Ultimate Abstraction"

Paul Hudak

slide-23
SLIDE 23

Make a DSL!

slide-24
SLIDE 24

Library

slide-25
SLIDE 25

Language

Library

slide-26
SLIDE 26

Library

slide-27
SLIDE 27

Producers Filters Playlists Multitracks

slide-28
SLIDE 28

Producers

slide-29
SLIDE 29

Producers

slide-30
SLIDE 30

Producers

render : Producer →

slide-31
SLIDE 31

Producers

render : Producer → clip : String → Producer

slide-32
SLIDE 32

Producers

render : Producer → clip : String → Producer (render (clip "demo.mp4")) ⇒

slide-33
SLIDE 33

Filters

slide-34
SLIDE 34

Producer Producer

Filter

slide-35
SLIDE 35

(attach-filter bunny-clip (sepia-filter))

slide-36
SLIDE 36

(attach-filter bunny-clip (sepia-filter))

slide-37
SLIDE 37

Playlists

slide-38
SLIDE 38

Producer Producer Producer Producer

Time

slide-39
SLIDE 39

(playlist (clip "jumping.mp4") (clip "flying.mp4"))

slide-40
SLIDE 40

Producer Producer Producer Producer

Time

slide-41
SLIDE 41

Producer Producer Producer Producer Transition

Time

slide-42
SLIDE 42

(playlist (clip "jumping.mp4") (fade-transition 1) (clip "flying.mp4"))

slide-43
SLIDE 43

Multitracks

slide-44
SLIDE 44

Producer Producer Producer Producer

Time Layers

slide-45
SLIDE 45

Producer Producer Producer Producer

Merge

Time Layers

slide-46
SLIDE 46

(define WIDTH 1920) (define HEIGHT 1080) (multitrack (color "black") (overlay-merge 0 0 (/ WIDTH 2) HEIGHT) (clip "running.mp4") (overlay-merge (/ WIDTH 2) 0 (/ WIDTH 2) HEIGHT) (clip "flying.mp4"))

slide-47
SLIDE 47

Library

Producers Filters Playlists Multitracks

slide-48
SLIDE 48

Language

Library

Producers Filters Playlists Multitracks

slide-49
SLIDE 49
slide-50
SLIDE 50

Primitives

slide-51
SLIDE 51

List Comprehensions

slide-52
SLIDE 52

Modules

slide-53
SLIDE 53
slide-54
SLIDE 54

Functions

slide-55
SLIDE 55
slide-56
SLIDE 56

#lang video ;; Create a mosaic of four videos (for/vertical ([i (in-range 2)]) (for/horizontal ([j (in-range 2)]) (external-video "branded.vid" (clip "logo.png") (clip (format "~aX~a.mp4" i j)))))

slide-57
SLIDE 57

#lang video (clip "dragon.mp4") ;; Create a mosaic of four videos (for/vertical ([i (in-range 2)]) (for/horizontal ([j (in-range 2)]) (external-video "branded.vid" (clip "logo.png") (clip (format "~aX~a.mp4" i j)))))

slide-58
SLIDE 58

Implementing Video + Editing Manual Editing

slide-59
SLIDE 59

From Libraries to

Languages

slide-60
SLIDE 60

We make DSLs using

Linguistic Inheritance

slide-61
SLIDE 61

We make DSLs using

Linguistic Inheritance

slide-62
SLIDE 62

We make DSLs using

Linguistic Inheritance

Movie Script

Video Implementation

Racket

slide-63
SLIDE 63

We make DSLs using

Linguistic Inheritance

Movie Script

Video Implementation

Racket

Re-export construct

slide-64
SLIDE 64

We make DSLs using

Linguistic Inheritance

Movie Script

Video Implementation

Racket

Re-export construct Remove construct

slide-65
SLIDE 65

We make DSLs using

Linguistic Inheritance

Movie Script

Video Implementation

Racket

Re-export construct Remove construct New construct

slide-66
SLIDE 66

We make DSLs using

Linguistic Inheritance

Movie Script

Video Implementation

Racket

Re-export construct Remove construct New construct Change construct

slide-67
SLIDE 67

(for/playlist ([scene (in-list scene-list)]) (multitrack scene (overlay-merge 10 10 300 300) (clip "logo.mp4")))

slide-68
SLIDE 68

(define (for/playlist seq body) (apply playlist (for/list ([i (in-list seq)]) (body i))))

slide-69
SLIDE 69

(define (for/playlist seq body) (apply playlist (for/list ([i (in-list seq)]) (body i)))) > (for/playlist (list (clip "a.mp4") (clip "b.mp4")) (λ (scene) (multitrack scene (overlay-merge 10 10 300 300) (clip "logo.mp4"))))

slide-70
SLIDE 70

(define-macro (for/playlist seq . body) `(apply playlist (for/list ,seq ,@body)))

slide-71
SLIDE 71

(for/playlist ([s (list (clip "a.mp4"))]) (multitrack ...))

⇒ elaborates

(apply playlist (for/list ([s (list (clip "a.mp4"))]) (multitrack ....)))

slide-72
SLIDE 72

(for/playlist ([s (list (clip "a.mp4"))]) (multitrack ...))

⇒ elaborates

(apply playlist (for/list ([s (list (clip "a.mp4"))]) (multitrack ....)))

⇒ evaluates

#<playlist>

slide-73
SLIDE 73

(let ([playlist 42]) (for/playlist ....))

slide-74
SLIDE 74

(let ([playlist 42]) (for/playlist ....))

⇒ elaborates

(let ([playlist 42]) (apply playlist ....))

slide-75
SLIDE 75

(let ([playlist 42]) (for/playlist ....))

⇒ elaborates

(let ([playlist 42]) (apply playlist ....))

⇒ evaluates

slide-76
SLIDE 76

(define-macro (for/playlist seq . body) `(apply playlist (for/list ,seq ,@body))) > (let ([playlist 42]) (for/playlist ([s (list (clip "a.mp4"))]) (multitrack s (overlay-merge 10 10 300 300) (clip "logo.mp4"))))

slide-77
SLIDE 77

(define-syntax-rule (for/playlist seq body ...) (apply playlist (for/list seq body ...)))

slide-78
SLIDE 78

(define-syntax-rule (for/playlist seq body ...) (apply playlist (for/list seq body ...))) > (let ([playlist 42]) (for/playlist ([s (list (clip "a.mp4"))]) (multitrack s (overlay-merge 10 10 300 300) (clip "logo.mp4"))))

slide-79
SLIDE 79
slide-80
SLIDE 80
slide-81
SLIDE 81
slide-82
SLIDE 82

Non-Local Language Features

slide-83
SLIDE 83

#lang video (define talk ...) (define logo ...) talk logo logo

slide-84
SLIDE 84

#lang video (define talk ...) (define logo ...) (provide vid) talk logo logo (define vid (playlist ))

slide-85
SLIDE 85

Interposition Points

#%app #%module-begin

slide-86
SLIDE 86

(+ 1 2)

⇒elaborates

(#%app + 1 2)

slide-87
SLIDE 87

#lang video logo talk ;; Where (define logo ...) (define talk ...)

(module anon video ( #%module-begin logo talk (define logo ...) (define talk ...)))

parses

slide-88
SLIDE 88

(module anon video ( #%module-begin logo talk (define logo ...) (define talk ...))) (module anon racket ( #%module-begin (require vidlib) (define logo ...) (define talk ...) (vid-begin vid logo talk)))

elaborates

slide-89
SLIDE 89

#lang racket

slide-90
SLIDE 90

(require syntax/wrapping-modbeg) (define-syntax video-module-begin (make-wrapping-module-begin ...))

slide-91
SLIDE 91

(require syntax/wrapping-modbeg) (define-syntax video-module-begin (make-wrapping-module-begin ...))

slide-92
SLIDE 92

#lang racket/base ... run time code ... (define-syntax macro-name ... compile time code ...) ... run time code ...))

slide-93
SLIDE 93

(define-syntax id expr)

id : run time binding expr : compile time expression

slide-94
SLIDE 94

Movies as Programs: A Tower of Languages

slide-95
SLIDE 95
slide-96
SLIDE 96
slide-97
SLIDE 97

FFI

slide-98
SLIDE 98

Source File Video Data Structure FFmpeg Filter Graph

101010 010101

Runtime Output

slide-99
SLIDE 99

We have a problem…

FFI

V

slide-100
SLIDE 100

We have a problem… We want to solve it in the problem domain's own language…

FFI

V

slide-101
SLIDE 101

We have a problem… We want to solve it in the problem domain's own language…

Make a DSL!

FFI

V

slide-102
SLIDE 102

An FFI DSL

int av_frame_get_buffer(AVFrame *frame, int align);

(Scheme Workshop, 2004)

slide-103
SLIDE 103

An FFI DSL

int av_frame_get_buffer(AVFrame *frame, int align);

(define-ffmpeg av-frame-get-buffer (_fun [frame : _av-frame] [align : _int]

  • > [ret : _int]
  • > (maybe-error? ret)))

(Scheme Workshop, 2004)

slide-104
SLIDE 104

An Object DSL

(define-ffmpeg av-frame-alloc ...) (define-ffmpeg av-frame-free ...) (define-constructor clip video ... av-frame-alloc ... av-frame-free ...)

slide-105
SLIDE 105

OpenGL FFmpeg

slide-106
SLIDE 106

Documentation

slide-107
SLIDE 107

We have a problem…

Documentation

V

slide-108
SLIDE 108

We have a problem… We want to solve it in the problem domain's own language…

Documentation

V

slide-109
SLIDE 109

We have a problem… We want to solve it in the problem domain's own language…

Make a DSL!

Documentation

V

slide-110
SLIDE 110

A Documentation DSL

(ICFP, 2009)

slide-111
SLIDE 111

A Documentation DSL

#lang video/documentation @title{Video: The Language} @(defmodulelang video) Video Language (or VidLang, sometimes referred to as just Video) is a DSL for editing...videos. It aims to merge the capabilities of a traditional

(ICFP, 2009)

slide-112
SLIDE 112
slide-113
SLIDE 113

OpenGL FFmpeg

slide-114
SLIDE 114

Types

slide-115
SLIDE 115

(clip "clip.mp4" #:start 0 #:end 50)

slide-116
SLIDE 116

(cut-producer #:start 0 #:end 100) (clip "clip.mp4" #:start 0 #:end 50)

slide-117
SLIDE 117

(cut-producer #:start 0 #:end 100) (clip "clip.mp4" #:start 0 #:end 50)

slide-118
SLIDE 118

A Typed DSL

slide-119
SLIDE 119

We have a problem…

Types

V

slide-120
SLIDE 120

We have a problem… We want to solve it in the problem domain's own language…

Types

V

slide-121
SLIDE 121

We have a problem… We want to solve it in the problem domain's own language…

Make a DSL!

Types

V

slide-122
SLIDE 122

A Typed DSL

(POPL, 2017)

slide-123
SLIDE 123

A Type Implementation DSL

(define-typed-syntax (clip f) ≫ [⊢ f ≫ _ ⇐ File] #:where n (length f)

  • [⊢ (untyped:clip f) ⇒ (Producer n)])

(POPL, 2017)

slide-124
SLIDE 124

OpenGL FFmpeg

slide-125
SLIDE 125

We have a problem…

DSL

V

slide-126
SLIDE 126

We have a problem… We want to solve it in the problem domain's own language…

DSL

V

slide-127
SLIDE 127

We have a problem… We want to solve it in the problem domain's own language…

syntax-parse

A DSL for making DSLs

DSL

V

(ICFP, 2010)

slide-128
SLIDE 128

(define-syntax-rule (define/playlist (name args ...) body ...) (define name (λ (args ...) (playlist body ...))))

slide-129
SLIDE 129

(define-syntax-rule (define/playlist (name args ...) body ...) (define name (λ (args ...) (playlist body ...)))) > (define/playlist (double A) A A)

slide-130
SLIDE 130

(define-syntax-rule (define/playlist (name args ...) body ...) (define name (λ (args ...) (playlist body ...)))) > (define/playlist (double (A B C)) A)

slide-131
SLIDE 131

(define-simple-macro (define/playlist header:function-header body ...) (define header.name (λ header.args (playlist body ...))))

slide-132
SLIDE 132

(define-simple-macro (define/playlist header:function-header body ...) (define header.name (λ header.args (playlist body ...)))) > (define/playlist (double A) A A)

slide-133
SLIDE 133

(define-simple-macro (define/playlist header:function-header body ...) (define header.name (λ header.args (playlist body ...)))) > (define/playlist (double (A B C)) A)

slide-134
SLIDE 134

OpenGL FFmpeg

slide-135
SLIDE 135
slide-136
SLIDE 136
slide-137
SLIDE 137

Editor-Oriented

Programming

slide-138
SLIDE 138

e Future…

slide-139
SLIDE 139

begin-for-syntax define-syntax

slide-140
SLIDE 140

begin-for-editor define-editor

slide-141
SLIDE 141

#lang editor (define-editor video-editor ...) ... (play )

slide-142
SLIDE 142

OpenGL FFmpeg

slide-143
SLIDE 143
slide-144
SLIDE 144

https://lang.video

slide-145
SLIDE 145

https://lang.video

slide-146
SLIDE 146
slide-147
SLIDE 147
slide-148
SLIDE 148

anks For Watching

http://lang.video @videolang

We make DSLs using

Linguistic Inheritance

OpenGL FFmpeg
