monolith to micro-services?


event sourcing can help

Doug

legacy
 Culture Amp (2012 - 2015)

Client Rails App
 (Murmur) Query Server DB Read-write Read-only

Our journey Our meandering path to CQRS & event sourcing

• Attempt 1 - Asynchronous micro-services


Event Log the monolith and introduce query services


• Attempt 2 - Greenfield systems of record


Rebuild part of the monolith as a stand alone command side service


• Attempt 3 - Refactor the monolith first


And start with the least depended upon aggregates

Attempt 1: Asynchronous Micro-services Why micro-services?

• Too many developers!
• Monolith was becoming too complex.
• Want teams to control their own assets.
• Flexibility to introduce fit for purpose technologies.


(for example, elastic search for our comments search)

• Scale different parts of the app independently.


(for example, capture has a very different profile)

Attempt 1: Asynchronous Micro-services Why asynchronous?

• Resilience is architected into the platform.


If a micro-service is down, all depended micro-services remain available
 and are eventually consistent. Also protects yourself from self inflicted DOS.

• Ability to replay history for consuming services


Much easier to refactor, or to introduce new services.

• Decoupled architecture enabling platform flexibility


Consumers don’t necessarily need to know where the producers are deployed

Reporting Service

Client Rails App
 (Murmur) Query Server DB Read-write Read-only Reporting
 Service Event
 Log

What went wrong

• Plagued with bad data issues as we tried to convert

• ur current production database to a stream of events
• Ongoing source-of-truth issues between the


monolith persistence layer and the synthesised event log.

• Events were generated at the wrong business points


intended for consumption but ironically problematic for consumers

• Events were too coarse-grained and slow to process.
• Some of the events weren't real business events.
• Multiple event streams - one for each event type - hurt.


What we learned

Asynchronous micro-services are the
 right long term aim. But, don’t start with event consumers,
 start with event producers. Event logging is not event sourcing!

What is
 Event Sourcing?

Add Employee A Add Employee B Remove Employee A Add Employee Add Employee B Add Employee

• Store the business events as the source of truth
• Can answer questions you don’t yet know you have.
• Legal, accounting, traditional professions have used


event sourcing for centuries.

Every method should either be a command that performs an action, or a query that returns data to the caller, but
 not both. In other words, asking a question should not
 change the answer.

— Bertrand Meyer (designer of Eiffel language) on CQS

“

Command Query Responsibility Segregation

What is CQRS?

Without CQRS With CQRS

EmployeeService

+ createEmployee(employee): void
 + getEmployee(id): Employee
 + updateEmployeeName(id, name): void
 + makeEmployeeAdmin(id) : void
 + getEmployees(account):

EmployeeReadService

+ getEmployee(id): Employee
 + getEmployees(account):

EmployeeWriteService

+ createEmployee(employee): void
 + updateEmployeeName(id, name): void
 + makeEmployeeAdmin(id) : void

CQRS &
 event sourcing
 architecture

Client Command Handler Aggregate event
 store Projection Query Handler Eventually
 consistent!

Attempt 2: Greenfield systems of record

Client Rails App
 (Murmur) Query Server DB Reporting
 Service Event
 Store Employee
 SoR Projector Event
 Log

What worked well?

• CQRS and event sourcing helped us be clear about the


boundaries of context.

• The new service owns the validation, so bad data issues


in accounts we migrated were found and fixed upfront

• We could treat the monolith as one massive projection


minimising work required on the Query side, and UI.

• Removed our source of truth problems.


Domain models can be deterministically built from events, not vice versa.

• We could incrementally migrate accounts

What didn’t work well?

• Required a leap of faith for the team to agree to try.
• Slow to develop as we were learning a new paradigm,


and rolling our own event sourcing system.

• Eventual consistency hurts:
• Upfront we needed to solve how to update


the monolith in a reasonable timeframe.

• We needed to refactor parts of the UI to cope


with the eventual consistency.

• Disaster recovery becomes a distributed problem.

With all the troubles of evented architecture

• it is a blessing when "shit hits the fan”.



 I don't know if in the past we would even be able to tell the customers affected by the issue.

— Unsolicited feedback from our
 Tech Lead for the Employee Service

“

• 1. Start with the Command Side.


Treat your existing application like one big projection.

• 2. Tackle a single Aggregate at a time.


No need for a big-bang migration.

• 3. Generate UUIDS in the legacy monolith first.


These will help you link the migration scripts back.

• 4. Start by synchronously updating your existing

application.
 Your legacy UI will thank you for it.

• 5. When all writes are through CQRS Commands, refactor


the UI to use new dedicated asynchronous projections.

• 6. When nothing still uses the legacy domain model,


Attempt 3:
 Refactor the monolith first

Account Survey Response Comment Question Employee

Identifying
 aggregates

* * * * *

1 1 1 1 1

Report

*

1

ActionItem

*

1

Demographi c

*

1

Start Here!

Monolith
 phase 1

Client

Survey
 C Handler Survey
 Aggregate

Event Store Legacy
 Domain Models

Participant
 C Handler Participant
 Aggregate Comment
 C Handler Comment
 Aggregate

Legacy
 DB Projector Monolith Rails Controllers

Synchronous
 update!

Monolith
 phase 2

Client

Survey
 C Handler Survey
 Aggregate

PostGres

Question
 C Handler Question
 Aggregate Participant
 C Handler Participant
 Aggregate

Projection Authentication layer Client Client Projection Query
 handler Query
 handler Projector

Asynchronous
 updates

Projector

Beyond the monolith

Employees
 Service

Ratings
 Analitycs Text Analytics Data Labs
 Experiments

Message Bus Capture
 Service Survey
 Designer Account
 Admin

Email
 Sender Data
 Warehous Public
 APIs

Key learnings

• 1. Event Logging is not event sourcing


and just leads to source of truth confusion.

• 2. CQRS and event sourcing can help you move to


micro-services, but start by refactoring the monolith

• 3. If you choose to event source your monolith, take

• ne step at a time, and focus on the command
• side.


Questions?
