slide-1
SLIDE 1

GTC ◆ March 26, 2018

This work was performed under the auspices of the U.S. Department of Energy by Lawrence Livermore National Laboratory under Contract DE-AC52-07NA27344. LLNL-PRES-747146

Modernizing OpenMP for an Accelerated World

Tom Scogland Bronis de Supinski

slide-2
SLIDE 2

Tom Scogland @ GTC LLNL-PRES-747146

What is OpenMP?

2

2

#pragma omp parallel for for(int i=0; i<N; +,i) { do_something(i); }

slide-3
SLIDE 3

Tom Scogland @ GTC LLNL-PRES-747146

History of OpenMP

3

3

26 25 26 22 19 17 17 15 15 13 13 13 11 11 11 11 8 8 8

1997 1998 1999 2000 2001 2002 2003 2004 2005 2006 2007 2008 2009 2010 2011 2012 2013 2014 2015

Permanent ARB Auxiliary ARB

In spring, 7 vendors and the DOE agree on the spelling of parallel loops and form the OpenMP ARB. By October, version 1.0 of the OpenMP specification for Fortran is released. 1.0 Minor modifications. 1.1 cOMPunity, the group

  • f OpenMP users, is

formed and organizes workshops on OpenMP in North America, Europe, and Asia. 2.0 First hybrid applications with MPI* and OpenMP appear. 1.0 The merge of Fortran
 and C/C+ specifications begins. 2.0 Unified Fortran and C/ C++: Bigger than both individual specifications

  • combined.


2.5 Incorporates task

  • parallelism. The

OpenMP memory model is defined and codified. 3.0 Support min/max reductions in C/C++. 3.1 Supports offloading execution to accelerator and coprocessor devices, SIMD parallelism, and

  • more. Expands

OpenMP beyond traditional boundaries. 4.0 OpenMP supports taskloops, task priorities, doacross loops, and hints for

  • locks. Offloading now

supports asynchronous execution and dependencies to host execution. 4.5

2016 2017 2018

?

5.0

slide-4
SLIDE 4

Tom Scogland @ GTC LLNL-PRES-747146

Why expand OpenMP target support now?

  • We need heterogeneous computing
  • Better energy efficiency
  • More performance without increasing clock speed
  • C/C++ abstractions (CUDA, Kokkos or RAJA) aren’t enough
  • Even the C++ abstractions have to run atop something!
  • Not all codes are written in C++, some are even written in F******!
  • New mainstream system architectures require it!

4

slide-5
SLIDE 5

Tom Scogland @ GTC LLNL-PRES-747146

Sierra: The next LLNL Capability System

5

slide-6
SLIDE 6

Tom Scogland @ GTC LLNL-PRES-747146

The Sierra system features a GPU-accelerated architecture

6

Mellanox Interconnect Single Plane EDR InfiniBand 2 to 1 Tapered Fat Tree IBM POWER9

  • Gen2 NVLink

NVIDIA Volta

  • 7 TFlop/s
  • HBM2
  • Gen2 NVLink

Components Compute Node

2 IBM POWER9 CPUs 4 NVIDIA Volta GPUs NVMe-compatible PCIe 1.6 TB SSD 256 GiB DDR4 16 GiB Globally addressable HBM2
 associated with each GPU Coherent Shared Memory

Compute Rack

Standard 19” Warm water cooling

Compute System

4320 nodes
 1.29 PB Memory 240 Compute Racks 125 PFLOPS ~12 MW

Spectrum Scale
 File System

154 PB usable storage 1.54 TB/s R/W bandwidth

slide-7
SLIDE 7

Tom Scogland @ GTC LLNL-PRES-747146

Sierra stats

7

Sierra uSierra Nodes 4,320 684 POWER9 processors per node 2 2 GV100 (Volta) GPUs per node 4 4 Node Peak (TFLOP/s) 29.1 29.1 System Peak (PFLOP/s) 125 19.9 Node Memory (GiB) 320 320 System Memory (PiB) 1.29 0.209 Interconnect 2x IB EDR 2x IB EDR Off-Node Aggregate b/w (GB/s) 45.5 45.5 Compute racks 240 38 Network and Infrastructure racks 13 4 Storage Racks 24 4 Total racks 277 46 Peak Power (MW) ~12 ~1.8

slide-8
SLIDE 8

Tom Scogland @ GTC LLNL-PRES-747146

Many Updates to Accelerator Support in OpenMP 4.5

  • Unstructured data mapping
  • Asynchronous execution
  • Scalar variables are firstprivate by default
  • Improvements for C/C++ array sections
  • Device runtime routines: allocation, copy, etc.
  • Clauses to support device pointers
  • Ability to map structure elements
  • New combined constructs
  • New way to map global variables (link)

8

8

Tons of non-accelerator updates for tasking, SIMD and even performance of classic worksharing

slide-9
SLIDE 9

Tom Scogland @ GTC LLNL-PRES-747146

Gaps in OpenMP 4.5

  • Base language support is out of date
  • C99
  • C++03
  • Fortran 03
  • Mapping complex data structures is painful
  • No direct support for unified memory devices
  • No mechanism for deep copying in mappings
  • Overlapping data transfers with computation is complex and error prone
  • Etc.

9

9

slide-10
SLIDE 10

Tom Scogland @ GTC LLNL-PRES-747146

Base Language Support in OpenMP 5.0

  • C99 -> C11
  • _Atomic still in discussion
  • C++03 -> C++17 (yes, 11, 14 and 17 all at once)
  • C++ threads still in discussion
  • Explicit support for mapping lambdas (sanely)
  • Improved support for device code
  • Classes with virtual methods can be mapped (may even be callable)
  • Fortran 2008? (in the works, maybe)

10

10

slide-11
SLIDE 11

Tom Scogland @ GTC LLNL-PRES-747146

Complex Data in OpenMP 5.0: Unified Memory and Deep Copy, Why Both?

  • 1. Mapping provides more information to both the compiler and the runtime
  • 2. Not all hardware has unified memory
  • 3. Not all unified memory is the same
  • 1. Can all memory be accessed with the same performance from everywhere?
  • 2. Do atomics work across the full system?
  • 3. Are flushes required for coherence? How expensive are they?

11

slide-12
SLIDE 12

Tom Scogland @ GTC LLNL-PRES-747146

Specifying unified memory in OpenMP

  • OpenMP does not require unified memory
  • Or even a unified address space
  • This is not going to change

12

slide-13
SLIDE 13

Tom Scogland @ GTC LLNL-PRES-747146

How do you make non-portable features portable?

  • Specify what they provide when they are present
  • Give the user a way to assert that they are required
  • Give implementers a way to react to that assertion

13

slide-14
SLIDE 14

Tom Scogland @ GTC LLNL-PRES-747146

One solution: Requirement declarations

#pragma omp requires [extension clauses…]

14

Extension name Effect unified_address Guarantee that device pointers are unique across all devices, is_device_ptr is not required unified_shared_memory Host pointers are valid device pointers and considered present by all implicit maps, implies unified_address, memory is synchronized at target task sync

slide-15
SLIDE 15

Tom Scogland @ GTC LLNL-PRES-747146

OpenMP unified memory example

int * arr = new int[50]; #pragma omp target teams distribute parallel for for (int i=0; i<50; +,i){ arr[i] = i; }

15

slide-16
SLIDE 16

Tom Scogland @ GTC LLNL-PRES-747146

OpenMP unified memory example

int * arr = new int[50]; #pragma omp target teams distribute parallel for for (int i=0; i<50; +,i){ arr[i] = i; }

16

slide-17
SLIDE 17

Tom Scogland @ GTC LLNL-PRES-747146

OpenMP unified memory example

#pragma omp requires unified_shared_memory int * arr = new int[50]; #pragma omp target teams distribute parallel for for (int i=0; i<50; +,i){ arr[i] = i; }

17

slide-18
SLIDE 18

Tom Scogland @ GTC LLNL-PRES-747146

OpenMP unified memory example

#pragma omp requires unified_shared_memory int * arr = new int[50]; #pragma omp target teams distribute parallel for for (int i=0; i<50; +,i){ arr[i] = i; }

18

slide-19
SLIDE 19

Tom Scogland @ GTC LLNL-PRES-747146

Deep copy today

  • It is possible to use deep copy in OpenMP today
  • Manual deep copy works by pointer attachment

19

slide-20
SLIDE 20

Tom Scogland @ GTC LLNL-PRES-747146

Pointer attachment

typedef struct myvec { size_t len; double *data; } myvec_t; myvec_t v = init_myvec(); #pragma omp target map(v, v.data[:v.len]) { do_something_with_v(&v); }

20

slide-21
SLIDE 21

Tom Scogland @ GTC LLNL-PRES-747146

Pointer attachment

typedef struct myvec { size_t len; double *data; } myvec_t; myvec_t v = init_myvec(); #pragma omp target map(v, v.data[:v.len]) { do_something_with_v(&v); }

21

Map structure v

slide-22
SLIDE 22

Tom Scogland @ GTC LLNL-PRES-747146

Pointer attachment

typedef struct myvec { size_t len; double *data; } myvec_t; myvec_t v = init_myvec(); #pragma omp target map(v, v.data[:v.len]) { do_something_with_v(&v); }

22

Map structure v Map data array and attach to v

slide-23
SLIDE 23

Tom Scogland @ GTC LLNL-PRES-747146

What’s the downside?

typedef struct myvec { size_t len; double *data; } myvec_t; size_t num = 50; myvec_t *v = alloc_array_of_myvec(num); #pragma omp target map(v[:50], ??????) { do_something_with_v(&v); }

23

Now we need a loop, more breaking up the code! Map an array of v structures

slide-24
SLIDE 24

Tom Scogland @ GTC LLNL-PRES-747146

The future of deep copy: User-defined mappers

  • Allow users to define mappers in terms of normal map clauses
  • Offer extension mechanisms to pack or unpack data that can’t be bitwise copied,
  • r expressed as flat maps

24

#pragma omp declare mapper(<type> <var>) [name(<name>)] [use_by_default] [map(<list-items>…)…]

slide-25
SLIDE 25

Tom Scogland @ GTC LLNL-PRES-747146

Our array example

typedef struct myvec { size_t len; double *data; } myvec_t; #pragma omp declare mapper(myvec_t v)\ use_by_default map(v, v.data[:v.len]) size_t num = 50; myvec_t *v = alloc_array_of_myvec(num); #pragma omp target map(v[:50]) { do_something_with_v(&v); }

25

slide-26
SLIDE 26

Tom Scogland @ GTC LLNL-PRES-747146

Our array example

typedef struct myvec { size_t len; double *data; } myvec_t; #pragma omp declare mapper(myvec_t v)\ use_by_default map(v, v.data[:v.len]) size_t num = 50; myvec_t *v = alloc_array_of_myvec(num); #pragma omp target map(v[:50]) { do_something_with_v(&v); }

26

No loop required, no extra code at usage, just map

slide-27
SLIDE 27

Tom Scogland @ GTC LLNL-PRES-747146

Composition of mappers

typedef struct myvec { size_t len; double *data; } myvec_t; #pragma omp declare mapper(myvec_t v)\ use_by_default map(v, v.data[:v.len]) typedef struct mypoints { struct myvec * x; struct myvec scratch; double useless_data[500000]; } mypoints_t; #pragma omp declare mapper(mypoints_t p) \ use_by_default \ map(/+ self only partially mapped, useless_data can be ignored *0\ p.x, p.x[:1]) /+ map and attach x *0 \ map(alloc:p.scratch) /+ never update scratch, including its internal maps *0 mypoints_t p = new_mypoints_t(); #pragma omp target { do_something_with_p(&v); }

27

slide-28
SLIDE 28

Tom Scogland @ GTC LLNL-PRES-747146

Composition of mappers

typedef struct myvec { size_t len; double *data; } myvec_t; #pragma omp declare mapper(myvec_t v)\ use_by_default map(v, v.data[:v.len]) typedef struct mypoints { struct myvec * x; struct myvec scratch; double useless_data[500000]; } mypoints_t; #pragma omp declare mapper(mypoints_t p) \ use_by_default \ map(/+ self only partially mapped, useless_data can be ignored *0\ p.x, p.x[:1]) /+ map and attach x *0 \ map(alloc:p.scratch) /+ never update scratch, including its internal maps *0 mypoints_t p = new_mypoints_t(); #pragma omp target { do_something_with_p(&v); }

28

Pick and choose what to map

slide-29
SLIDE 29

Tom Scogland @ GTC LLNL-PRES-747146

Composition of mappers

typedef struct myvec { size_t len; double *data; } myvec_t; #pragma omp declare mapper(myvec_t v)\ use_by_default map(v, v.data[:v.len]) typedef struct mypoints { struct myvec * x; struct myvec scratch; double useless_data[500000]; } mypoints_t; #pragma omp declare mapper(mypoints_t p) \ use_by_default \ map(/+ self only partially mapped, useless_data can be ignored *0\ p.x, p.x[:1]) /+ map and attach x *0 \ map(alloc:p.scratch) /+ never update scratch, including its internal maps *0 mypoints_t p = new_mypoints_t(); #pragma omp target { do_something_with_p(&v); }

29

Pick and choose what to map Re-use the myvec_t mapper

slide-30
SLIDE 30

Tom Scogland @ GTC LLNL-PRES-747146

Composition of mappers

typedef struct myvec { size_t len; double *data; } myvec_t; #pragma omp declare mapper(myvec_t v)\ use_by_default map(v, v.data[:v.len]) typedef struct mypoints { struct myvec * x; struct myvec scratch; double useless_data[500000]; } mypoints_t; #pragma omp declare mapper(mypoints_t p) \ use_by_default \ map(/+ self only partially mapped, useless_data can be ignored *0\ p.x, p.x[:1]) /+ map and attach x *0 \ map(alloc:p.scratch) /+ never update scratch, including its internal maps *0 mypoints_t p = new_mypoints_t(); #pragma omp target { do_something_with_p(&v); }

30

No explicit map required! Pick and choose what to map Re-use the myvec_t mapper

slide-31
SLIDE 31

Tom Scogland @ GTC LLNL-PRES-747146

Defining mappers from explicit serialization and deserialization (OpenMP 5.1+)

  • Declare mappers by stages, all are replaceable
  • alloc
  • pack_to
  • unpack_to
  • pack_from
  • unpack_from
  • release
  • Any arbitrary data can be mapped, transformed, or munged how you like!

31

slide-32
SLIDE 32

LLNL-PRES-730445

32

▪ Pipelining normally requires users to:

— Split their work into multiple chunks — Add another loop nesting level over the chunks — Explicitly copy a subset of their data — Transform accesses to reference that subset — Ensure all chunks are synchronized

▪ Doing this as an extension to OpenMP requires:

— A data motion direction — The portion of data accessed by each iteration — Which dimension is being looped over

▪ Optionally we can do more with:

— Number of concurrent transfers — Memory limits — Schedulers — Etc.

Dealing with overlapping complexity (OpenMP 5.1+):
 Automating pipelined data transfers

Lots of work for the user! Simpler, more automatic Greater capabilities!

slide-33
SLIDE 33

LLNL-PRES-730445

33

▪ Default synchronous data motion ▪ Pipelined data motion

Pipelining for OpenMP:
 Why pipelining?

Copy in Copy Out Compute

Copy in Copy Out Compute Copy in Copy Out Compute Copy in Copy Out Compute Copy in Copy Out Compute Copy in Copy Out Compute Copy in Copy Out Compute

slide-34
SLIDE 34

LLNL-PRES-730445

34

Pipelining in OpenMP: non-pipelined stencil

#pragma omp target data \ map(to:A0[0:nz-1][0:ny-1][0:nx-1]) \ map(from:Anext[0:nz-1][0:ny-1][0:nx-1]) for(k=1;k<nz-1;k++) { #pragma omp target teams distribute parallel for for(i=1;i<nx-1;i++) { for(j=1;j<ny-1;j++) { Anext[Index3D (i, j, k)] = (A0[Index3D (i, j, k + 1)] + A0[Index3D (i, j, k - 1)] + A0[Index3D (i, j + 1, k)] + A0[Index3D (i, j - 1, k)] + A0[Index3D (i + 1, j, k)] + A0[Index3D (i - 1, j, k)])*c1

  • A0[Index3D (i, j, k)]*c0;

} } }

slide-35
SLIDE 35

LLNL-PRES-730445

35

Pipelining in OpenMP: non-pipelined stencil

#pragma omp target data \ map(to:A0[0:nz-1][0:ny-1][0:nx-1]) \ map(from:Anext[0:nz-1][0:ny-1][0:nx-1]) for(k=1;k<nz-1;k++) { #pragma omp target teams distribute parallel for for(i=1;i<nx-1;i++) { for(j=1;j<ny-1;j++) { Anext[Index3D (i, j, k)] = (A0[Index3D (i, j, k + 1)] + A0[Index3D (i, j, k - 1)] + A0[Index3D (i, j + 1, k)] + A0[Index3D (i, j - 1, k)] + A0[Index3D (i + 1, j, k)] + A0[Index3D (i - 1, j, k)])*c1

  • A0[Index3D (i, j, k)]*c0;

} } }

slide-36
SLIDE 36

LLNL-PRES-730445

36

Pipelining in OpenMP: pipelined stencil

#pragma omp target \ pipeline(static[1,3])\ pipeline_map(to:A0[k-1:3][0:ny-1][0:nx-1])\ pipeline_map(from:Anext[k:1][0:ny-1][0:nx-1])\ for(k=1;k<nz-1;k++) { #pragma omp target teams distribute parallel for for(i=1;i<nx-1;i++) { for(j=1;j<ny-1;j++) { Anext[Index3D (i, j, k)] = (A0[Index3D (i, j, k + 1)] + A0[Index3D (i, j, k - 1)] + A0[Index3D (i, j + 1, k)] + A0[Index3D (i, j - 1, k)] + A0[Index3D (i + 1, j, k)] + A0[Index3D (i - 1, j, k)])*c1

  • A0[Index3D (i, j, k)]*c0;

} } }

slide-37
SLIDE 37

LLNL-PRES-730445

37

Pipelining in OpenMP: pipelined and buffered with our proposed extension

#pragma omp target \ pipeline(static[1,3])\ pipeline_map(to:A0[k-1:3][0:ny-1][0:nx-1])\ pipeline_map(from:Anext[k:1][0:ny-1][0:nx-1])\ pipeline_mem_limit(MB_256) for(k=1;k<nz-1;k++) { #pragma omp target teams distribute parallel for for(i=1;i<nx-1;i++) { for(j=1;j<ny-1;j++) { Anext[Index3D (i, j, k)] = (A0[Index3D (i, j, k + 1)] + A0[Index3D (i, j, k - 1)] + A0[Index3D (i, j + 1, k)] + A0[Index3D (i, j - 1, k)] + A0[Index3D (i + 1, j, k)] + A0[Index3D (i - 1, j, k)])*c1

  • A0[Index3D (i, j, k)]*c0;

} } }

Replicating this manually requires ~20 more lines of error-prone boilerplate per loop!

slide-38
SLIDE 38

LLNL-PRES-730445

38

Pipelining in OpenMP:
 Kernel and benchmark performance (Sierra EA, P100)

All results with PGI OpenACC on k40 GPUs, LLNL surface cluster

Nearly 2x speedup! Only 1.5x, why?

Higher is better

slide-39
SLIDE 39

LLNL-PRES-730445

39

Pipelining in OpenMP:
 Lattice QCD benchmark memory usage

Buffering reduces memory by 80%

Lower is better

slide-40
SLIDE 40

Tom Scogland @ GTC LLNL-PRES-747146

OpenMP into the Future: What’s next?

  • Descriptive loop constructs
  • Automated pipelining
  • Arbitrarily complex data transformation and deep copy
  • Memory affinity
  • Multi-target worksharing
  • Support for complex hierarchical memories
  • Better task dependencies and taskloop support
  • Free-agent threads, possibly even detachable teams

40

slide-41
SLIDE 41

Tom Scogland @ GTC LLNL-PRES-747146

References

  • X. Cui, T. R. Scogland, B. R. de Supinski, and W.-c. Feng. Directive-based partitioning

and pipelining for graphics processing units. In International Parallel and Distributed Processing Symposium, pages 575–584. IEEE, 2017.

  • Scogland T., Earl C., de Supinski B. (2017) Custom Data Mapping for Composable

Data Management. In: Scaling OpenMP for Exascale Performance and Portability. IWOMP 2017.

41
