SLIDE 1
#QConSP @vertx_project
Modern app programming
with RxJava and Eclipse Vert.x
#QConSP @vertx_project
Who am I?
Vert.x core team member since 2016 Working at since 2012 Contributing specifically to monitoring and clustering
@tsegismont
Modern app programming with RxJava and Eclipse Vert.x #QConSP - - PowerPoint PPT Presentation
Modern app programming with RxJava and Eclipse Vert.x #QConSP - - PowerPoint PPT Presentation
Modern app programming with RxJava and Eclipse Vert.x #QConSP @vertx_project Who am I? Vert.x core team member since 2016 Working at since 2012 Contributing specifically to monitoring and clustering @tsegismont
SLIDE 2
SLIDE 3
Eclipse Vert.x
A toolkit to build reactive applications on the JVM
Started in 2O12 Eclipse / Apache licensing 7K on Built on top of Netty
@vertx_project https://vertx.io
SLIDE 4
SLIDE 5
#QConSP @vertx_project
Pay the right price
- Tiny footprint
- Do one thing and do it well
- Modular set of extensions
SLIDE 6
Why going reactive?
SLIDE 7
#QConSP @vertx_project
A hotel room booking startup story
SLIDE 8
2
SLIDE 9
SLIDE 10
2002
SLIDE 11
SLIDE 12
2003
SLIDE 13
SLIDE 14
2006
SLIDE 15
SLIDE 16
2009
SLIDE 17
SLIDE 18
2011
NoSQL
SLIDE 19
SLIDE 20
SLIDE 21
1/ Many channels 2/ Lots of I/O
SLIDE 22
while (isRunning) { String line = bufferedReader.readLine(); switch (line.substring(0, 4)) { case "ECHO": bufferedWriter.write(line); break; // ... // other cases (...) // ... } }
SLIDE 23
x 1000 =
SLIDE 24
“But I don’t do Internet scale. I do enterprise!”
SLIDE 25
2018 server: 28 cores, 512 GB memory
SLIDE 26
Microservices
SLIDE 27
Your container share: 2 vCPU, 512 MB memory
SLIDE 28
1/ Keep the number of threads to a minimum 2/ Keep them busy
SLIDE 29
Thread Events Event-loop
SLIDE 30
Event loops in Vert.x project
SLIDE 31
2 event-loops per core
SLIDE 32
class HttpServerVerticle extends AbstractVerticle { public static void main(String[] args) { Vertx vertx = Vertx.vertx(); vertx.deployVerticle(HttpServerVerticle.class.getName()); } @Override public void start() throws Exception { vertx.createHttpServer() .requestHandler(req -> { req.response().end("Hello world!"); }).listen(8080); } }
Verticles
SLIDE 33
DeploymentOptions options = new DeploymentOptions() .setInstances(3); vertx.deployVerticle(httpVerticle, options);
Load-balancing
SLIDE 34
Communication between verticles?
SLIDE 35
EventBus
Messaging passing, not shared data
Multi-paradigm Standalone or clustered Browser and mobile bridges
SLIDE 36
EventBus eventBus = vertx.eventBus(); eventBus.<String>consumer("greeting").handler(msg -> { String name = msg.body(); msg.reply(String.format("Hello %s!", name)); }); EventBus eventBus = vertx.eventBus(); eventBus.<String>send("greeting", "QConSP", ar -> { if (ar.succeeded()) { System.out.println(ar.result().body()); } else { ar.cause().printStackTrace(); } });
1 2
SLIDE 37
Verticle Bridge
SLIDE 38
#QConSP @vertx_project
Distributed EventBus demo
SLIDE 39
#QConSP @vertx_project
Reactive Programming with RxJava
SLIDE 40
Everything is a stream: data or events
SLIDE 41
Java 8 streams on steroids
SLIDE 42
Lazy and push based
Observable Observer Subscription
SLIDE 43
Backpressure
Observable Observer Subscription Request
SLIDE 44
#QConSP @vertx_project
Different flavors
None One Many Completable Single<T> Observable<T> * plus Maybe<T> and Flowable<T> in RxJava 2
SLIDE 45
Composing data flows
SLIDE 46
SLIDE 47
Great to deal with failures and latencies in distributed systems
SLIDE 48
SLIDE 49
SLIDE 50
SLIDE 51
Observable<String> loadPostsFromRDBMS(LocalDate date); Observable<Comment> loadFromDocumentStore(String postId); loadPostsFromRDBMS(date) .concatMap(postId -> loadFromDocumentStore(postId)) .retry(4) .timeout(500, TimeUnit.MILLISECONDS) .subscribe();
Composition
SLIDE 52
No need to create your own Observables with Vert.x
SLIDE 53
#QConSP @vertx_project
Rxified APIs
import io.vertx.ext.web.Router; import io.vertx.reactivex.ext.web.Router;
SLIDE 54
#QConSP @vertx_project
Rxified APIs
Single<HttpServer> rxListen(int port); void listen(int port, Handler<AsyncResult<HttpServer>> handler);
SLIDE 55
#QConSP @vertx_project
Rxified ReadStream<T>
class AsyncFile implements ReadStream<Buffer> { // ... // RxJava1 Observable<Buffer> toObservable(); // RxJava2 Flowable<Buffer> toFlowable(); // ... }
SLIDE 56
#QConSP @vertx_project
Music Store demo
https://github.com/tsegismont/vertx-musicstore
SLIDE 57
Mongo Postgres Cover Art Archive
SLIDE 58
#QConSP @vertx_project
Learning
SLIDE 59
#QConSP @vertx_project
Learning
SLIDE 60
Thank you!
More questions? Come to the Red Hat booth!
