Modelling and Control of Dynamic Systems Linear Systems

Sven Laur University of Tartu

Formal definition

Let F be a mapping from the state and input signal to an output signal: [x(t0), u(t), t ≥ t0] − →

F

[y(t), t > t0] . Then the corresponding system is linear if for all plausible time moments t0, input signals u1(·), u2(·), states x1(t0), x2(t0), and a constant α ∈ R: [x1(t0), u1(t), t ≥ t0] − →

F

[y1(t), t > t0] , [x2(t0), u2(t), t ≥ t0] − →

F

[y2(t), t > t0] , ⇓ [α · x1(t0), α · u1(t), t ≥ t0] − →

F

[α · y1(t), t > t0] , [α · x2(t0), α · u2(t), t ≥ t0] − →

F

[α · y2(t), t > t0] , [x1(t0) + x2(t0), u1(t) + u2(t), t ≥ t0] − →

F

[y1(t) + y2(t), t > t0] .

Modelling and Control of Dynamic Systems, Linear Systems, 29 September, 2008 1

Canonical decomposition

For linear systems, we can always express y(t) = yzi(t) + yzs(t) , where yzi(·) denotes the zero-input response [x(t0), u(t) ≡ 0, t ≥ t0] − →

F

[yzi(t), t ≥ t0] and yzs(·) denotes the zero-state response [x(t0) = 0, u(t), t ≥ t0] − →

F

[yzs(t), t ≥ t0] .

Modelling and Control of Dynamic Systems, Linear Systems, 29 September, 2008 2

What happens with the state?

The state of a lumped linear system must also evolve linearly [x(t0), u(t), t ≥ t0] − →

F

[x(t), t > t0]

• r otherwise non-linearity appears to the output, as well. The latter is true

for the state variables that can influence the output. Important consequences: ⊲ A system stays in the zero state if the input is constantly zero. ⊲ Generally, we can describe the evolution through the equations ˙ x(t) = A(t)x(t) + B(t)u(t) , y(t) = C(t)x(t) + D(t)u(t) .

Modelling and Control of Dynamic Systems, Linear Systems, 29 September, 2008 3

• Examples. Continuous systems

⊲ Low-band filter

R2 C u(t) x2(t) x1(t) x3(t) R3

   y(t) = x1(t) ˙ x1(t) = u − x1 R3C − x1 R2C

Zero-input and zero-state responses

u(t) = sin(10t) u(t) = sin(100t) u(t) ≡ 0 x1(0) = 1 Modelling and Control of Dynamic Systems, Linear Systems, 29 September, 2008 4

• Examples. Continuous systems

⊲ Simplest radio receiver

R2 L C u(t) x2(t) x1(t) x3(t) R3

     y(t) = x1(t) ˙ x1(t) = u−x1−R3x2

R3C

˙ x2(t) = x1−R2C

L

Zero-input and zero-state responses

x2(t) x1(t) x1(t) x2(t) u(t) = const Modelling and Control of Dynamic Systems, Linear Systems, 29 September, 2008 5

• Examples. Discrete systems

⊲ Smoother (moving average)

Adder

D D D u[k] y[k]      y[k] = x1[k] + x2[k] + u[k] x1[k + 1] = u[k] x2[k + 1] = x1[k]

Zero-input and zero-state responses

! "# "! $# #%# #%! "%# "%! $%# $%! &%#

x1[0] = 2 x2[0] = 1

! "# "! $# " $ % & ! '

u = [1, 2, 3, 1, 2, 3, . . .] Modelling and Control of Dynamic Systems, Linear Systems, 29 September, 2008 6

• Examples. Discrete systems

⊲ Bank deposit: y[k + 1] = 1.02 · y[k] + u[k + 1]

• y[k] = x[k]

x[k + 1] = 1.02x[k] + u[k] Adder D 1.02 u[k] y[k]

Zero-input and zero-state responses

! "! #! $! %! &!! & " ' # ( $ ) ! "! #! $! %! &!! ! '! &!! &'! "!! "'! (!!

x[0] = 1 u[k] ≡ 1 Modelling and Control of Dynamic Systems, Linear Systems, 29 September, 2008 7

Discrete Linear Systems

Input signal as a sum

Let δ[·] be the step function with the peak at zero: δ[k] =

• 1,

if k = 0 , 0, if k = 0 . Then we can decompose one-dimensional input signal u[·] into a sum u[k] =

∞

• m=−∞

u[m]δ[k − m] and thus the output is determined by the responses to the pulses δm[k] = δ[k − m] .

Modelling and Control of Dynamic Systems, Linear Systems, 29 September, 2008 8

Input-output description

An impulse response sequence g[·, ·] defined through the mapping F δm[·] − →

F

g[·, m] captures the behaviour of the system for all inputs. Due to linearity u[·] =

∞

• m=−∞

u[m]δm[·] − →

F ∞

• m=−∞

u[m]g[·, m] = y[·] and thus we can express y[k] =

∞

• m=−∞

g[k, m]u[m] .

Modelling and Control of Dynamic Systems, Linear Systems, 29 September, 2008 9

Extension to multi-dimensional case

If an output signal consists of q components, then we must define a different impulse response sequence for every output component. If an input signal is p dimensional, then we must consider excitements in every dimension. As a result, we get an impulse response matrix G[k, m] =     g11[k, m] g12[k, m] · · · g1p[k, m] g21[k, m] g22[k, m] · · · g2p[k, m] . . . . . . ... . . . gq1[k, m] gq2[k, m] . . . gqp[k, m]     where gij[k, m] measures the influence of an input ui[·] to the output yj[·]. The resulting signal can be computed as a sum y[k] =

∞

• m=−∞

G[k, m]u[m] .

Modelling and Control of Dynamic Systems, Linear Systems, 29 September, 2008 10

Extension to time-invariant systems

If the input state is zero and then the it stays there until input is excited. Consequently, it is irrelevant when the first peak arrives δ[·] − →

F

g[·] = ⇒ δm[k] = g[k − m] , where g[−k] ≡ 0 for all k = 1, 2, 3, . . .. Consequently, we can express the output signal through a convolution y[k] = yzs[k] + yzi[k] =

k

• m=0

g[k − m]u[m] + yzi[k] , y[k] = yzs[k] + yzi[k] =

k

• m=0

G[k − m]u[m] + yzi[k]

Modelling and Control of Dynamic Systems, Linear Systems, 29 September, 2008 11

Z-transform

To get rid of the convolution, we must change the domain for input and

• utput signals. For that we use z-transform that maps y[·] to ˆ

y[·]: ˆ y(z) =

∞

• k=0

y[k]z−k, z = 1, 2, 3, . . . .

• Fact. The z-transform is invertible provided that it exists.

Now observe that z-transform takes convolution into a multiple

ˆ y[z] =

∞

X

k=0

y[k]z−k =

∞

X

k=0 k

X

m=0

g[k − m]u[m] ! z−(k−m)z−m = ∞ X

ℓ=0

g[ℓ]z−ℓ ! ∞ X

m=0

u[m]z−m ! = ˆ g[z]ˆ u[z] .

Modelling and Control of Dynamic Systems, Linear Systems, 29 September, 2008 12

Transfer function

Now if we define z-transform for vectors and matrices as an elementwise application, then due to linearity of the z-transform ˆ y[z] = ˆ G[z]ˆ u[z] , where ˆ G is referenced as a transfer function.

• Fact. For lumped systems, the transfer function ˆ

G[z] has always rational matrix elements. For distributed systems, the transfer function is irrational.

• Fact. For causal lumped systems, the transfer function is always proper

ˆ gij = Nij(z) Dij(z) with deg Nij(z) ≤ deg Dij(z) .

Modelling and Control of Dynamic Systems, Linear Systems, 29 September, 2008 13

Examples

⊲ Smoother y[k] = u[k − 2] + u[k − 1] + u[k]: ˆ G[z] = 1 + 1 z + 1 z2 ⊲ Feedback loop y[k] = αy[k + 1] + u[k] ˆ G[z] = 1 + α z + α2 z2 + · · · = z z − α ⊲ Compensator for positive feedback loop y[k] = u[k] − αu[k − 1] ˆ G[z] = 1 − α z = z − α z

Modelling and Control of Dynamic Systems, Linear Systems, 29 September, 2008 14

From state space to transfer function

As the evolution of the state and output can be expressed x[k + 1] = A[k]x[k] + B[k]u[k] , y[k] = C[k]x[k] + D[k]u[k] , we can derive the transfer function directly for time-invariant systems ˆ y[z] =

• C(zI − A)−1B + D

ˆ u[z] ⇓ ˆ G[z] = C(zI − A)−1B + D provided that the initial state x(0) is 0.

Modelling and Control of Dynamic Systems, Linear Systems, 29 September, 2008 15

Examples

⊲ Smoother y[k] = u[k − 2] + u[k − 1] + u[k]: ˆ G[z] = 1 + 1 z + 1 z2 ⊲ Feedback loop y[k] = αy[k + 1] + u[k] ˆ G[z] = 1 + α z + α2 z2 + · · · = z z − α ⊲ Compensator for positive feedback loop y[k] = u[k] − αu[k − 1] ˆ G[z] = 1 − α z = z − α z

Modelling and Control of Dynamic Systems, Linear Systems, 29 September, 2008 16

Continuous Linear Systems

What happens if the sampling rate grows?

If the sampling rate grows infinitely, then the effect of δ∆[·] decreases to

• zero. Hence, we must consider pulses with constant area δ∆[·]/∆.

As a result, we obtain the following equality y(t) = ∞

−∞

G(t, τ)u(τ)dτ , where gij(t, τ) corresponds to excitements with Dirac delta function. For causal time-invariant systems, we again get a convolution y(t) = ∞

−∞

G(t − τ)u(τ)dτ ,

Modelling and Control of Dynamic Systems, Linear Systems, 29 September, 2008 17

Laplace transform

The Laplace transform L allows us to break the convolution into a product ˆ y(s) = ˆ G(s)ˆ y(s) . The Laplace transform is a generalisation of the z-transform ˆ y(s) = ∞ y(t)e−stdt The Laplace transform is also invertible and linear. For lumped systems, the corresponding transfer function is rational. For distributed systems, the transfer function is irrational. For causal lumped systems, the transfer function is proper.

Modelling and Control of Dynamic Systems, Linear Systems, 29 September, 2008 18

From state space to transfer function

As the evolution of the state and output can be expressed ˙ x(t) = A(t)x(t) + B(t)u(t) , y(t) = C(t)x(t) + D(t)u(t) , we can derive the transfer function directly for time-invariant systems ˆ y[z] =

• C(zI − A)−1B + D

ˆ u[z] ⇓ ˆ G[z] = C(zI − A)−1B + D provided that the initial state x(0) is 0.

Modelling and Control of Dynamic Systems, Linear Systems, 29 September, 2008 19

Realisations

Basic components of digital electronics

Every linear state equation can be implemented with these components.

Adder ˆ G[z] = [1 1] u1 u2 y y u Unit delay ˆ G[z] = z−1 u Duplicator ˆ G[z] = [1 1]T y1 y2 y u Multiplier ˆ G[z] = α

Fact. Any proper transfer function ˆ G[z] or transfer matrix ˆ G[z] has a corresponding linear state equation.

Modelling and Control of Dynamic Systems, Linear Systems, 29 September, 2008 20

Explanation for SISO systems

The following state space description y[k] = β1x1[k] + β2x2[k] + · · · + βrxr[k]        x1[k + 1] x2[k + 1] · · · xr[k + 1]        =       −α1 −α2 · · · −αr 1 · · · 1 · · · . . . . . . ... . . . · · · 1              x1[k] x2[k] · · · xr[k]        +        u[k] · · ·        has a transfer function ˆ G[z] = β1zr−1 + β2zr−2 + · · · + βr zr + α1zr−1 + α2zr−2 + · · · + αr .

Modelling and Control of Dynamic Systems, Linear Systems, 29 September, 2008 21

Basic components of analog electronics

Every linear state equation can be implemented with these components. − −

Adder Integrator

R/a R/b R/c R/a R/b R/c R C v1 v2 v3 ˙ y = −(av1 + bv2 + cv3) y = −(ax1 + bx2 + cx3)

x1 x2 x3

Fact. Any proper transfer function ˆ G(s) or transfer matrix ˆ G(s) has a corresponding linear state equation.

Modelling and Control of Dynamic Systems, Linear Systems, 29 September, 2008 22

Explanation for SISO systems

The following state space description y(t) = β1x1(t) + β2x2(t) + · · · + βrxr(t)        ˙ x1(t) ˙ x2(t) · · · ˙ xr(t)        =       −α1 −α2 · · · −αr 1 · · · 1 · · · . . . . . . ... . . . · · · 1              x1(t) x2(t) · · · xr(t)        +        u(t) · · ·        has a transfer function ˆ G(z) = β1sr−1 + β2sr−2 + · · · + βr sr + α1sr−1 + α2sr−2 + · · · + αr .

Modelling and Control of Dynamic Systems, Linear Systems, 29 September, 2008 23
