Modeling & Control of a Longboard-Riding Robot Matt Keeter mkeeter@mit.edu 6.832 Final Project Spring 2012 Inspiration System Model Simplified Model State Variables Control Inputs System Parameters System Summary q = [ x , y ,
SLIDE 2
SLIDE 3
System Model
SLIDE 4
Simplified Model
SLIDE 5
State Variables
SLIDE 6
Control Inputs
SLIDE 7
System Parameters
SLIDE 8
System Summary
- q = [x, y, α]′
SLIDE 9
System Summary
- q = [x, y, α]′
- u = [F, τ]′
SLIDE 10
System Summary
- q = [x, y, α]′
- u = [F, τ]′
- Gliding and pushing modes
- ytoe ≤ 0 → pushing
- ytoe > 0 → gliding
SLIDE 11
Dynamics
- Wrote tools to automatically solve dynamics
SLIDE 12
Dynamics
- Wrote tools to automatically solve dynamics
- Written in Python using Sage
SLIDE 13
Dynamics
- Wrote tools to automatically solve dynamics
- Written in Python using Sage
- Solves for:
- Second derivatives ¨
q
- Co-located PFL equations
SLIDE 14
Dynamics
- Wrote tools to automatically solve dynamics
- Written in Python using Sage
- Solves for:
- Second derivatives ¨
q
- Co-located PFL equations
- Exports as MATLAB scripts
SLIDE 15
Feedback Linearization
- Solve dynamics equations for ¨
x, F, τ
SLIDE 16
Feedback Linearization
- Solve dynamics equations for ¨
x, F, τ
- Solutions are in terms of q, ˙
q, ¨ y, ¨ α (as well as constants)
SLIDE 17
Feedback Linearization
- Solve dynamics equations for ¨
x, F, τ
- Solutions are in terms of q, ˙
q, ¨ y, ¨ α (as well as constants)
- Plug in ¨
y, ¨ α for feedback linearization
- ¨
y = ¨ ydesired
- ¨
α = ¨ αdesired
SLIDE 18
Feedback Linearization
- Solve dynamics equations for ¨
x, F, τ
- Solutions are in terms of q, ˙
q, ¨ y, ¨ α (as well as constants)
- Plug in ¨
y, ¨ α for feedback linearization
- ¨
y = ¨ ydesired
- ¨
α = ¨ αdesired
- Double integrator control
SLIDE 19
Controller Strategy
High-level strategy breaks motion into stages
Push off Stand up Lower self
Switch to pushing state
Swing leg forward
Switch to gliding state
SLIDE 20
Controller Strategy
Push off Stand up Lower self
Switch to pushing state
Swing leg forward
Switch to gliding state
SLIDE 21
Controller Strategy
Push off Stand up Lower self
Switch to pushing state
Swing leg forward
Switch to gliding state
SLIDE 22
Controller Strategy
Push off Stand up Lower self
Switch to pushing state
Swing leg forward
Switch to gliding state
SLIDE 23
Controller Strategy
Push off Stand up Lower self
Switch to pushing state
Swing leg forward
Switch to gliding state
SLIDE 24
Controller Strategy
Push off Stand up Lower self
Switch to pushing state
Swing leg forward
Switch to gliding state
SLIDE 25
Demo
SLIDE 26
Controller Parameters
Controller is parameterized by three terms: αhit Angle of collision αstand Angle ending push ¨ αswing Swinging acceleration
SLIDE 27
Controller Parameters
αhit Angle of collision αstand Angle ending push ¨ αswing Swinging acceleration
SLIDE 28
Controller Parameters
αhit Angle of collision αstand Angle ending push ¨ αswing Swinging acceleration
SLIDE 29
Controller Parameters
αhit Angle of collision αstand Angle ending push ¨ αswing Swinging acceleration
SLIDE 30
Stochastic Gradient Descent
Optimized for distance travelled in fixed time
SLIDE 31
Stochastic Gradient Descent
Optimized for distance travelled in fixed time
20 40 60 80 100 36 38 40 42 44 46 48 50 Iteration Distance travelled
SLIDE 32
Optimized Demo
SLIDE 33
Optimized Demo
20% improvement!
SLIDE 34
Summary
- Developed simplified system model
- Wrote dynamics-solving tools
- Designed high-level controller behavior
- Used gradient descent to optimize parameters
