Mobile Networks Module I Part 2 Securing Vehicular Networks Prof. J.-P. Hubaux 1 Outline Motivation Threat model and specific attacks Security architecture Security analysis Certificate revocation

slide-1
SLIDE 1
  • Prof. J.-P. Hubaux

Mobile Networks Module I – Part 2 Securing Vehicular Networks

1

slide-2
SLIDE 2

Outline

  • Motivation
  • Threat model and specific attacks
  • Security architecture
  • Security analysis
  • Certificate revocation
  • Data-centric trust
  • Conclusion

2

slide-3
SLIDE 3

What is a VANET (Vehicular Ad hoc NETwork)?

  • Communication: typically over the

Dedicated Short Range Communications (DSRC) (5.9 GHz)

  • Example of protocol: IEEE 802.11p
  • Penetration will be progressive (over 2 decades or so)

3

slide-4
SLIDE 4

Vehicular communications: why?

Combat the awful side-effects of road traffic

  • In the EU, around 40’000 people die yearly on the roads;

more than 1.5 millions are injured

  • Traffic jams generate a tremendous waste of time and of fuel

Most of these problems can be solved by providing appropriate information to the driver or to the vehicle

4

slide-5
SLIDE 5

Why is VANET security important?

  • Large projects have explored vehicular communications:

Fleetnet, PATH (UC Berkeley),…

  • No solution can be deployed if not properly secured
  • The problem is non-trivial
  • Specific requirements (speed, real-time constraints)
  • Contradictory expectations
  • Industry front: standards are still under development and suffer from

serious weaknesses

  • IEEE P1609.2: Standard for Wireless Access in Vehicular Environments
  • Security Services for Applications and Management Messages
  • Research front
  • A growing number of papers

5

slide-6
SLIDE 6

A modern vehicle

Forward radar Computing platform Event data recorder (EDR) Positioning system Rear radar Communication facility Display (GPS) Human-Machine Interface

A modern vehicle is a network of sensors/actuators on wheels !

6

slide-7
SLIDE 7

Threat model

  • An attacker can be:
  • Insider / Outsider
  • Malicious / Rational
  • Active / Passive
  • Local / Extended
  • Attacks can be mounted on:
  • Safety-related applications
  • Traffic optimization applications
  • Payment-based applications
  • Privacy

7

slide-8
SLIDE 8

Attack 1 : Bogus traffic information

Traffic jam ahead

Attacker: insider, rational, active

8

slide-9
SLIDE 9

Attack 2 : Generate “Intelligent Collisions”

SLOW DOWN The way is clear

Attacker: insider, malicious, active

9

slide-10
SLIDE 10

Attack 3: Cheating with identity, speed, or position

Wasn’t me!

Attacker: insider, rational, active

10

slide-11
SLIDE 11

Attack 4: Jamming

Roadside base station

Jammer 11

slide-12
SLIDE 12

Attack 5: Tunnel

12

slide-13
SLIDE 13

Attack 6: Tracking

A

* A at (x1,y1,z1) at time t1 * A communicates with B * A refuels at time t2 and location (x2,y2,z2) 1 2

A

B A

* A enters the parking lot at time t3 * A downloads from server X 3

13

slide-14
SLIDE 14

Our scope

We consider communications specific to road traffic: safety and traffic optimization

  • Safety-related messages
  • Messages related to traffic information

We do not focus on more generic applications, e.g., toll collect, access to audio/video files, games,…

14

slide-15
SLIDE 15

Security system requirements

Sender authentication Verification of data consistency Availability Non-repudiation Privacy Real-time constraints

15

slide-16
SLIDE 16

Security Architecture

16

slide-17
SLIDE 17

Tamper-proof device

Each vehicle carries a tamper-proof device

  • Contains the secrets of the vehicle itself
  • Has its own battery
  • Has its own clock (notably in order to be able to sign

timestamps)

  • Is in charge of all security operations
  • Is accessible only by authorized personnel

Tamper-proof device Vehicle sensors (GPS, speed and acceleration,…) On-board CPU Transmission system ((( )))

17

slide-18
SLIDE 18

Digital signatures

  • Symmetric cryptography is not suitable: messages are

standalone, large scale, non-repudiation requirement

  • Hence each message should be signed with a DS
  • Liability-related messages should be stored in the EDR

Verifier Signer Verifier Verifier

Safety message Cryptographic material {Position, speed, acceleration, direction, time, safety events} {Signer’s DS, Signer’s PK, CA’s certificate of PK}

18

slide-19
SLIDE 19

VPKI (Vehicular PKI)

PKI Security services

Positioning Confidentiality Privacy ... CA

PA PB Authentication Authentication Shared session key

  • Each vehicle carries in its Tamper-Proof Device (TPD):
  • A unique and certified identity: Electronic License Plate (ELP)
  • A set of certified anonymous public/private key pairs
  • Mutual authentication can be done without involving a server
  • Authorities (national or regional) are cross-certified

19

slide-20
SLIDE 20

The CA hierarchy: two options

Country 1

Region 1 Region 2

District 1 District 2

Car A Car B Car A Car B

  • Manuf. 1
  • Manuf. 2
  • 1. Governmental

Transportation Authorities

  • 2. Manufacturers
  • The governments control certification
  • Long certificate chain
  • Keys should be recertified on borders to

ensure mutual certification

  • Vehicle manufacturers are trusted
  • Only one certificate is needed
  • Each car has to store the keys of all

vehicle manufacturers

20

slide-21
SLIDE 21

Secure VC Building Blocks

  • Authorities
  • Trusted entities issuing

and managing identities and credentials

21

slide-22
SLIDE 22

Secure VC Building Blocks

Authorities

  • Hierarchical organization
  • ‘Forest’

22

slide-23
SLIDE 23

Secure VC Building Blocks (cont’d)

Roadside Unit ‘Re-filling’ with or

  • btaining new

credentials Providing revocation information Roadside Unit Wire-line Connections

Identity and Credentials Management

23

slide-24
SLIDE 24

Anonymous keys

Preserve identity and location privacy Keys can be preloaded at periodic checkups The certificate of V’s ith key: Keys renewal algorithm according to vehicle speed (e.g., ≈ 1 min at 100 km/h) Anonymity is conditional on the scenario The authorization to link keys with ELPs is distributed

[ ] [ ]

CA i SK i i V

ID PuK Sig PuK PuK Cert

CA

| | =

24

slide-25
SLIDE 25

What about privacy: how to avoid the Big Brother syndrome?

At 3:00

  • Vehicle A spotted

at position P1 At 3:15

  • Vehicle A spotted

at position P2

  • Keys change over time
  • Liability has to be enforced
  • Only law enforcement agencies should be allowed to retrieve

the real identities of vehicles (and drivers)

25

slide-26
SLIDE 26

DoS resilience

Vehicles will probably have several wireless technologies onboard In most of them, several channels can be used To thwart DoS, vehicles can switch channels or communication technologies In the worst case, the system can be deactivated

Network layer

DSRC UTRA-TDD Bluetooth Other

26

slide-27
SLIDE 27

Data verification by correlation

  • Bogus info attack relies on false data
  • Authenticated vehicles can also send wrong data (on purpose or not)
  • The correctness of the data should be verified => data-centric trust
  • Correlation can help

27

slide-28
SLIDE 28

Security analysis

How much can we secure VANETs? Messages are authenticated by their signatures Authentication protects the network from outsiders Correlation and fast revocation reinforce correctness Availability remains a problem that can be alleviated Non-repudiation is achieved because:

  • ELP and anonymous keys are specific to one vehicle
  • Position is correct if secure positioning is in place

28

slide-29
SLIDE 29

Certificate revocation in VANETs

The CA has to revoke invalid certificates:

  • Compromised keys
  • Wrongly issued certificates
  • A vehicle constantly sends erroneous information

Using Certificate Revocation Lists (CRL) or online status checking is not appropriate There is a need to detect and revoke attackers fast

29

slide-30
SLIDE 30

System model

There is a CA (Certification Authority) Each vehicle has a public/private key pair, a TC (Trusted Component = TPD), and an EDR (Event Data Recorder) Safety messages:

  • Are broadcast and signed
  • Include time and position

Several possible communication channels:

  • DSRC
  • Cellular
  • WiMax
  • Low-speed FM

30

slide-31
SLIDE 31

Adversary model

The adversary can be:

  • Faulty node
  • Misbehaving node

Example attack: false information dissemination Adversaries have valid credentials Honest majority in the attacker’s neighborhood

31

slide-32
SLIDE 32

Message validation TPD

(Tamper-Proof Device)

RTC

(Rev. of the Trusted Component )

LEAVE

(Local Eviction of Attackers by Voting Evaluators)

MDS

(Misbehavior Detection System)

Evidence Collection Revocation Information

CA (Certification Authority) and Infrastructure Functionality

Fail (ID)

Revocation Decision RC2RL

(Rev. by Compressed CRLs)

Node ID

Vehicle Functionality

CA Policies

Local Warning Messages Revocation Command

Scheme overview

32

slide-33
SLIDE 33

Revocation protocols

We propose 2 protocols to revoke a vehicle’s keys:

  • Rev. of the Trusted Component (RTC): CA revokes all keys
  • Rev. by Compressed CRLs (RC2RL): if TC is not reachable

Local Eviction of Attackers by Voting Evaluators (LEAVE):

  • Initiated by peers
  • Generates a report to the CA, which triggers the actual

revocation by RTC/RC2RL

33

slide-34
SLIDE 34

Revocation of the Trusted Component (RTC)

34

RSU: Road Side Unit; PuK = Public Key; T = Timestamp

slide-35
SLIDE 35

Revocation by Compressed CRLs (RC2RL)

CRLs are compressed using Bloom filters Bloom filter: space-efficient probabilistic data-structure

  • Can be queried to check if an element is in a set or not
  • Configurable rate of false positives (but no false negatives)

1 2 3 m vector with m bits element “a” k different hash functions with range 1…m … H1(a) H2(a) Hk(a) … 1 1 1

35

slide-36
SLIDE 36

Local Eviction of Attackers by Voting Evaluators (LEAVE)

36

slide-37
SLIDE 37

Data-Centric Trust

37

Data Trust Decision on event

slide-38
SLIDE 38

What is Data-Centric Trust?

slide-39
SLIDE 39

Data-Centric Trust in Networks Packet forwarding Security associations Reputation

A M B

Data dissemination Insufficient Hard

39

Traditional ad hoc networks Ephemeral networks

Data Trust = Entity Trust Data Trust = F(Entity Trust, context)

slide-40
SLIDE 40

Event‐specific trust Dynamic trust metric Security status

) ), ( (

j k

v f λ τ

) , (

j k l v λ

μ ) ( k v s

)) , ( ), ), ( ( ), ( (

j k l j k k

v v f v s F λ μ λ τ

A C B M

General Framework Trust Computation

Weights (data‐centric trust levels)

( )

k

v τ

is the default trustworthiness Location Time

Event reports

  • f type

from nodes

j

λ

k

v

j k

e

slide-41
SLIDE 41

A C B M

General Framework Evidence Evaluation

( )

j B

F e

Decision Logic Decision on Reported Event

Report contents

Event reports

  • f type

from nodes

j

λ

k

v

j k

e

( )

j C

F e ( )

j M

F e

slide-42
SLIDE 42

Decision Logics

Most trusted report Weighted voting Bayesian inference

  • Takes into account prior knowledge

Dempster-Shafer Theory

  • probability is bounded by belief and plausibility
  • Uncertainty (lack of evidence) does not refute nor support

evidence

slide-43
SLIDE 43

Conclusion

  • Vehicular communications could lead to the largest mobile ad hoc

network (around 1 billion nodes)

  • The security of that network is a difficult and highly relevant problem
  • Car manufacturers seem to be poised to massively invest in this area
  • Slow penetration makes connectivity more difficult
  • Security leads to a substantial overhead and must be taken into

account from the beginning of the design process

  • The field offers plenty of novel research challenges
  • Pitfalls
  • Defer the design of security
  • Security by obscurity
  • More information at http://ivc.epfl.ch

43
